B5K-0763-00 (K)© 2020 JVCKENWOOD Corporation
KW-Z1000W
MONITOR WITH RECEIVER
Quick Start Guide
MONITEUR AVEC RÉCEPTEUR
Guide de démarrage rapide
MONITOR CON RECEPTOR
Guía de inicio rápido
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<https://www.jvc.net/cs/car/>.
• Les informations les plus récentes (dernier mode d'emploi, mises à jour
du système, nouvelles fonctions, etc.) sont disponibles sur
<https://www.jvc.net/cs/car/>.
• Encontrará la información actualizada (el Manual de instrucciones más
reciente, las actualizaciones del sistema, las nuevas funciones, etc.) en
<https://www.jvc.net/cs/car/>.
Hi-Res Audio logo and Hi-Res Audio
Wireless logo are used under license
from Japan Audio Society.
!B5K-0763-00_20KWV_K_FP_QSG.indb 1 2020/07/02 14:28

2
Important Notice on Software
Ñ Software License on This
Product
The software embedded in this product
comprises a number of independent software
components, each of which is copyrighted by
JVCKENWOOD Corporation or by a third party.
This product uses software components that
are based on an End-User License Agreement
(hereinafter called“EULA”) stipulated by
JVCKENWOOD Corporation and by third parties.
The EULA dictates the availability of the source
codes of free-software components as a
prerequisite to distributing them in executable
form under the terms of the GNU General
Public License or the Lesser General Public
License (hereinafter called“GPL/LGPL”). To get
information about the software components
that are subject to the terms of the GPL/LGPL,
please visit the following Website:
Website URL https://www3.jvckenwood.com/
english/download/gpl/
Queries concerning the contents of the source
code or the like will not be accepted.
Please note that software components based on
a EULA that is not subject to the terms of the GPL/
LGPL or those that have been developed or created
by JVCKENWOOD Corporation will be excluded
from the scope of source code disclosure.
Because licenses to use software components
distributed under the GPL/LGPL are offered to
the customers for free of charge, no warranty is
granted to the customers, whether explicitly or
implicitly, to the extent of the applicable laws.
Unless otherwise stipulated by the applicable
laws or agreed upon in writing, the copyright
holders or those who are entitled to modify
and redistribute the software components are
not held responsible for any and all damages
resulting from their use or from inability to use
them. For more information about the terms of
use of the software components, required items
of compliance and so on, please refer to the
GPL/LGPL.
Customers wishing themselves to use a software
component that is subject to the GPL/LGPL
embedded in this product are encouraged to
read the terms of the corresponding license
before use. Because each individual license
is prescribed by a third party other than
JVCKENWOOD Corporation, the original (English)
of the license is presented.
EULA
Ñ Software License Agreement
JVCKENWOOD Corporation (hereinafter called
“Licensor”) holds either the copyright to the
embedded software or the right to sublicense it.
This agreement establishes the conditions under
which the customer uses this“Licensed Software.”
The customer shall agree to the terms of this
license agreement before proceeding to use
Licensed Software.
This agreement is deemed to have taken effect
when the customer (hereinafter called“User”)
has used a product implementation of Licensed
Software.
The Licensed Software may contain software
Licensor has been licensed to use by third
parties directly or indirectly. Some third parties
may have terms of use prescribed for their
customers, apart from this Software License
Agreement. This agreement does not apply to
such software. Be sure to consult“Important
Notice on Software”as presented separately.
Article 1 (General)
Licensor grants to User a non-exclusive,
non-assignable right of use Licensed Software
within the country where the User purchases
the Product (hereinafter the "Country") (except
for the exception provided for in Paragraph 1,
Article 3).
Article 2 (Right of Use)
1. The rise of use granted under this agreement
is the right to use Licensed Software in this
product.
2. User may not duplicate, copy, modify, add to,
translate or otherwise alter, or loan licensed
Software and the associated literature in
whole or in part.
3. Use of Licensed Software is limited to a
private extent , and Licensed Software may
not be distributed, licensed or sublicensed
for any purposes whatsoever, including
commercial use.
4. User shall use Licensed Software as per the
instruction manual or instructions given in the
help file and may not use or duplicate data in
violations of the regulations of the Copyright
Law or other governing laws by using
Licensed Software in whole or in part.
!B5K-0763-00_20KWV_K_FP_QSG.indb 2 2020/07/02 14:28

