Surface-Mounted NS Series Network Sensors without LCD Installation
Instructions
1
Refer to the QuickLIT website for the most up-to-date version of this document.
Applications
The surface-mounted NS Series Network Sensor
without LCD is an electronic zone sensor designed to
function directly with Johnson Controls® BACnet®
Master-Slave/Token-Passing (MS/TP) digital
controllers in HVAC systems. Models in this series
monitor the zone temperature and humidity, and
transmit this data to a field controller on the Sensor
Actuator (SA) Bus.
A warmer/cooler dial is included on certain models for
minor temperature adjustments from the setpoint. An
occupancy override button is also featured on some
models, which allows the user to signal the controller
that the space is occupied, to request an override of
time-of-day scheduling. Rotation of the warmer/cooler
dial signals occupancy as well. Select models include
DIP switches to set a unique address in averaging
applications. Models are available with or without a
Johnson Controls logo on the face of the unit.
Depending on the model chosen, the wires connecting
the network sensor to the controller can be terminated
using either a modular jack or screw terminal block,
offering wiring flexibility.
Note: Models featuring a modular jack are not
intended for installations where daisy chaining to the
MS/TP Bus is required.
All models include an SA Bus access port for
connecting accessories to access the SA Bus. This
feature allows a technician to commission or service
the controller via the network sensor.
Note: Since some NS Series Network Sensor
features are not supported in previous releases of
Metasys® or Facility Explorer system software, it is
recommended that the system software be kept up to
date.
North American Emissions Compliance
United States
IMPORTANT: The surface-mounted NS Series
Network Sensor is intended to provide an input to
equipment under normal operating conditions.
Where failure or malfunction of the network sensor
could lead to personal injury or property damage to
the controlled equipment or other property,
additional precautions must be designed into the
control system. Incorporate and maintain other
devices, such as supervisory or alarm systems or
safety or limit controls, intended to warn of or protect
against failure or malfunction of the network sensor.
IMPORTANT: Le surface-mounted NS Series
Network Sensor est destiné à transmettre des
données entrantes à un équipement dans des
conditions normales de fonctionnement. Lorsqu'une
défaillance ou un dysfonctionnement du network
sensor risque de provoquer des blessures ou
d'endommager l'équipement contrôlé ou un autre
équipement, la conception du système de contrôle
doit intégrer des dispositifs de protection
supplémentaires. Veiller dans ce cas à intégrer de
façon permanente d'autres dispositifs, tels que des
systèmes de supervision ou d'alarme, ou des
dispositifs de sécurité ou de limitation, ayant une
fonction d'avertissement ou de protection en cas de
défaillance ou de dysfonctionnement du network
sensor.
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference, in which case the
users will be required to correct the interference at
their own expense.
Surface-Mounted NS Series Network Sensors without LCD
Installation Instructions
NS-AHP7001-0, NS-AHN700x-x,
NS-ATN700x-x, NS-ATP700x-x
Part No. 24-10094-17, Rev. R
Issued May 2018
*241009417R*
(barcode for factory use only)
24-10094-17, Rev. R

Surface-Mounted NS Series Network Sensors without LCD Installation Instructions
2
Canada
Installation
Special Tools Needed
A 1/16 in. (1.5 mm) Allen wrench or a Johnson Controls T-4000-119 Allen-Head Adjustment Tool is required during
installation.
Mounting
Location Considerations
Locate the network sensor:
• on a partitioning wall, approximately 5 ft (1.5 m) above the floor in a location of average temperature
• away from direct sunlight, radiant heat, outside walls, outside doors, air discharge grills, or stairwells; and from
behind doors
• away from steam or water pipes, warm air stacks, unconditioned areas (not heated or cooled), or sources of
electrical interference
Note: The network sensor is shock and vibration resistant; however, be careful not to drop the unit or mount it
where it could be exposed to excessive vibration.
The following ambient operating conditions apply:
• Temperature: 32 to 104°F (0 to 40°C)
• Humidity: 10 to 90% Relative Humidity (RH), noncondensing; 85°F (29°C) maximum dew point
To mount the network sensor to the wall:
1. Use a 1/16 in. (1.5 mm) Allen wrench or Johnson Controls T-4000-119 Allen-Head Adjustment Tool to loosen
the security screw on the top of the unit.
2. Insert a coin into the slot next to the security screw location, then carefully pry the top edge of the sensor
assembly away from its mounting base and remove.
3. Pull out approximately 6 in. (152 mm) of cable from the wall, and insert the cable through the hole in the
mounting base.
4. Align the mounting base on the wall, and use the base as a template to mark the location of the two mounting
holes on the surface.
Note: Confirm that the mounting base is positioned with the proper edge up. The mounting base is positioned
properly when the security screw is located on the top edge of the base.
5. Secure the mounting base to the wall using the appropriate mounting hardware (field furnished).
6. Wire the network sensor. For more details on wiring the MS/TP Communications Bus, refer to the MS/TP
Communications Bus Technical Bulletin (LIT-12011034) or the FX-PC Series Controllers MS/TP
Communications Bus Technical Bulletin
(LIT-12011670).
This Class (A) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
IMPORTANT: Do not remove the Printed Circuit Board (PCB). Removing the PCB voids the product warranty.

