KaZAM Trooper X3.5 User manual

USER MANUAL

ALL RIGHTS RESERVED
©2013. All rights are reserved. No part of this document can
be reproduced without permission. All trademarks and brand
names mentioned in this publication are property of their
respective owners.
While all the efforts have been made to ensure the accuracy
of contents in this manual, we presume no responsibility for
errors or omissions or statements of any kind, whether such
errors are omissions or statements resulting from negligence,
accidents, or any other cause. We operate a policy of
continuous development and reserve the right to make
changes, modifications and improvements to the device,
device features/specifications or any of its parts without prior
notice.
Your device may have preinstalled bookmarks and links for
third party internet sites and may allow you to access third
party sites. These are no affiliated with us, and we do not
endorse or assume liability for them. If you access such sites,
take precautions for security or content.
The limited warranty does not cover user manuals or any third
party software, settings, content, data or links, whether
included/downloaded in the product, whether included during
installment, assembly, shipping or any other time in the
delivery chain or otherwise and in any way acquired by you.
To the extent permitted by applicable law(s), we do not
warrant that any our software will meet your requirements, will
work in combination with any hardware or software
applications provided by a third party, that the operations of
the software will be uninterrupted or error free or that any
defects in the software are correctable or will be corrected.
User’s Manual is provided just to guide the user
about the functionality of the device. This does not
seem to be any certificate of technology. Some
functions may vary due to modifications and
up-gradations of software or due to printing mistake.

SAFETY PRECAUTIONS
Please read the following safety guidelines before using the
device.
Do not use the phone while you are driving.
Do not place magnetic storage media near your phone.
Radiation from the phone may erase the information
stored on them.
Keep your phone and its accessories away from
children.
Mobile phones can interfere with the functioning of
medical devices such as hearing aids or pacemakers.
People having active medical implants should keep
their cell phone at least 15 cm away from the implant.
Permanent hearing loss may occur if you use
earphones or headphones at high volume.
Use a wireless hands-free system (headphone/
headset) with a low power Bluetooth emitter.
Make sure the cell phone has a low SAR.
Keep your calls short or send a text message (SMS)
instead. This advice applies specially to children
adolescents and pregnant women.
Use cell phone when the signal quality is good.
Notice:
Do not dismantle the device or accessories otherwise,
manufacturer is not liable to pay for damages as the
device and accessories are not covered by warranty.
Use only original batteries and charging devices.
Please back up your important data timely and keep
them properly. The company is not liable for any failure
to call or loss of data due to mis-operation, poor signal
or power cut, etc.
All the screens in this manual are for reference only,
and some contents actually displayed may depend
upon the presetting of the service provider or the
network operator, or the SIM card. If any functions

referred to in this manual are different from those of
your device, please follow your device.
Do not put use it in a place with flammable gas such as
a petrol pumps. The temperature recommended for
using the device is 5-35℃. Do not touch the charger,
power cable or socket with wet hands. This may cause
an electric shock.
If your phone or any of its accessories do not
function normally, then please visit your nearest
authorized service facility. The qualified personnel
will assist you, and if necessary, will arrange for the
service.

TABLE OF CONTENTS
ALL RIGHTS RESERVED……………………………...1
SAFETY PRECAUTIONS………………………………3
TABLE OF CONTENTS…………………………………6
1. UNDERSTANDING YOUR DEVICE……………….8
1.1 GENERAL INFO…………………………………….8
1.0 DEVICE OVERVIEW……………………………….9
2. GETTING STARTED……………………………….10
2.1 INSTALLING CARDS & BATTERY……………..10
2.2 POWERING ON/OFF THE DEVICE…………….11
3. BASIC OPERATIONS……………………………...12
3.1 CALLING……………………………………………12
3.2 MESSAGING………………………………………12
3.3 CONTACTS………………………………………..13
3.4 EMAIL……………………………………………….14
3.5 BROWSER…………………………………………14
4. HOME SCREEN……………………………………..15
4.1 STATUS BAR………………………………………15
4.2 APPLICATION TAB…………………………….....15
4.3 CUSTOMIZING SCREEN………………………...15
5. MULTIMEDIA………………………………………..17
5.1 FILE MANAGER…………………………………...17
5.2 MUSIC PLAYER…………………………………...17
5.3 CAMERA……………………………………………17
5.4 SOUND RECORDER……………………………..17
5.5 GALLERY…………………………………………..17
5.6 FM RADIO………………………………………….17
6. NETWORK…………………………………………..19
6.1 WI-FI………………………………………………...19
6.2 3G…………………………………………………...19
6.3 BLUETOOTH………………………………………19
7. SETTINGS……………………………………………20
7.1 SIM MANAGEMENT………………………………20
7.2 WIRELESS & NETWOKS………………………...20
7.3 AUDIO PROFILES………………………………...20
7.4 DISPLAY……………………………………………20
7.5 STORAGE………………………………………….20
7.6 BATTERY…………………………………………..20
7.7 APPLICATIONS……………………………………21

