KaVo L-MOTOR 181 DB INTRAmatic I User manual

Instructions for use
L-MOTOR 181 DB INTRAmatic I - REF 0.535.5060
D
Distributed by:
KaVo Dental GmbH
Bismarckring 39
D-88400 Biberach
Phone [phone]
Fax [phone]
Manufacturer:
Kaltenbach & Voigt GmbH
Bismarckring 39
D-88400 Biberach
www.kavo.com
T
Table of contents
1 User instructions ....................................................................................................................................................................... 7
2 Safety ................................................................................................................................................................................... 10
2.1 Description of safety instructions ..................................................................................................................................... 10
2.1.1 Description of safety instructions: Warning symbol ................................................................................................ 10
2.1.2 Description of safety instructions: Structure .......................................................................................................... 11
2.1.3 Description of safety instructions: Description of danger levels ................................................................................. 12
2.2 Safety instructions ........................................................................................................................................................ 14
Table of contents 1
3
3Product description .................................................................................................................................................................. 19
3.1 Purpose – Intended use ................................................................................................................................................ 20
3.2 Technical Data ............................................................................................................................................................. 22
3.3 Transportation and storage conditions .............................................................................................................................. 24
3.4 Operating conditions ..................................................................................................................................................... 26
4 First use ................................................................................................................................................................................ 27
4.1 Check the pressure ....................................................................................................................................................... 28
5 Operation .............................................................................................................................................................................. 30
5.1 Connecting the drive motor to the supply hose ................................................................................................................... 31
Table of contents 2

5.2 Regulating the spray water ............................................................................................................................................. 32
5.3 Attaching attachment instruments to the drive motor ............................................................................................................ 33
5.4 Removing the attachment instrument from the drive motor .................................................................................................... 36
5.5 Regulating the speed and changing the direction of rotation .................................................................................................. 36
6
6Troubleshooting ...................................................................................................................................................................... 37
6.1 Check for malfunctions at initial startup ............................................................................................................................. 37
6.2 Troubleshooting ........................................................................................................................................................... 39
6.2.1 Troubleshooting: Exchanging the O-rings ............................................................................................................ 39
Table of contents 3
7
7Preparation methods according to ISO 17664 ............................................................................................................................... 42
7.1 Preparation at the site of use .......................................................................................................................................... 42
7.2 Cleaning ..................................................................................................................................................................... 43
7.2.1 Cleaning: Manual external cleaning .................................................................................................................... 44
7.2.2 Cleaning: Automated external cleaning ............................................................................................................... 44
7.2.3 Cleaning: Manual internal cleaning ..................................................................................................................... 45
7.2.4 Cleaning: Automated internal cleaning ................................................................................................................ 45
7.3 Disinfection ................................................................................................................................................................. 46
7.3.1 Disinfection: Manual external disinfection ............................................................................................................ 47
Table of contents 4
7.3.2 Disinfection: Manual internal disinfection ............................................................................................................. 48
7.3.3 Disinfection: Automated external and internal disinfection ....................................................................................... 49
7.4 Drying ....................................................................................................................................................................... 49
7.5 Care products and systems - Servicing ............................................................................................................................. 50
7.5.1 Care products and systems - Servicing: Care with KaVo Spray ................................................................................ 52
7.5.2 Care products and systems - Servicing: Care with KaVo SPRAYrotor ....................................................................... 53
7.5.3 Care products and systems - Servicing: Care with KaVo QUATTROcare ................................................................... 54
7.6 Sterilisation ................................................................................................................................................................. 56
7.7 Storage ...................................................................................................................................................................... 56
Table of contents 5
8
8Auxiliary equipment ................................................................................................................................................................. 57
9 Warranty terms and conditions ................................................................................................................................................... 59
Table of contents 6

1
1
User instructions
Dear User
Congratulations on purchasing this KaVo quality product. By following the instructions below you
will be able to work smoothly, economically and safely.
© Copyright by KaVo Dental GmbH
User instructions 7
S
Symbols
Refer to the chapter on Safety/Warning symbol
Important information for users and service technicians
Action request
User instructions 8
CE mark (European Community). A product with this mark meets the requirements of
the relevant EC directives, i.e. the standards applicable in Europe.
Non-sterilisable
Target group
This document is intended for dentists and their assistants. The section on starting up is also
intended for service technicians.
User instructions 9
2
2
Safety
2.1.1
Description of safety instructions: Warning symbol
Warning symbol
Safety 10

