Kaco blueplanet XP10U-H4 PSD User manual

Instruction Manual
• Authorized Electricians
blueplanet
XP10UH4 / H6
XP10UH4 / H6 PSD

Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
 General Notes............................................ 
. About this documentation .................................
. Design features .......................................................
 Safety .........................................................
. Intended use............................................................
. Protection features ................................................ 
. Standards and regulations.................................. 
 Description ................................................
. How it works ............................................................
. Unit description ......................................................
 Technical Data .......................................... 
. Trip Ievel settings to shutdown Inverter.......
. Trip Ievel settings to stop Inverter ..................
 Transportation and Delivery...................
. Delivery.................................................................... 
. Transportation....................................................... 
 Mounting the Inverter.............................
 Installing the Inverter..............................
. Opening the connection area ..........................
. Drilling holes for electrical and interface
connection...............................................................
. Carrying out the electrical connection ........ 
. Connecting the interfaces ................................
. Sealing the connection area ............................
. Starting up the inverter......................................
 Conguration and Operation ................
. Controls....................................................................
. Initial start-up .........................................................
. Menu structure.......................................................
. Monitoring the inverter .....................................
. Performing a software update........................
 Maintenance/Troubleshooting..............
. Visual inspection ..................................................
. Cleaning the inverter externally .....................
. Shutting down for maintenance and
troubleshooting....................................................
. Faults.........................................................................
. Messages on the display and
the “Fault” LED ......................................................
. Replacing or cleaning the fan......................... 
 Service...................................................... 
 Shutdown/Disassembly .........................
. Shutting down the inverter............................. 
. Removing the inverter....................................... 
. Dismantling the inverter................................... 
 Recycling and disposal ........................... 
Installation Instructions
for authorized electricians
Contents

General Notes
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
 General Notes
. About this documentation
WARNING
Improper handling of the inverter can be hazardous
›IMPORTANT SAFETY INSTRUCTIONS.
›For your safety, you must read and understand the operating instructions before you install and use the
inverter.
This manual is intended for inverter model blueplanet XPU-H and shall be followed during installation and mainte-
nance of this inverter model.
.. Other Applicable Documents
During installation, observe all assembly and installation instructions for components and other parts of the system.
These instructions are delivered together with the respective components and other parts of the system.
Visit http://www.kaco-newenergy.com/service/warranty to register your system for warranty-based service. If a copy of
the warranty card is included with the operating instructions, you may use this to register your system.
.. Retention of documents
SAVE THESE INSTRUCTIONS. These instructions and other documents must be stored near the system and be available
whenever they are needed.
. Design features
.. Symbols used in this document
General hazard symbol Risk of re or explosion
High voltage Risk of burns
Authorised electrician The tasks indicated with this symbol may only be carried out by an authorised
electrician.
.. Description of safety instructions
DANGER
Imminent danger
Failure to observe this warning will lead directly to serious bodily injury or death.
WARNING
Potential danger
Failure to observe this warning may lead to serious bodily injury or death.

General Notes
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
CAUTION
Low-risk hazard
Failure to observe this warning will lead to minor or moderate bodily injury.
CAUTION
Hazard with risk of property damage
Failure to observe this warning will lead to property damage.
.. Description of additional information
NOTICE
Useful information and notes
.. Description of action instructions
a) One-step actions or actions that can be carried out in any sequence:
Action instructions
↻Prerequisite(s) for your action(s) (optional if they have been performed earlier)
Carry out action.
(Additional actions, if applicable)
» Result of your action(s) (optional)
b) Multi-step action instructions that must be carried out in a xed sequence:
Action instructions
↻Prerequisite(s) for your actions (optional if they have been performed earlier)
. Carry out action.
. Carry out action.
. (Additional actions, if applicable)
» Result of your actions (optional)