7.8 LOCATION ACCESS……………………………...21
7.9 SECURITY…………………………………………21
7.10 LANGUAGE AND INPUT………………………..21
7.11 BACKUP & RESET………………………………22
7.12 ACCOUNTS………………………………………22
7.13 DATE AND TIME…………………………………22
7.14 SCHEDULE POWER ON/OFF…………………22
7.15 ACCESSIBILITY…………………………………22
7.16 ABOUT PHONE………………………………….22
8. APPLICATIONS AND UTILITIES………………...23
8.1 CALCULATOR……………………………………..23
8.2 CLOCK……………………………………………...23
8.3 GMAILTM………………………………………………23
8.4 LOCAL………………………………………………23
8.5 PLAY STORE………………………………………23

1. UNDERSTANDING YOUR DEVICE
1.1 GENERAL INFO
KAZAM Trooper X3.5 is a multi SIM phone that encloses
features, such as Andriod version 4.2, Wi-Fi, 1.0 GHz Dual
Core Processor, 3 MP Camera, etc. This phone is provided
with two SIM slots for two different SIM cards. The SIM card
inserted in the slot1 is called SIM1, and the other one in the
slot2 is known as SIM2. You can select to operate SIMs as
per your personal and professional needs.

1.0 DEVICE OVERVIEW
Position of Keys
1. Earpiece
2. Touch Screen
3. Home Key
4. Menu Key
5. Back Key
6. Front camera lens
7. Earphone Jack
8. Volume control key
9. USB port
10. Camera lens
11. LED flash light
12. Battery cover
13. Power Key
14. Speaker

2. GETTING STARTED
2.1 INSTALLING CARDS & BATTERY
Please switch off your device before inserting or removing the
battery/ SIM card or memory card.
Installing SIM Card and Battery
Your device is provided with two SIM slots for two different
SIM cards. In order to install battery and SIM card in the
device, please follow the steps mentioned below:
Remove the back cover of the device.
Hold the device with the front facing downwards and
pull the battery cover.
Insert the SIM cards in the device.
Attach the battery.
Push the battery cover until it clicks into place.
Installing Memory Card
Your device supports T-Flash card, which is a multimedia
memory card used to multiply the memory of the device. The
T-flash card is small and should be pulled out and installed
carefully and prudently in order to avoid any kind of damage.
Please follow the steps mentioned below to install the memory
card in the device:
Switch off your device.
Remove the battery cover.
Slot the T-Flash memory card into the slot.
Attach the battery.
Fix the battery cover until it mount properly into
place.

Charging the Battery
The device prompts a warning tone and message stating
insufficient battery when the battery power is low.
Please follow the instructions mentioned below to charge your
device:
Plug the connector of the charger into the jack of the
device.
Plug the charger into a standard AC wall outlet.
Charging……. Fully Charged…….
You should fully charge the battery before using the device for
the first time. It is recommended to charge the battery for
three hours before using the device for the first time.
2.2 POWERING ON/OFF THE DEVICE
Turning On the Device
After installing the SIM cards and charging the battery, you
are now ready to turn on your device.
Long press and hold the Power Key to turn on the
device.
The first screen that appears is known as the
home/idle Screen.
Drag the lock icon sidewards to unlock the screen.
If the screen turns off, then short press the Power
Key to turn on the display.
Turning Off the Device
Press and hold the Power Key for 3 seconds.
A pop-up window appears, select Power off.
Select OK to confirm.

