Keepower Classic User manual
Classic 6V
Keepower MICRO
Nominal battery voltage 12V
Charge current 0.8 A
Fully charged
Charging
Keepower Battery Charger
User guide
Classic 6V
The Keepower Charger kit
Classic 6V 0.8A/6V
Clamp Cable
0.75mm² 74753607
Motorbike cable
0.75mm² 74753580
Keepower 6V
Nominal battery voltage 6V
Charge current 0.8 A
Fully charged
Charging
Classic 6V
Keepower6V
Nominal battery voltage 6V
Chargecurrent 0.8 A
Keepower 6V
Nominalbattery voltage 6V
Chargecurrent 0.8 A
Fully charged
Charging
Fully charged
Charging
• Battery acid is highly corrosive. Acid on the clothes should be rinsed off immediately in running water. Acid on the skin or in
the eyes, rinse thoroughly in running water and contact a doctor.
• A battery produces explosive gases during charging and good ventilation should therefore be ensured if charging takes
place indoors.
• The charger have to be placed upright on a solid surface or hanged on the wall with the possibility for good ventilation.
• The charger may not be covered or exposed to direct sunlight.
• The battery manufacturer advices have to be followed carefully.
• The charger can only be used for rechargeable lead/acid batteries.
• Do not recharge non-rechargeable batteries.
• The charging wires can only be changed to other keepower wires.
• If the supply cord is damaged, it must be replaced by authorised shop.
• Repair of the charger may only be done by an authorised shop.
• The charger is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the charger by
a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
English
Keepower Classic 6V battery charger
The battery charger can be set up in 4 different positions:
Battery charger set-up
As a mobile unitAs a stationary unit
1230V ~
2
Protect charger from moisture and keep dry.
Riskofexplosion!Avoidre,openameandsparks.
Turn off the charger before attaching and removing the charging clamps.
• thebatteryterminalnotconnectedtothechassishastobeconnectedrst.
The other connection is to be made to the chassis, remote from the battery
and fuel line. The battery charger is then to be connected to the supply mains;
• after charging, disconnect the battery charger from the supply mains. Then remove the
chassis connection and then the battery connection.
Before charging, please read this guide instruction.
As a device on
the wall
As a device
hanging on an
edge.
Safety instructions
!
BATTERY CHARGER FOR 6V LEAD ACID BATTERIES
!
Classic 6V
How is the battery charged?
Battery charging occurs in four phases.
1)Therstpartofthechargingprocedureisrealisedwithaconstantcurrentof0.8Auntilthe
voltage on the battery reaches 7.2 V. The battery is then charged to about 85% of its full
capacity.
2) The charging current drops slowly as soon as the voltage of 7.2 V is achieved, with the
voltage being maintained at 7.2 V. Charging is terminated as soon as the charging current
has dropped to 0.25A. The battery is now fully charged.
3) The battery voltage is monitored in phase three. This status can endure for a very long time,
depending on the quality and age of the battery. This period of time is reduced accordingly if, for
example, electronic components are active in the vehicle (a clock or alarm system).
4) The trickle charging mode commences operation if the voltage drops below 6.3 V. The
battery is charged up to 7.2 V in this fourth phase. The third phase (voltage monitoring) is
activated once again as soon as the battery is fully charged.
This sequence continues for as long as the charger is connected to the battery. The battery
charger can be continuously connected.
Battery types
The Keepower 6V battery charger can be used for all 6 volt lead-acid battery types. These include
standard batteries, maintenance-free batteries, VRLA (valve-regulated lead-acid batteries), AGM
and most GEL types.
The Keepower 6V battery charger can be used to charge batteries from 1.2 Ah to 32 Ah and for
trickle (maintenance) charging of batteries with up to 100 Ah.
Charging the battery
Connect the clamps to the battery.
• Red to + terminal
• Black to - terminal
Before disconnection.
• Switch off mains supply.
• Unplug the charger.
• Remove the clamps.
Connect to mains supply and switch on.
• Charging begins automatically and yellow LED illuminates during charging.
• The battery is fully charged and ready for operation when the green LED illuminates.
• The Keepower 6V battery charger can be continuously connected to the battery.
• It is recommended that the acid level in the battery be checked at regular intervals.
Classic 6V
Guarantee
Please retain your purchasing receipt. Contact a dealer should problems arise with the battery
charger.
Maintenance
Cleanthebatterychargerwithacleancloth.Donotuseowingwaterorcleaningagentscontain-
ing solvents! The battery charger should only be repaired by an authorised workshop. This also
applies to replacement of the battery cables.
Use of eyelet connector:
Connect the red cable to the plus pole on the battery and the black cable to the minus pole. The
Keepower 6V battery charger can then be connected via the adapter for charging. The cable to
the adapter then remains permanently on the battery. It is recommended that the dummy con-
nectorbettedifthebatteryisnotbeingchargedtoavoidanycontactbetweenthesleeveand
vehicle chassis.
Error indicator
Constant light, when:
• Clamps are wronly polarized.
Classic 6V
Classic 6V
Classic 6V
Technical data
Nominal
battery voltage
Charge
Current
Battery size
Max. total
input power
Input voltage
(Mains voltage)
Ripple voltage
(charging old
battery with 40%
capacity left)
Current ripple
(charging old
battery with 40%
capacity left)
IPclassication
KeepowerCLASSIC 6V
Nominalbatteryvoltage 6V
Chargecurrent0.8A
Fullycharged
Charging
KeepowerMICRO
Nominalbatteryvoltage12V
Charge current 0.8A
Fullycharged
Charging
CLASSIC MICRO SMALL MEDIUM LARGE XL-con XL-pro
6V 12V 12V 12V 12V 12/24V 12/24V
0.8A 0.8A 4A 8A 15A 30A/15A 30A/15A
1.2Ah to 32 Ah 1.2Ah to 32Ah 3Ah to 80Ah 20Ah to 160Ah 40Ah to 300Ah 90Ah to 600Ah 3Ah to 600Ah
8W 15W 75W 150W 275W 525W 525W
230Vrms±10%
50Hz ±3Hz
100mVpp <100mVpp <100mVpp <100mVpp <100mVpp <100mVpp <100mVpp
3% 3% 3% 3% 4% 4% 4%
IP65 IP65 IP65 IP65 IP44 IP44 IP44
Inelco A/S
Industrivej 3
DK-9690 Fjerritslev
phone: +45 98 21 15 55
www.inelco.com
51121034 V4
