Applications
The TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers are stand-alone and
field-selectable BACnet® MS/TP or N2 networked devices that provide control of the following:
• local hydronic reheat valves
• pressure-dependent variable air volume (VAV) equipment with or without local reheat
• two- or four-pipe fan coils
• cabinet unit heaters
• other individual zone equipment using an on/off or floating control input
The networked models feature a field-selectable Building Automation System (BAS) BACnet MS/TP or N2
communication capability that enables remote monitoring and programming for efficient space temperature control.
All models include a USB port configuration that reduces installation time by allowing simple backup and restore
features from a USB drive, which enables rapid cloning of configuration between like units.
Some models have occupancy sensing capability built into the device. These thermostat controllers maximize up to
30% energy savings in high-energy usage commercial buildings, such as schools and hotels, during occupied
times by using additional standby setpoints.
All models feature an intuitive onboard touchscreen UI with backlit display that makes setup and operation quick
and easy. Multiple fan configurations are supported for fan coil equipment types:
• single-speed
• multi-speed (two or three discrete speeds)
• variable-speed/EC motors (0 to 10 VDC control)
Some models support dehumidification on two-pipe fan coil units with reheat, and four-pipe fan coil units with or
without reheat. When no heating is required, the thermostat controller monitors space humidity and activates
dehumidification control as necessary. Heat and/or reheat is used as required to maintain the space temperature.
For optimal dehumidification performance, use a fan coil unit that has a multi-speed or variable-speed fan (VSF).
TEC3000 Series On/Off or Floating Fan Coil and Individual
Zone Thermostat Controllers with Dehumidification
Capability
Installation Instructions
TEC3310-xx-xxx, TEC3311-xx-xxx, TEC3312-xx-xxx, TEC3313-xx-xxx,TEC3610-xx-xxx, TEC3611-xx-xxx, TEC3612-xx-xxx, TEC3613-xx-xxx
Part No. 24-10787-6, Rev. F
Issued July 2018
(barcode for factory use only)
24-10787-6, Rev. F
*24107876F*

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
2
North American Emissions Compliance
United States
Canada
Installation
Parts Included
• one TEC3000 Series Thermostat Controller with integral mounting base
• one installation instructions sheet
IMPORTANT: The TEC3000 Series Thermostat Controller is intended to provide an input to equipment under
normal operating conditions. Where failure or malfunction of the thermostat controller could lead to personal
injury or property damage to the controlled equipment or other property, additional precautions must be
designed into the control system. Incorporate and maintain other devices, such as supervisory or alarm systems
or safety or limit controls, intended to warn of or protect against failure or malfunction of the thermostat
controller.
IMPORTANT : Le TEC3000 Series Thermostat Controller est destiné à transmettre des données entrantes à un
équipement dans des conditions normales de fonctionnement. Lorsqu'une défaillance ou un dysfonctionnement
du thermostat controller risque de provoquer des blessures ou d'endommager l'équipement contrôlé ou un autre
équipement, la conception du système de contrôle doit intégrer des dispositifs de protection supplémentaires.
Veiller dans ce cas à intégrer de façon permanente d'autres dispositifs, tels que des systèmes de supervision ou
d'alarme, ou des dispositifs de sécurité ou de limitation, ayant une fonction d'avertissement ou de protection en
cas de défaillance ou de dysfonctionnement du thermostat controller.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class (B) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (B) respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
3
Location Considerations
Locate the TEC3000 Series Thermostat Controller:
• on a partitioning wall, approximately 5 ft (1.5 m)
above the floor in a location of average
temperature, allowing for vertical air circulation to
the TEC
• away from direct sunlight, radiant heat, outside
walls, outside doors, air discharge grills,
stairwells, and from behind doors
• away from steam or water pipes, warm air stacks,
unconditioned areas (not heated or cooled), or
sources of electrical interference
For integrated passive infrared (PIR) models, be sure
that the thermostat controller is located centrally,
where occupant movement is frequent.
Use insulating foam pads for installations where
wiring passes through the wall to the thermostat.
Note: Allow for sufficient clearance to insert a USB
drive into the USB port.
Installing the Thermostat Controller
1. Use a 1/16 in. (1.5 mm)Allen wrench or Johnson Controls® T-4000-119 Allen-HeadAdjustment Tool (order
separately) to remove the security screw if it is installed on the top of the thermostat controller cover as
illustrated in Figure 2.
2. Pull the top edge of the cover and open the thermostat controller as illustrated in Figure 2.
IMPORTANT: Only connect memory devices to the USB port. Do not use it for charging external devices.
IMPORTANT: The cover is not secured on the bottom. Be careful not to drop the cover.
IMPORTANT: If you are installing more than one thermostat controller, keep track of which cover attaches to
which base.
IMPORTANT: Use proper Electrostatic Discharge (ESD) precautions during installation and servicing to avoid
damage to the electronic circuits of the thermostat controller.
Figure 1: Thermostat Controller
Shown without Occupancy Sensor,
Dimensions, in. (mm)
FIG:thermostat features
USB Port
Display
Security Screw
1-13/32
(36)
4-23/32
(120)
5-5/8
(143)

