DIGITAL VIDEO RECORDER
VR-609
Client Software
INSTRUCTIONS

2
Contents
Contents
1. Overview .....................................................................................4
1.1 In This Manual .......................................................................4
1.2 CD-ROM Content .........................................................................4
1.3 Operating Environment ........................................................4
1.4 Overview ..................................................................................4
2. Installation .................................................................................5
2.1 Installation Procedures .......................................................5
2.2 Running Procedure ................................................................8
3. Client Live Mode (VR-609 Client-SW-(M) ) .............................9
3.1 Functions ................................................................................9
3.2 Descriptions ..........................................................................10
(1) Minimize / Exit ........................................................................10
(2) Title/Boarder Display ...............................................................10
(3) Search ...................................................................................10
(4) Connect .................................................................................11
(5) Display Mode ..........................................................................12
(6) Zoom/Focus Control .................................................................13
(7) PTZ Channel Selection ..............................................................13
(8) Pan Tilt Control ........................................................................13
(9) Channel Selection ....................................................................14

3
4. Client Search Mode (VR-609 Client-SW-(S) ) ......................15
4.1 Functions ...............................................................................15
4.2 Descriptions ..........................................................................16
(1) Minimize / Exit ........................................................................16
(2) Connect / Disconnect ...............................................................16
(3) Time/Date Search ...................................................................17
(4) Event Search ..........................................................................18
(5) Play Button .............................................................................19
(6) Download (Remote Backup) ................................................21
(7) Play (9CH Player) ...................................................................23
1). Open ................................................................................24
2). Play ..................................................................................24
3). Print .................................................................................24
4). Printer Setup .....................................................................25
5). Create AVI ........................................................................25
(8) Channel Selection ...............................................................26
5. 9 Channel DVR .....................................................................27

4
1. Overview
1.1 In This Manual
This manual describes the features, installation, and how to use of 9ch Embeded
DVR (Digital Video Recorder) Client Software (Client SW) to remotely view, search,
and download an image.
* All Product names stated in this manual are trademarks or registered trademarks
of their respective companies. Marks such as ©, ® are omitted in this manual.
1.2 CD-ROM Content
Following files and folder are in CD-ROM.
(1)"VR-609 ClientSW" Folder
Client software. As double click "setup.exe" as start installation.
(2)"VR-609 ClientSW Manual(Japanese).pdf"
Instructions of this software.(Japanese)
(3)"VR-609 ClientSW Manual(English).pdf"
Instructions of this software.(English)
1.3 Operating Environment
System Requirements
1.4 Overview
Installer/ Menu/ buttons are written in English.
Client SW has the following functions.
-LiveMode
-SearchMode
-PlayerMode
- PTZ camera control
- Download(Back-up) Mode
- Support converting to AVI format to play with Windows Media Player
Free space 12MB and moreHDD
Windows 98/ 2000/ Me/ XPCompatible OS
64MB and moreMemory
Pentium III 500MHz and more
PC/AT compatible machine
CPU
TypePC

5
2. Installation
2.1 Installation Procedures
Please insert Client_SW CD to your PC and will be opened installation files.
Double Click Setup Icon and select a language you want to install to start
installation.
Click Yes button and Installation will be proceeded shown as below.

6
Click Next button to continue it.
Select a setup type to install.
Typical : Standard (Please usually choose this item.)
Compact : Minimum
Custom : For advanced users

7
Setup status will be proceeded.
Setup has finished and click Finish button to exit installation.

8
CLIENT SW Icon will be displayed on your desk top
Press the Icon to run DVR Client Live Mode
2.2 Running Procedure
VR-609
Client-SW-(M)

9
3. Client Live Mode (VR-609 Client-SW-(M) )
3.1 Functions
(1) Minimize, Exit Button
(2) Title/Boarder Display Buttons
(3) Search Button
(4) Connect Button
(5) Display Mode Buttons
(6) Zoom/Focus Control Buttons
(7) PTZ Channel Selection Button
(8) Pan Tilt Control Button
(9) Channel Selection Buttons
(9)
(6)
(4)
(1)
(3)
(5)
(7)
(8)
(2)