Surface-Mounted NS Series Network Sensors without LCD Installation Instructions
3
For models featuring a modular jack, simply snap the wiring plug into the jack. See Figure 1 for modular jack
pin number assignments. Modular jack models require a straight-through, one-to-one connection (not a
crossover). For models featuring a screw terminal block, wire the unit as illustrated in Figure 2.
!
CAUTION: Risk of Electric Shock.
Disconnect the power supply before making electrical connections to avoid electric shock.
MISE EN GARDE : Risque de décharge électrique.
Débrancher l'alimentation avant de réaliser tout raccordement électrique afin d'éviter tout risque de
décharge électrique.
IMPORTANT: Failure to adhere to these wiring details causes the network sensor to function incorrectly. You
will not be able to connect to the system using the wireless commissioning converter or the handheld Variable
Air Volume (VAV) balancing tool, and you will not be able to expand the system with future offerings.

Surface-Mounted NS Series Network Sensors without LCD Installation Instructions
4
7. Align the tabs on the bottom edge of the mounting base with the slots on the bottom edge of the network
sensor assembly, and rotate the assembly onto its mounting base.
Note: On models featuring a screw terminal block, be certain that the terminal block pins align with the holes in
the terminal block.
Figure 1: Modular Jack Pin Number Assignments
Pin NumberAssignment for
Straight-Through Cable
Printed Circuit Board
SAPower (Network Sensor)
2
3
45
61
FIG:mdlr_jck
SA+
SA-
SABus Common (Tool Access)
SAPower (Tool Access)
Main
Network
Port
SABus Common (Network Sensor)
Figure 2: Wiring to the Screw Terminal Block
FIG:scrw_trmnl_blck

Surface-Mounted NS Series Network Sensors without LCD Installation Instructions
5
8. Use a 1/16 in. (1.5 mm) Allen wrench or Johnson Controls T-4000-119 Allen-Head Adjustment Tool to tighten
the security screw and fasten the network sensor assembly to the mounting base.
Note: Do not overtighten the security screw to avoid damaging the unit.
9. Use the Metasys Controller Configuration Tool (CCT) or Facility Explorer Programmable Controller Tool (FX-
PCT) software to commission the network sensor. Refer to the Controller Tool Help (LIT-12011147) for more
details.
Setup and Adjustments
Warmer/Cooler Adjustment
Certain models include a warmer/cooler dial designed to make minor temperature adjustments from the setpoint.
Turning the warmer/cooler dial adjusts the temperature setpoint up to ±5.0F°/±3.0C°.
Occupancy Override
Some models include an occupancy override push button on the left side of the network sensor, inline with the
green Light-Emitting Diode (LED). If the green LED is illuminated, the network sensor is in the occupancy override
mode. If the green LED is not illuminated, pressing the occupancy override push button activates the
normal-working-hours comfort mode.
Some NS-series sensor models also include a PIR Occupancy Sensor, or can initiate occupancy by rotating the
setpoint dial. The LED is not illuminated when the PIR sense occupancy or the setpoint dial is rotated.
Network Sensor Addressing
Most network sensors have a default device address of 199 on the SA Bus. For averaging models, the sensor
address must be set on the dual-switch DIP switch block on the network sensor Printed Wire Board (PWB).
Averaging models are shipped with both switches set to ON, resulting in a device address of 203. Device
addresses can be DIP switch set from 200 to 203; see Figure 3 and Table 1 for more details.
Figure 3: Dual-Switch
DIP Switch Block
1
O
N2
ON
FIG:dp_swtch_blck

