Kärcher BP 2 Garden User manual

BP 2 Garden
BP 2 Garden / Set Plus
BP 3 Garden / Set Plus
BP 4 Garden / Set
59692330 01/20
English 3
Register
your product
www.kaercher.com/welcome

2

3
Please read these original operating in-
structions and the enclosed safety in-
structions prior to the initial use of your device. Proceed
accordingly. Keep both booklets for future reference or
subsequent owners.
Please follow the safety instructions before starting up
the pump!
This appliance has been designed for use in private
households and is not intended for commercial use.
The manufacturer is not responsible for any damages
that may occur on account of improper use or wrong op-
erations.
The appliance is mainly intended for the use in a garden
and provides constant pressure for garden irrigation.
When sprinklers are connected, the following maximum
surfaces can be irrigated:
BP 2 Garden: 350 m2
BP 3 Garden: 500 m2
BP 3 Garden Set Plus: 500 m2
BP 4 Garden Set: 800 m2
몇CAUTION
Water that has been delivered with this appliance is no
drinking water!
Used water
Well water
Water source
Rain water
Water from swimming pool (provided the dosing of
additives is proper)
몇WARNING
Caustic, slightly inflammable and other explosive sub-
stances (such as petrol, petroleum, diluted nitrogen),
greases, oils, salt water and waste water from toilets as
well as sludgy water that has a slower flow capacity than
water, must not be transported with this pump.
The temperature of the delivered liquid must not exceed
35 °C
The appliance is not suitable for continuous pump
operation or as a stationary installations (such as a
lifting device, fountain pump).
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service centre.
Please submit the proof of purchase.
Notes about the ingredients (REACH)
You will find current information about the ingredients
at:
www.kaercher.com/REACH
Please observe the requirements of EN 1717 when con-
necting this product to the drinking water network and
contact your sanitation specialists if you have any ques-
tions.
DANGER
Immediate danger that can cause severe injury or even
death.
몇WARNING
Possible hazardous situation that could lead to severe
injury or even death.
몇CAUTION
Pointer to a possibly dangerous situation, which can
lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation, which can
lead to property damage.
Contents
Contents EN 3
Safety instructions EN 3
General notes EN 3
Environmental protection EN 3
Connection to the public drinking water
network EN 3
Danger or hazard levels EN 3
Operation EN 4
Maintenance and Care EN 4
Transport EN 4
Storage EN 4
Troubleshooting EN 5
Specifications EN 6
Customer Service EN 6
Safety instructions
General notes
Proper use
Approved fluids
Warranty
Environmental protection
The packaging material can be recycled. Please
arrange for the environmentally appropriate dis-
posal of the packaging.
Electrical and electronic devices often contain
components which could potentially pose a dan-
ger to human health and the environment if han-
dled or disposed of incorrectly. However, these
components are necessary for the proper opera-
tion of the device. Devices marked with this sym-
bol must not be disposed of with regular house-
hold rubbish.
Old appliances contain valuable recyclable mate-
rials that should be recycled properly. Batteries
and accumulators contain substances that must
not enter the environment. Please dispose of old
devices and batteries or accumulators in an envi-
ronmentally friendly way.
Connection to the public drinking water
network
Danger or hazard levels

