Wine Cooler
Bodega
WCL 20629
115V~60Hz 130W
www.KALORIK.com


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
2 WCL 20629 - 140728
Assembly page 2/20
Fax [phone]
GB
1 “Temp -” for upper zone
2 “Temp +“ for upper zone
3 LCD display
4 “Temp -” for lower zone
5 “Temp +“ for lower zone
ES
1 “Temp -” de la zona superior
2 “Temp +“ de la zona superior
3 Pantalla LCD
4 “Temp -” de la zona inferior
5 “Temp +“ de la zona inferior


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
3 WCL 20629 - 140728
Assembly page 3/20
Fax [phone]
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
 Read all instructions before use!
 After removing the wine cooler from the package, look it over to
make sure that it is in good condition. If there are any issues, do
not use the appliance—contact the authorized service center
instead.
 Plastic bags, nails, etc. should be kept out of the reach of
children.
 Check that the voltage in your home corresponds to what is
stated on the appliance.
 When in use, never leave the appliance unsupervised.
 Never leave children unsupervised when their taking beverages
out or putting them in the cooler. As a rule, keep out of the reach
of children as the appliance is not designed to be used by them.
 From time to time, check the power cord for damage. Never use
the appliance if the cord or appliance shows any signs of
damage.
 Never move the appliance by pulling on the cord. Make sure
that the cord cannot get caught. Do not wind the cord around
the appliance and do not bend it. Keep the power cord away
from sources of heat.
 Only use the appliance for domestic purposes and in the way
indicated in these instructions.
 Do not operate any appliance with a damaged cord or plug, or
after it malfunctions or has been damaged in any manner. Return
appliance to the nearest authorized service facility for
examination, repair, or adjustment.
 Never use the appliance near hot surfaces or in direct sunlight.
 Never use the appliance outside and always place it in a dry
environment.
 Stand the appliance on a sturdy table or flat surface in order to
avoid it falling. Ensure that there is at least a 10 cm / 4 in
clearance around the sides and an 8 cm / 3 in clearance at the


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
4 WCL 20629 - 140728
Assembly page 4/20
Fax [phone]
back of the cooler in order to allow adequate ventilation.
Kitchen units (cupboards) should be at least 5 cm / 2 in away
from the top of the appliance in order to assure adequate
ventilation.
 Do not place objects on top of the appliance.
 Do not use extension cords.
 Never use accessories that are not recommended by the
producer. They could constitute a danger to the user and risk to
damage the appliance.
 Plug the appliance directly into the power outlet; do not use
extension cords or multiple power sockets.
 This cooler is designed to store wine bottles, however, if placing
food inside, ensure that there is sufficient airflow between items.
 Do not place hot beverages into the appliance; let them cool
down to room temperature beforehand.
 Close the cooler door immediately after putting items inside so
that the inside temperature will not rise dramatically.
 When positioning or moving the appliance, ensure that it is not
set horizontally or inclined less than 45° or turned upside down.
 Should you notice any damage on the appliance, please unplug
it immediately and contact a competent qualified service
company.
 All repairs should be made by a qualified service company
authorized by the manufacturer of the appliance.
 To reduce the risk of fire, replace only with same type fuse.
 nplug the appliance before cleaning or when it is not in use.
 To avoid risk of child entrapment, leave the shelves in place so
children cannot easily climb inside, even when the appliance is
not in use.
 Avoid exposing to direct sunlight and high temperature.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
Save time and money. Before you call for service, check the
troubleshooting section at the end of this manual. It lists the causes of
some common issues that you can correct yourself.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
5 WCL 20629 - 140728
Assembly page 5/20
Fax [phone]
Warning:
Changes or modifications made to this unit that are not expressly
approved by the manufacturer will void the warranty of the unit.
3 PRONG PLUG INSTRUCTIONS
For your personal safety, this appliance must be grounded. This
appliance is equipped with a power supply cord having a 3-prong
grounding plug. To minimize possible shock hazard, the cord must be
plugged into a mating 3-prong, grounding type, wall receptacle,
grounded in accordance with the National Electrical Code
ANSI/NFPA 70 latest edition and all local codes and ordinances. If a
mating wall receptacle is not available, it is the personal
responsibility and obligation of the customer to have a properly
grounded, 3-prong, wall receptacle installed by a qualified
electrician.
TECHNICAL DATA
Volume: 52 liters / 1.85 cu.ft.
Capacity: 18 bottles of 750 ml
Cooling zones: 2
Adjustable temperature: 45°F to 64°F (7°C – 18°C)
CFC-Free
NOTE: this appliance is not a standard refrigerator. The maximum
cooling capacity is around 30 degrees F (15 degrees C) below the
ambient temperature.
POSITIONING THE APPLIANCE
For best results, use the height-adjustable foot to level the wine
cooler. This will allow it to stand perfectly horizontal, which allows for
stability.
The height-adjustable foot is located under the lower hinge. It is
smaller than the feet placed on the other 3 corners of the appliance.
It is positioned in a threaded insert on the hinge, marked by an arrow