2
2.1.2
Description of safety instructions: Structure
DANGER
The introduction describes the type and source of the hazard.
This section describes the potential consequences of non-observance.
▶
The optional step includes necessary measures for hazard prevention.
Safety 11
2
2.1.3
Description of safety instructions: Description of danger levels
The safety instructions listed here, together with the three levels of danger will help avert property
damage and injury.
CAUTION
CAUTION
indicates a hazardous situation that can cause damage to property or mild to moderate injuries.
Safety 12
WARNING
WARNING
indicates a hazardous situation that can cause death or serious injury.
DANGER
DANGER
indicates a hazardous situation that can directly cause death or serious injury.
Safety 13
2
2.2
Safety instructions
WARNING
Hazard to the care provider and patient.
Irregular running noise, significant vibration, overheating, imbalance or insufficient grip.
▶
Stop working and contact service support.
Safety 14

CAUTION
Damage from soiled and moist cooling air.
Contaminated and moist cooling air can cause malfunctions and lead to premature bearing
wear.
▶
Make sure that the supply of cooling air is dry, clean and uncontaminated according to
ISO 7494-2.
Safety 15
CAUTION
Damage due to contaminated water.
Ensure that the water quality generally complies with ISO 7494-2. Permissible pH value 7.2 to
7.8.
Safety 16
CAUTION
Premature wear and malfunctioning from improper storage during long periods of nonuse.
Reduced product life.
▶
The medical device should be cleaned, serviced and stored in a dry location, according to
instructions, before long periods of nonuse.
The following individuals are authorized to repair and service KaVo products:
▪ Technicians at KaVo branches throughout the world
▪ Technicians specially trained by KaVo
Safety 17
To ensure proper function, the medical device must be set up according to the reprocessing meth‐
ods described in the KaVo Instructions for Use, and the care products and care systems descri‐
bed therein must be used. KaVo recommends specifying a service interval at the dental office for
a licensed shop to clean, service and check the functioning of the medical device. This service
interval depends on the frequency of use and should be adjusted accordingly.
Service may only be carried out by KaVo-trained repair shops using original KaVo replacement
parts.
Safety 18

3
3
Product description
L-MOTOR 181 DB INTRAmatic (
Mat. no. 0.535.5060
)
Product description 19
3
3.1
Purpose – Intended use
Purpose:
The motor is:
▪ an air motor intended to operate/drive a dental handpiece or contra-angle handpiece
▪ only for dental treatment by a dental professional. The product may not be changed or used
for any other purpose since this may be hazardous
▪ a medical device according to relevant national statutory regulations
Product description 20
P
Proper use:
According to these regulations, this medical device may only be used for the described application
by a knowledgeable user. The following must be observed:
▪ the applicable health and safety regulations
▪ the applicable accident prevention regulations
▪ these instructions for use
Product description 21
According to these regulations, it is the responsibility of the user to:
▪ only use equipment that is operating correctly,
▪ use the equipment for the proper purpose,
▪ protect him or herself, the patient and third parties from danger, and
▪ avoid contamination from the product.
3
3.2
Technical Data
Drive speed 5,000 to 20,000 min-1
Drive pressure 2.2 to 2.7 bar (32 to 39 psi)
Product description 22

Air consumption up to 60 Nl/min
Idle torque 2.3 Ncm at 2.2 bar (32 psi)
The INTRAmatic L motor can be attached to all hoses with Borden 2-hole connection.
With INTRAmatic 1 coupling.
All straight and contra-angle handpieces with INTRAmatic connection ISO 3964 can be attached.
Product description 23
3
3.3
Transportation and storage conditions
CAUTION
It is hazardous to start up the medical device after it has been stored strongly refrigerated.
This can cause the medical device to malfunction.
▶
Prior to start-up, very cold products must be heated to a temperature of 20°C to 25°C
(68°F to 77°F).
Product description 24
Temperature: -20°C to +70°C (-4°F to +158°F)
Relative humidity: 5% RH to 95% RH absence of condensation
Air pressure: 700 hPa to 1060 hPa (10 psi to 15 psi)
Protect from moisture
Product description 25
3
3.4
Operating conditions
Temperature: +5 °C to +40 °C (41 °F to 104 °F)
Maximal rel. humidity: < 80 %
Air pressure: 700 hPa to 1060 hPa (10 psi to 15 psi)
Product description 26

4
4
First use
WARNING
Hazard from contaminated products.
Infection danger to the care provider and patient.
▶
Before first use and after each use, prepare the product.
First use 27
4
4.1
Check the pressure
CAUTION
Compressed air connections on device.
Dirty and moist compressed air causes premature bearing wear.
▶
Ensure dry, clean and uncontaminated compressed air according to ISO 7494-2.
First use 28
▶ Insert the test manometer (M
Mat. no. 0.411.8531
) between hose and motor and check the fol‐
lowing pressures:
- Drive pressure: 2.2 to 2.7 bar (32 to 39 psi) (recommended: 2.5 bar (36 psi))
- Air and water: 0.8 to 1.0 bar (12 to 15 psi)
First use 29
5
5
Operation
Note
At the beginning of each workday, the water-conducting systems should be rinsed for at least 2
min. without the instrument being attached; if there is a risk of contamination from reflux or back
suction, the system must be rinsed for 20-30 seconds.
Operation 30