3
Article 3 (Terms of License)
1. In assigning this product, User may not retain
the original copy of the embedded Licensed
Software (including associated literature,
updates and upgrades) and any duplicates
and associated literature with regard to
the license to use Licensed Software. User
may transfer Licensed Software only to the
condition of binding the assignee to abide by
the terms of this Software License Agreement.
2. User may not reverse-engineer, disassemble,
decompile or otherwise analyze the source
code of Licensed Software.
Article 4 (Rights to Licensed Software)
All rights to Licensed Software and the
associated literature, including copyrights, shall
reside with Licensor or
the original right holder who has granted the
Right of Use and right to sublicense to Licensor
(hereinafter referred to as“Original Right
Holder”), and User does not have any rights
other than Right of Use granted hereunder
with regard to Licensed Software and the
associated literature.
Article 5 (Exemption Granted to Licensor)
1. Licensor and Original Right Holder do not
assume any responsibility for damages
caused to User or third parties resulting from
the exercise by User of the license granted
hereunder, unless otherwise provided by any
law to the contrary.
2. Licensor does not warrant Licensed Software
to be merchantable, compatible and fit for
specific purposes.
Article 6 (Responsibility for Third Parties)
If disputes over the infringement of third
parties’intellectual property rights, such as
copyrights and patent rights, arise out of the
use of Licensed Software by User, User shall
resolve these disputes at User’s own expenses
while keep Licensor and Original Right Holder
harmless.
Article 7 (Secrecy Obligation)
User shall keep confidential Licensed Software
provided hereunder, information contained in
the associated literature or the like and those
provisions of this agreement not yet in public
knowledge and may not disclose or leak these to
third parties without prior written consent from
Licensor.
Article 8 (Cancellation of the Agreement)
Licensor reserves the right to cancel this
agreement forthwith and claim compensation
from User for the damages caused by such
cancellation when User:
(1) Breaches any of the provisions of this
agreement, or
(2) Has received a petition for seizure, provisional
seizure, provisional disposition or any other
kind of compulsory execution.
Article 9 (Destruction of Licensed Software)
If this agreement is terminated under the
provision of the foregoing paragraph, User
shall destroy Licensed Software, along with all
associated literature and its duplicates, within
two (2) weeks from the date of termination.
Article 10 (Copyright Protection)
1. Copyrights and all other intellectual property
rights relating to Licensed Software shall
reside with Licensor and Original Right Holder
and in no circumstances with User.
2. User shall abide by the laws relating to
copyrights and intellectual property rights in
using Licensed Software.
Article 11 (Export Control)
1. Licensed Software and the associated
literature or the like may not be exported
to places outside the Country (including
transmission outside the Country over the
Internet or the like).
2. User agrees that Licensed Software is subject
to export controls imposed by the Country
and the United States of America.
3. User agrees to comply with all the
international and domestic laws that apply
to this software (U.S. Export Administration
Regulations and regulations established by
the U.S., the Country and their governmental
agencies regarding usage by end users and
export destinations).
Article 12 (Miscellaneous)
1. Even if this agreement is invalidated in part by
law, all other provisions shall remain in effect.
2.
Licensor and User shall consult each other in
good faith to resolve any matters not provided
for in this agreement or questions arising from
the interpretation of this agreement.
3. Licensor and User agree that this agreement
is governed by the law of Japan and that all
disputes involving claims and obligations that
may arise out of this agreement will be settled
by arbitration at the Tokyo District Court as
the court of first instance.
!B5K-0763-00_20KWV_K_FP_QSG.indb 3 2020/07/02 14:28

4
Before Use
Before Use
About the Quick start guide
• This Quick Start Guide describes basic functions of this
unit. For functions not described in this Guide, refer to
the Instruction Manual on the following website:
https://www.jvc.net/cs/car/
• The Instruction manual is subject to change for
modification of specifications and so forth. Be sure to
download the latest edition of the Instruction manual
for reference.
How to read this manual
• The screens and panels shown in this manual are
examples used to provide a clear explanation of
operations.
For this reason, they may be different from the actual
screens or panels, or some display patterns may be
different from the actual ones.
• Display language: English is used for the purpose of
explanation. You can select a display language from
the [SETUP]menu. See System Setup (P.68) in the
Instruction Manual.
Precautions
#WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metallic
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your JVC dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your JVC dealer to make sure that
they work with your model and in your area.
Before Use .............................................4
About the Quick start guide ................................. 4
How to read this manual........................................ 4
Precautions ................................................................. 4
Basic Operations................................... 6
Functions of the Buttons on the Front Panel .... 6
Turning on the Unit.................................................. 6
Initial Settings ............................................................ 7
Adjusting the volume ............................................. 9
Touch screen operations........................................ 9
Popup menu.............................................................10
HOME screen descriptions ..................................11
Source selection screen description................12
Source control screen descriptions..................14
List screen..................................................................14
USB/iPod..............................................15
Connecting a USB device.....................................15
Connect iPod/iPhone............................................15
USB/iPod Basic Operation ...................................16
HD Radio™ Tuner.................................16
HD Radio Tuner Basic Operation ......................16
Memory Operation ................................................17
Bluetooth Control...............................18
Register the Bluetooth device............................18
Using the Hands-Free Unit..................................19
Controlling Audio ...............................21
Connection/Installation.....................22
Before Installation ..................................................22
Installing the unit....................................................25
Appendix.............................................33
Note for specifications..........................................33
Contents
Important Notice on Software............................. 2
EULA.............................................................................. 2
Contents ................................................4
!B5K-0763-00_20KWV_K_FP_QSG.indb 4 2020/07/02 14:28