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
4
Figure 2: Removing the Security Screw from the Thermostat Controller Cover
(Shown without Occupancy Sensor) (Left) and Removing the Thermostat Controller Cover (Right)
3. Align the thermostat controller mounting base on the wall with the security screw on the top and use the base
as a template to mark the two mounting hole locations. See Figure 3.
Notes:
• If you need to install the thermostat controller on an electrical junction box, use
2-1/2 x 4 in. (63 x 101 mm) square boxes with mud ring covers and avoid smaller 1-1/2 x 4 in.
(38 x 101 mm) square or 3 x 2 in. (76 x 51 mm) boxes. This procedure ensures that you have enough
space for cabling, if needed.
• For surface-mounted applications, use durable mounting hardware, such as wall anchors, that cannot be
easily pulled out of the mounting surface.
4. Pull approximately 6 in. (152 mm) of wire from the wall and insert the wire through the center hole in the
thermostat controller mounting base. See Figure 3.
5. Secure the mounting base to the wall surface using two mounting screws (user supplied) as illustrated in
Figure 3.
Note: Be careful not to overtighten the mounting screws.
FIG:securit y screw
FIG:thermostat cover

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
5
Figure 3: Mounting Hole Locations, Dimensions, in. (mm) (Left) and
Securing the Thermostat Controller Mounting Base to the Wall (Right)
Wiring
Whenanexistingthermostatcontrollerisreplaced,removeandlabelthewirestoidentifytheterminalfunctions.
Risk of Electric Shock.
Disconnect the power supply before making electrical connections to avoid electric shock.
Risque de décharge électrique.
Débrancher l'alimentation avant de réaliser tout raccordement électrique afin d'éviter tout risque de décharge
électrique.
Risk of Property Damage.
Do not apply power to the system before checking all wiring connections. Short circuited or improperly connected
wires may result in permanent damage to the equipment.
Risque de dégâts matériels.
Ne pas mettre le système sous tension avant d'avoir vérifié tous les raccords de câblage. Des fils formant un
court-circuit ou connectés de façon incorrecte risquent d'endommager irrémédiablement l'équipement.
IMPORTANT: Make all wiring connections in accordance with local, national, and regional regulations. Do not
exceed the electrical ratings of the TEC3000 Series Thermostat Controller.
4-1/16
(103)
FIG:TEC Backplane2
3-1/4
(83)
FIG:TEC Backplane1

