JVC XR-D400SLE User manual

XR-D400 [E] EN
LET0169-001A
XR-D400SL
Multiple Compact Disc Recorder
Mehrfach-CD-Recorder
Enregistreur CD polyvalent
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
LET0169-001A
[E]
For Customer Use:
EnterbelowtheModelNo.andSerialNo.
which are located on the rear, bottom or
side of the cabinet. Retain this informa-
tion for future reference.
Model No.
Serial No.
Introduction
Einleitung
Introduction
Getting started
Betriebsvorbereitungen
Préparatifs avant le lancement
Playback operations
Wiedergabebetrieb
Opérations de lecture
Recording operations
Aufnahmebetrieb
Opérations d’enregistrement
Using as a CD-R/RW drive
Verwendung als CD-R-/RW-
Laufwerk
Utilisation comme lecteur
CD-R/RW
Additional information
Zusätzliche Informationen
Informations
complémentaires
1
4
10
17
24
27
English
Deutsch
Français
POWER
1TRACK ALLREPEAT
SPEED
ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC

XR-D400 [E] EN
LET0169-001A
1. CLASS 1 LASER PRODUCT
2. DANGER:Visiblelaserradiationwhenopenandinterlockfailedordefeated.Avoiddirectexposure
to beam.
3. CAUTION: Do not open the top cover. There are no user serviceable parts inside the Unit; leave
all servicing to qualified service personnel.
1. LASER-PRODUKT DER KLASSE 1
2. GEFAHR: Sichtbare Laserstrahlung bei Öffnung und fehlerhafter oder beschädigter Spre.
Direkten Kontakt mit dem Strahl vermeiden!
3. ACHTUNG: Das Gehäuse nicht öffnen. Das Gerät enthält keinerlei Teile, die vom Benutzer
gewartet werden können. Überlassen Sie Wartungsarbeiten bitte qualifizierten Kundendienst-
Fachleuten.
1. PRODUIT LASER CLASSE 1
2. ATTENTION: Radiation laser visible quand l'appareil est ouvert ou que le verrouillage est en
panne ou désactivé. Eviter une exposition directe au rayon.
3. ATTENTION: Ne pas ouvrir le couvercle du dessus. Il n'y a aucune pièce utilisable à l'intérieur.
Laisser à un personnel qualifié le soin de réparer votre appareil.
1CLASSIFICATION LABEL, PLACED ON EXTERIOR SURFACE
(Except for U.S.A. and Canada)
1KLASSIFIZIERUNGSHINWEIS BEFINDET SICHAUF DER AUSSENSIETE
(Außer U.S.A. und Kanada)
1ÉTIQUETTE DE CLASSIFICATION, PLACÉE SUR LASURFACE EXTÉRIEURE
(Sauf Etats-Unis et le Canada)
2WARNING LABEL, PLACED INSIDE THE UNIT
2WARNETIKETTE IM GERÄTEINNEREN
2ETIQUETTE D'AVERTISSEMENT PLACÉE À L'INTERIEUR DE L'APPAREIL
IMPORTANT FOR LASER PRODUCTS / WICHTIGER HINWEIS FÜR LASER-PRODUKTE / IMPORTANT
POUR LES PRODUITS LASER
REPRODUCTION OF LABELS / ANBRINGUNGSORTE FÜR LASER-PRODUKTE / REPRODUCTION
DES ETIQUETTES
Warnings, Cautions and Others
Warnungen, vorsichtsmaßnahmen und Hinweise
Mises en garde, précautions et indications diverses
DANGER: Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laser-
stråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgåudsæt-
telse for stråling (d)
VARNING: Osynlig laser-
strålning när denna del
är öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO: Avattaessa ja suo-
jalukitus ohitettaessa olet
alttiina näkymättömälle
lasersäteilylle. Älä katso
säteeseen. (f)