Safety
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
 Safety
DANGER
Lethal voltages are still present in the terminals and leads of the inverter even after the inverter
has been switched o and disconnected. Lethal voltages are still present from the PV array, and
PV System Disconnect’s touch safe fuse holders.
With the PDS disconnected from both AC and DC sources, the inverter terminals are open, and can
be removed and replaced with no voltage present.
Severe injuries or death may result if the leads and/or terminals in the inverter are touched when voltage
is present.
Only authorised electricians who are approved by the supply grid operator may open, install and main-
tain the inverter.
›Keep the inverter closed when the unit is in operation.
›Do not touch the leads and/or terminals when switching the unit on and o.
›Do not make any modications to the inverter.
The electrician is responsible for observing all existing standards and regulations.
• Keep unauthorized persons away from the inverter and PV system.
• Complete all electrical installations in accordance with local electrical codes and the National Electrical Code (NEC),
ANSI/NFPA .
• Ensure operational safety by providing proper grounding, conductor dimensioning and appropriate protection against
short circuiting.
• Observe the safety instructions on the inverter and in these operating instructions.
• Switch o all voltage sources and secure them against being inadvertently switched back on before performing visual
inspections and maintenance.
• When taking measurements while the inverter is live:
–Do not touch the electrical connections.
–Remove all jewelry from your wrists and ngers. Remove or fasten all jewelry around your neck.
–Ensure that the testing equipment is in safe operating condition.
• Stand on an insulated surface when working on the inverter while it is switched on.
• Modications to the surroundings of the inverter must comply with the applicable national and local standards.
. Intended use
The XPU converts clean renewable DC energy into AC energy for export (feed-in) into the utility.
The XPU-H was designed, tested, and listed to the UL , CSA-C. No. .. and the NFPA .
The XPU-H was designed, tested, and listed to the CSA-C. No. .. and the NFPA .
WARNING
Potential danger
Only authorized personnel who are qualied for the VAC and VDC voltage ratings should install or
maintain this equipment. Lethal hazards exist which may result in serious injury.
Operate the inverter only with a permanent connection to the public power grid.
Any other or additional use is not considered the intended use. This includes but is not limited to:
• Mobile use
• Use in rooms where there is a risk of explosion
• Use in rooms where the humidity is higher than %
• Operation outside of the specication published by the manufacturer
• Standalone operation.

Safety
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
. Protection features
For your safety, the following monitoring and protective functions are integrated into the XPU inverter:
• Overvoltage conductors/varistors to protect the power semiconductors from high-energy transients on the
grid and PV array side
• Temperature monitoring of the heat sink
• EMC lters to protect the inverter from high-frequency grid interference
• Grid-side grounded varistors to protect the inverter against surge pulses
• Islanding detection according to IEEE . and VDE --
. Safety standards and regulatory compliance
The XPU product line has been evaluated, and certied by nationally recognized test laboratories to the following
safety features and regulatory compliance:
XP10U-H4 XP10U-H6
UL 1741-1:1999 Rev. May 2007 X -
CSA 22.2 No. 107-1:2001 Rev 2006 X X
IEEE Std. 1547-2003 X X
IEEE Std. 1547.1-2005 X X
FCC Part 15 Class B X X
NFPA 70 X X
Directive concerning Electromagnetic
Compatibility with Class B (Council Directive
2004/108/EC)
XX
Low Voltage Directive (Council Directive
2006/95/EC)
XX
The blueplanet inverter has complete on-board over-current, over-temperature and anti-islanding protection.

PV system description
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
 PV system description
. Summary of operation
The PV system creates clean AC energy from sunlight. The PV array absorbs the energy of sunlight, and produces DC
energy. The inverter’s role is to maximize the amount of DC energy inverted into AC, and exported to the utility grid
during the feed in mode of operation.
The feed in process starts with enough sunlight exposed to the PV array for the specic minimum voltage and current
levels. The amount of energy available to the inverter is directly tied to the amount of sunlight being absorbed by the PV
array.
. Major components of a PV system
.. PV system illustration
Figure : PV system illustration with two inverters
KWhKWh
PV array PV array
XPU Inverter XPU Inverter
AC Branch Circuit
Protection
Consumer
Load Usage
Feed-in meterReference
meter
Utility Electric
Disconnect Switch
Grid connection
point
AC Branch Circuit
Protection
DC Circuit Termination DC Circuit Termination
Utility Electric
Disconnect Switch