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
6
To wire the thermostat controller:
1. Strip the ends of each wire 1/4 in. (6 mm) and connect them to the appropriate screw terminals as indicated in
Table 2 and Figure 6 or Figure 7.
Note: For more details on wiring the MS/TP Communications Bus, refer to the MS/TP Communications Bus
Technical Bulletin (LIT-12011034).
2. Carefully push any excess wire back into the wall.
Note: Seal the hole in the wall with fireproof material to prevent drafts from affecting the ambient temperature
readings.
3. Reattach the communication wires to the terminal block.
Note: If multiple wires are inserted into the terminals, be sure to properly twist the wires together before
inserting them into the terminal connectors.
4. Set the bus end-of-line (EOL) termination switch to the desired location on the TEC3610-00-000,
TEC3611-00-000, TEC3612-00-000, and TEC3613-00-000 models only.
The bus EOL termination switch allows you to designate the thermostat controller as the end of the Field
Controller (FC) Bus and N2 Bus. The default position is OFF. If the thermostat controller is at the end of a daisy
chain of devices on the FC Bus and N2 Bus, set the EOL switch to the ON position. See Figure 4.
Figure 4: EOL Switch Position (Left) and Installing the Thermostat Controller Cover (Right)
5. Reattach the thermostat controller cover to the mounting base (bottom side first).
IMPORTANT: Use proper ESD precautions during installation and servicing to avoid damage to the electronic
circuits of the thermostat controller.
IMPORTANT: Make sure you reattach the cover that corresponds to its correct base. The CPU board number
needs to match the base board number. Otherwise, an operation error occurs after you reattach a cover and
base that do not belong together (as shown in Figure 5). See Table 1 on page 7 for TEC3000 model names and
code numbers.
FIG:EOL_Swtch
EOL Switch
ON Position
EOL Switch
OFF Position
O
N
O
N
FIG:TEC Backplane2_EOL Switch
O
N
FIG:close thermostat cover

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
7
6. Use a 1/16 in. (1.5 mm)Allen wrench or Johnson Controls T-4000-119 Allen-Head Adjustment Tool (order
separately) to reinstall the security screw on the top of the thermostat controller cover. See Figure 2 for security
screw placement.
7. Remove the protective plastic cover sheet from the display.
Table 1: TEC3000 Model Names and Code Numbers
Name Code Number1
1. The two-character code number is listed within the error code to
indicate that the CPU board and base board do not belong together.
However, if the same code number appears as both the CPU board
and base board, there is no error. For example, if 0B is listed as the
CPU board and the base board, the model is the TEC3611.
Name Code Number1
TEC3310 00 TEC3610 0A
TEC3311 01 TEC3611 0B
TEC3312 02 TEC3612 0C
TEC3313 03 TEC3613 0D
TEC3320 04 TEC3620 0E
TEC3321 05 TEC3621 0F
TEC3322 06 TEC3622 10
TEC3323 07 TEC3623 11
TEC3330 08 TEC3630 12
TEC3331 09 TEC3631 13
IMPORTANT: If the display is dirty, gently wipe it clean with isopropyl alcohol or ethyl alcohol. Do not scrub
hard as to avoid damaging the surface. Do not use other cleaners such as water, ketones, and aromatic
solvents, since they may damage the polarizer.
CPU Board Base Board
Figure 5: Error Code Indicating
Mismatched Boards

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
8
Table 2: Terminal Identification (See Figure 6 and Figure 7 for Wiring Diagrams)
Terminal Label Function
TEC3310, TEC3311, TEC3312, TEC3313
Floating FC/VAV and On/Off FC1TEC3610, TEC3611, TEC3612, TEC3613
Floating FC/VAV and On/Off FC1
24 V 24 VAC hot from transformer
FAN H Fan high
FAN M Fan medium
FAN L Fan on (single-speed, variable speed), Fan low (multi-speed)
AUX Auxiliary binary output
AUX Auxiliary power
COM224 VAC common from transformer
CLG O Cool open (Floating), Cooling NC (On/Off), Triac
CLG C Cool close (Floating), Cooling NO (On/Off), Triac
HTG O Heat open (Floating), Heating NC (On/Off), Triac
HTG C Heat close (Floating), Heating NO (On/Off), Triac
COM2Common
VSF Variable speed fan command (configurable 0 to 10 V range)
BI2 Configurable binary input 2
BI1 Configurable binary input 1
COS Changeover sensor
R SEN Remote zone temperature sensor
NET+ Not connected Field bus+/N2+
NET- Not connected Field bus-/N2-
NET COM Not connected Isolated common for field bus
1. There is no support for an On and Off VAV.
2. The common terminals, which do not include NET COM, are internally connected and can be used for all inputs and
outputs.

