SERVICE MANUAL
KVT-50DVDRY/512/522DVD
MONITOR WITH DVD RECEIVER
/522DVDY/532DVD/532DVDM
OFF
OPEN
/CLOSE
TEL
SCAN
MONITOR WITH DVD RECEIVER
V.OFF
SRC NAV
SF
KVT-522DVD
ATT
AUTO +FM
VOLUME
EJECT
TI
Illustrations is KVT-522DVD
Remote controller *
(A70-2083-15)
RC-DV340
Escutcheon
(B07-3159-02)
Mounting hardware assy
(J21-9716-03) Lever
(D10-4589-04) x2
Screw set *
(N99-1758-15)
SIZE AAA BATTERY *
(NOT SUPPLIED)
DC cord *
(E30-6815-05)
DC cord *
(E30-6816-05)
Cord with plug
(E30-6813-05)
*Depends on the models. Refer to the parts list.
REV: 5m
PRK: 2m
BU,GND: 1m
The IC3, and IC11 in the DVD unit (X37-1100-03) are not replaceable components.
When these ICs are defective, replace the whole DVD mechanism assembly (X92-6160-00).
You cannot replace only the board.
TEST MODE is the same as DDX512.
Please refer to the service manual (DDX512: B53-0620-00).

2
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
CAUTIONS IN ASSEMBLING PANEL DRIVE MECHANISM (A10-5171)
Observe the instructions described in this document when
you are going to replace the parts or components that are
shown in this document.
1. Replacement of motor flat spring
• When mounting the flat spring that shall be in contact
with the worm gear, press the spring toward the direction
shown with an arrow so that there will be no gap be-
tween the tip of the gear and the spring and then mount
the spring. The gear shall be pressure-inserted into the
motor.
• Note that there are two motors. Above operation of
mounting the flat spring is required on both of them.
Tilt drive gear train Slide drive gear train
Mount the flat spring
while pressing it
towards the direction
shown with an arrow
so that there will be no
clearance.
Mount the flat spring
while pressing it
towards the direction
shown with an arrow
so that there will be no
clearance.
DC Motor
Worm
Flat Spring
DC Motor
Worm
Flat Spring

3
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
CAUTIONS IN ASSEMBLING PANEL DRIVE MECHANISM (A10-5171)
2. Phase matching among gears
• Monitor tilt is driven under the control of the
rotary sensor and the phase matching among
gears and sensor is required.
The procedure for the phase matching is de-
scribed in the rest of this subsection.
1) Align the mark on the rack with the pin. (When
the monitor is folded down at 0 degree, the
rack is located at the position where the mark
and pin are aligned.
2) Insert the gear while keeping aligning the rack
pin with the notched section on the tilt gear 7.
3) Pre-assemble the tilt motor bracket assembly
(BKT Assy).
4) Align the notch on the sensor BKT with the
concave section of the sensor in the Assy.
5) While keeping the conditions stated in 3) and
4), insert the tilt motor BKT Assy transversally,
and fix the motor.
Tilt drive gear train
Location of mark
on the Rack
T-Rack-A Pin
Location of
notched section
Tilt Gear 7
Location of
notched section
Sensor Tilt Sensor Bkt

4
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
3. Insertion of slider
• This subsection describes cautions for inserting the
slider (slide section inside of the unit) into the outer
chassis.
1) On the rail at the left side of the slider, there is a part
called a stabilizer that is used to minimize play in
right and left sides.
The slide is made of resin. (Note that the rail is
shown at the right side of the slider in the picture.)
When inserting the slider, press the stabilizer towards
the direction shown with a blue arrow and insert it
into the groove on the rail.
2) PCB holder is pushed out towards the downside of
the picture due to the spring force and thus the chas-
sis and photo reflection sheet may be get caught by
the holder during the assembly.
Insert the slider while slightly lifting up the holder with
a pair of tweezers or any other similar device.
3) Insert the gear after confirming that the both of D
shaft gears at the right and left sides of the slider are
aliened with the tip of the right and left racks on the
chassis.
(Otherwise the slider will be inserted sidelong.
CAUTIONS IN ASSEMBLING PANEL DRIVE MECHANISM (A10-5171)
(Slider -Slide section inside of the unit)
Stabilizer
PCB Holder
These portions
tend to be get
caught.
Hold and lift up the holder
with a pair of tweezers.
Push the opposite side of
the PCB holder towards
the downside of the picture
and lift up the portions
that may get caught.
D shaft gear
D shaft gear
Rack gear
Rack gear

