Julabo Corio C Installation instructions

Heating immersion circulator, open bath heating circulator,
refrigerated circulator
Original operating manual
1.950.0400.us.V04 03/2022

2
Legal
JULABO USA, Inc.
884 Marcon Boulevard
Allentown, PA 18109
Phone: [phone]
Fax.: [phone]
[e-mail]
www.julabo.us
The content of this operating manual is protected by copyright. Information,
including texts, images, and other contents may not be reproduced, distributed,
transmitted, stored or otherwise used in any form without prior explicit written
consent.
Illustrations in this operating manual are for illustrative purposes and are not
necessarily displayed to scale.

3
1Foreword............................................................................................ 5
2About this manual............................................................................. 6
2.1 Original JULABO spare parts ......................................................... 6
2.2 Accessories.................................................................................... 6
2.3 Warnings........................................................................................ 6
2.4 Symbols used................................................................................. 7
3Intended use ...................................................................................... 8
4Safety ................................................................................................. 9
4.1 General Safety Instructions for the operating company.................. 9
4.2 General Safety Instructions for the operator................................... 9
4.3 General Safety instructions for device operation.......................... 10
4.4 Safety symbols............................................................................. 11
4.5 Safety function ............................................................................. 11
5Product description ........................................................................ 13
5.1 Product overview.......................................................................... 13
5.2 Operating and functional elements............................................... 14
5.2.1 Key description........................................................................ 15
5.3 Alarm messages........................................................................... 15
5.4 Technical data.............................................................................. 16
5.4.1 Material of parts that come into contact with the medium ....... 18
5.4.2 Bath fluids ............................................................................... 18
6Transport and installation .............................................................. 20
6.1 Transporting the device................................................................ 20
7Initial operation................................................................................ 21
7.1 Connect the device to the power supply....................................... 21
7.2 Fill device ..................................................................................... 21
8Operation ......................................................................................... 23
8.1 Switch on the unit......................................................................... 23
8.2 Switch off the unit......................................................................... 23
8.3 Configuring setpoint temperature ................................................. 23
8.4 Start temperature control application............................................ 24
8.5 Activate autostart function ............................................................ 24
8.6 Setting the timer ........................................................................... 25
8.7 Adjusting the temperature sensor (ATC)...................................... 26

4
9Maintenance..................................................................................... 27
9.1 Check safety symbols .................................................................. 27
9.2 Test the low liquid level safety function ........................................ 27
9.3 Replace detachable power cord................................................... 27
9.4 Emptying ...................................................................................... 28
9.5 Clean device................................................................................. 28
9.6 Device storage ............................................................................. 29
9.7 Technical Service......................................................................... 29
9.8 Warranty....................................................................................... 30
10 Disposal ........................................................................................... 33
10.1 Device disposal ............................................................................ 33
11 Appendix.......................................................................................... 34
11.1 Alarms and Warnings................................................................... 34

Foreword
5
1 Foreword
Congratulations!
You have made an excellent choice.
JULABO would like to thank you for the trust you have placed in our company
and products.
This operating manual will help you become acquainted with the use of our
units. Read the operating manual carefully. Keep the operating manual handy at
all times.

About this manual
6
2 About this manual
This manual is intended for the equipment specified on the cover page.
NOTE
Observe the safety instructions!
Read the Safety section of this manual before using the equipment for the
first time.
2.1 Original JULABO spare parts
Hassle-free continuous operation and safety also depend on the quality of the
spare parts used.
Only original JULABO spare parts guarantee the highest possible quality and
safety. Original JULABO spare parts are available directly from JULABO or your
specialist dealer.
Please note that JULABO cannot provide a warranty service if non-original
JULABO spare parts are used.
2.2 Accessories
JULABO offers a wide range of accessories for the devices. Accessories are not
described in this manual.
The complete range of accessories for the devices described in this manual can
be found on our website www.julabo.com. Use the Search function on the
website.
2.3 Warnings
The manual contains warnings to increase safety when using the device.
Warnings must always be observed.
A warning sign displayed in signal color precedes the signal word. The signal
word, highlighted in color, specifies the severity of the hazard.