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
9
Notes:
• VAV and 2-pipe systems should connect their valve to the heating output.
• Only one transformer is required for each TEC.
Figure 6: On/Off Wiring Diagram (See Table 2 for Terminal Identification)
Zone Temp
Thermistor
Supply Temp
Switch
FIG:Model 1 Wiring_on_off_output
24 V
R SEN
24V
NET COM
COS
VSF
COM
Supply Temp
Thermistor
Vin
Common
or
24 V
High
Med
FAN H
AUX
TB1
CLG C
Low
Fan
on
Fan
Common
Hot
Heating
Common
Hot
FAN M
FAN L
AUX
FIG:Model 1 Wiring_on_off_input
N.C.
Common
Hot
Common
Hot
N.O.

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
10
Notes:
• For VAV and 2-pipe systems, connect the valve to the heating output.
• Only one transformer is required for each TEC.
Figure 7: Floating Wiring Diagram (See Table 2 for Terminal Identification)
FIG:Model 1 Wiring_floating_output
Zone Temp
Thermistor
SupplyTemp
Switch
24 V
Vin
Common
R SEN
24V
NET COM
COS
VSF
COM
SupplyTemp
Thermistor
EC Motor
or
24 V
High
Med
FAN H
AUX
TB1
CLG C
Low
Fan
on
Fan
Heating
FAN M
FAN L
AUX
FIG:Model 1 Wiring_floating_input
Open
Hot
Close
Open
Hot
Close

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
11
Note: VAV and 2-pipe systems should connect their valve to the heating output.
Figure 8: Floating Control (Pressure-Dependent VAV)
Figure 9: Floating Control (Pressure-Dependent VAV with Changeover Sensor/Switch)
Figure 10: Floating Control (Pressure-Dependent VAV with Changeover Sensor/Switch and Reheat)
Note: Power to the AUX contact comes from the reheat coil.
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted onActuator)
Floating
Actuator
COS
COM
24V
HTG O
HTG C
F
I
G
:
m
o
d
e
l
_
1
_
c
l
n
g
_
o
n
l
y
FIG:model_1_htng_clng_chngvr
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted onActuator)
Floating
Actuator
Supply Air
Temperature Sensor
COS
COM
24V
HTG O
HTG C
FIG:model_1_htng_clng_chngvr_rht
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted onActuator)
Heating/Cooling
and On/Off
Duct Heater
Floating
Actuator
Supply Air
Temperature Sensor
1
C
COS
COM
24V
HTG O
HTG C
AUX
AUX

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
12
Note: VAV and 2-pipe systems should connect their valve to the heating output.
Figure 11: Floating Control Two-Pipe Heating and Cooling Hydronic Valve Control Fan Coil Application
Figure 12: Floating Control Two-Pipe Heating and Cooling Hydronic Valve Control with Changeover Fan
Coil Application
Figure 13: Floating Control (On/Off Two-Pipe and Four-Pipe Fan Coil Applications)
FIG:model_1_htng_clng_hdrnc
Room Temperature
Control Thermostat
COS
COM
24V
HTG O
HTG C
FIG:model_1_htng_clng_hdrnc_chngvr
Floating
Heating/Cooling
Valve
Optional Water
Supply Sensor
Room Temperature
Control Thermostat
Supply Water
Temperature Sensor
COS
COM
24V
HTG O
HTG C
Two-Pipe Applications Four-Pipe Applications
FIG:model_1_onoff
COM
24V
COM
24V
Cooling
Valve
Heating
Valve
Triac Switch Triac Switch Triac Switch