5
5.1
Connecting the drive motor to the supply hose
▶ Attach plug-in fitting to the motor connection and screw tight in clockwise direction using the
sleeve.
Note
Details on the hose connection can be obtained from the manufacturer.
Operation 31
5
5.2
Regulating the spray water
CAUTION
Hazard from insufficient spray water.
Overheating of the medical device and damage to the tooth.
▶
Adjust the water amount for spray cooling, with the spray ring fully opened, to approx. 80
cm3/min.
▶
Comply with the settings recommended by the manufacturers.
Operation 32
▶ Rotate the spray tap of the hose or device to adjust the water portion of the spray.
5.3
Attaching attachment instruments to the drive motor
All straight and contra-angle handpieces with INTRAmatic connection ISO 3964 can be attached.
Operation 33
CAUTION
Attaching and removing instruments during rotation.
Can cause damage.
▶
Do not attach or remove the instruments during rotation.
▶
Only use reliable handpieces.
Operation 34

▶ Attach the KaVo instrument to the motor until it locks in place.
▶ Pull on it to make sure that the instrument is securely attached to the motor.
Operation 35
5
5.4
Removing the attachment instrument from the drive motor
▶ Pull the instrument off the motor in axial direction through a slight rotating motion.
5.5
Regulating the speed and changing the direction of rotation



▶ Rotate the regulating sleeve to regulate between idle ② in clockwise rotation ① or counter‐
clockwise rotation ③ and maximal speed in a continuous manner.
Operation 36
6
6
Troubleshooting
6.1
Check for malfunctions at initial startup
CAUTION
Missing or damaged O-rings.
Malfunctions and premature failure.
▶
Make sure that all O-rings are on the coupling and undamaged.
Troubleshooting 37
Note
Stop working if the O-ring is missing or damaged.
The motor runs too hot under load:
▶ Also check the handpiece.
When the speed drops or is uneven:
▶ Check the hose connection.
Troubleshooting 38

Motor coupling O-ring is missing:
▶ Replace O-rings.
6
6.2.1
Troubleshooting: Exchanging the O-rings
CAUTION
Vaseline, oils or other greases.
This can cause malfunctions.
▶
Do not use Vaseline, oils or other greases on this medical device.
Troubleshooting 39
Note
The O-rings on the motor attachment may only be lubricated with a cotton ball which has been
wetted with KAVO Spray.
▶ Press the O-rings between your fingers to form a loop.
▶ Slide the O-rings forwards and remove them.
Troubleshooting 40
▶ Insert new O-rings into the grooves and spray them with KaVo spray.
▶ Press the O-rings between your fingers to form a loop.
▶ Slide the O-rings forwards and remove them.
▶ Insert new O-rings into the grooves and spray them with KaVo spray.
Troubleshooting 41
7
7
Preparation methods according to ISO 17664
7.1
Preparation at the site of use
WARNING
Hazard from nonsterile products.
There is a risk of infection from contaminated medical devices.
▶
Take suitable personal protective measures.
▶ Remove all residual cement, composite or blood without delay.
Preparation methods according to ISO 17664 42

▶ The medical device must be dry when transported for reconditioning.
▶ Do not place it in a solution or similar.
▶ Recondition the medical device as soon as possible after treatment.
7
7.2
Cleaning
CAUTION
Malfunction of the product from cleaning in the ultrasonic unit.
▶
Only clean manually!
Preparation methods according to ISO 17664 43
7
7.2.1
Cleaning: Manual external cleaning
▶ Wipe the surface of the motor with a water-soaked cotton cloth and then dry with a soft cot‐
ton cloth.
7.2.2
Cleaning: Automated external cleaning
Not applicable.
Preparation methods according to ISO 17664 44
7
7.2.3
Cleaning: Manual internal cleaning
Not applicable.
7.2.4
Cleaning: Automated internal cleaning
Not applicable.
Preparation methods according to ISO 17664 45
7
7.3
Disinfection
CAUTION
Malfunctioning from using a disinfectant bath or chlorine-containing disinfectant.
Defects in the product.
▶
Disinfect manually only!
Preparation methods according to ISO 17664 46