About this manual
7
CAUTION
This signal word designates a danger with a low level of risk which, if it not
prevented, may result in minor to moderate injuries.
WARNING
This signal word designates a danger with a medium level of risk which, if it
not prevented, may result in death or serious injuries.
DANGER
This signal word designates a danger with a high level of risk which, if it not
prevented, will result in death or serious injuries.
NOTE
This signal word designates a possibly harmful situation. If it is not avoided,
the system or objects in its vicinity may be damaged.
2.4 Symbols used
Various symbols are used throughout this manual to aid reading
comprehension. This list describes the symbols used.
Tools needed for the following approach
Prerequisite to be met for the following procedure
1. Numbered action steps
Interim result for individual action steps
Additional note for individual action steps
Final result of a procedure
<> Terms in angle brackets denote control menu
[] Terms in square brackets denote keys, softkeys and buttons

Intended use
8
3 Intended use
This section defines the purpose of the unit so that the operator can operate the
unit safely and avoid misuse.
JULABO heating immersion circulators and open heating bath circulators are
designed to control water temperature. Samples in suitable tanks can be
temperature-controlled.
These devices are not suitable for direct temperature control applications for
food, other consumables, or pharmaceutical or other medical products.
Do not use bath fluids other than water, as this is not in accordance with the
device's intended use.
These devices are not suitable for use in explosive environments.
These devices are not intended for use in living areas. They may cause
interference with radio reception.

Safety
9
4 Safety
4.1 General Safety Instructions for the operating company
This section outlines the General Safety Instructions that must be observed by
the operator to ensure safe operation.
• The operator is responsible for the qualifications of its operating personnel.
• The operator must ensure that the operating personnel has been instructed
in use of the device.
• The device operators must receive regular training about the dangers
involved in their work and measures to prevent such dangers.
• The operator must ensure that persons entrusted with the operation,
installation and maintenance have read and understood the operating
manual.
• The device may only be configured, installed, maintained and repaired by
trained personnel with appropriate qualifications.
• If hazardous substances or substances that may become hazardous are
used, the device may only be used by personnel who are qualified to handle
these substances and the device.
• The operator must ensure that the device is checked for safety and
functionality at regular and usage-related intervals.
• The operator must ensure that the mains supply has a low impedance to
prevent influencing other devices powered by the same supply.
4.2 General Safety Instructions for the operator
This section outlines the General Safety Instructions that must be observed by
the user to ensure safe operation.
• Read the operating manual before initial operation
• The device may only be connected to mains power outlets with a protective
earth (PE)
• The mains plug is a safe insulator of the power supply grid and must be
freely accessible at all times
• Do not start the device if it has a damaged power cable
• Do not operated damaged devices
• Only mount the circulator in suitable bath tanks or refrigeration units
• When connecting to external devices, observe the respective assembly
instructions, connection assignment of the plugs and technical data for the
products
• Observe the safety symbols on the device.
• Do not remove safety symbols
• Have all service and repair work carried out by authorized specialists only

Safety
10
• Protect device from dirt
• Protect device direct UV radiation
4.3 General Safety instructions for device operation
This section lists the General Safety Instructions for device operation. These
Safety Instructions must be followed to ensure safe operation.
• Vapors may escape during the temperature control application. Operate the
device in a well-ventilated location.
• If flammable substances are used in the bath, the device must be under
constant observation during operation
• The safety functions of the device should be checked at least twice per year

Safety
11
4.4 Safety symbols
There are safety symbols included with the device, which should be attached to
the device before initial operation.
Safety
symbols
Description
Warning of a danger zone. Note operating manual
Warning about hot surface
Warning of cold surface
Read operating manual before switching on
4.5 Safety function
Technical protective devices provide for safe operation. If a safety function is
triggered, the operator is alerted with a message on the display and an acoustic
signal.
Overheating protection
The overheating protection prevents overheating of the heater.
• The protective mechanism is triggered when the device recognizes a
temperature difference of more than 20 K between the working
temperature sensor and the safety temperature sensor. Am error message
appears on the display. A restart is required.

Safety
12
Low liquid level protection
A level switch recognizes when the bath fluid fill level in the bath tank is too
low. The unit has a warning system to prevent overheating of the heater or dry
running of the pump.
• The low liquid level alarm is triggered when the float reaches its lower limit
stop. The device switches off the pump and heater. A continuous signal
tone sounds. An error message appears on the display. A restart is required.
Productdescription

Product description
13
5 Product description
Productoverview
5.1 Product overview
The circulators can be combined with various baths with volumes of up to 30 l.
Depending on the device combination and accessories used, the circulators work
in a temperature range from +20°C to +100°C.
Heating immersion circulator Open heating bath circulator
CORIO C circulator for bath tanks up
to 30 l.
Circulator with transparent bath
tank. Example: CORIO C-BT9.