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
13
Note: VAV and 2-pipe systems should connect their valve to the heating output.
Figure 14: Floating Control (Floating Two-Pipe and Four-Pipe Fan Coil Applications)
Figure 15: AUX Contact Wiring
Figure 16: Binary Input Wiring
Setup and Adjustments
Overview
Figure 17 shows the thermostat controller home screen. You can customize it to show or hide various elements
from the occupant. See Table 3 for a listing of the touchscreen icons and Table 10 to identify the home screen
settings under the Display Settings. When screen customization is used in conjunction with a passcode, the
building owner can control which options the occupant can access and adjust.
IMPORTANT: Table 10 provides a full list of TEC3000 menu settings. In the upcoming sections, step-by-step
instructions are included on how to access and adjust the more commonly used menus.
IMPORTANT: If lockout levels are used, some icons are hidden. Table 4 provides details of these levels.
Two-Pipe Applications Four-Pipe Applications
FIG:model_1_floating
COM
24V
CLG O
Cooling
Valve
Heating
Valve
CLG C
HTG O
HTG C
COM
24V
HTG O
Heating/Cooling
Valve
HTG C
Triac Switch Triac Switch Triac Switches
AUX Contact
FIG:Aux Contact Wiring
Load
Hot 19 to 30 VAC
FIG:Binary Input Wiring
BI1
Dry Contact Bi2
Dry Contact

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
14
Figure 17: Thermostat Controller Home Screen
The humidity level appears on the home screen if there is a humidity sensor in the unit, or if the thermostat
controller has a network override written to it.
Customizing the Home Screen
Customizing the Home screen settings include:
You can also show or hide these items on the Home screen:
To customize the Home screen:
1. Press the Menu icon.
2. Press Display Settings.
3. Enable or disable elements of the home screen as appropriate for the building owner and occupants.
4. Set the passcode on the thermostat controller to prevent the occupants from changing settings that they should
not have access to change.
Touchscreen Icons
Table 3 describes the home screen touchable icons. Press and release a touchscreen icon to activate the TEC.
Additional touchable icons appear based on the menu, and those icons are also described in Table 3.
• Brightness • Units • Time Zone • Date
• Enable Backlight • Time • Time Format • Date Format
• Fan Button • Off Button • Alarm Indication • Date/Time
• Space Temperature • Hold Button • Occupancy Status
• Humidity • Setpoint • Unit Status
Table 3: Touchscreen Icons (Part 1 of 3)
Icon Icon Name Description
Menu Displays the configuration screens where various settings may be adjusted.
Alarm Indicates that the thermostat controller has triggered an alarm.

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
15
Unit Power
On
Off
Powers the thermostat controller on or off.
Note: This icon disables all equipment control, but does not physically power
down the unit.
Network Communication Indicatesthat thethermostat controllerdetectedasupervisory controllerand both
are online.
Arrow
Increases or decreases a value depending on the configuration screen.
Run/Hold
Displays the current setpoint. Hold mode is enabled by pressing the button.
No Hold/Hold
Displays the current setpoint. Hold mode is not enabled.
Hold/Hold
Displays the active setpoint. Hold mode is not enabled.
Right Arrow Proceeds to the next screen.
Fan Overrides for
Single-speed Fans
On
Auto
Quiet
Adjusts the fan override between On, Auto, and Quiet for single-speed fans.
Fan Overrides for
Variable-speed Fans
On
Auto
Quiet
Adjusts the fan override between On, Auto, and Quiet for variable-speed fans.
Table 3: Touchscreen Icons (Part 2 of 3)
Icon Icon Name Description

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
16
Fan Overrides for
Multi-speed Fans
Low
Medium
High
Auto
Quiet
Adjusts the fan override between Low, Medium, High, Auto, and Quiet for
multi-speed fans.
Home Returns the display to the main home screen.
Back Returns to the previous screen.
Save Saves the current configuration and parameter settings.
Delete Deletes the scheduled event.
Clear Clears the password entry on the keypad screen.
Wrench Indicates that the value is editable.
Checkmark Indicates that an event or schedule is programmed for a specific day of the week.
Exclamation Point Indicates that an error has occurred.
Table 3: Touchscreen Icons (Part 3 of 3)
Icon Icon Name Description

