WARNING
--------------------------------------------------
The distance between the supporting
surface for the cooking vessels on the hob
and the lower part of the hood must be at
least 65 cm. If the instructions for installation
for the hob specify a greater distance, this
has to be taken into account.
The air collected must not be conveyed
into a duct used to blow off smokes from
appliances fed with an energy other than
electricity (central heating systems, ther-
mosiphons, water-heaters, etc.).
Comply with the official instructions provided
by the competent authorities in merit when
installing the disposal duct. In addition,
exhaust air should not be discharged into
a wall cavity, unless the cavity is designed
for that purpose.
The room must be well aerated in case a
hood and some other heat equipment fed
with an energy other than electricity (gas,
oil, coal heaters, etc) operate at the same
time. In fact the intake hood, disposing of
air, could create a vacuum in the room.
The vacuum should not exceed 0,04mbar.
This prevents the gas exhausted by the
heat source from being intaken again. It is
therefore advisable to ensure the room
contains air taps able to ensure a steady
flow of fresh air.
ATTENTION: This appliance must be
grounded.
The following warning is valid in the United
Kingdom only: in case your cable is not
furnished with a plug, read the following
instructions; as the colours of the wires in
the mains lead of this appliance may not
correspond with the coloured markings
identifying the terminals in your plug,
proceed as follows:
– the wire which is coloured green and
yellow must be connected to the terminal
in the plug which is marked with the letter
E or by the earth symbol [ ], or coloured
green or green and yellow;
– the wire which is coloured blue must be
connected to the terminal which is marked
with the letter N or coloured black;
– the wire which is coloured brown must
English
be connected to the terminal which is
marked with the letter L or coloured red.
When making the electrical connections,
check that the current socket has a ground
connection and that the voltage values
correspond to those indicated on the data
plate inside the appliance itself.
In case your appliance is not furnished with
a non separating flexible cable and has no
plug, or has not got any other device ensu-
ring omnipolar disconnection from the elec-
tricity main, with a contact opening distance
of at least 3 mm, such separating device
ensuring disconnection from the main must
be included in the fixed installation. If your
unit features a power lead and plug, position
this so the plug is accessible.
Always switch off the electricity supply be-
fore carrying out any cleaning or servicing
operations on the appliance.
USE
--------------------------------------------------
Avoid using materials which could cause
spurts of flame (flambées) near the ap-
pliance.
When frying, take particular care to prevent
oil and grease from catching fire. Already
used oil is especially dangerous in this re-
spect. Do not use uncovered electric grates.
To avoid possible risks of fire always comply
with the indicated instructions when
cleaning anti-grease filters and when
removing grease deposits from the
appliance.
MAINTENANCE
--------------------------------------------------
Thorough servicing guarantees correct and
long-lasting operation.
Pay special attention to the grease filters.
The grease filters must be cleaned
approximately once every 30 hours of
operation (when the central segment on the
display goes on or starts blinking). To
remove the filters: press inward on the
clamps at the handles and pull the filter
downward (Fig. 3). Wash out the filter by
hand or in the dishwasher using a neutral
soap. Once the cleaned filters are
reinstalled, keep button R (Reset) pressed
for two seconds to reset the counter. For
further information, see the Commands in
the paragraph entitled "Operation".
Any fat deposits should be removed from
the appliance periodically depending on

amount of use (at least every 2 months).
Avoid using abrasive or corrosive products.
To clean painted appliances on the outside,
use a cloth dipped in lukewarm water and
neutral detergent. To clean steel, copper
or brass appliances on the outside, it is
always best to use specific products,
following the instructions on the products
themselves. To clean the inside of the
appliance, use a cloth (or brush) dipped in
denatured ethyl alcohol.
DESCRIPTION
--------------------------------------------------
This apparatus includes a hood, a hanging
telescopic structure and a telescopic flue that
must be set on top of the hood to cover the air
evacuationpipe.Thisapparatuscanbeafiltering
version one, an ducting version one.