XR-D400 [E] EN
LET0169-001A
Caution –– POWER switch!
Disconnect the mains plug to shut the power off
completely. The POWER switch in any position
does not disconnect the mains line.
Achtung –– POWER-Schalter!
Den Netzstecker aus der Steckdose ziehen, um
die Stromversorgung vollkommen zu
unterbrechen.DerSchalter POWERunterbrichet
in keiner Stellung die Stromversorgung
vollkommen.
Attention –– Commutateur POWER!
Déconnecter la fiche de secteur pour couper
complètement le courant. Le commutateur
POWER ne coupe jamais complètement la ligne
de secteur, quelle que soit sa position.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d'éviter tout risque d'électrocution, d'incendie,
etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas
ouvrir le coffret de l'appareil.
2. Nepas exposerl'appareilà lapluie niàl'humidité.
ACHTUNG
Zur Verhinderung von elektrischen Schlägen,
Brandgefahr,usw:
1. Keine Schrauben lösen oder Abdeckungen
enlfernen und das Gehäuse nicht öffnen.
2. Dieses Gerät weder Regen noch Feuchtigkeit
aussetzen.
Caution: Proper Ventilation
To avoide risk of electric shock and fire and to
protect from damage.
Locate the apparatus as follows:
Front: No obstructions open spacing.
Sides: No obstructions in 3 cm from the
sides.
Top: No obstructions in 5 cm from the
top.
Back: Noobstructionsin15 cm fromthe
back
Bottom: No obstructions, place on the
levelsurface.
Achtung: Angemessene Ventilation
Stellen Sie das Gerät zur Verhütung von
elektrischemSchlagundFeuerundzumSchutz
gegen Beschädigung wie folgt auf:
Vorderseite: Offener Platz ohne Hindernisse.
Seiten: Keine Hindernisse innerhalb 3
cm von den Seiten.
Oberseite: Keine Hindernisse innerhalb 5
cm von der Oberseite.
Rückseite: Keine Hindernisse innerhalb 15
cm von der Rückseite.
Unterseite: Keine Hindernisse. Auf eine
ebene Oberfläche stellen.
Attention: Ventilation Correcte
Pour éviter les chocs électriques, l’incendie et
tout autre dégât. Disposer l’appareil en tenant
compte des impératifs suivants
Avant: Rien ne doit gêner le
dégagement
Flancs: Laisser 3 cm de dégagement
latéral
Dessus: Laisser 5 cm de dégagement
supérieur
Arriére: Laisser 15 cm de dégagement
arriére
Dessous: Rien ne doit obstruer par
dessous;poserl’appareilsurune
surface plate.

XR-D400 [E] EN
LET0169-001A
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
For U.S.A.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
For Canada/pour le Canada
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B
LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL
APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED "DIGITAL APPARATUS",
ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE
BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS
NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME
SUR LE MATERIEL BROUILLEUR: "APPAREILS NUMERIQUES",
NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.
DISCLAIMER
JVC DISCLAIMS WARRANTIES, EXPRESS OR IM-
PLIED, IN RESPECT TO THE PRODUCTS DELIV-
ERED,INCLUDINGBUTNOTLIMITEDTOIMPLIED
WARRANTIES OF MERCHANTABILITY OR FIT-
NESS FOR A PARTICULAR PURPOSE. IN NO
EVENT SHALL JVC BE LIABLE TO PURCHASER
FOR ANY LOST PROFITS OR FOR SPECIAL, INCI-
DENTAL, INDIRECT OR CONSEQUENTIAL DAM-
AGES, OR FOR LOSS OR DAMAGE OF DATA.
Haftungsausschlusserklärung
JVC dementiert ausgedrückte und implizierte
Garantien in Bezug auf das gelieferte Erzeugnis,
einschließlich implizierter Gewährleistung der
Durchschnittsqualität oder der Tauglichkeit für einen
bestimmten Zweck, aber nicht begrenzt hierauf. In
keinem Fall soll JVC dem Käufer für verlorenen Profit
oder besondere, zufällige, indirekte oder mittelbare
Schäden oder für Verlust oder Beschädigung von
Daten haften.
Renonciation de responsabilité
JVC rejette toute responsabilité pour les garanties,
expresses ou tacites, relatives aux produits délivrés,
y compris, mais sans s’y limiter, les garanties tacites
de commerciabilité et d’adéquation à un usage
particulier. En aucun cas JVC ne saurait être
responsable vis-à-vis de l’acheteur pour toute perte
de profit ou pour tout dommage spécial, connexe,
indirectouconsécutif,oupourtouteperteoudommage
de données.