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
6 WCL 20629 - 140728
Assembly page 6/20
Fax [phone]
in the picture below. Turn the foot clockwise or counter-clockwise to
adjust its height and to ensure the perfect horizontality of the unit.
CAUTION: The wine cooler should not be built-in. Standalone use
only!
OPERATION
CAUTION: Before connecting the appliance to an electrical power
supply, let it stand for about 4 hours. This will reduce the possibility of
malfunctioning in the cooling system due to transport handling.
• Before use, clean the appliance thoroughly, especially inside the
cavity (See Cleaning and Maintenance).
• Rearrange the shelves in the cavity properly if they are not
correctly placed.
• Make sure that the voltage in your home is compatible with the
appliance.
• Position the appliance in a cool place, on a stable surface near a
wall outlet, with sufficient clearance on all sides to allow proper
ventilation. Do not attempt to install the appliance into a built in
unit!
• Plug in the appliance into an earthed wall outlet.
• Once connected to a power source, the fans will start turning
and the wine cooler will start cooling. The cooler will need up to
one and a half hours to reach 15°C/ 60°F and up to 4 hours to
reach the temperature set up as the factory standard.
NOTE: The inside temperature of the thermoelectric wine cooler
depends on exterior the room temperature. To reach the minimum


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
7 WCL 20629 - 140728
Assembly page 7/20
Fax [phone]
temperatures indicated below, the appliance should be located in a
room whose temperature is maximum 75°F / 25ºC!
Temperature control and display
The upper zone of the appliance is for storage of white wine,
featuring a temperature range from 45°F to 54°F (7°C to 12°C). The
lower zone is for storage of red wine with a temperature range from
54°F to 64°F (12°C to 18°C).
The temperature range of the wine cooler is intended for 45°F to 64°F
(7°C to 18°C).
The display usually shows the average current temperature of each
cooling zone at any given moment.
Manual temperature setting
A standard temperature for each cavity is preset at the factory. If
you want to change the target temperature for a cooling zone,
please select the cooling zone and select accordingly.
The temperature of the wine cooler can be set anywhere from 45°F
to 64°F (7°C to 18°C) using the temperature up “△”and
temperature down “▽”buttons as follows:
1) There are four buttons on the panel: on the left, push “Temp
△
” to
increase the temperature or push “Temp
▽
” to decrease the
temperature of the upper zone. On the right, push “Temp △
” to
increase the temperature or push “Temp
▽
” to decrease the
temperature of the lower zone.
2) When the unit is plugged into a wall outlet, the system starts
cooling. The target temperature is set on certain level, which
means that if the inner temperature reaches the set point, the
thermostat will stop the system from cooling further, so that the
temperature in the cabinet will slowly rise.
3) When the inside temperature rises above the set point, the
thermostat will let the unit start cooling again.
4) The wine cellar will repeatedly follow these cooling cycles, which
is normal for any thermostatically-controlled device.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
8 WCL 20629 - 140728
Assembly page 8/20
Fax [phone]
Light switch
You can turn the interior light ON or OFF by pressing the light switch
inside the upper compartment.
CLEANING
• nplug the appliance from the wall outlet before cleaning it.
• Clean the exterior of the appliance with water and a mild
household detergent. Do not use abrasive cleaners as they can
damage the finish of the appliance.