PV system description
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
... A summary of the components
PV array
PV arrays consist of PV modules connected in series and parallel. Each series-connected set is called a string. The electri-
cal properties of the PV array are determined by how many PV modules are in a string, and how many of the strings are
connected in parallel.
DC circuit connection
The PV array comprises individual PV circuits, with each circuit containing one positive and one negative contributor. The
individual PV circuits are connected in parallel at a DC circuit termination point. The DC circuits can be terminated either
outside the inverter, or inside the inverter as shown in Figure .
Over-current protection devices
Feed-in meter
The feed-in meter is specied and installed by the utility operator. Some utility operators also allow the installation of
your own calibrated meters.
Utility Electric Disconnect Switch
Your utility operator or authority having jurisdiction (AHJ), may require an external visibile blade disconnect, which is not
required by the NFPA .
.. Design of the inverter
1
2
3
4
5
Figure : Inverter without integrated PV System
Disconnect
Figure : Inverter with integrated PV System
Disconnect
Key
1 Operator panel 5 Mounting plate
2 Cover for the XP10U AC and DC circuit termination 6 PV system disconnect (PSD)
3 Gland plate 7 DC disconnect switch
4 USB interface 8 Lock - PSD cover
9 AC disconnect switch
Note: Items 1 -4are the same for Figure 2and Figure 3.
6
8
5
7
9

PV system description
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
.. Electrical functions
... Fault signal relay
A potential-free relay contact is integrated in the inverter. The contact closes as soon as there is a fault during operation.
.. Interfaces
The inverter oers the following interfaces for communication and remote monitoring:
• RS interface
• Ethernet interface
• USB interface
• S interface
The conguration of communication interfaces is via the inverter menu.
... RS interface
Use this monitoring variant if you cannot check the function of the system on-site on a regular basis, e.g. if your place of
residence is located a great distance from the system. To connect the RS interface, contact your authorised electri-
cian.
For monitoring your PV system using the RS interface, KACO new energy oers several solar monitoring devices.
... Ethernet interface
The monitoring can occur directly on the unit using the integrated Ethernet interface. A local web server is installed in
the unit for this purpose.
For monitoring a system comprising several inverters, we recommend you use an external data logging and monitoring
system.
... USB interface
The USB connection of the inverter is a type A socket. It is located on the connection board on the underside of the
inverter under a cover. The USB connection is specied to draw  mA of power. Use the USB interface for reading out
stored operating data and loading software updates using a FAT-formatted USB stick.
... S interface
The S interface transmits pulses between a pulsing counter and a tari metering unit. It is a galvanically isolated
transistor output. It is designed according to DIN EN -:- (Pulse output devices for electromechanical and
electronic meters).
The S interface pulse rate can be chosen in three unit intervals (, , and , pulses/kWh).