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
17
User Lockout
You can select from three different levels of access at the local display to manage functionality through the
supervisory controller. This lockout is independent of any display or passcode settings. The existing temporary
occupancy capability is unaffected by this feature. User lockout hides the icons that are not operable. The lockout
levels are described in Table 4.
Using the USB Port
The USB port allows you to quickly and easily load firmware upgrades, backup settings, and restore settings to the
TEC3000 by using a USB drive. The TEC3000 can recognize eight configuration files or firmware package files.
The USB drive format must be FAT or FAT32. The drive cannot be NTFS or USB 3.0. If you are upgrading firmware
or copying configuration files, you need the TEC3000 passcode, if it has been set up. Do not remove the USB drive
until the firmware upgrade is complete. The TEC3000 may restart and go offline to the NAE after a firmware
upgrade. The upgrade takes approximately three minutes.
Configurations are copied, except for the Communication mode. See Choosing the Communication Mode
(TEC3610-00-000, TEC3611-00-000, TEC3612-00-000, and TEC3613-00-000 Models) to configure each device.
Loading the Firmware
1. Ensure that the TEC screen is on.
2. Insert the USB drive into the right side of the TEC.
See Figure 1 for the USB port location.
3. Press the Menu icon.
4. Scroll down the menu and press Update.
5. Press Load Firmware.
6. Select the correct firmware version. The correct file name has the .pkg extension.
7. Press Confirm if you have the correct firmware version.
The firmware is loaded from the USB drive into the TEC3000 operating system. The TEC3000 locates the new
firmware only if the new firmware is on the root drive of the USB drive. See Troubleshooting if the firmware is
not loaded correctly.
8. Remove the USB drive from the TEC3000 controller when the update is complete.
The TEC3000 firmware update is complete when the TEC3000 restarts and returns to the home screen.
Backing Up the Settings
1. Ensure that the TEC screen is on.
2. Insert the USB drive into the right side of the TEC.
See Figure 1 for the USB port location.
3. Press the Menu icon.
4. Scroll down the menu and press Update.
5. Press Backup.
A message appears stating that the file is saved locally and on a USB drive.
Table 4: User Lockout Levels
Lockout Level Capability
State 0 Allows full access to Home Screen Display Adjustments and icons (default).
State 1 Hides the Menu icon.
State 2 Only allows the screen to trigger temporary occupancy. Menu, Unit Power, the Up
and Down arrows, and Run/Hold are hidden.

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
18
6. Press Confirm to save locally and on USB.
The setting files are named based on the TEC3000 model name, date, and time stamp
(for example, TEC3311-00_2015-10-08T1). The files are saved locally and on the USB drive’s root directory.
See Troubleshooting if the settings are not backed up correctly.
7. After the settings are saved onto the USB drive, remove the USB drive from the TEC3000.
Restoring the Settings
1. Ensure that the TEC screen is on.
2. Insert the USB drive into the right side of the TEC.
See Figure 1 for the USB port location.
3. Press the Menu icon.
4. Press Update.
5. Press Restore.
6. Select Local Storage or the correct configuration file created from a previous backup operation.
The setting files are named based on the TEC3000 model name, date, and time stamp
(for example, TEC3311-00_2015-10-08T1). The files are saved locally and on the USB drive’s root directory.
7. Press Confirm if you have the correct file name.
The settings are loaded from the USB drive.
8. After the settings are loaded from the USB drive, remove the USB drive from the TEC3000.
Choosing the Communication Mode (TEC3610-00-000, TEC3611-00-000, TEC3612-00-000, and
TEC3613-00-000 Models)
1. Ensure the TEC screen is on.
2. Press the Menu icon.
3. Press Network Setup.
4. Press FC Comm Mode.
5. Select BACnet or N2 by pressing .
6. Proceed to Step 7 to perform BACnet communication and Step 15 to perform N2 communication.
7. Press to return to the previous screen.
8. Press BACnet Instance ID.
9. Enter the unique BACnet® instance ID using the keypad. This value should be different to the other controllers
on the site.
10. Press Save.
11. Press to return to the previous screen.
12. Press BACnet Address.
13. Enter the BACnet MS/TP address through the keypad.
14. Press Save.
15. After selecting N2 in Step 5, press Save.