3. BASIC OPERATIONS
3.1 CALLING
To Make Calls
If the icon appears on the screen, then you can make or
receive calls.
To make a call, please follow the steps mentioned below:
Enter the Main Menu, select Phone.
Enter the phone number using the on-screen
keyboard.
Tap to delete a wrong number. Tap and
hold it to erase the entire number.
After entering phone number, tap .
To end the call, tap
Answer/Reject an Incoming Call
When you receive an incoming call, a notification message
appears on the screen. In order to accept the call, drag
towards right. If you wish to reject the call, drag towards
left.
Other Options during the call
To put a call on hold
If you are having a call conversation and there is another
incoming call, select hold to put the first call on hold. To
unhold the call, select unhold.
To set up conference calls
If you are already having a call conversation, select
Hold to put the call on hold.
Select Add Call to make another call. .
After connecting to the second call, select merge
calls to set up the conference call.
3.2 MESSAGING
Your device features, sending and receiving of SMS (Short

Message Service) and MMS (Multimedia Message Service).
Go to Main Menu and then select Messaging.
Creating a Message
Tap Compose new message.
In To field; enter the recipient‟s phone number.
Type message in the Type to compose field.
Tap to Send.
Receiving and Managing Messages
When you send and receive messages to or from a contact,
these messages are grouped as a message thread. A
message thread looks like an exchanged conversation.
MULTIMEDIA MESSAGE
A Multimedia message or MMS can contain letters, an image,
an audio or video file. To create and send a MMS, please
follow the steps mentioned below:
Enter the Main Menu, select Messaging.
Tap Compose new message.
Select Menu > Add subject.
In the To field, enter the recipient‟s phone number or
email address and enter the Subject.
To insert a picture or video file, etc, tap .
To insert text, tap Type to Compose, and then enter
your message.
3.3 CONTACTS
Contacts refer to the phonebook that lets you store names,
phone numbers, e-mail addresses and other information. You
can save information such as name, picture, phone numbers,
e-mail addresses, etc for each contact listed in your Contacts
menu.
To add a Contact
Enter the Main Menu select Phone.
Enter number > Tap Menu > Add to contacts >
Create New contact.
Select the storage

You can enter contact information such as name,
phone number, email address etc, if you select
storage as “Phone”.
Tap Done to save the contact.
Tip: Or enter the Main Menu and select Contacts, tap
create New contact.
To import contacts
Enter the Main Menu select Contacts.
Tap Menu > Import/Export.
Select to import contacts from Phone contact/ Phone
storage/ SIM Card/ SD Card.
Select a particular source to import the contacts
from.
Select Next.
Select the destination, such as Phone to copy
contacts to.
Select Next.
Select “Select All” to import all contacts or mark the
required contacts.
Select OK.
3.4 EMAIL
Your device allows you to compose, read and send emails.
3.5 BROWSER
Browser is a tool which enables you to access the Internet.

4. HOME SCREEN
4.1 STATUS BAR
The Status bar icons indicate different types of information.
The table below lists various icons that might appear on the
status bar of the device.
Network intensity of SIM card 1 or SIM card
2
Battery level of the device
New short message
Missed call notification
USB connected
Bluetooth is activated
Wi-Fi is connected.
GPRS network is in use.
4.2 APPLICATION TAB
Tap Application Drawer to access applications and settings of
the device. The Application tab enables you to access the
Main Menu and choose among the various utilities/ features
available in the device.
4.3 CUSTOMIZING SCREEN
The device features a touch screen with idle displays and
access to utilities at just one-touch. So swipe right or left to

navigate through various screens accessing your favorite
features without entering the main menu. Each screen can be
customized by adding various widgets, shortcuts and folders.
Shortcuts
In order to add a shortcut on the screen: Long press on the
desired application to add on the screen.
Widgets
Save time with live updates right on Home screen and get all
of your personalized updates at one place.
Setting the wallpaper
You can customize the wallpaper of your Home screen with
default wallpaper or with pictures taken from your device.
In the idle mode, tap Menu Key > Wallpaper.
Select your desired wallpaper from the various
options:
Gallery
Live Wallpapers
Video Wallpaper
Wallpapers
Rotating Your Mobile Phone Screen
The orientation of most screens will change to
landscape or portrait view when you rotate your
phone sideways.
On the Home screen, tap > Settings >
Display > Auto-rotate screen to disable this function.