Technical Data XP10U H4 / H6 (with optional PSD)
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
 Technical Data XPU H / H (with optional PSD)
DC electrical specications
DC maximum input voltage (VDC) 600
DC maximum peak power operating range
(MPP) input A - B (VDC) 280-550
DC operating range (VDC) 200-600
DC minimum start voltage (VDC) 250
DC maximum operating current per
input A - B (ADC) 18.6
DC maximum short circuit current per
input A - B (ADC) 37 / 45
Max. input source back feed current (ADC) 0
DC input overload protection Voltage and current
DC input terminals / conductor size per
channel A - B
2 Pos and 2 Neg / 8-14 AWG
AC electrical specications
AC max continuous output power (W) 10.000
CEC weighted e (%) 97
AC nominal voltage / operating range
L to Neutral (VAC)
480 / 243 to 304
600 / 305 to 381
AC Continuous output current (A) 480 / 600 12 .1 / 9.7
AC branch circuit protection 20 / 15
Frequency nominal / range (Hz) 60 / 60.5 to 59.3
Power factor > .99
Total harmonic distortion % < 5
Standby losses (W) < 1.5
AC input terminals and conductor 4 / 4-18 AWG
AC maximum output fault current (A), RMS, and
duration (ms)
(NA for H4) / 355 (P-P), 12.95, 46.5
Utility Connection H6- Wye 4 wire (A,B,C,N)
PV system disconnect (optional)
Integrated AC / DC disconnect Yes
AC Disconnection means Rotary switch visible and accessible from outside of enclosure
AC Disconnection ratings 480 / 600 20 A Break L1-L2-L3
AC over-current protection devices (OCPD) Current limiting inverter, OCPD provided by branch circuit breaker
AC LOTO provision LOTO in OPEN, tamper proof option CLOSED
AC input terminals / conductor size per L1 - L3, N 4-14 / 12 AWG

Technical Data XP10U H4 / H6 (with optional PSD)
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
DC Disconnection means Rotary switch accessible from outside of enclosure
DC Disconnection ratings 20 A - Break Pos and Negative
DC over-current protection devices (OCPD) 8 x Touch safe fuse holders with 20 A rating
DC LOTO provision LOTO in OPEN
DC input terminals / conductor size per channel
A - B 4 Pos and 4 Neg / 6-14 AWG
Mechanical and environmental specications
Mechanical integration Wall mount
Enclosure construction Cast Aluminum
Unit weight with / without PSD (lb / kg) (100 / 45) / (88 / 40)
Unit dimensions with / without PSD
HxWxD (in / mm)
(32 x 16.5 x 7.9 / 690 x 420 x 200)
(27.2 x 16.5 x 7.9 / 690 x 420 x 200
Operating temp range (°F / °C) (-13 to 140 / -25 to 60)
Storage temp range (°F / °C) (-22 to 158 / -30 to 70)
Noise emissions (db) < 55
Humidity % 0 to 95 non condensing
Enclosure rating - inverter and PV system
disconnect NEMA 4
Cooling Forced convection with variable speed fan
Altitude (ft / m) 6500 / 2000
Communications and user interface
User interface Graphical user interface with 3 LED status indicators
Connectivity (Ethernet / USB / RS485 / S0 output)
Safety features and regulatory compliance
UL / IEEE / CSA / FCC UL 1741 2nd Ed 2010 * / CSA C22.2No 107.1 / IEEE 1547 / FCC Class A
Fault signal relay Potential free normally open contact
Polarity safeguard Short circuit diode
GFDI compliant with NEC 690.35 for use with
ungrounded PV system arrays
IEC 62109-2 certied by Bureau of VERITAS for residual ground fault
current isolation monitor and interrupter function
Table 1: Electrical Data

Technical Data XP10U H4 / H6 (with optional PSD)
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
. Trip Ievel settings to shutdown Inverter
No. Description Trip setting Trip time
1 DC Input Over Voltage Level 1 550 V_DC 2 sec
2 DC Input Over Voltage Level 2 600 V_DC 20 msec
3 DC Input Under Voltage 200 V_DC 1 sec
4 DC Input Over Current (SW) 23 A_DC 100 µsec
5 DC Input Instantaneous Over Current (HW) 35 A_DC 2 µsec
6 DC Link Instantaneous Over Voltage 1050 V_DC 200 µsec
7 DC Link Instantaneous Under Voltage 825 V_DC 1 msec
8 Inverter Over Current 21 A_peak 100 µsec
9 Inverter Instantaneous Over Current 25 A_peak 2 µsec
Table 2: Trip level settings to shutdown Inverter
. Trip Ievel settings to stop Inverter
Description Minimum
level
Maximum
level
Default
level
Minimum
time
Maximum
time
Default
time
Line Under Voltage Fast 50 % 88 % 50 % 0.16 sec 0.16 sec 0.16 sec
Line Under Voltage Slow 50 % 100 % 88 % 0.16 sec 2 sec 2 sec
Line Over Voltage Fast 110 % 110 % 110 % 0.16 sec 0.16 sec 0.16 sec
Line Over Voltage Slow 100 % 110 % 110% 0.16 sec 1 sec 0.16 sec
Line Under Frequency Level 1 57 Hz 59.8 Hz 59.3 Hz 0.16 sec 300 sec 0.16 sec
Line Under Frequency Level 2 57 Hz 57 Hz 57 Hz 0.16 sec 0.16 sec 0.16 sec
Line Over Frequency 60 Hz 60.5 Hz 60.5 Hz 0.16 sec 0.16 sec 0.16 sec
Table 3: Trip level settings to stop Inverter