• Clean the interior of the appliance with lukewarm water and a bit
of vinegar, or baking soda.
• If needed, remove the shelves in the cavity by sliding them out;
clean them with water and a mild liquid detergent. Do not put
any parts in the dishwasher.
• Never use metal utensils or harsh, abrasive products to clean the
appliance.
• Never immerse the appliance in water or any other liquid.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
9 WCL 20629 - 140728
Assembly page 9/20
Fax [phone]
TROUBLESHOOTING
Symptoms Possible cause Solutions
The appliance
does not cool
– Plug not connected
to power source;
– Low voltage;
– Fuse has tripped
– Check if the unit is
plugged in and if the wall
outlet is operational.
– Ensure the voltage of the
wall outlet is compatible
–
Change the fuse
The temperature
inside is not cold
enough
– The cooler is placed
too close to a heat
source;
– Bad ventilation;
– Fans don’t work;
– The door is not
closed tightly or
opened too
frequently or for too
long time;
– Keep the cooler away
from direct sunlight or
other heat sources.
– Place the cooler in an
area with good ventilation
and make sure that the
fans are clear from foreign
objects.
– Check whether the unit is
connected to a power
source.
– Close the door tightly and
don’t open the door too
frequently or for too long.
– se the unit standalone,
never built-in.
There is an odd
smell inside the
cooler
– Check whether
anything inside has
spoiled
– Wrap the source of the
smell or remove it.
– Clean the cavity with pure
baking soda.
– Only use the unit to store
wine or bottles.
The inside light
flashes
– Set the temperature
higher than the inner
temperature;
– Adjust the temperature.
There is frost
inside the
appliance
– Too much humidity
or too low of a
temperature inside
the case
– nplug the unit, let it
defrost completely, and
then connect to wall
outlet again after
removing the water
remaining inside the unit.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
10 WCL 20629 - 140728
Assembly page 10/20
Fax [phone]
WARRANTY
We suggest that you complete and return the enclosed Product
Registration Card promptly to facilitate verification of the date of
original purchase. However, return of the Product Registration Card is
not a condition of these warranties. You can also fill out this warranty
card online, at the following address: www.KALORIK.com
This KALORIK product is warranted in the .S.A. for 1 year from the
date of purchase against defects in material and workmanship. This
warranty is not transferable. Keep the original sales receipt. Proof of
purchase is required to obtain warranty performance.
During this period, if the KALORIK product, upon inspection by
KALORIK, is proven defective, it will be repaired or replaced, at
Kalorik’s option, without charge to the customer. If a replacement
product is sent, it will carry the remaining warranty of the original
product.
This warranty does not apply to any defect arising from a buyer's or
user's misuse of the product, negligence, failure to follow KALORIK
instructions noted in the user’s manual, use on current or voltage
other than that stamped on the product, wear and tear, alteration
or repair not authorized by KALORIK, or use for commercial purposes.
There is no warranty for glass parts, glass containers, filter basket,
blades and agitators, and accessories in general. There is also no
warranty for parts lost by the user.
ANY WARRANTY OF MERCHANTABILITY OR FITNESS WITH RESPECT TO
THIS PROD CT IS ALSO LIMITED TO THE ONE YEAR LIMITED WARRANTY
PERIOD.
Some states do not allow limitation on how long an implied warranty
lasts or do not allow the exclusion of incidental or consequential
damages, so the above limitations may not apply to you. This
warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
