John Thomas BJ6TCL User manual

ITEM NO.: BJ6TCL
REVISED JAN 23, 2015
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
: TALL MISSION COFFEE TBL W/LIFT TOP
: BJ6TCL

ITEM NO.: BJ6TCL
REVISED JAN 23, 2015
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your table. Protect the surface of the table with cloth if you are using any product
with rubber feet or base.
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A Top 1
B Side frame 2
C Shelf 1
BEFORE ASSEMBLY

ITEM NO.: BJ6TCL
REVISED JAN 23, 2015
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1 Bolt
(M6x30mm) 12
3 Flat washer
(6.5 x 13mm) 12
2 Spring washer
(6.5 x11mm) 12 4
Allen Key
(4 X 80mm) 1
STEP 1
Attach side frames (B) to top (A) and shelf (C) with bolts (1), and washers (2) and (3), as shown below.
Tighten with Allen key (4).

ITEM NO.: BJ6TCL
REVISED JAN 23, 2015
Printed in Vietnam
- 4 -
STEP 2
Up
Down