Transportation and Delivery
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
 Transportation and Delivery
. Delivery
Every inverter leaves our factory in proper electrical and mechanical condition. Special packaging ensures that they are
transported safely. The shipping company is responsible for any transport damage that occurs.
Scope of delivery
•  inverter
•  wall bracket
•  gland plate
•  installation kit
• Documentation set (Instruction manuals for operator and authorized electricians)
Checking your delivery
. Thoroughly inspect your inverter.
. Immediately notify the shipping company in case of the following:
–Damage to the packaging that indicates that the inverter may have been damaged
–Obvious damage to the inverter
. Immediately send a damage report to the shipping company.
The damage report must be delivered to the shipping company as soon as possible after the receipt of the inverter. We
will be glad to help you, if necessary.
. Transportation
WARNING
Impact hazard, risk of breakage to the inverter
›Securely pack the inverter for transport.
›Carefully transport the inverter using the the carrying handles of the pallet.
›Do not subject the inverter to shocks.
For safe transportation of the inverter, use the holding openings in the carton.

Mounting the Inverter
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
 Mounting the Inverter
DANGER
Risk of fatal injury from re or explosions
Fire caused by ammable or explosive materials in the vicinity of the inverter can lead to serious injuries.
›Do not mount the inverter in an area at risk of explosion or in the vicinity of highly ammable materials.
CAUTION
Risk of burns from hot housing components.
Coming into contact with the housing can cause burns.
›Mount the inverter so that it cannot be touched unintentionally.
Installation space
• The ideal installation space would be as dry as possible, climate-controlled, with the waste heat dissipated away from
the inverter
• Unobstructed air circulation
• When installing the unit in a control cabinet, provide forced ventilation so that the heat is suciently dissipated
• Easily accessible from the front and sides
• Protected from direct sunshine outdoors
• For easy operation, ensure during installation that the display is slightly below eye level.
Wall
• With sucient load-bearing capacity
• Accessible for installation and maintenance
• Made from heat-resistant material (up to °F/°C)
• Flame resistant
• Minimum clearance during installation: see Figure  on page  and Figure  on page .
CAUTION
Use suitable mounting xtures.
›Only use the supplied mounting xtures.
›Mount the inverter upright on a vertical wall only.
NOTICE
Power reduction due to heat accumulation.
If the recommended minimum clearances are not observed, the inverter can have power regulation and a
protective shutdown due to insucient ventilation and the associated heat
›Maintain minimum clearances.
›Provide for sucient heat dissipation.

Mounting the Inverter
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
54 3/5
16
10 59/260
22 1/4
44 1/10
13
Figure : Instructions for wall mounting Figure : Drill stencil for wall mounting with minimum clearances (inches)
1
2
3
10 in
10 in
10 in
Clearance from ceiling 20 in
Clearance from another inverter 27 3/5 in
Clearance from the oor 20 in
Clearance from another inverter 27 3/5 in
4
5
Figure : Minimum clearances/mounting plate
Key
1 Mounting screw anchors - not included 4 Detachment protector
2 Mounting plate 5 Inverter suspension brackets (back of housing)
3 Mounting screws - not included
Mounting the inverter
. Mark the positions of the drill holes using the cut-outs in the mounting plate.
NOTICE: The minimum clearances between two inverters, or the inverter and the ceiling/oor have already been
taken into account in the drawing.
. Fix mounting plate to the wall with the mounting screws.
Make sure that the mounting plate is oriented correctly.
. Hang the inverter on the mounting plate using the suspension brackets on the back of the housing.
. Fix the inverter with the enclosed screws to the detachment protector at the connection area.
» The mounting of the inverter is complete. Continue with the installation.