Introduction
1
Introduction
XR-D400 [E] EN
LET0169-001A
English
Introduction
Features............................................ 2
Supplied accessories .................... 2
Notes on handling ......................... 3
Preliminary knowledge about
discs .................................................. 4
Getting started
Names of parts and controls
Front panel ........................................ 6
Rear panel .......................................... 8
Connections .................................... 9
Playback operations
Before operation
To turn on the unit ..........................10
To insert a disc ................................ 11
To remove a disc ............................. 11
Playing a CD
To play a CD .....................................12
To adjust the volume level ............. 12
To stop playback completely or
temporarily ......................................13
To advance or reverse play rapidly
while playing ................................... 13
To locate the beginning of a track ... 13
To locate a track directly ................13
Playing repeatedly [REPEAT]
To play the current track
repeatedly ........................................14
To play an entire disc repeatedly ..... 14
Playing tracks in the desired
order [PROGRAM]
To create a program ....................... 15
Table of contents
Recording operations
Before operations ........................ 17
Recording a disc
[AUTO REC] ................................... 18
Recording desired tracks
[PROGRAM REC] ..........................20
Finalizing a disc
[FINALIZE] ......................................22
Erasing the recorded data
[ERASE] .......................................... 23
Using as a CD-R/RW drive
Connecting and setting
System configuration .....................24
Connecting ......................................24
About the SCSI daisy chain ........... 25
Operation
To use the unit as a CD-R/RW
drive .................................................26
Additional information
Care and handling of discs ....... 27
Troubleshooting ........................... 28
Error messages ............................ 30
Specifications ...............................31
Introduction

Introduction
2
XR-D400 [E] EN
LET0169-001A
Features
7Simple operation
You can record an Audio CD source to a CD-R or CD-RW
disc (Audio) by simple operation.
7Multi-speed dubbing
You can select the recording speed from among 1x, 2x, or 4x.
7Program recording
• You can record tracks in the desired order.
• You can make your original CD by selecting the desired
songs from two or more Audio CD sources.
7Variety of playback functions
You can play tracks in the desired order and repeat play-
back of the current track or all tracks.
7Using as a CD-R/RW drive
The unit can be used as a device for high-speed reading
and writing of data by connecting to a host computer.
Audio CD
dubbing
Audio CD
playback
Other
functions
Supplied accessories
• Audio cable (x 1)
• Instructions (x 1)
• AC power cord (x 1)
• Software (x 1)
• Guarantee card (x 1)
• Safety instructions (only for UK models) (x 1)
* When you use the unit as a SCSI drive, the SCSI cable
(optional) and the SCSI card (optional) are required.

Introduction
3
Introduction
XR-D400 [E] EN
LET0169-001A
English
Important cautions
Installation of the unit
• Select a place which is level, dry and neither too hot nor too cold (between 5˚C and
35˚C, 41˚F and 95˚F).
• Leave sufficient distance between the unit and the TV.
• Do not use the player in a place subject to vibrations.
AC Power cord
• Do not handle the power cord with wet hands!
• A small amount of power (2 watts) is always consumed while the power cord is
connected to the wall outlet.
• When unplugging the unit from the wall outlet, always pull the plug, not the power
cord.
To prevent malfunction of the unit
• There are no user-serviceable parts inside. If anything goes wrong, unplug the
power cord and consult your dealer.
• Do not insert any metallic object into the unit.
• Do not use any non-standard shape disc available on the market, because it may
damage the unit.
• Do not use a disc with tape, seals, or paste on it, because damage to the unit may result.
• Do not use a disc with a label that is printed by a label printer.
Note about copyright laws
• Please check the copyright laws in your country before recording Audio CD discs.
Recording of copyrighted material may infringe copyright laws (see page 17).
Safety precautions
Avoid moisture, water and dust
Do not place your player in moist or dusty places.
Avoid high temperatures
Do not expose the unit to direct sunlight or place it near a heating device.
When you’re away
When away on travel or otherwise for an extended period of time, remove the plug
from the wall outlet.
Do not insert foreign objects into the unit
Do not insert wires, hairpins, coins, etc. into the unit.
Do not block the vents
Blocking the vents may damage the unit.
Care of the cabinet
When cleaning the unit, use a soft cloth and follow the relevant instructions on the
use of chemically-coated cloths. Do not use benzene, thinner or other organic
solvents and disinfectants. These may cause deformation or discoloring.
If water gets inside the unit
Turn off the power switch and remove the plug from the wall outlet, then call the
store where you made your purchase. Using the unit in this state may cause a fire or
electrical shock.
Notes on handling

