John Thomas BD-504QR User manual

ITEM NO. : BD-504QR
REVISED JUN 30, 2016
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
BD-504QR AND BD-504QH AND BD-504QF BD-504QR AND BD-702QH AND BD-702QF
BD-504QR AND BD-201QH AND BD-201QF BD-504QR AND BD-703QH AND BD-703QF
Description
Item No.
: QUEEN RAILS
: BD-504QR

ITEM NO. : BD-504QR
REVISED JUN 30, 2016
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO. : BD-504QR
REVISED JUN 30, 2016
Printed in Vietnam
- 3 -
PART LIST BD-504QH AND BD-504QF
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
BD-504QH
(packed in
separate
carton)
1
B
BD-504QF
(packed in
separate
carton)
1
OR PART LIST BD-702QH AND BD-702QF
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
BD-702 QH
(packed in
separate
carton)
1
B
BD-702 QF
(packed in
separate
carton)
1
RT LIST BD-504FH OR BD-702FH AND BD-502FF OR BD
OR PART LIST BD-201QH AND BD-201QF
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
BD-201QH
(packed in
separate
carton)
1
B
BD-201QF
(packed in
separate
carton)
1

ITEM NO. : BD-504QR
REVISED JUN 30, 2016
Printed in Vietnam
- 4 -
OR PART LIST BD-703QH AND BD-703QF
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
BD-703 QH
(packed in
separate
carton)
1
B
BD-703 QF
(packed in
separate
carton)
1
PART LIST BD-504FH OR BD-702FH AND BD-502FF OR BD-7
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
C
Side Rail
2
D
Slat
5
E
Support Leg
5
PART LIST BD-504QR
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware (in box of siderails and slats):
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Wood screw
(M4x35mm)
15
2
Allen key
(M4 x30mm x 120mm)
1
NOTE: HARDWARE IS PACKED IN CARTON BD-504QR

ITEM NO. : BD-504QR
REVISED JUN 30, 2016
Printed in Vietnam
- 5 -
STEP 1
Use the Allen key (2) to loosen the bolts and washers, as shown below.
Attach side rails (C) to headboard (A) and footboard (B) with bolts and washers (from step 1). Tighten
with Allen key (2).
STEP 2

ITEM NO. : BD-504QR
REVISED JUN 30, 2016
Printed in Vietnam
- 6 -
Attach support legs (E) to slats (D) with screws (1), as shown below. Tighten with a screwdriver.
Attach slats (D) to side rails (C) with screws (1), as shown below. Tighten with a screwdriver.
STEP 3