10
3.2 Descriptions
(1) Minimize/Exit
Minimize program, exit the Client Live mode program.
(2) Title/Boarder Display Buttons
Title: Display channel name, recording status(red circle), date, and time
Boarder: Display boarder among each channel.
(3) Search
Click Search Button to open Search program mode in another windows.
<Title/Boarder On> <Title/Boarder Off>

11
(4) Connect
Click Connect button to connect to the DVR Client Live mode.
Add a list to connect.
- Type Server Name what you be named.
- Type IP Address and Port Number of the DVR. (Default setting : 80)
- Please input the PORT Number into the "Server" column.
- Click Add button and server name will be added in the server list shown as
below.
Image of channel 1 will displayed in full screen mode at the first
connection as the default.

12
(5) Display Mode
Client SW displays 1,4,9ch mode.
1ch Mode 4ch Mode
9ch Mode

13
(6) Zoom/Focus Control
+ : Zoom In - : Zoom Out
+ : Focus In - : Focus Out
(7) PTZ Channel Selection
Select ch#1 for Pan Tilt Zoom control
Select ch#9 for Pan Tilt Zoom control
(8) Pan Tilt Control
Up Button
Down Button
Left Button
Right Button
* It only works one time at each press.

14
(9) Channel Select
Select a channel to be displayed
Ex) Select ch#9 : Ch#9 will be displayed on top left side of 9ch mode
CH8CH7CH6
CH5CH4CH3
CH2CH1CH9

15
4. Client Search Mode ( VR-609 Client-SW-(S) )
* In the case to move to Search mode from Live mode, it automatically moves to the site
the current Live mode has.
* Only one user can access to the Search Mode displaying the following
message “Server is preoccupied. Please try again later” if more than one
users are trying to access to same Search mode of DVR at the same time.
4.1 Functions
(1) Minimize, Exit Button
(2) Connection/Disconnect Button
(3) Time Date Search Button
(4) Event Search Button
(5) Playback Control Button
(6) Download Button
(7) DVR Player
(8) Channel Selection Button
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)

16
4.2 Descriptions
(1) Minimize / Exit
Minimize program, exit the Client Search mode program
(2-1) Connect
Click Connect button to connect to the DVR Client Search mode.
Add a list to connect
- Type Server Name what you be named.
- Type IP Address and Port Number of the DVR. (Default setting : 80)
- Plaese input the PORT Number into the "Server" column.
- Click Add button and server name will be added in the server list shown as
below.

17
(2-2) Disconnect
Disconnect the current connection to the DVR.
Message ‘Please wait a 10 second…” will be displayed.
(3) Time/Date Search
Click the Time/Date Search button to search a specific time and date.
* How to use Time/Date Remote Search
- Set up the time you want to search, and click the OK button.
- You can select the both of play or reverse play as you wish.
( Play Button, Backward Play Button, Pause Button )
- Select the channel number you want to play back.

18
(4) Event Search
Click the Event Search button to search specific event lists of DVR.
* How to use Event Remote Search
- Click OK button after you select the time and event type you want to search.
- Click OK button after you select the time and list you want to search in the Event
List.

19
Play Button
The playback speed will be increased as the button is
clicked. (5 Speed mode : 0,1,2,3,4 x)
Backward Play Button
The reverse playback speed will be increased as the button
is clicked.(5 Speed mode : 0,1,2,3,4 x)
Pause Button
(5) Play
Click Play button after searching a specific date & time.
- You can select the both of play or reverse play as you wish.
( Play Button, Backward Play Button, Pause Button )
- You can select the channel you want to playback.

20
Caution!
While a user is retrieving the image through Web browser like MS Internet Explorer
and when another user connects to the same server and tries to retrieve the image
through Client S/W at the same time, the Web browser user might meet the program
locked-up.
!This is because the image retrieving from server is only allowed one client at a
time. The web browser user will not be warned by any message of it.