5. MULTIMEDIA
5.1 FILE MANAGER
You can browse, open and manage the data saved in the
Device and Memory card by accessing the File Manager
sub-menu. The device provides a certain space for users to
manage files and supports the T-Flash card. You can use the
file browser to conveniently manage various directories and
files on the T-Flash card.
5.2 MUSIC PLAYER
Use the Music player to play music files. The songs saved in
your SD Card can be played using the Music Player of the
device.
Tap select Application tab
Select Music
The songs are categorized by Artists, Albums and Songs. You
can make your favorite playlist by long pressing on a song and
selecting Add to Playlist.
5.3 CAMERA
Your device is equipped with camera and camcorder, which
enables you to capture photos and videos.
The rear camera is 5 megapixels, when you choose the size
of the preview for the standard (4:3).
5.4 SOUND RECORDER
You can use the sound recorder to record sounds and also
select to save the recordings in your phone. Tap select
Application tab > Sound Recorder. When in the sound
recorder interface, press menu key to select recording mode.
5.5 GALLERY
You can view the captured images, recorded video clips, and
downloaded images in the Gallery.
The picture folder and video folder will be displayed.
Select to view the camera pictures or camera videos. The
images or videos will be displayed in thumbnails.
5.6 FM radio
You can use your phone to listen to FM radio stations once
the original Headset is plugged into the connector. Please
press the side key to adjust music volume.

Tap to exit FM radio function. Tap the ( ) to
search the channels.

6. NETW ORK
6.1 WI-FI
Connect to a wireless network to browse Internet.
Enter Main Menu and tap Settings.
Tap „ON‟ to activate Wi-Fi.
Tap Wi-Fi > Network notification to start
detecting networks. The available networks will then
be listed.
Tap Add Wi-Fi network to add a connection.
6.2 3G
The device supports WCDMA protocol. Please make sure that
you device is turned off, then insert or remove the SIM card.
6.3 BLUETOOTH
You can transfer data, such as music to other device using
Bluetooth. Search the device and accept/transfer data. The
received data is automatically stored in the directory.
Access Settings by entering the main menu
Check Bluetooth to turn on Bluetooth
To make your device discoverable, select bluetooth
settings and check discoverable.

7. SETTINGS
7.1 SIM MANAGEMENT
Your device supports two SIM cards, which can be managed
by accessing the SIM Management sub-menu. You can
view/change the roaming settings of the cards using this
menu.
7.2 WIRELESS & NETWOKS
Access this sub-menu to change/view the Wi-Fi, Bluetooth,
Mobile Networks, VPN settings, etc. Please refer to network
section for detailed information on Wi-Fi and bluetooth.
7.3 AUDIO PROFILES
Your device provides four pre-defined user profiles that allow
the operations of the device to best suit the environment you
are in. The profiles are General, Silent, Meeting and Outdoor.
The Touch icon adds a new profile; tap the icon
to select Reset to restore the default settings.
7.4 DISPLAY
With this function you can configure the display characteristics
of the device including brightness, Auto-rotate screen, etc.
7.5 STORAGE
View and manage the data storage of your device:
Total Space and Available Space: Lists the amount of space
on the microSD card installed in your device and the amount
you have used to store photos, videos, music, and other files.
Un-mount SD Card: Un-mounts the microSD card from your
device so that you can format the card or safely remove it
when the device is on.
Available Space: The amount of internal phone storage used
by the operating system, its components, applications
(including those you downloaded), and their permanent and
temporary data.
7.6 BATTERY