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
19
16. Press to return to the previous screen.
17. Press N2 Address.
18. Enter the N2 address through the keypad.
19. Press Save.
Configuring the Thermostat Controller
Use the Menu icon on the home screen to access and change the basic operating parameters of the thermostat
controller. During normal operation, press the Menu icon once to access the following parameters:
Installer Configuration Menu
The thermostat controller comes from the factory with default settings for all configuration parameters. The UI
menu navigation and default settings are shown in Table 10. Before any outputs turn on, the controller must be
configured for the equipment connected. You need to start from the home screen to perform any of the following
tasks.
Screen Reset
The current screen returns to the home screen if the current screen is not touched for 3 minutes.
Selecting the Unit Type
There are three unit types. They are:
• 4-pipe—This unit type has both heating and cooling coils plus a supply fan. This configuration can also be used
on configurations that are heating or cooling only.
• 2-pipe—This unit type has a single set of pipes that can serve hot or chilled water plus a supply fan. The
Supply Temp Type allows for the connection of an analog sensor or an aquastat to a binary input. Based on the
water temperature or aquastat state, the unit controls heating or cooling.
• VAV—This unit type is designed for a pressure-dependent zone damper and the supply fan outputs are
disabled. The TEC senses the supply air temperature coming from the unit. The Supply Temp Type setting
allows for the connection of an analog sensor or binary duct thermostat. Based on the air temperature or duct
thermostat state, the zone damper controls for heating or cooling. The TEC does not control the unit delivering
the air. The logic needs to be part of another controller.
By default, the thermostat controller is configured for 4-pipe fan coil mode. To change to a 2-pipe or
Pressure-Dependent VAV mode:
1. Press the Menu icon.
2. Press Equipment Setup.
3. Press General.
4. Press Unit Type and select 2-pipe, 4-pipe, or VAV.
5. Press to save and to return to the previous screen.
Note: Selecting VAV reboots the controller in order to apply the change.
• Faults Status • Display Settings • Equipment Setup • Controller Information
• Setpoints • Control Setup • System Status • Commissioning
• Schedule • Network Setup • Control Status • Update

TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
20
Selecting the Heating and Cooling Device Type
By default, the thermostat is configured for On-Off (2-position) control. This can be changed to Floating
(Incremental) mode when the Unit Type is not set to VAV. For VAV mode, only floating actuators are supported
and this option is unavailable. To change the Heating/Cooling Device Type:
1. Press the Menu icon.
2. Press Equipment Setup.
3. Press General.
4. Press Htg/Clg Device Type and select On-Off or Floating. Changing this option reboots the controller in
order to apply the change.
5. Press to save and to return to the previous screen.
When in Floating mode, the Actuator Stroke Time must also be set to match the equipment. To set the actuator
stroke time:
1. Press the Menu icon.
2. Press Equipment Setup.
3. Press General.
4. Press Actuator Stroke Time and adjust accordingly.
5. Press to save and to return to the previous screen.
Configuring the Supply Fan - Fan Coil Only
On fan coil units (2-pipe or 4-pipe), three different types of supply fans are supported. These are single-speed fans,
multi-speed fans (up to three discrete speeds), and VSF using a 0 to 10 V control signal and an optional binary on/
off command. Note that fan control is not available when in VAV mode. To select the fan type:
1. Press the Menu icon.
2. Press Equipment Setup.
3. Press Supply Fan.
4. Press Supply Fan Type and select Single Speed, Multi-Speed, or Variable Speed.
5. Press to save and to return to the previous screen.
For multi-speed fan control, you can adjust the point when the medium or high speed turns on. The fan speed is
based on the load on the cooling/heating device, and is a percentage between 0 and 100. By default, the Med
Speed On Cmd is 33% and the High Speed On Cmd is 66%. When only two fan speeds are used, you must set the
High Speed On Cmd to 100% to disable the third speed and set the Med Speed On Cmd to 50%. To adjust these
values:
1. Press the Menu icon.
2. Press Equipment Setup.
3. Press Supply Fan.
4. Press Medium Speed On Cmd and adjust accordingly.
5. Press High Speed On Cmd and adjust accordingly.
6. Press to save and to return to the previous screen.