4
1 Connection adapter for pumps G1
2 Stopper
3 Connection G1 (33.3 mm) suction pipe (inlet)
4 Connection G1 (33.3 mm) delivery line (output)
5 ON/OFF switch
6Cable clip
7 Power cord with plug
8 Suction hose set* incl. 3.5 m ready for connection,
vacuum-proof spiral hose with suction filter and
backflow stop
* Included in the scope of delivery with sets only.
Remove the plug.
Illustration
Screw the connection adapter in the suction con-
nection of the pump (inlet).
Tighten manually.
Connect the vacuum-proof suction hose.
Note
Depending on the degree of soiling of the fluid to be de-
livered, use a pre-filter (see accessories).
Note
In order to reduce the time required for suction to start
again, use a suction hose that is equipped with a back-
flow stop. This prevents the emptying of the suction
hose after use (see accessories).
Illustration
Fill the pump with water via the delivery connection
until it is overflowing.
Illustration
Screw the connection adapter in the delivery con-
nection of the pump (outlet).
Tighten manually.
Connect delivery line.
Insert the mains plug into the socket.
Switch on the appliance using the ON/OFF switch.
Illustration
In order to reduce the suction time, lift the delivery
hose approx. 1m.
Wait till the pump sucks in and transports water uni-
formly
Note
The ON/OFF switch can also be conveniently operated
with your foot.
몇CAUTION
Dry running damages the pump.
Do not leave the pump unattended during opera-
tion.
Note
The pump BP4 Garden Set is equipped
with a thermo switch, which automati-
cally switches off the pump in case of
overheating. As soon as the water in-
side the appliance has cooled down, the
appliance automatically switches back
on and can be used again.
Switch off the appliance using the On/Off switch.
Disconnect the main plug from the socket.
DANGER
Turn off the appliance and remove the mains plug prior
to any care and maintenance work.
Rinse the pump after every use if you use to trans-
port water with additives.
The appliance is maintenance free.
몇CAUTION
In order to prevent accidents or injuries, keep in mind
the weight of the appliance during transport (see Spec-
ifications).
Lift appliance by the carrying handle and carry it.
몇CAUTION
Tripping hazard due to loose cables!
Coil cable and secure it by means of a cable clip.
Secure the appliance against shifting and tipping
over.
몇CAUTION
In order to prevent accidents or injuries, keep in mind
the weight of the appliance when selecting a storage lo-
cation for it (see Specifications).
Depressurise the appliance by opening the water
outlet connected on the delivery side (e.g. opening
the tap).
Drain hoses.
Remove suction pipe and delivery line.
Drain the pump via the connections suction / and
delivery line by turning it around.
Store the appliance in a frost free area.
Operation
Description of the Appliance
Preparing the Appliance
Operation
Finish operation
Maintenance and Care
Care
Maintenance
Transport
When transporting by hand
When transporting in vehicles
Storage
Storing the Appliance

5
Troubleshooting
몇Caution
To avoid risks, all repairs and replacement of spare parts may only be carried out by authorized customer service
personnel.
First pull out the plug from the mains before carrying out any tasks on the machine.
Fault Cause Remedy
Pump runs but does not transport Air in the pump see chapter "Preparation" fig. B and
and chapter "Operations" fig. D
Suction area blocked Pull out the mains plug and clean the
suction area
Suction hose or connection adapter not
screwed in correctly or completely.
Manually tighten the suction hose
and the connection adapter.
Pump does not run or suddenly
comes to a standstill during opera-
tions
Power supply interrupted Check fuses and electrical connec-
tions
Thermal protection switch has switched
off the pump due to over-heating
(Only with BP 4 Garden Set).
Pull out the mains plug, let the pump
cool down, clean the suction area,
prevent dry running
Pump transports is reducing or
transported quantity is too low
Suction area blocked Pull out the mains plug and clean the
suction area
The quantity transported by the pump
depends on the transport height and the
connected periphery
Keep max. flow height, see technical
data. If necessary, select a different
hose diameter or hose length.
Cross section on the delivery side con-
stricted, e.g. due to valve/ball valve that
is not completely opened.
Completely open the valve/ball
valve.
Hose on the delivery side is kinked. Remove kinks from the hose.
Our Kärcher branch will be pleased to help you further in the case of questions or faults. See address on the reverse.

6
Subject to technical modifications!
*The max. flow rate is derived from the measurement without the backflow valve installed.
Australia
KÄRCHER Pty. Ltd.
40 Koornang Road
Scoresby, VIC 3179
1800 675 714 (Free Call)
www.karcher.com.au
Specifications
BP 2 Garden
BP 2 Garden Set Plus
BP 3 Garden
BP 3 Garden Set Plus
BP 4 Garden
BP 4 Garden Set
Voltage V 230 - 240 230 - 240 230 - 240
Frequency Hz 50 50 50
Output Pnom W 700 800 1000
Max. flow rate* l/h 3000 3500 4000
Max. Suction height m 8 8 8
Max. pressure MPa
(bar)
0,35
(3,5)
0,4
(4,0)
0,45
(4,5)
Max. flow height m 35 40 45
Max. delivery temperature °C 35,0 35,0 35,0
Max. grain size of the dirt particles
that can be transported
mm 1,0 1,0 1,0
Pump type Jet Jet Jet
Values determined as per EN ISO 20361
Sound pressure level LpA dB(A) 57 61 60
Sound power level LWA, guaran-
teed
dB(A) 72 76 75
Weight (without accessories) kg 8,1 8,3 9,0
I/h
m
1000 2000 3000 4000 5000 6000
40
70
60
50
30
20
10
BP 2 Garden
BP 4 Garden
10m = 0,1MPa (1bar)
BP 3 GardenBP 3 Garden
The possible delivery rate is even larger:
- the smaller the suction and delivery heights are.
- the larger the diameter of the hoses used are.
- the shorter the hoses used are.
- the less loss of pressure is caused by the connected accessories.
