VR-D1016-1TB
VR-D1008-1TB
VR-D1004-500
Digital Video Recorders
•H.264 Video compression
•Main stream supports encoding at up to
WD1 resolution in real time and sub
stream at CIF/QCIF resolution
•Simultaneous HDMI and VGA outputs at
up to 1920 x 1080p resolution
•Supports dual stream
•HDD quota management
•WD1 / 4CIF / 2CIF / CIF / QCIF Encoding
resolutions
•2-way Audio
•Alarm In / Out
•Smart searching for the event triggered
record files
•Digital zoom of video in live view or
playback mode
•Up to 4/8/16-ch synchronous playback
•10M/100M network interface
•IPv6 is supported
•Network detection function
•NTP, SMTP, NFS, UPnP™ and iSCSI
protocols supported
Introducing three economical Super LoLux™ stand-alone Analog digital recorders with all the features you’d expect
from JVC. All models offer H.264 compression for reduced storage and bandwidth, WD1 and 4CIF encoding resolution
for support of 700 TVL cameras as well as essential features such as Dual-stream, 30fps Frame Rate and Synchronous
Playback. Record in a multitude of formats and playback via VGA/HDMI outputs or remotely via the web interface and
smartphone application. The Super LoLux Series versatility and affordability make it possible for any home or business
owner to have a full-featured, worry-free surveillance system.
Key features:
Security at its Highest Level

Digital Video RecordersSuper LoLux Series
JVC’s all new Super LoLux Series DVRs are built to connect with any of our analog surveillance cameras to create full-
featured, powerful surveillance networks. Each can work as a stand-alone recorder or in cooperation with other
surveillance equipment to build a complete surveillance system. With a multitude of recording, monitoring and playback
options, our Super LoLux DVRs are perfectly suited to most industry applications including; finance, public security,
military, education, industrial, law enforcement, and more.
DISTRIBUTED BY pro.jvc.com
Printed in the U.S.A.
"JVC" is the trademark or registered trademark of JVC KENWOOD Corporation.
Copyright © 2013, JVC KENWOOD Corporation. All Rights Reserved.
Specifications are tentative and subject to change without notice.
Series Comparison Chart
Rear Panel Configurations Typical Applications
VR-D1008-1TB Back
VR-D1016-1TB Back
VR-D1004-500 Back
11
6
12 11
1
2 6
1
1
2
2
11
6
987543
5
5
7 8 9
8 9
43
4 73
10
10
10
12
12
Interface Legend
1. Video In
2. Video Out
3. USB interface
4. HDMI interface
5. VGA interface
6. Audio In, RCA
7. Audio Out, RCA
8. LAN Network interface
9. RS-485 Serial interface
10.12VDC Power input
11. Power switch
12. GND
Video input
Video compression
Audio input
Audio compression
Encoding resolution
Frame rate
Video bit rate
Audio output / Audio bit rate
Dual-stream
Stream type
Playback resolution
Sync. playback
SATA / Capacity
Network interface / Network bandwidth
Network connection number
USB interface
Alarm in / Alarm out
Power supply / Consumption
Working humidity
Two-way audio
HDMI output
VGA output
CVBS
4-ch BNC analog camera
Standard H.264
1-ch, RCA (2.0 Vp-p, 1KΩ) (Using AUDIO in)
1-ch, resolution: 1920 x 1080P / 60Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz, 1024 x 768 / 60Hz
WD1 / 4CIF / 2CIF / CIF / QCIF
30fps NTSC / 25fps PAL
32kbps-3072kbps, or user defined (Max. 3072kbps)
1-ch, RCA (Linear, 1KΩ) / 64kbps
Support, (Sub-stream at CIF / QCIF)
Video, Video & Audio
WD1 / 4CIF / 2CIF / CIF /QCIF
4-ch
1 SATA interface / 500GB HDD
1, RJ45 10M/100M adaptive Ethernet interface / 60Mbps
128
Serial interface 1 RS-485 interface, half-duplex
2, USB2.0
4 in / 1 out
12 VDC / ≤10W 12 VDC / ≤15W 12 VDC / ≤20W
10% - 90%
1-ch, resolution: 1920 x 1080P / 60Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz, 1024 x 768 / 60Hz
1-ch, BNC (1.0 Vp-p, 75Ω) / Resolution: PAL: 704 x 576, NTSC: 704 x 480
VR-D1004-500
8-ch BNC analog camera
1-ch RCA
G.711
8-ch
2 SATA interface / 1TB HDD
8 in / 4 out
VR-D1008-1TB
16-ch BNC analog camera
16-ch
2 SATA interface / 1TB HDD
16 in / 4 out
VR-D1016-1TB