Before Use
5English
• You can select a language to display menus,
audio file tags, etc. See System Setup (P.68)
in the Instruction Manual.
• The Radio Data System or Radio Broadcast
Data System feature won’t work in areas
where the service is not supported by any
broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with a sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe it with
a cloth moistened with neutral cleaner, then
wipe it again with a clean soft dry cloth.
NOTE
• Applying spray cleaner directly to the unit
may damage its mechanical parts. Wiping the
faceplate with a hard cloth or using a volatile
liquid such as thinner or alcohol may scratch the
surface or erase the screened print.
Ñ Acquiring GPS signal
The first time you turn on this unit, you must
wait while the system acquires satellite signals
for the first time. This process could take up
to several minutes. Make sure your vehicle
is outdoors in an open area away from tall
buildings and trees for fastest acquisition.
After the system acquires satellites for the first
time, it will acquire satellites quickly each time
thereafter.
Ñ About GLONASS
This unit uses Global Navigation Satellite System
(GLONASS) in addition to GPS.
Combining GPS and GLONASS can refine
positioning accuracy than using GPS only.
Ñ Caution for Smartphone Users
Simultaneously running multiple applications
on your smartphone while screen sharing places
heavy demand on the microprocessor of the
phone, potentially affecting communication and
performance.
For best results while pairing with your JVC
receiver, please be sure to close any unused
applications.
!B5K-0763-00_20KWV_K_FP_QSG.indb 5 2020/07/02 14:28

Basic Operations
6
Basic Operations
Functions of the Buttons on the Front Panel
2
1
3 4 5
NOTE
• The panels shown in this manual are examples
used to provide a clear explanation of operations.
For this reason, they may be different from the
actual panels.
Number Name Motion
1
Remote
Sensor
• Receives the remote control signal.
2
–, +
(Volume)
• Adjusts the volume.
The volume will go up to 15 when you keep pressing [+]. (P.9)
3
FNC/[ ] • Displays the popup menu screen.
• Pressing and holding, displays the screen you have set in the Favorite Customize
screen. (P.13)
4
[ ]/[ ]
• Displays the HOME screen (P.11).
• When the power is off, turns the power on.
• Pressing and holding, turns the power off.
5
[ ]
• Switches the voice recognition function on/off.
• When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is
connected, pressing and holding displays Bluetooth pairing waiting dialog.
Turning on the Unit
1
Press the [ ]/[ ] button.
 The unit is turned on.
NOTE
• If it is your first time to turn the unit on after
installation, it will be necessary to perform Initial
SETUP (P.7).
●To turn off the unit:
1
Press and hold the [ ]/[ ] button.
 The unit is turned off.
!B5K-0763-00_20KWV_K_FP_QSG.indb 6 2020/07/02 14:28

