Johnson Controls MS2 Manual

FANs 125, 121
Temperature Controls Section A
Installation Bulletin
Issue Date 1199
© 1999 Johnson Controls, Inc. 1
Part No. 24-7664-1725, Rev. A www.johnsoncontrols.com
Code No. LIT-125209
IMPORTANT: All MS2 controls are designed for
use only as operating controls.
Where an operating control
failure would result in personal
injury or loss of property, it is the
responsibility of the installer to
add devices (safety, limit
controls) or systems (alarm,
supervisory systems) that protect
against, or warn of, control
failure.
Refer to the MS Series Multi-Stage Electronic
Temperature Controls Product Bulletin, LIT-125198, for
necessary information on operation and performance
specifications for this product.
Mounting
The MS2 control is not position-sensitive but should be
mounted for convenient wiring and adjustment.
To mount the DIN Rail Mount version, install the DIN
rail where appropriate. Snap the control onto the rail in
position.
To mount the Panel Mount version, ensure that there is
sufficient space behind the panel. At least
2-3/4 inches (70 mm) are needed. Make a cutout
1-3/16 by 2-13/16 inches (29 by 71 mm). Remove
retaining clip from control. Insert the control into the
hole. Install retaining clip and adjust for tightness.
Wiring
!
WARNING: Risk of Electrical Shock.
Disconnect power supply before
making electrical connections to
avoid possible electrical shock or
equipment damage.
Follow these wiring guidelines:
All wiring must conform to the National Electric
Code and local regulations.
Make all wiring connections using adequate gauge
copper conductors only. Connectors are rated for
14-22 AWG wiring.
SC
DV1 V2
Internal to Control
Process
Sensor
Binary
Input
Binary and Sensor Common
Power
Supply
C1 C2
Stage 

Stage 
Refer to Rating Table for more information.
Terminal Not Used
Figure 1: MS2 Panel Mount Wiring
Internal to Control
Process
Sensor
Binary
Input

Stage

Stage
Power
Supply
V1 V2
CD

C1
SC 
C2
S1 D
Sensor Common Binary
Common
Terminal Not Used
Refer to Rating Table for more information.
Figure 2: MS2 DIN Rail Mount Wiring
INSTALLATION BULLETIN
MS2 Two Stage Electronic Temperature Control

2A—MS2 Two Stage Electronic Temperature Control Installation Bulletin
Use this table, with function So, to compensate for long
sensor wire.
Table 1: Sensor Wire Size and Length
18 AWG
20 AWG
22 AWG
Offset
300-599 ft
91-183 m
190-374 ft
58-114 m
120 -239 ft
36-73 m
1F°
1C°
600-899 ft
183-274 m
375-564 ft
114-172 m
240-349 ft
73-107 m
2F°
2C°
900+ ft
274+ m
565+ ft
172+ m
350+ ft
107+ m
3F°
3C°
Table 2: Rating Table
Rating Category
120
VAC
240
VAC
24
VDC
Horsepower
1/4
1/2
-
Full Load Amperes
5.8
4.9
-
Locked Rotor Amperes
34.8
29.4
-
Inductive (non-motor)
Amperes
8
8
8
Pilot Duty VA
275
450
-
Relay outputs must not exceed 20 amperes total
connected load. Power supply is 24 VAC.
FCC Compliance
This equipment has been tested and found to comply
with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the
instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in
a residential area is likely to cause harmful
interference, in which case the user will be required to
correct the interference at his/her own expense.
Canadian DOC Compliance
This digital apparatus does not exceed the Class A
limits for radio noise emissions from digital apparatus
set out in the Radio Interference Regulations of the
Canadian Department of Communications.
Display
Press Up and Down buttons to scroll through process
temperature and binary input status (On or OF). After
15 seconds of inactivity, the display shows the process
temperature.
Setting Up the Stage Control
To lock/unlock the unit for programming
Press the Enter, Up, and Down buttons
simultaneously and hold until “- - -” is displayed.
Hold for about 10 seconds until the current
temperature is displayed. This toggles the
keypad between locked and unlocked.
To run the self test procedure
IMPORTANT:Disconnect loads before beginning self-test
procedure. Cycle power to resume normal
operation.
Press the Up and Down buttons in sequence,
and hold for 5 seconds.
To select the mode of operation
1. Press and hold the Enter and Down buttons
simultaneously for approximately 7 seconds.
2. Press the Up or Down button until the desired
setting is shown.
2d = Direct (cool)
2r = Reverse (heat)
2b = Deadband
2i = Independent Setpoint
3. Press the Enter button to save the new mode
of operation.
To change the setpoint (modes b, d, and r only)
1. Hold the Enter button down for 3 seconds.
The display will change to show the setpoint.
2. Press the Up or Down button until you reach
the new setpoint.
3. Press the Enter button to save the new
setpoint.
Note: If you do not press the Enter button after selecting the new
setpoint, it is not saved. The control reverts to old setpoint.
To program other settings (modes b, d, r only) or to
program setpoints and settings (mode i only)
1. Hold the Enter button down for about
10 seconds. The display will change to HY.
(The display shows S1 if in Mode i.)
2. Press the Up or Down button until the desired
setting is shown.
3. Press the Enter button. The setting’s current
value is displayed.
4. Press the Up or Down button until the desired
value is shown.
5. Press the Enter button to save the new value.
After 10 seconds of inactivity, the display will
return to its normal function.
Note: If you do not press the Enter button after selecting the new

A—MS2 Two Stage Electronic Temperature Control Installation Bulletin 3
value, it is not saved. The control reverts to the old value.