In the Filtering version the air and the kitchen
fumes that are conveyed by the apparatus are
depuratedbythecharcoalfilterandputbackinto
theroomthroughthesmallgrillesoftheventilation
flue(Fig.1).ATTENTION:Whenusingthefiltering
version, a charcoal filter and an air baffle (Fig.
1A) must be used, which placed at the top of the
structure, allows the air to recycle back into the
room. In theDucting version, cooking vapours
and odours are conveyed straight outside by a
disposal duct which passes through the ceiling
(Fig. 2).
INSTALLATION
--------------------------------------------------
ATTENTION: Two persons are required for
properinstallation;theunitshouldbeinstalled
by a qualified operator. Also follow carefully
each step of the assembly instructions, and
once installation has been completed, make
sure that the hood is firmly secured in place.
To facilitate installation, before starting remove
theanti-greasefilters:pressinwardontheclamp
atthehandleandpullthefilterdownward(Fig.3).
For assembling it is essential to: – prepare the
connection to the mains within the telescopic
structure. – prepare the hole for evacuating the
airifyourapparatusistobeinstalledasanducting
version.
ASSEMBLING
Using the special drilling template, drill the
holes for fixing to the ceiling on the vertical side
of your hob. Carefully observe all the indications
for final positioning of the apparatus. Take into
account that one of the template axes must cor-
respond to the axis of the hood controls.
Fixthebrackettotheceilingusingthescrews
and screw anchors provided (Fig. 4). Be careful,
because the position of the bracket determines
the final position of the apparatus: the side with
the slot B corresponds to the control side.
Ducting version: Fix the telescopic structure to
the bracket using 4 screws (provided), running
the air evacuation pipe and the electric power
cable through the structure (Fig. 5). Adjust the
heightofthetelescopicstructurebymeansofthe
fourretainingscrewsC(Fig.6),takingintoaccount
thattheheightofthehoodis130mmandthatthe
distance between the hood and the hob must be
at least 650 mm (Fig. 7).
Take the telescopic flue and with some ad-
hesive tape fix the lower pipe to the upper pipe.
Check that the slots of the upper pipe are in the
lower part (Fig. 8); if not, turn around the upper
pipe.Fitthetelescopicflueonthetelescopicstruc-
tureandfix it tothebracket with twoscrews(pro-
vided) – Fig. 9. Fit the hood to the telescopic
structure by means of 6 screws (provided) – Fig.
10. Through the openings D (Fig. 10) fix the air
evacuation pipe to the air outlet mouth of the
hood. Make the electrical connection by means
of the power cable. Remove the adhesive tape
and pull the lower pipe downwards, placing it
gently onto the apparatus. Installation is now
complete and the anti-grease filters can be re-
mounted.
Filtering version: Fix the telescopic structure to
the bracket using 4 screws (provided), running
the electric power cable through the structure
(Fig. 5). Adjust the height of the telescopic struc-
turebymeansofthefourretainingscrewsC(Fig.
6),takingintoaccountthat the heightofthehood
is 130 mm and that the distance between the
hood and the hob must be at least 650 mm (Fig.
7). Insert the air baffle in the structure (Fig.11).
ThroughtheopeningsE(Fig.11),fittheflangeto
thebafflelocking itwitha turningmovement. Fix
a flexible pipe to the flange for air evacuation
(Fig.12). Takethe telescopicflue and withsome
adhesivetapefixthelowerpipetotheupperpipe.
Check that the slots of the upper pipe are in the
upper part (Fig. 13); if not, turn around the upper
pipe.Fitthetelescopicflueonthetelescopicstruc-
tureandfix it tothebracket with twoscrews(pro-
vided) – Fig. 9. Fit the hood to the telescopic
structure by means of 6 screws (provided) – Fig.
10. Through the openings D, mount the flange
(provided) on the air outlet mouth of the hood
(Fig. 14). Then fit the air evacuation pipe to the
flange.Make theelectrical connection by means
of the power cable. Remove the adhesive tape

and pull the lower pipe downwards, placing it
gently onto the apparatus. Install the charcoal
filtersclipping the2 filterclips intoplace (Fig.15)
and turn the filter upwards. Installation is now
complete and the anti-grease filters can be
remounted.