Installing the Inverter
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
 Installing the Inverter
DANGER
Lethal voltages are still present in the terminals and leads of the inverter even after the inverter has
been switched o and disconnected.
Severe injuries or death may result if the leads and terminals in the inverter are touched.
Only authorised electricians who are approved by the supply grid operator may open and install the
inverter.
The inverter must be mounted in a xed position before being connected electrically.
›Observe all safety regulations and the currently applicable technical connection specications of the
responsible power supply company.
›Disconnect the AC and DC circuits.
›Lock Out and Tag Out the AC and DC circuits in compliance with local regulations.
›Assure that the AC and DC circuits are completely de-energized.
›Connect the inverter only after the aforementioned steps have been taken.
NOTICE
Install the inverter in accordance with NFPA  and additional local requirements.
. Opening the connection area
Opening the connection area - XPU H / H and XPU H / H PSD
↻You have mounted the inverter on the wall.
. Without PSD - unscrew the four T Torx screws from the front side of the connection cover.
With PSD - insert blade into PSD cover lock and twist counter clockwise to release. Turn the AC disconnect to the o
position to release the cover interlock.
. Remove the connection cover.
. Terminate both AC and DC circuits in accordance with the NFPA  and other local requirements.

Installing the Inverter
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
. Knock-outs (KO) and circuit entry
.. Accessing the XPU H / H inverter AC and DC circuit connections
The inverter is shipped with a gland plate which seals the inverter electronics. You must remove the gland plate and
have holes fabricated to the dimensions of the desired trade size knock outs from /” to ”. The XPU inverter is NEMA 
rated. KACO requires that you use UL B watertight conduit connection at the conduit entrance.
In order to avoid interference between current-carrying leads and interface cables, adhere to the following drawings:
3
2
1
4
Figure : Gland plate
Key
1 Connection area for DC leads 3 Connection area for AC leads
2 Connection area for interface and
grounding leads
4USBport
.. Accessing the XPU H / H PSD inverter AC and DC circuit connections
The integrated PSD is a NEMA  enclosure. KACO requires that you use UL B watertight conduit connections at the
conduit entrances.
Figure  shows the recommended placement, and the trade size K.O’s.
In order to avoid interference between current-carrying leads and interface cables, adhere to the following drawings:
. Making the electrical connections
Make the connection to the PV array and the grid connection via the PCB terminals in the connection area of the inverter.
Maintain the following conductor cross-sections:
AC circuit Inv / PSD
L1-L3 / N
DC circuit Inv / PSD
Max. conductor cross-section without wire sleeves 6 / (4 / 12) AWG 8 / 6 AWG
Length of insulation to be stripped o 2/5 in 3/5 in

