JWA NAXOS 70624 User manual

NAXOS SINGLE MONITOR SIT/STAND TABLE
70624
915mm
277mm
510mm
710-1150mm
820mm

2
PRE-ASSEMBLY PREPARATION
Allow 15 min For 1 person Additional tools required
Before you start:
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may
damage the product
2. Take care when lifting. Product should be assembled as near as possible to the
point of use
3. Ensure that you have all required contents for complete assembly
4. Always read the assembly instructions carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over tighten the screws and bolts as this may damage the threads
7. Assembly is to be carried out by a competent adult(s) ONLY
8. During assembly, children should be kept away from the product due to possible
risk to injury.
9. Do not use this item if any components are missing or damaged.
10. Please keep the instructions for future reference.

PARTS INCLUDED

TOOLS REQUIRED NOT INCLUDED
TOOLS REQUIRED NOT INCLUDED
M5x14 (x19)
M6x14 (x10)
M5x12 (x9)
(x1)
A
B
C
D
E
F
G
S=4mm
(x4)
(x1)
M6x30 (x4)

INSTALLATION
INSTALLATION
M6x14
C
E
S=4mm
A
M6x30
M6x30 (x4)
M6x14 (x4)
1

3
INSTALLATION
C
M6x14 (x4)
S=4mm
6
2

INSTALLATION
3
M5x14 (x17)
B
7
3

INSTALLATION
3
8
M5x12 (x9)
D
4

3
INSTALLATION
9
5

General Product Care
To protect your furniture, we suggest the following:
Avoid placing your furniture in direct sunlight.
Do not place furniture directly under windows.
Do not place sharp materials (knife, fork, etc.) directly onto your furniture
as sharp material may scrape and damage the finish.
Do not place material with high temperature directly onto the surface of
your furniture.
Clean up spills quickly. Water left over a prolonged period of time may
cause damage. Alcohol, perfume, nail polishes, aftershave and some
medication may cause severe finish damage if not cleaned immediately.
Use a clean, soft, dry, lint free absorbent cloth to clean your furniture.
Do not use any detergent as they may contain ingredients that may react
and damage the finish.
3
10

6
SAFETY BRACKETS
INSTRUCTIONS
1. Attach one Mounting Plate to the wall with the Large Screws. Make sure to
attach the Mounting Plate into a stud. If mounting into brick or masonry you
will need to acquire wall anchors.
2. Attach the second Mounting Plate to the furniture frame with the Short
Screws.
3. Move the furniture to its final position. Thread a Wall Strap through the both
Mounting Plates and tighten until snug. Do not over tighten.
4. Make sure that the Mounting Plates are firmly attached to the wall and
furniture and that the Wall Strap is snug.
11