Basic Operations
7English
Initial Settings
Initial SETUP
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■[Language]
Select the language used for the control
screen and setting items. Default is“American
English(en)”.
1Touch [Language].
2Touch [Language Select].
3Select the desired language.
4Touch [
].
For details, see System Setup (P.68) in the
Instruction Manual.
■[Clock]
Sets the synchronization of the clock and
adjusts it.
For details, see Calendar/clock settings
(P.8).
■[Display & Button]
Set the button illumination color.
1Touch [Display & Button].
2Touch [Button Illumination Color].
3Select the desired color.
4Touch [
].
For details, see Display & Button Setup
(P.65) in the Instruction Manual.
■[Camera]
Set the parameters for the camera.
1Touch [Camera].
2Set each item and touch [
].
For details, see Camera Setup (P.47) in
the Instruction Manual.
■[OEM SETUP]
This function requires a commercial adaptor.
Consult your JVC dealer for details.
■[DEMO]
Set the demonstration mode. Default is “ON”.
2
Touch [Finish].
NOTE
• These settings can be made from the SETUP
menu. See Setup (P.63) in the Instruction
Manual.
Security Code Setup
You can set up a security code to protect your
receiver system against theft.
When the Security Code function is activated,
the code cannot be changed and the function
cannot be deactivated. Note that the Security
Code can be set with a 4 to 8 digit number of
your choice.
Preparation
• Set [DEMO]to [OFF]in the System setting
menu. See System Setup (P.68) in the
Instruction Manual.
1
Press the [ ]/[ ] button.
2
Touch [ ].
3
Touch [SETUP].
 SETUP Menu screen appears.
!B5K-0763-00_20KWV_K_FP_QSG.indb 7 2020/07/02 14:28

Basic Operations
8
4
Touch [System].
 System setting menu appears.
5
Touch [Security Code Set]in the system
setting menu.
 Security Code Set screen appears.
6
Enter a security code with 4 to 8 digits
and touch [Enter].
7
Enter the same code again and touch [Enter].
Now, your security code is registered.
NOTE
• Touch [BS]to delete the last entry.
• If you enter a different security code, the
procedure returns to step 6 (for first code entry).
• If you have disconnected the Receiver from the battery,
enter the correct security code as that you have entered
in step 6 and touch [Enter]. You can use your receiver.
To change the security code:
1
Touch [Security Code Change]on the
Security screen.
 Security Code Set screen appears.
2
Enter the current registered security code
and touch [Enter].
3
Enter a new security code with 4 to 8
digit number and touch [Enter].
4
Enter the same code again and touch [Enter].
The new security code is registered.
To clear the security code:
1
Touch [Security Code Cancellation]on
the Security screen.
 Security Code Set screen appears.
2
Enter the current registered security code
and touch [Enter].
The security code is cleared.
Calendar/clock settings
1
Press the [ ]/[ ] button.
2
Touch [ ].
3
Touch [SETUP].
 SETUP Menu screen appears.
4
Touch [System].
 System setting menu appears.
5
Set each item as follows.
Scroll the page to show hidden items.
■[Time Format]
Select the time display format.
[12-Hour](Default)/[24-Hour]
■[Clock]
[GPS-SYNC](Default): Synchronizes the clock
time with the GPS.
[Manual]: Set the clock manually.
■[Time Zone]
Select the time zone.
■[Clock Adjust]
If you select [Manual]for Clock, adjust the
date and time manually. (P.9)
NOTE
• Please set the date and time. If they are not set,
some functions may not work.
!B5K-0763-00_20KWV_K_FP_QSG.indb 8 2020/07/02 14:28

Basic Operations
9English
●Adjust the date and time manually
1
Touch [Clock Adjust]in the System
setting menu.
2
Adjust the date, then adjust the time.
3
Touch [Set].
Adjusting the volume
You can adjust the volume (0 to 40).
Press [+]to increase, and press [–]to decrease.
Holding [+]increases the volume continuously
to level 15.
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to
select an item, display a setting menu screen
or change pages.
●Touch
Touch the screen gently to
select an item on the screen.
●Touch and hold
Touch the screen and keep
your finger in place until
the display changes or a
message is displayed.
●Flick
Slide your finger quickly
to the left or right on the
screen to change the page.
You can scroll a list screen
by flicking up/down on the
screen.
●Swipe
Slide your finger up or down
on the screen to scroll the
screen.
Gesture Touch Control:
You can also control playback by moving your
finger on the touch panel as follows (for some
sources, the gesture touch control function is
not available).
• Sliding the finger upward/downward:
Equivalent to the operation of pressing []/
[](Media). Tuner Preset broadcast stations
are switched.
• Sliding the finger leftward/rightward:
Equivalent to the operation of pressing [E]
/ [F].
• Moving your finger clockwise or counter-
clockwise: Increases/decreases the volume.
On the HOME screen, you can control the
widget by sliding two fingers. (P.11)
!B5K-0763-00_20KWV_K_FP_QSG.indb 9 2020/07/02 14:28

