2200 GM English
1 Spray lance with pressure regulator
2 Spray lance extension
3 Hand gun
4 Safety catch
5 Push handle
6 Basket for detergent reservoir
7 Detergent suction hose with filter
and metering ring
8 Pull-start handle
9 Throttle lever
10 Tank cap
11 Oil drain plug
12 High-pressure hose
13 High-pressure outlet
14 Hose coupling
15 Water inlet with strainer
16 Oil filler hole with dipstick
1.1 Unpacking the unit
lShould you notice any transport damage during
unpacking, notify your dealer immediately.
lBecauseyoucareabouttheenvironment,please
donotdisposeofpackagingcomponentsinregu-
lar domestic waste. Instead, take the items to a
collection point for recycling.
1.2 Attaching the accessories
lMounttheholdingbasketforthedetergent(3me-
tal hoops) to the push handle.
lAttach the push handle to the unit.
1.3 Engine
lPrior to using the unit, read the operating instruc-
tions supplied by the engine manufacturer, and
pay particular attention to the safety instructions.
lFillthefueltankwithunleadedpetrol.Donot use
a petrol/oil mixture for two-stroke engines.
lThe engine is supplied without engine oil. A cer-
tainamountofengineoilispackagedwiththeunit.
Pour this engine oil into the oil filler hole on the
engine.
lChecktheengineoillevel.Donotstarttheengine
if the oil level has dropped below the „MIN“ level.
Top up oil if necessary.
For draining the engine oil, the front cover of the
pump must be removed.
1.4 Pump
lThe pump is filled with oil. An oil change is not
required.
– FIRE HAZARD! Do not operate the high-
pressure cleaner if fuel has been spilled.
Instead, move the machine to a different
location and avoid creating sparks of any
kind.
– Donotstore,spilloruseenginefuelsnear
open flame or in the vicinity of devices
featuring an open pilot flame, such as
boilers,water heaters, etc.,ordevice that
may create sparks of any kind.
– Keepflammableitemsandmaterialsaway
from the engine silencer (minimum di-
stance: 2 meters).
– Do not operate the motor without the si-
lencer, and check and clean the latter on
a regular basis. Replace if necessary.
– Do not use the motor in woods, scrubs
and grasslands without having a spark
catcher attached to the silencer.
– Except during engine tuning, do not ope-
rate the engine with the air cleaner remo-
ved, or without a suitable cover over the
air intake.
– Do not make adjustments to governor
springs, governor linkages or other parts
that may result in a higher engine RPM.
– BURN HAZARD! Do not touch hot si-
lencers, cylinders or cooling fins.
– ASPHYXIATION HAZARD! Exhaust fu-
mesarepoisonous.Neveroperatetheunit
in enclosed rooms.
1. Unit Start-Up