Installing the Inverter
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
.. Connecting the inverter to the power grid
The grid connection leads are connected on the right side of the connection area (see gure ).
DANGER
Risk of fatal injury due to electric shock
Severe injuries or death will result if the live connections are touched.
›Disconnect the inverter from all power sources before you insert the grid power lead into the unit.
CAUTION
Risk of re
Insucient over-current protection can increase the risk of re.
›Connect only to a circuit provided with a branch circuit over-current protection in accordance with the
national electrical code ANSI/NFPA .
›XPU-H / PSD*:  A
›XPU-H / PSD*:  A
* OCPD rating unchanged with PSD
AC circuit voltage drop of % or less is recommended for runs of greater than  feet from the point of common coupling (PCC).
AC conductor ampacity calculations are based on the NFPA  and additional requirements.
NOTICE
This unit is provided with adjustable trip limits and can be aggregated above kW on a single point of
common connection.
NOTICE
The installation shall indicate wiring methods in accordance with NFPA  and additional local require-
ments.
NOTICE
Use copper conductors only.
NOTICE
When impedance of the AC circuit to the utility connection is high, the voltage at the grid terminals of the
inverter will increase during feed-in to the utility. The inverter monitors this voltage, and if the value
exceeds the country-specic threshold value, the inverter will disconnect with an error message.
AC circuit voltage drop of % or less is recommended for runs of greater than  feet from the point of
common coupling (PCC).
AC conductor ampacity calculations are based on the NFPA  and additional requirements.

Installing the Inverter
Page  Installation Instructions blueplanet XPU H / H and XPU H / H PSD
Connecting the inverter to the utility grid
↻You must remove the gland plate and have holes fabricated to the dimensions of the desired trade size knock outs
from /” to ”. The XPU inverter is NEMA  rated. KACO requires that you use UL B watertight conduit connec-
tion at the conduit entrance.
. Strip AC circuit conductors /” per section .
. Route the AC circuit conductors to the AC terminals.
. Open the locks of the PCB terminals.
. Connect the AC circuit to the PCB terminals, and in accordance with the PCB labeling, L, L, L, N, and Gnd.
. Close the locks of the PCB terminals.
. Check that all connected conductors are tightly seated.
» The inverter is now connected to the utility grid.
NOTICE
An AC branch circuit protection must be provided in accordance with the NFPA  and other local require-
ments. The maximum branch circuit protection is stated in Section , and ...
If a residual current circuit breaker is necessary due to local requirements, KACO requires that you must
use a type A AFI (AC/DC-sensitive residual current circuit breaker).
.. Connecting the PV array
Connect the PV array to the  DC positive and the  DC negative connection terminals in the connection area of the
inverter, or the PSD.
DANGER
Risk of fatal injury due to contact voltages.
›During installation: Electrically disconnect the DC positive and DC negative from the protective earth
(PE).
Removing the connection without previously disconnecting the inverter from the DC array can result in a
hazard to health and damage to the inverter.
MPP
tracker A
MPP
tracker B
Figure : Connection terminals for DC positive and DC negative leads

Installing the Inverter
Installation Instructions blueplanet XPU H / H and XPU H / H PSD Page 
... Before the connection
Ensure that there is no ground fault
. Determine the DC voltage between the
–Protective earth (PE) and the positive lead of the PV array
–Protective earth (PE) and the negative lead of the
PV array
If stable voltages can be measured, there is a ground fault in the DC generator or its wiring. The ratio between the
measured voltages gives an indication as to the location of this fault.
. Rectify any faults before taking further measurements.
. Determine the electrical resistance between the
–Protective earth (PE) and the positive lead of the PV array
–Protective earth (PE) and the negative lead of the PV array
Low resistance (<  MΩ) indicates a high-ohm ground fault of the PV array.
. Rectify any faults before connecting the PV array.
... Maximum input power
The input power of the inverter is limited only by the maximum input current of . A per input. This causes the maxi-
mum input power per path to increase with the input voltage.
NOTICE
The overall power of the unit continues to be limited. If one input is connected to more than P(DCmax)/,
the maximum input power of the second input decreases accordingly. Take care that the maximum input
power is not exceeded.
... Standard  MPP PV system connection
Equal MPP voltages must be applied to input  and , as well as inputs  and . The MPP voltages of the two DC paths can
be dierent. They are tracked by separate, independently operating MPP trackers (MPP trackers A and B). (n=n, n=n).
Electrical data for standard connection
Connection of the DC inputs Number of modules per string n=n, n=n
Pmax per string < 6 kW
MPP trackers A+B together < 12 kW
Imax < 18.6 A per tracker