Introduction
4
XR-D400 [E] EN
LET0169-001A
Preliminary knowledge about discs
Playable discs
Audio CD CD-R CD-RW
Recordable and playable discs
CD-R (Audio) CD-RW (Audio)
For Audio use
Playable and recordable disc types are as follows:
Unrecordable discs
CD-R CD-RW
CD-TEXT* CD-EXTRA*
* The unit can play these discs, but the unit is not compatible the CD-TEXT, or CD-
EXTRA function.
For SCSI use
Recordable disc types are as follows:
Recordable discs
CD-R CD-RW CD-R (Audio) CD-RW (Audio)

Introduction
5
Introduction
XR-D400 [E] EN
LET0169-001A
English
About recordable discs
• You cannot erase the recorded data once you record a CD-R disc. When you use a
CD-RW disc, you can erase the recorded data (see page 23).
• Some discs may not be recorded correctly. We recommend purchasing one disc and
recording on a trial basis before you purchase a large amount of discs for this unit.
• CD-R or CD-RW discs that are recorded by the unit can be played back in the unit
only. To play a recorded CD-R or CD-RW disc on a CD player, the disc need to be
finalized (see page 22).
• CD-RW discs may not be played on a CD player. CD-RW discs can be played on a
CD-RW recorder or a CD/DVD player with MultiRead logo.
• Discs for only high speed recording (ex. 4x – 10x disc) cannot be used. Use a disc
such as 1x – 4x disc.
CD-R disc
A CD-R disc can be recorded only once. You cannot erase the recorded data.
CD-RW disc
ACD-RW disc can be recorded many times. When you erase the recorded data, you
can use the disc as a blank disc.
• For audio recording
Use CD-R or CD-RW discs for audio recording. The unit cannot record on CD-R or
CD-RW discs for an general use.
Caution
Normally, CD materials are copyrighted. The price of CD-R or CD-RW discs for
audio recording includes a compensation fee for personal recording to protect
copyright. CD-R or CD-RW discs for audio recording contain a special code for
identification. When you purchase CD-R or CD-RW discs, make sure they are for
audio recording.

Getting started
6
XR-D400 [E] EN
LET0169-001A
Names of parts and controls
Refer to the corresponding pages indicated in () for details.
Front panel
Getting started
POWER
1TRACK ALLREPEAT
SPEED
ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC
9
-
=
~
!
0
8
5
6
3
2
1
@
#
$
%
^
&
*
(
)
_
+
7
4

Getting started
7
Getting
Started
XR-D400 [E] EN
LET0169-001A
English
1TRACK button (13)
Select the track for program play
and recording.
TRACK indicator (15)
Indicates the track and error
information.
2POWER indicator (10)
Lights when the unit is turns on.
3POWER button (10)
Turns the unit on or off .
4REPEAT/SPEED indicators (14/
18)
Indicates the dubbing speed or
repeat mode.
56(Play/Pause) button (12)
Starts playback or pauses during
playback.
64¢(Skip) buttons (13)
Performs skipping or previous/next
operation.
77(Stop) button (13)
Stops playback.
8SOURCE indicator
Lights when the disc that is inserted
to the disc tray (SOURCE) is being
accessed.
9Disc loading tray (SOURCE)
(18)
Used to load discs. Insert a source
disc such as an audio CD into this
tray.
0SCSI button/indicator (26)
Switches the SCSI mode ON and
OFF.
Lights when the SCSI mode is set
to ON.
-REC/PLAY indicator
Lights when the disc that is inserted
to the disc tray (REC/PLAY) is being
accessed.
=Disc loading tray (REC/PLAY)
(11)
Used to load discs. Insert a disc for
playing or recording. When you use the
unit as a CD/RW drive, use this tray.
~PHONES jack (12)
Connection jack for headphones.
!PHONES LEVEL control (12)
Adjusts the volume level of
headphones connected to the
PHONES jack.
@OVER indicator (30)
Lights when an error occurs.
#PROGRAM REC indicator
Flashes during program recording.
$FINALIZE indicator (22)
Flashes during finalizing.
%ERASE indicator (23)
Lights when the ERASE button is
pressed.
^ERASE button (23)
Erases the recorded data of a CD-
RW disc.
&FINALIZE button (22)
Finalizes a disc so that it can be
played by a normal CD player.
*OPEN/CLOSE 0button
(SOURCE) (18)
Opens and closes the disc loading
tray for SOURCE.
(PROGRAM REC button (20)
Enters the program play or
recording mode.
)REPEAT/SPEED button (14/18)
Changes the dubbing speed/
Change the repeat mode.
_OPEN/CLOSE 0button (REC/
PLAY) (11)
Opens and closes the disc loading
tray for REC/PLAY.
+AUTO REC button/indicator
(19)
Executes Auto recording.
Lights during Auto recording.