Basic Operations
10
Popup menu
1
Press the [FNC]/[ ] button.
 Popup menu appears.
2
Touch to display the popup menu.
2
1
The contents of the menu are as follows.
• Displays the control screen of current
source. Icon feature differs depending on
the source. This icon is for USB source.
• Switches between screens.
The screen to be switched to depends
on the [DISP Key]setting in the Key
Assignment setting menu. See Key
Assignment Setup (P.69) in the
Instruction Manual.
• Touch and hold to turns the screen off.
• Displays the Screen Adjustment screen.
• Close the popup menu.
• Displays the Device List screen.
• Displays the SETUP Menu screen.
1
• Function key1 to 3: The current screen
changes to the one you have set. The
function key1 and 2 are set to [Camera]
and [Speaker]function as default. For
the function setting, refer to Customize
popup menu functions (P.10).
– [
]: Displays the view camera screen.
– [
]: Displays the Audio screen.
(P.21)
• Touch and hold to display the Customize
FNC Menu screen.
2
• Short-cut source icons: The source
changes to the one you have set with a
short-cut. For the short-cut setting, refer
to Customize Short-cut source icons
(P.13).
Customize popup menu functions
1
Press the [ ]/[ ] button.
2
Touch [ ].
3
Touch [SETUP].
4
Touch [Key Assignment].
5
Touch [Customize FNC Menu].
6
Select the function key you want to
customize.
 The function list screen appears.
7
Select a function.
8
Touch [Close].
!B5K-0763-00_20KWV_K_FP_QSG.indb 10 2020/07/02 14:28

Basic Operations
11English
HOME screen descriptions
Most functions can be performed from the
HOME screen.
2 7
3 4
68
5
9
1
1
• Short-cut playback source icons (P.13)
2
• Displays the source selection screen. (P.12)
3
• Widget
– You can change the display to big or split
widgets mode by sliding 2 fingers upward/
downward.
4
• Displays the screen you have set in the
Favorite Customize screen. (P.13)
5
• Displays the Audio screen. (P.21)
6
• Switches between the big and the split
widgets mode. (P.11)
7
• Displays the SETUP screen.
8
• Swipe your finger from left hand side to right
hand side on the screen to display the widget
selection menu. (P.11)
9
• Swipe your finger from right hand side to
left hand side on the screen to display the
setting menu for some functions. For details,
see Display the setting menu for some
functions (P.11) in the Instruction Manual.
Display the HOME screen
1
Press the [ ]/[ ] button.
 HOME screen appears.
Widget
Big widget
Split widgets
●To change the widget style
Touch the widget area. You can change the
displayed information or design.
●To change the widget
Slide two fingers leftward/rightward.
When the split widgets mode is selected, you
should put the fingers on each of the windows
before slide.
●To select the widget
Swipe your finger from the left edge on the
display to right hand side to display the widget
selection menu.
Touch [
]to return to the HOME screen.
!B5K-0763-00_20KWV_K_FP_QSG.indb 11 2020/07/02 14:28

Basic Operations
12
●To change the widget format
Slide two fingers upward/downward to switch
between the big widget mode and the split
widgets mode.
Source selection screen
description
You can display icons of all playback sources
and options on the source selection screen.
To change pages, flick your finger leftward/
rightward on the screen.
4
31
2
1
• Changes playback sources.
For playback sources, see Select the
playback source (P.12).
2
• Page indication
3
• Returns to the previous screen.
4
• Displays the SETUP screen.
Select the playback source
1
Press the [ ]/[ ] button.
 HOME screen appears.
2
Touch [ ].
From the screen, you can select the
following sources and functions.
• Switches to the Apple CarPlay screen
from the connected iPhone.
• Switches to the Android Auto
screen from the connected Android
smartphone.
• Displays the Hands-Free screen. (P.19)
When neither Apple CarPlay, Android
Auto, nor a Bluetooth Hands-Free phone
is connected, displays Bluetooth pairing
waiting dialog. *1
• Switches to the HD Radio broadcast.
(P.16)
• Switches to the SiriusXM® satellite radio
broadcast.
• Plays a Bluetooth audio player.
• Plays an iPod/iPhone. (P.16)
• Plays files on a USB device. (P.16)
• Switches to an external component
connected to the AV Audio input and the
Video input terminal. *2 *3
• Displays the Wireless Mirroring screen.
• Turns off the AV source. (P.13)
*1When connecting as Apple CarPlay or Android
Auto, it works as a phone provided in Apple
CarPlay or Android Auto. If Apple CarPlay or
Android Auto are connected during talking by
the Bluetooth device or iDatalink phone, the
current call will be continued.
*2You can use the [AV-IN]source when a
cable from a visual source except a camera is
connected to the Video input terminal, and
a cable is connected to the AV Audio input
terminal. (P.30)
*3Set “VIDEO IN”to “None”in Camera Assignment
Settings. (P.33)
!B5K-0763-00_20KWV_K_FP_QSG.indb 12 2020/07/02 14:28