7
7.3.1
Disinfection: Manual external disinfection
KaVo recommends the following products based on material compatibility. The microbiological ef‐
ficacy must be ensured by the disinfectant manufacturer.
▪ Mikrozid AF Liquid made by Schülke & Mayr
▪ FD 322 made by Dürr
▪ CaviCide made by Metrex
Consumables required:
▪ Cloths for wiping off the medical device.
Preparation methods according to ISO 17664 47
▶ Spray the disinfectant on a cloth, then wipe down the medical device and allow the disinfec‐
tant to act according to the instructions of the disinfectant manufacturer.
▶ Follow the instructions for use of the disinfectant.
7.3.2
Disinfection: Manual internal disinfection
Not applicable.
Preparation methods according to ISO 17664 48
7
7.3.3
Disinfection: Automated external and internal disinfection
Not applicable.
7.4
Drying
Manual Drying
▶ If there is any residual moisture after cleaning and disinfecting, soak up the residual mois‐
ture with a soft cotton cloth and then wipe dry.
Preparation methods according to ISO 17664 49
A
Automatic Drying
Not applicable.
7.5
Care products and systems - Servicing
CAUTION
Premature wear and malfunctions from improper servicing and care.
Reduced product life.
▶
Perform proper care regularly!
Preparation methods according to ISO 17664 50

The bearing sites of the INTRAmatic L motors are provided with a high-quality, lifelong lubrication.
Note
Excess fluids exiting the contra-angle handpiece (oil, cleanser or disinfectant) can penetrate the
motor and cause a malfunction. Please only care for all instruments according the care instruc‐
tions accompanying the instruments.
Note
KaVo only guarantees that its products will function properly when the care products used are
those listed as accessories, as they were tested for proper use on our products.
Preparation methods according to ISO 17664 51
7
7.5.1
Care products and systems - Servicing: Care with KaVo Spray
KaVo recommends servicing the product after each time it is used, i.e. after each cleaning.
▶ Unscrew the motor from the hose.
▶ Cover the product with the Cleanpac bag.
▶ Use an appropriate cannula and apply spray into the larger of the two tubes for one second.
Preparation methods according to ISO 17664 52
7
7.5.2
Care products and systems - Servicing: Care with KaVo SPRAYrotor
KaVo recommends servicing the product after each time it is used, i.e. after each cleaning.
▶ Unscrew the motor from the hose.
▶ Place matching care insert on the appropriate coupling on the
KaVo SPRAYrotor
and cover
the product with the Cleanpac bag.
Preparation methods according to ISO 17664 53
▶ Apply spray into the larger of the two tubes for one second.
S
See also:
Instructions for use K
KaVo SPRAYrotor
7.5.3
Care products and systems - Servicing: Care with KaVo QUATTROcare
Cleaning and care unit with expansion pressure for effective cleaning and care.
Preparation methods according to ISO 17664 54

KaVo recommends servicing the product after each time it is used, i.e. after each cleaning.
▶ Servicing the product.
See also:
Instructions for Use K
KaVo QUATTROcare
Preparation methods according to ISO 17664 55
7
7.6
Sterilisation
Non-sterilisable.
7.7
Storage
▶ Reprocessed products should be stored protected from dust with minimum exposure to
germs in a dry, dark and cool space.
Preparation methods according to ISO 17664 56
8
8
Auxiliary equipment
Available from dental suppliers.
Material summary Mat. no.
Seal 0.533.0042
O-ring 0.200.6120
Cleanpac 10 units 0.411.9691
Material summary Mat. no.
KaVo Spray 2112 A 0.411.9640
ROTAspray 2142 A 0.411.7520
Auxiliary equipment 57
Auxiliary equipment 58

9
9
Warranty terms and conditions
The following warranty conditions apply to this KaVo medical device:
KaVo provides the end customer with a warranty of proper function and guarantees zero defects
in respect of material and processing for a period of 12 months from the date of the invoice, sub‐
ject to the following conditions:
In case of justified complaints, KaVo will honour its warranty with a free replacement or repair.
Other claims of any nature whatsoever, in particular with respect to compensation, are excluded.
In the event of default, gross negligence or intent, this shall only apply in the absence of mandato‐
ry legal regulations to the contrary.
Warranty terms and conditions 59
KaVo shall not be liable for defects and their consequences that have arisen or may arise from
natural wear, improper handling, cleaning or maintenance, non-compliance with operating, main‐
tenance or connection instructions, calcination or corrosion, contaminated air or water supplies or
chemical or electrical factors deemed abnormal or impermissible in accordance with KaVo's in‐
structions for use or other manufacturer's instructions. The warranty granted does not usually ex‐
tend to lamps, light conductors made of glass and glass fibres, glassware, rubber parts, and the
colourfastness of plastic parts.
All liability is excluded if defects or their consequences originate from manipulations or changes to
the product made by the customer or a third party that is not authorised by KaVo.
Warranty terms and conditions 60
Warranty claims will only be accepted if the product is submitted along with proof of purchase in
the form of a copy of the invoice or note of delivery. The dealer, purchase date, type, and serial
number must be clearly evident from this document.
Warranty terms and conditions 61

0.589.2152 · kb · 20111020 - 03 · en