Getting started
8
XR-D400 [E] EN
LET0169-001A
Rear panel
1LINE OUT jacks (L/R) (9)
Output stereo analog audio signals.
2SCSI ID Device number selector (25)
Selects the SCSI ID device number.
3SCSI connector (24)
Connects the SCSI cable.
4AC power connector (9)
Connects the AC power cord.
5TERMINATION switch (25)
Switches the terminator setting ON and OFF.
2
14
SCSI
TERMINATION
ON OFF
I / O
ID
~ AC IN
LINE
OUT
L
R
3
5
6
7
0
1
2
3
4
5

Getting started
9
Getting
Started
XR-D400 [E] EN
LET0169-001A
English
Connections (for audio use)
Before making any connections
• Do not connect the AC power cord until all other connections have been made.
• Since different components often have different terminal names, carefully read the
instructions supplied with the component you wish to connect.
• Be sure to make connections correctly between corresponding terminals.
Audio cable (supplied)
The unit
Amplifier/receiver
To AC outlet
AC power cord
(supplied)
To connect the AC power cord
When all the connections have been made, insert the power plug into the wall
outlet firmly.
Warning
• Disconnect the power cord if you are not going to use the unit for a long time.
• Disconnect the power cord before cleaning the unit.
• Disconnect the power cord before moving the unit.
• Do not connect or disconnect the power cord with wet hands.
• Do not pull the power cord when disconnecting it, as this may damage the cord and
cause fire, electric shock, or other accidents.
Caution
• Do not damage, remodel, twist, or pull the power cord, as this may cause fire, electric
shock, or other accidents.
• Contact a dealer and get a new power cord if the cord is damaged. A damaged cord
may cause fire, electric shock, or other accidents.
• Do not put anything heavy, or the unit, on the power cord, as this may cause fire, electric
shock, or other accidents.
SCSI
TERMINATION
ON OFF
I / O
ID
~ AC IN
LINE
OUT
L
R
6
7
0
1
2
3
4
5
AUDIO
RIGHT
LEFT
For the SCSI connection,
see page 24.

Playback operations
10
XR-D400 [E] EN
LET0169-001A
This chapter explains the basic operation for using the unit as an audio CD
player.
Before operation
Prepare the unit for playback.
Playback operations
To turn on the unit
•Press POWER.
The POWER indicator lights.
Make sure that the SCSI indicator
goes off. When the SCSI indicator
lights, press SCSI so that the SCSI
indicator goes off.
To turn off the unit
Press POWER so that the POWER indicator goes off.
POWER
0OPEN/CLOSE
(for REC/PLAY)
SCSI
goes off
POWER
1
11
2
12
3
13
4
14
5
15
6
16
1 TRACK ALL ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC
REPEAT
SPEED
POWER

Playback operations
Playback
operations
11
XR-D400 [E] EN
LET0169-001A
English
To insert a disc
1Open the loading tray by pressing
0OPEN/CLOSE.
2Place the disc into the loading tray.
Make sure the disc edge does not overlap
the edge of the recessed area.
3Close the loading tray by pressing
0OPEN/CLOSE.
You can check the track information by
viewing the TRACK indicator.
To remove a disc
1Open the loading tray by pressing 0OPEN/CLOSE.
2Remove the disc from the loading tray.
3Close the loading tray by pressing 0OPEN/CLOSE.
NOTES
• Never pull on the loading tray when it is in the open position.
• Always keep the loading tray in the closed position except when inserting or removing a
disc.
• Do not insert a disc to the loading tray for SOURCE. The unit cannot play a disc that is
inserted into the loading tray for SOURCE.
• When you insert an improper disc, the disc is ejected. Make sure that a disc is proper
before inserting.
OPEN/CLOSE
Insert a disc into the loading
tray for REC/PLAY.
POWER 1
11
2
12
3
13
4
14
5
15
6
16
1TRACK ALL
ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC

Playback operations
12
XR-D400 [E] EN
LET0169-001A
Playing a CD
To play a CD
Press 6.
The unit starts playback.
The TRACK indicator of the track that
is played flashes.
To adjust the volume level
•For amplifier or receiver
Adjust the volume level of the connected amplifier or receiver.
See the instructions of the amplifier or receiver.
•For headphones
To increase the volume, turn PHONES LEVEL to the right. To decrease the
volume, turn PHONES LEVEL to the left.
6
HEADPHONE jack
4/¢
7
PHONES LEVEL
TRACK buttons
TRACK indicators
POWER
1
11
2
12
3
13
4
14
5
15
6
16
1 TRACK ALL ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC
REPEAT
SPEED

Playback operations
Playback
operations
13
XR-D400 [E] EN
LET0169-001A
English
To stop playback completely or temporarily
•To stop playback completely, press 7.
The unit stops playback.
•To stop playback temporarily, press 6.
The unit pauses playback. To continue playback,
press 6again.
To advance or reverse play rapidly while playing
7During playback
Press and hold ¢or 4.
Press and hold ¢to advance playback rapidly,
and 4to reverse playback rapidly. When you
release the button, the unit starts normal
playback from the point you release the button.
To locate the beginning of a track
7During playback
Press ¢or 4.
Press 4to locate the beginning of the current
track, and press ¢to locate the beginning of
the next track. When you press repeatedly, you
can select the preceding track.
To locate a track directly
Press the desired TRACK button.
The unit starts playback from the selected track.
1
Example

Playback operations
14
XR-D400 [E] EN
LET0169-001A
Playing repeatedly [REPEAT]
You can play a disc/track repeatedly.
To play the current track repeatedly
1Press REPEAT repeatedly so that the 1 TRACK
indicator lights up.
2Press 6.
1 track repeat play starts.
To play an entire disc repeatedly
1Press REPEAT repeatedly so that the ALL indicator
lights up.
2Press 6.
Disc repeat play starts.
To cancel repeat play
Press REPEAT so that the 1 TRACK and ALL indicator go off.
• You can activate the repeat function during playback.
• You can advance or reverse playback rapidly by pressing and holding 4or ¢,
and locate the beginning of the track by pressing 4or ¢during repeat play.
6
1 TRACK indicator
REPEAT
ALL indicator
SPEED
REPEAT
1TRACK ALL
4x 2x
SPEED
REPEAT
1TRACK ALL
4x 2x
POWER
1
11
2
12
3
13
4
14
5
15
6
16
1 TRACK ALL ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC
REPEAT
SPEED

Playback operations
Playback
operations
15
XR-D400 [E] EN
LET0169-001A
English
Playing tracks in the desired order [PROGRAM]
You can arrange the order of the tracks.
To create a program
1Press 6while pressing 4.
• The TRACK indicators of tracks that you can
program flashes.
2Press the desired TRACK button.
• The track is programmed in the order you press.
• The selected TRACK indicator lights up.
3Repeat step 2 for more programming.
4Press 6.
Program play starts.
6
TRACK buttons
TRACK indicators
Programmed tracks
(light up)
4
123
Track that is not
programmed (flashes)
POWER
1
11
2
12
3
13
4
14
5
15
6
16
1 TRACK ALL
ERASE
OVER
OPEN/CLOSE
SOURCE
SPEED
REPEAT
FINALIZE
PROGRAM
REC
4x 2x 1x
7
17
8
18
9
19
10
20
OPEN/CLOSE
REC/PLAY
SCSI AUTO REC
REPEAT
SPEED

Playback operations
16
XR-D400 [E] EN
LET0169-001A
To cancel program play
Press 7.
To check the programmed tracks manually
Before step 4 above, press ¢. Each time you press ¢, the TRACK
indicator lights up in the order that you programmed.
To add a track
When checking programmed tracks manually, press the desired TRACK
button. The track is added before the track that currently lights up.
To cancel a track
When checking programmed tracks manually, press the TRACK button that
you want to cancel. The track is canceled and the TRACK indicator goes off.
To repeat a programmed track
1Create a program (see page 15).
2Press REPEAT repeatedly so that the ALL indicator lights up (see page 14).
3Press 6.
• You can advance or reverse playback rapidly by pressing and holding 4or ¢,
and locate the beginning of a track by pressing 4or ¢during Program play.
NOTES
• You cannot program a track you have already programmed.
• You cannot program tracks numbered higher than 20.