Basic Operations
13English
To turn off the AV source
1
Press the [ ]/[ ] button.
 HOME screen appears.
2
Touch [ ].
3
Touch [AV Off].
Customize Short-cut source icons
You can arrange the positions of the source
icons as you like.
1
Press the [ ]/[ ] button.
 HOME screen appears.
2
Touch [ ].
3
Touch and hold the icon which you want
to move in the customizing mode.
4
Drag the icon to the desired position.
Customize Favorite key
1
Press the [ ]/[ ] button.
2
Touch [ ].
3
Touch [SETUP].
4
Touch [Key Assignment].
5
Touch [Favorite Customize].
6
Select a favorite function.
7
Touch [Close].
!B5K-0763-00_20KWV_K_FP_QSG.indb 13 2020/07/02 14:28

Basic Operations
14
Source control screen
descriptions
There are some functions which can be
performed from most screens.
1 2 3
5 4
1
Displays the source selection screen. (P.12)
2
Displays the SETUP Menu screen.
3
Short-cut source icons
The source changes to the one you have set
with a short-cut. For the short-cut setting, refer
to Customize Short-cut source icons (P.13).
4
Connected Bluetooth device information.
5
Indicator items
Displays the current source condition and so on.
List screen
There are some common function keys in the
list screens of most sources.
Display the list screen
1
Touch [1].
 The list screen appears.
51
2 43
1
Displays the list type selection window.
2
etc.
Keys with various functions are displayed here.
• : Plays all tracks in the folder containing
the current track.
• : Jumps to the letter you entered
(alphabetical search).
• : Moves to the upper hierarchy
level.
3
Text scroll
Scrolls the displayed text.
4
[ ] / [ ] / [ ] / [ ] Page scroll
You can change pages to display more items by
touching [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
5
Return
Returns to the previous screen.
!B5K-0763-00_20KWV_K_FP_QSG.indb 14 2020/07/02 14:28

USB/iPod
15English
USB/iPod
Connecting a USB device
1 Connect the USB device with the USB
cable. (P.31)
Ñ Disconnect the USB device
1 Press the [ ]/[ ] button.
2 Touch a source other than [USB].
3 Detach the USB device.
Ñ Usable USB device
You can use a mass-storage-class USB device
with this unit.
The word“USB device”appearing in this manual
indicates a flash memory device.
Connect iPod/iPhone
Preparation
• With an iPhone compatible with Apple CarPlay,
turn off Apple CarPlay by operating the iPhone
at functional setup before connecting iPhone.
For details of the setup method, contact the
manufacturer of the terminal.
• Only one iPod/iPhone can be connected.
Wired connection
Preparation
• Connect an iPod/iPhone with the KS-U62
(optional accessory) while Apple CarPlay is not
connected.
1 Connect the iPod/iPhone using the KS-
U62. (P.31)
●To disconnect the iPod/iPhone connected
with the cable:
1 Detach the iPod/iPhone.
Bluetooth connection
Pair the iPhone through Bluetooth.
Preparation
• To connect an iPhone via Bluetooth, register it
as a Bluetooth device and do the profile setting
for the connection beforehand. See Switch the
connected device (P.53) in the Instruction
Manual and Register the Bluetooth device
(P.18).
• Connect an iPhone via Bluetooth while Apple
CarPlay and an iPod/iPhone are not connected
via USB.
Ñ Connectable iPod/iPhone
The following models can be connected to
this unit.
Made for
• iPhone XS
Max
• iPhone XS
• iPhone XR
• iPhone X
• iPhone 8 Plus
• iPhone 8
• iPhone 7 Plus
• iPhone 7
• iPhone SE
• iPhone 6s
Plus
• iPhone 6s
• iPod
touch (6th
generation)
!B5K-0763-00_20KWV_K_FP_QSG.indb 15 2020/07/02 14:28

