Johnson Controls BMMS-1P Original operating instructions

Updated 11.8.17 © Copyright 2018 Johnson Controlswww.johnsoncontrols.com |414.524.1200 |5757 N. Green Bay Ave., P.O. Box 591, Milwaukee, WI 53201
Installation & Operation Guide
Thank you for purchasing the Johnson Controls
Single Phase Building Management Motor Starter!
Please read this manual thoroughly to ensure
safe installation and proper operation.
Precautions
To prevent injury and property damage, follow these instructions.
Failure to adhere to installation/operation procedures and all applicable
codes may result in hazards as indicated by warning
codes outlined below:
indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury. This signal word is to be limited to the
most extreme situations.
indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against
unsafe practices.
This is the safety alert symbol. Read and follow instructions carefully to
avoid a dangerous situation.
This symbol alerts the user to the presence of “dangerous voltage”
inside the product that might cause harm or electrical shock.
DANGER
WARNING
CAUTION
Safety Instructions
Equipment starts automatically. Lockout/tagout before servicing.
As with all electrical products, read manual thoroughly. Only qualified,
expert personnel should perform maintenance and installation. Contact the
nearest authorized service facility for examination, repair, or adjustment.
Do not disassemble or repair unit unless described in this manual; death
or injury to electrical shock or fire hazard may result. Specifications and
manual data subject to change. Consult factory for additional information.
DANGER
CAUTION
1Ø AC Input 50/60 Hz
L1 L2/N
T1 T2
M
Voltage Input
Auto Run
Fault
Output
Status
Output
Dry Input
Auto Run
Normally Open
Input
12-120V
AC/DC
Input
Main Power Wiring
Wire main power input and output to the appropriate 12AWG wire leads utilizing
properly sized wire nuts. Use only copper conductors rated at least 60°C.
Maintain proper clearances and verify that no possibility of an electrical short
exists between the power conductors or enclosure. Ensure that wires are not
under stress and all insulation is intact.
Low Voltage Wiring
Automation system control wiring should be run in a separate conduit. The
control terminals accept 26~14AWG wire torqued to 3.5 in-lb.
Installation
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN DEATH OR
SERIOUS INJURY
Mounting
Mount the starter on a minimum 14 cu-in single gang junction box. To access
mounting holes, slide upper and lower covers to the open position.
(See Figure 1)
Using provided mounting screws (6-32 x 7/8”), attach starter housing to junction
box (once appropriate wiring has been completed).
•
materials. Contact arcing can induce explosion or fire.
• Install starter in UL Type 1 (NEMA 1) appropriate locations only. Safe mounting
requires a dry, protected environment.
• The BAS-1P is rated for maximum ambient temperature of 40°C
• Do not allow any metal shavings or debris from installation to enter enclosure.
WARNING
Figure 1
HAZARDOUS VOLTAGE
• Disconnect and lock out all power before installing or servicing equipment.
• This equipment may require locking out multiple power sources prior to service
• Install and wire in accordance with all applicable local & national electrical and
construction codes
LIT-12013012

QSTART-BAS1P-V1 © Copyright 2018 Johnson Controlswww.johnsoncontrols.com |414.524.1200 |5757 N. Green Bay Ave., P.O. Box 591,Milwaukee, WI 53201
3.288
4.984
2.808
1.427
2.147
HAND RESET
AUTO
All dimensions in inches
Dimensions
Operation
Overload Adjustment
Confirm nameplate Full Load Amperage (FLA) to ensure proper overload
protection. Using a flathead screwdriver, turn the adjustment dial to the desired
amperage setting. The starter is not rated to protect loads exceeding 16 amps
@120VAC, and 8.8A @230VAC.
LED Status Indicators
POWER (PWR)
Illuminates when voltage is applied to the input terminals and
main power switch is in the ON (I) position.
RUN
Under a RUN condition, the RUN LED will remain illuminated if
the BAS-1P senses current providing status. The LED will flash
when the unit does not sense current.
FAULT (FLT) - Overload Trip
The BAS-1P indicates a fault condition by flashing the red FAULT
LED which will remain constant in the event of a fault trip. The LED
will also flash if a RESET attempt is made during the 180 second
overload cool down period.
Operation Modes
RESET
To reset the starter to normal operation following a Fault
condition, slide the 3-position switch to RESET and hold for
a minimum of 5 seconds (after 180 second cool down period
has elapsed). Once starter has been reset, return switch to the
desired mode.
MANUAL (HAND MODE)
In Manual or HAND mode, the BAS-1P will function as a
manual motor controller. Select the ON (I)
position on the main
power switch to engage motor.
AUTOMATIC (AUTO MODE)
When utilizing the starter in the AUTO mode, a signal sent via
the terminal inputs (located on rear of unit) determine motor
operation (ON or OFF).
Lockout Options
To lockout, slide the lower cover upward to reveal concealed locking grasp.
Insert a standard padlock to prevent unauthorized access or tampering. If
multiple padlocks are required, an optional padlocking attachment can be utilized
(not included). See Figure 2B.
Figure 2A Figure 2B
HAND RESET
AUTO
PWR
RUN
FLT
Product Ratings
1
2
3
4
5
6
Overload Adjustment
Operation Mode Selector
Main Power Switch*
PWR Power Status LED
RUN Run Status LED
FLT Fault / Overload LED
UL 508 Horsepower
Short Circuit Protection Interrupt
Current Max Current Overload Reset
115VAC 230VAC
BAS-1P
1HP
Suitable for use on a circuit capable of delivering not more
than 1kA RMS Symmetrical Amperes, 230 Volts maximum
when protected by Class RK5 fuses (30 Amp max) or
inverse time circuit breaker (40 Amp max)
Ik ≤ 1kA RMS
Symmetrical
16A @ 120VAC I2t Class 10
Manual
BAS-1P-AR
Automatic -
3 attempts max,
3 minutes between
attempts
1
2
3
4
5
6
*This device meets NFPA-70 (NEC) motor disconnect requirements per
paragraph 430.109 (C)(2) Stationary Motors of 2HP or Less.
8.8A @230VAC