4A—MS2 Two Stage Electronic Temperature Control Installation Bulletin
Table 3: Functions and Settings
Mode
2d = Direct 2r = Reverse 2b = Deadband 2i = Independent Setpoint
d
Setting
Description
Setting Range
Default
SI Setpoint
Modes d, r, b: relay cut-off point
Mode i: heating independent setpoint
-40 to 99°F
(-40 to 70°C)
—
HI Differential (Hysteresis)
Temperature difference relative to setpoint or offset at
which the load is switched On or Off
1 to 9F° (1 to 9C°)
5
S2 Setpoint 2 (Offset)
Modes d, r: difference between setpoint and Stage 2
Mode b: deadband (centered on setpoint)
Mode I: cooling independent setpoint
d, r: 1 to 40F°
(1 to 40C°)
b: 2 to 40F°
(2 to 40C°)
I: LL to HL
5
H2 Differential (Hysteresis) 2
See Differential (hysteresis)
1 to 9F° (1 to 9C°)
5
LL Low Setpoint Stop
Lower limit of end-user setpoint adjustment
-40F° (-40C°) to HL
32
HL High Setpoint Stop
Upper limit of end-user setpoint adjustment
LL to 99°F (70°C)
90
Cc Anti-short Cycle Timer,
Cool
Time delay between equipment On cycles for cooling
stages
0 to 9 minutes
2
CH Anti-short Cycle Timer,
Heat
Time delay between equipment On cycles for heating
stages
0 to 9 minutes
0
rt Soft Start
Rate at which process temperature approaches setpoint
0 to 99
minutes/degrees
10
AH High Temperature Alarm
High temperature alarm setpoint relative to main setpoint
0 to 50F° (0 to 50C°)
above setpoint
15
AL Low Temperature Alarm
Low temperature alarm setpoint relative to main setpoint
-50 to 0F° (-50 to 0C°)
below setpoint
-15
Ad Alarm Differential
Temperature difference relative to high and low alarms at
which alarm output is switched Off
1 to 9F° (1 to 9C°)
5
At Alarm Time Delay
Delay between alarm detection and activation
0 to 99 minutes
15
So Sensor Offset
Compensates for long sensor leads or sensor location
-20 to +20F°
(-20 to +20C°)
0
Un Units Used
Temperature units used
0 = °C 1 = °F
1
PU Display Refresh Rate
Time delay between display refreshes
1 to 99 seconds
1
IF Binary Input Function
Configuration for normally closed binary input
0 = No binary input
1 = Shutoff/alarm
signaling
2 = Setback
3 = Remote shutoff
0
Sb Setback
Value of setpoint shift when binary input is open and IF=2
0 to 20F° (0 to 20C°)
10
Id Binary Input Time Delay
Time between binary input detection and enabling of IF
0 to 99 minutes
0
iS Interstage Time Delay
Minimum amount of time between two successive stages
3 to 90 seconds
3
Repair and Replacement
Field repair must not be made. In case of defective or
improperly functioning control, contact your nearest
authorized Johnson Controls/PENN distributor.
When requesting a replacement, reference the model
number found on the data plate of the control.

A—MS2 Two Stage Electronic Temperature Control Installation Bulletin 5
Fault/Alarm Codes
Table 4: Status Codes (steady on display)
Status Code
Indicates
On
Binary Input is closed.
OF
Binary Input is open.
Table 5: Fault/Alarm Codes
Error Code (Flashing on Display)
System Status
EE Program failure; control must be replaced.
Alarm message displays, other outputs off.
FI Indicates an open or shorted temperature sensor.
Alarm message displays. Correct problem and cycle
power to reset.
AI Binary input (IF) Option 1 selected and binary input open
for longer than time delay (id).
Control output is switched off; alarm message displays.
Correct condition to reset.
DF Binary input (IF) Option 3 is selected and binary input open.
Control output is switched off. Close binary input to reset.
HI Temperature has reached or exceeded (setpoint + AH).
Alarm message displays. Correct condition to reset.
LO Temperature has reached or fallen below (setpoint - AL).
Alarm message displays. Correct condition to reset.
Ordering Information
Table 6: Specifications
Power Requirements
3.7 VA @ 24 VAC, 50/60 Hz, Class 2 (20-30 VAC)
Ambient Conditions
Operating: +14 to +140°F (-10 to +60°C); 0 to 95% RH (non-condensing)
Storage: -22 to +176°F (-30 to +80°C); 0 to 95% RH (non-condensing)
Accuracy
+1.8 F° (+1C°)
Agency Listings
UL Recognized: File E194024, CCN XAPX2
Canadian UL Recognized: File E194024, CCN XAPX8
FCC Compliant per Class A Digital Device, Part 15
Canadian DOC Compliant per Class A, Radio Interference Regulations
Table 7: Ordering Information
Item Code
Description
MS2DR24T-11C
MS2 DIN Rail Mount Control; A99BB-200C sensor included
MS2PM24T-11C
MS2 Panel Mount Control; A99BB-200C sensor included
A99BB-200C
A99B Temperature Sensor; Cable length 6-1/2 ft (2 m)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult Johnson Controls/Penn Refrigeration Application Engineering at [phone]. Johnson Controls, Inc. shall not be
liable for damages resulting from misapplication or misuse of its products.
Controls Group
507 E. Michigan Street
P.O. Box 423 Printed in U.S.A
Milwaukee, WI 53201 www.johnsoncontrols.com