OPERATION
--------------------------------------------------
Commands (Fig. 16):
Button A = turns the lights on/off.
Button B = turns the TIMER on/off: press once
to turn the timer on, therefore, after 5 minutes,
the motor cuts out (at the same time the
selected speed blinks on the display); the timer
remains on if the motor speed is changed.
Display C =
- indicates the selected motor speed (from 1 to
4); 4: intensive speed.
- indicates Timer On when the number blinks;
- indicates Filter Alarm when the central
segments is on or blinking.
Button D = makes the motor work (at the last
speed selected); pushing the button again, the
speeds of the motor are sequentially selected
from 1 to 4; keeping this button pressed for
about 2 seconds shuts down the motor.
Button R = resets the grease filters or charcoal
filters; when the filter alarm appears (i.e. when
the central segment on the display goes on),
the grease filters must be cleaned (30 hours of
operation); when the central segment starts
blinking, the grease filters must be cleaned and
the charcoal filters replaced (120 hours of
operation). Obviously, if the hood is not a
filtering model and does not have a charcoal
filter , clean the grease filters both when the
central segment goes on and when it starts
blinking. The filter alarm can be seen when the
motor is off and for about 30 seconds. To reset
the hour counter, keep the button pressed for
2 seconds while the alarm can be seen.
Replacing the carbon filters: If the unit is a
filtering hood, the charcoal filters must be
replaced: to remove them press inward on the
clamp (Fig. 15) and rotate the filter downward
untilthe2tabscanberemovedfromthehousing.
The charcoal filters must be replaced whenever
the central segment of the display starts blinking
(i.e. every 120 hours of operation).
Lighting: To remove the halogen lamps, turn
thelocknut counter-clockwise(Fig. 17). Replace
with the same type of lamp.
ATTENTION
---------------------------------------------------
La distance minimum entre la surface de
support des casseroles sur le plan de
cuisson et la partie inférieure de la hotte
doit être de 65 cm. Si les consignes, pour
l’installation du plan de cuisson, indiquent
une plus grande distance, il faut en tenir
compte.
L'air aspiré ne doit pas être canalisé dans
un conduit qui est utilisé pour évacuer les
fumées produites par des appareils
alimentés par des sources d'énergies autres
que l'énergie électrique (installations de
chauffage central, radiateurs, chauffe-eau,
etc.).
Pour évacuer l'air qui doit être éliminé
respectez les prescriptions des autorités
compétentes. De plus l'air qui doit être
évacué ne doit pas être déchargé dans une
cavité du mur, à moins que cette cavité
soit prévue pour ce but.
Prévoyez une aération de la pièce adéquate
quand une hotte et des appareils alimentés
par une énergie autre que l'énergie
électrique (poêle à gaz, à huile, à charbon
etc.) sont utilisés en même temps. En effet,
en évacuant l'air, la hotte pourrait créer une
dépression dans la pièce. La pression
négative de la pièce ne doit pas dépasser
0,04mbar, évitant ainsi que la source de
chaleur provoque un appel des gaz qui
doivent être évacués. Il est donc nécessaire
d'équiper la pièce de prises d'air alimentant
un flux d'air frais constant.
ATTENTION: cet appareil doit être relié
à la terre.
Lors du raccordement électrique assurez-
vous que la prise de courant est munie de
connexion de mise à terre; vérifiez aussi
que les valeurs de tension correspondent à
celles qui sont indiquées sur la plaque des
caractéristiques de l’appareil, qui se trouve
à l'intérieur de celui-ci. Si votre appareil,
n'a pas de câble flexible qui ne peut pas
être séparé ni de prise, ou bien d'autre
dispositif qui garantisse le débranchement
de tous les pôles du réseau, avec une
distance d'ouverture entre les contacts d'au
moins 3 mm, ces dispositifs de séparation
Français

12
6
3
4
5
A
B
C
7
min 65cm
130
8
9

11
12
10
D
E
13
14
D
15 17
16
A B D RC
