Jura GIGA Guide

1 / 2
Compact Payment Box
JURA Elektroapparate AG, Kaffeeweltstrasse 10, CH-4626 Niederbuchsiten, www.jura.com
Supplied as standard Compatibility
ZHousing (with built-in MDB interface)
Z2 keys
ZCoin box
ZMains adapter
ZMains cable with mains plug
ZRS232 cable
ZUSB cable
ZPC software
ZInstructions for use
The compact payment box is compatible with all professional
models in the GIGA and IMPRESSA X lines (except IMPRESSA X30/
X7/X70/X95/X90 and Xs95/Xs90 avantgarde). Please note that not
all available accounting systems are compatible with the compact
payment box.
The compact payment box has been tested with the following
accounting systems:
ZNRI G-13 Coin Validator
ZHug-Witschi DIVA2
ZPBV Kaufmann Mifare Vending Reader VR1
ZMicrotronic Mlight5 Reader
ZFage Giody
ZFage Oscar