16
USB/iPod
USB/iPod Basic Operation
Most functions can be controlled from the
source control screen and playback screen.
1 Press the [ ]/[ ] button.
 HOME screen appears.
2 Touch [ ].
3 Touch [USB]or [iPod]. (P.12)
Control screen
3 2
1
1
[CODEC]
• When a high-resolution source is played, its
format information is displayed.
2
Operation keys
• [1]: Searches track/file. For details on search
operation.
• [E][F]: Searches the previous/next track/
file.
Touch and hold to fast forward or fast
backward.
• [DH]: Plays or pauses.
• [
]: Touch to attenuate/restore the sound.
• [
]: Repeats the current track/folder. Each
time you touch the key, repeat modes are
switched in the following sequence:
File repeat ( ), Folder repeat ( ), Repeat
all ( )
• [
]: Randomly plays all tracks in the current
folder. Each time you touch the key, random
modes are switched in the following sequence:
File random ( ), Random off ( )
3
Content list
• Touch the left side of the screen to display the
Content list. Touch again to close the list.
• Displays the playing list. When you touch a
track/file name on the list, playback will start.
HD Radio™ Tuner
HD Radio Tuner Basic
Operation
To listen to the HD Radio source, touch [HD
Radio]icon on the source selection screen.
(P.12)
NOTE
• HD Radio broadcasting is for North American
sales area only.
Control screen
3
4
6
5
1
2
1
Operation keys
• [E][F]: Tunes in a station. The method of
switching frequencies can be changed (see
3
Seek mode/Band keys).
• [CHS][CHR]: Selects a channel.
• [1]: Display the Channel List screen.
• [ ] : Display a list of registered bookmarks.
• [
]: Touch to attenuate/restore the sound.
2
Function panel
Touch the right side of the screen to display the
function panel. Touch again to close the panel.
• [10key Direct]: Display the direct station/
channel search screen.
• [SETUP](FM only): Displays the TUNER SETUP
screen.
• [AME]: Presets stations automatically. (P.17)
• [RCV]: Change the HD Radio reception mode.
[Auto]: Switch between digital and analog
audio automatically.
[Digital]: Select this to tune to digital audio
only.
[Analog]: Select this to tune to analog audio
only.
• [PTY](FM only): Searches for a program by
program type.
!B5K-0763-00_20KWV_K_FP_QSG.indb 16 2020/07/02 14:28

HD Radio™ Tuner
17English
• [ ] : Stores the information about the song
being received.
• [Emergency Alerts]: Turn on or off the alert
message.
• [Alert Message Log]: Displays the alert
message received.
3
Seek mode/Band keys
• Touch to switch seek mode in the following
sequence: [AUTO1], [AUTO2], [MANUAL].
– [AUTO1]: Tunes in a station with good reception
automatically.
– [AUTO2]: Tunes in the memorized stations one after
another.
– [MANUAL]: Switches to the next frequency
manually.
• Switches bands (between FM and AM).
4
Information display
Displays the information on the current station:
Frequency and Channel
Touching [
]allows you to switch between
Content A, Content B and Content C.
Content A: Station name, Song Title, Artist Name
Content B: Station Message, Radio Text
Content C: PTY Genre, Album Name
5
Preset list
• Touching [
]/[ ] allows you to change the
display size.
• Recalls the memorized station or channel.
• When touched for 2 seconds, stores the
currently being received station or channel in
the memory.
6
Indicator display
While receiving an HD Radio station, it lights
with orange when the audio is digital and lights
with gray when it is analog. While receiving an
analog station, it is off.
Memory Operation
Ñ Auto memory
You can store stations with good reception in
the memory automatically.
1 Touch desired band key.
2 Touch [ ] on the right side of the screen.
Touch [AME].
3 Touch [Ye s ].
 Auto memory starts.
Ñ Manual memory
You can store the currently being received
station or channel in the memory.
1 Select the station or channel you wish to
store in the memory.
2 Touch [FM#](#:1-15) or [AM#](#:1-5)
in which you want to store the station
or channel for 2 seconds until a beep
sounds.
Ñ Preset select
1 Touch [ ] on the left side of the screen.
Select a station or channel from the list.
!B5K-0763-00_20KWV_K_FP_QSG.indb 17 2020/07/02 14:28