Surface-Mounted NS Series Network Sensors without LCD Installation Instructions
6
Repair Information
If the NS Series Network Sensor fails to operate within its specifications, replace the unit. For a replacement
network sensor, contact the nearest Johnson Controls representative.
Technical Specifications
Table 1: Network Sensor Addressing
DIP Switch Address Switch 2 Switch 1
200 OFF OFF
201 OFF ON
202 ON OFF
203 ON ON
Surface-Mounted NS Series Network Sensors without LCD (Part 1 of 2)
Supply Voltage 9.8 to 16.5 VDC; 15 VDC nominal (from SA Bus)
Current
Consumption Temperature Only Models 13 mA maximum (non-transmitting)
Temperature
and Humidity
Models
17 mA maximum (non-transmitting)
Terminations Modular jack or screw terminal block
Network
Sensor
Addressing
NS-ATx7003-0,
NS-AHx7003-0
Models
DIP switch set from 200 to 203; factory set at 203
All Other
Models Fixed address of 199
Wire Size Modular Jack
Models 24 or 26 AWG (0.5 or 0.4 mm diameter); three twisted pair (six conductors)
Screw
Terminal
Block Models
18 to 22 AWG (1.0 to 0.6 mm diameter); 22 AWG (0.6 mm diameter) recommended
Communication Rate Auto-detect: 9.6k, 19.2k, 38.4k, or 76.8k bps
Temperature Measurement
Range 32.0°F/0.0°C to 104.0°F/40.0°C
Humidity
Measurement
Range
Full Range 0 to 100% RH
Calibrated
Range 10 to 90% RH
Temperature Sensor Type Local 1k Ohm platinum resistance temperature detector (RTD); Class A per IEC 60751
Humidity Sensor Type Thin film capacitive sensor
Temperature
Accuracy NS Series Network Zone
Sensor
±1.0F°/±0.6C°
Temperature
Element Only 0.35F° at 70°F (0.2C° at 21°C)
Humidity Element Accuracy ±3% RH for 20 to 80% RH;
±6% RH for 10 to 20% and 80 to 90% RH
Time Constant 10 minutes nominal at 10 fpm airflow
Default Temperature Setpoint
Adjustment Range ±5.0F°/±3.0C°

Published in U.S.A. www.johnsoncontrols.com
Surface-Mounted NS Series Network Sensors without LCD Installation Instructions
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls.
All other marks herein are the marks of their respective owners. © 2018 Johnson Controls.
Building Technologies & Solutions
507 E. Michigan Street, Milwaukee, WI 53202
7
European Single Point of Contact: NA/SA Single Point of Contact: APAC Single Point of Contact:
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
JOHNSON CONTROLS
C/O CONTROLS PRODUCT MANAGEMENT
NO. 22 BLOCK D NEW DISTRICT
WUXI JIANGSU PROVINCE 214142
CHINA
Ambient
Conditions Operating 32 to 104°F (0 to 40°C); 10 to 90% RH, noncondensing; 85°F (29°C) maximum dew point
Storage -40 to 158°F (-40 to 70°C); 5 to 95% RH, noncondensing
Compliance BACnet
International BACnet Testing Laboratories™ (BTL) 135-2004 Listed BACnet Smart Sensor (B-SS)
United States UL Listed, File E107041, CCN PAZX,
Under UL 916, Energy Management Equipment
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
Canada UL Listed, File E107041, CCN PAZX7,
Under CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada, ICES-003
Europe CE Mark – Johnson Controls, Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Australia and
New Zealand RCM Mark, Australia/NZ Emissions Compliant
Dimensions
(Height x Width x Depth) 3-5/32 x 3-5/32 x 1-3/8 in. (80 x 80 x 35 mm)
Shipping Weight 0.20 lb (0.09 kg)
Surface-Mounted NS Series Network Sensors without LCD (Part 2 of 2)