Product description
14
5.2 Operating and functional elements
The following figure shows the operating and functional elements and their
position on the unit.
Fig. 1: Control and function elements
1 Mains switch
2 Heating control LED
3 LED display
4 Alarm control LED
5 Keypad with display
6 Service key (covered)
7 Mains fuse
8
Mains fuse
9 Mains connection

Product description
15
5.2.1 Key description
The device is operated using the key panel. This is used to control all menu
functions and make entries.
Key Function
Press [OK] to start a temperature control application or to
stop a running temperature control application.
Press [OK] to enable a selected function, open a menu
option, or confirm a set value.
Use the arrow keys to select a function or set a value. Short
press for single steps, press and hold for fast counting.
5.3 Alarm messages
Alarms and warnings are indicated on the display using error codes. Important
error code descriptions can be found in the appendix. If you are unable to rectify
a fault, contact Technical Service.
Alarm:
In the event of an alarm, the control LED lights up. The temperature control is
stopped. At the same time, a continuous acoustic signal sounds and an error
code is shown on the display. The acoustic signal can be deactivated by pressing
the [OK] key. The fault causing the alarm must be remedied. A restart is
required.
Warning:
In the event of a warning, the temperature control application is not interrupted.
A signal tone is emitted at intervals. The display alternates between the actual
temperature and the error code. The acoustic signal can be deactivated by
pressing the [OK] key. If the underlying cause of the warning is remedied, the
signal tone ceases. Depending on the cause, warnings may cease automatically
after a period of time, e.g. when the device cools down.

Product description
16
5.4 Technical data
Performance specifications measured in accordance with DIN12876.
Performance specifications apply at an ambient temperature of 20°C.
Grouping of the device acc. to CISPR 11:
• The device is an ISM device of group 1, which uses high frequency for
internal purposes
• Class A: Use in an industrial electromagnetic environment
• The device is designed for connection to a separate power transformer or
generator. Connection to a low voltage line is not permitted
In accordance with IEC 61010-1, the device is designed for safe operation under
the following ambient conditions:
• Indoor use
• Altitude up to 2000 m above sea level
• Ambient temperature +5 … +40°C
• Maximum relative humidity 80% for temperatures up to 31°C, decreasing
linearly down to 50% relative humidity at 40°C
• Mains voltage fluctuations up to ±10% of the nominal voltage permissible
if not otherwise specified
• Contamination level 2
Protection class according to EN 60 529:
• Protection class IP21

Product description
17
Technical data CORIO C
Working temperature range °C +20 … +100
Temperature stability °C ± 0.03
Temperature resolution °C 0.01
Temperature control PID1
Temperature setting
Digital
ATC sensor adjustment 1-point adjustment
Pump
Volume flow rate at 0 bar l/min 6
Supply pressure at 0 l bar 0.1
Maximum viscosity cSt 1
Dimensions
Dimensions (W x D x H) cm 13.2 x 16.0 x 36.2
Immersion depth cm 16.6
Weight kg 1.9
Display
Display LED
Performance data
Mains connection 100 V
50/60 Hz
115 V
60 Hz
230 V
50/60 Hz
Current consumption A 8 10 9
Heating capacity kW 0.8 1.0 2.0
Mains fuse, reset
A
15

Product description
18
5.4.1 Material of parts that come into contact with the medium
The table lists parts that could come into contact with the bath fluid as well as
the material that the parts are made of. This data can be used to check the
compatibility of the parts with the bath fluid used.
Parts that come into contact with the medium Material
Motor
1.4301
Pump PPS
Heating element 1.4404/316L
Inbuilt temperature sensor Pt100 1.4571
Connection of temperature sensor 1.4301
Float 1.4401
Float pipe 1.4571
Hose olive
1.4301
Single-ear clamp 1.4301
Hose FPM/FKM
5.4.2 Bath fluids
Only water with an electrical conductivity of 0.1 to 50 µS is permitted as bath
fluid.
NOTE
No liability accepted for usage of bath fluids that are not
suitable!
Unsuitable bath fluids that are not approved by JULABO can damage the
water bath.
• Use bath fluids that are recommended by JULABO
• Before filling, check the parts that are in contact with the medium for
compatibility with the bath fluid
• Do not exceed the maximum permissible viscosity during operation
• Consult JULABO before using a bath fluid other than the recommended
one

Product description
19
Water as bath fluid
• Water can be used for working temperatures from +5 °C to +90 °C
• Only use ultra-pure water or distilled water, with the addition of 0.1 mg
Na2CO3per liter

Transport and installation
20
6 Transport and installation
6.1 Transporting the device
This section describes how to transport the device safely.
CAUTION
Burn hazard on the heating element!
The heating element may still be hot even after the device has been switched
off, and may cause burns if touched.
• Allow the device to cool down to room temperature after switching off
• Wear protective gloves
The device is switched off and cooled to room temperature.
1. Disconnect the mains cable from the device.
2. Disconnect the circulator from the bath before transport.
3. Empty the bath.
See the technical data for weight information.
The device can be safely transported to its installation location.