Bluetooth Control
18
Bluetooth Control
Register the Bluetooth device
It is necessary to register the Bluetooth audio
player or smartphone/cell-phone in this unit
before using the Bluetooth function.
1 Press the [ ]/[ ] button.
2 Touch [ ].
3 Touch [SETUP].
 SETUP Menu screen appears.
4 Touch [Connections & AV].
5 Touch [Device List].
6 Select a device type.
■[Bluetooth]
To connect as Bluetooth audio source.
■[Apple CarPlay]
To connect as Apple CarPlay source.
■[Android Auto]
To connect as Android Auto source.
7 Touch [ ].
 Bluetooth pairing waiting dialog
appears.
NOTE
• If an Apple CarPlay device is currently connected,
the Apple CarPlay device will be disconnected.
• When neither Apple CarPlay, Android Auto, nor
a Bluetooth Hands-Free phone is connected,
pressing and holding the [
]button displays
Bluetooth pairing waiting dialog.
8 Search for the unit (“KW-Z1000W”) from
your smartphone/cell-phone.
Complete steps 8 to 10 within 30 seconds.
9 Operate your smartphone/cell-phone
according to the displayed messages.
●Confirm the request both on the
smartphone/cell-phone.
●Input the PIN Code in your
smartphone/cell-phone.
PIN Code is set to“0000”as the default.
10
Touch [Ye s ].
When data transmission and connection
have completed, the Bluetooth connection
icon appears on the screen.
NOTE
• When registering the iPhone that is available for
Apple CarPlay wirelessly, a confirmation message
appears. Touch [Ye s ]to display the Apple CarPlay
screen for wireless connection.
!B5K-0763-00_20KWV_K_FP_QSG.indb 18 2020/07/02 14:28

Bluetooth Control
19English
Using the Hands-Free Unit
You can use the telephone function by
connecting the Bluetooth telephone to this
unit.
NOTE
• While Apple CarPlay or Android Auto is
connected, the Bluetooth Hands-Free function
and two Bluetooth devices connections cannot
be used. Only the Apple CarPlay or Android Auto
Hands-Free function can be used.
Ñ Make a call
1 Press the [ ]/[ ] button.
 HOME screen appears.
2 Touch [ ].
3 Touch [Phone]. (P.12)
 Hands-Free screen appears.
NOTE
• If your smartphone/cell-phone supports PBAP,
you can display the phonebook and call lists onto
the touch panel screen when the smartphone/
cell-phone is connected.
– Phonebook: up to 1000 entries
– Up to 50 entries including dialed calls, received
calls, and missed calls
4 Select a dialing method.
• [ ]: Call using call records
• [
]: Call using the phonebook
• [
]: Call using the preset number
• [
]: Call by entering a phone number
●Select the smartphone/cell-phone to use
When you connect two smartphones/cell-
phones
1) Touch [
]to select the phone
you want to use.
Call using call records
1 Touch [ ].
2 Select the phone number from the list.
Call using the phonebook
1 Touch [ ].
2 Touch [ ].
3 Select the initial.
• Characters with no corresponding name
will not appear.
• A first character with an accent character
such as“ü”can be searched for with a
non-accent character“u”. A character
with an accent character in a sentence
cannot be searched for.
4 Select the person you want to call from
the list.
5 Select the phone number from the list.
!B5K-0763-00_20KWV_K_FP_QSG.indb 19 2020/07/02 14:28

Bluetooth Control
20
NOTE
• You can sort the phone numbers in the list by last
name or first name. For details, see Hands-Free
Setup (P.62) in the Instruction Manual.
• When Russian or Hebrew is selected in "Language
select" (P.68) in the Instruction Manual, you
can switch between English keyboard and the
selected language keyboard.
• You can search with 3 initial letters on the English
keyboard and 1 initial letter on the Russian /
Hebrew keyboard.
Call using the preset number
1 Touch [ ].
2 Touch the name or phone number.
Call by entering a phone number
1 Touch [ ].
2 Enter a phone number with number keys.
3 Touch [ ].
Ñ Receive a call
1 Touch [ ] to answer a phone call or
[
]to reject an incoming call.
NOTE
• When shifting the gear to the reverse (R) position
and monitoring the picture from the rear view
camera, this screen does not appear even if a call
comes in.
• The portrait registered in the phonebook is
displayed while making/receiving calls and
during a call.
• If you edit the phonebook on the connected
device side after downloading the phonebook,
the portrait may not be displayed depending on
the edited content. It is recommended that you
download the phonebook whenever you edit it.
• The image quality of a displayed portrait may
depend on a connected device.
To end call
1 While talking, touch [ ].
Ñ Operations during a call
●Adjust the volume of your voice
1) Touch [Speech Quality].
2) Touch [T]or [U]for [Microphone Level].
●Adjust the receiver volume
Press the [–]or [+]button.
●Mute your voice
Touch [
]to mute or not to mute your voice.
●Output the dial tone
Touch [DTMF]to display the tone input screen.
You can send tones by touching desired keys
on the screen.
●Switching between speaking voice
output destinations
Touching [
]/[ ] each time switches
speaking voice output destinations between
the smartphone/cell-phone and the speaker.
!B5K-0763-00_20KWV_K_FP_QSG.indb 20 2020/07/02 14:28