5
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
In assembling the Traverse UD arm, Drive cam assembly,
Drive gear 5 and Drive gear 4C, align register marks on
these components.
GEAR POSITION IN A DVD MECHANISM
BLOCK DIAGRAM
Drive gear 5
Drive cam assembly
Do not forcibly press gears to engage their teeth
but freely let the gears fall under their own weight
and engage their teeth.
Traverse UD arm
Drive gear 4C
Inscriptions
(register marks)
on gears
Align 6 marks as
shown in the
figure
DVS-8000V BLOCK DIAGRAM (X37-1100)
SPINDLE
MOTOR
DISC
OPTICAL PICKUP
STEPPING
2 PHASE
CN1
30PIN
28PIN
CN3
MOTOR &
DRIVER
ACTUATOR
M
DC MOTOR
LO/EJ
PROCESSOR
FRONT-END
IC1
IC12
IOP
DET
Q7,8
OPTICAL DISC
CONTROLLER
RESET IC CN2
50PIN
3.3V REG
IC7
D3.3V
A3.3V
A5V
D5V
1.5V REG
IC9
1.5V VOLTAGE DET
IC8
to
MAIN
Tr
APC
IC10
Q1,2
IC4
IC3
FLASH ROMEEPROM
IC11
HALL
IC
HFM3.3V
D7
SW LOEND
SW LOST
UNIT
U,V,W COIL
HALL BIAS
HALL SENSOR
DVD LD/CD LD
VREFH
IMON/VR DVD/VR CD
PDIC I/V OUT
FO+/-,TR+/-
THERMISTER
FO5,RO5
P5V
FO2,RO2
3
3
H1H,H1L,HB
A1,A2,A3
P5V
VHALF
FG
A5V
D5V
A3.3V
7
3
VHALF
IOP(AD)
VHALF(1.65V)
TRCRS
TE
SEN,SCK,STDI
FBAL,JLINE,
ARF,NARF
TSTSG
FG,EXCNT1 SDA,SCL DRV.MUTE,LO.MTE, FADR0-17, TRDRV,PWM8, BMS,STEP A,STEP B NCE,NWE,NOE FTD0-7
28
D5V A3.3V 1.5VD3.3V
16.897849MHz
NRST
D3.3V
ATAPI IF
D5V
P5V
DISC DET
ON/OFF
A5V
LIM-SW
4
SEN,SCK,STDI
VREF,EC
RF,FE1,FE2
A,B,C,D,E,F,
9
3
FE,AS,RFENV,RFDIFO
OFTR,BDO,VREF2
21
D3.3VD3.3V
9
DVDON/
CDON
TEMP
DET(AD)
2
D3.3V
HFM
A3.3V
2
VR
SPDRV,FODRV,
LPC1,2
VREFH
4
FO3,RO3
FO4,RO4
FO6,RO6
BMS,MUTE
HFM3.3V
PDIC VCC
HFM
SW EJEND
STBY,SPIN,IN2-6
A5V
SW
4

6
KVT-50DVDRY/512/522DVD /522DVDY/532DVD/532DVDM
BLOCK DIAGRAM
J1
DC CN MOLEX 15A
CN351
AUDIO AV IN
DVS-8020V DVD MECHA
CN701
WH UBS
W801
TV-BOX (E,M,X)
CN351
SAT I/F
CN353
AV IN VIDEO
CN351
CN354
NAVI
IC701
(MAGNUM)
BE
FLASH ROM
IC702
CATION
i-Pod AUTHENTI-
IC851
J681
IC602
LPF
USB H/C
IC801
PROTECTION
OVER CURRENT
IC804
LPF
IC601
AUDIO
DAC
IC651
LPF
MUTE ISO-1
SEL
MUTE1 BUFF1
ISO-2 MUTE2 BUFF2
ISO-3 MUTE3 BUFF3
ISO-4
ISO-5
ISO-6
ISO-7 AUDIO BLOCK
IN-6
IN-5
VIDEO BLOCK
SEL
IN-4
IN-3
IN-2
IN-1
6dB
6dB
6dB
SW
SW
SW
IC358
iPod
CN352
F-ZB
SYNC-TIP
CLAMP
SYNC
RGB
SW
IC361
SDRAM 128MHz
IC703,704
D OUT
ISO
AMP
SEL
ISO
AMP
INPUT SEL &
VOL
OUT
MUTE
FM/AM
(S07 F/E)
A1
RDS
IC355
E2PROM
X86-403
IC351
PWIC
MUTE
ANT FM/AM
W351
CN351
MUTE
CN351
MUTE
AV OUT
u-COM
IC9
ILLUMI
VARIABLE
VMUTE
MOTOR
IC5
DRIVER
X35-496 to
CN3
MOTOR
DRIVER
IC6
X15-110 B/2 to
CN4
BU14V
BU5V
A8.5V SIR SW14V
BU3.3V
BE A5V T P+5VA5V
SW+14V
DCDC DCDC
SW5V D3.3V D5VV5VMECHA
D1.8V USB3.3VUSB1.8VTC3.3V
USB5V
SW3.3V V3.3V P5V
7.5V
X15-110 A/2 to
CN551
X15-110 to
CN101
REMO
IC551
11 LEDS
10 KEYS
PANEL MECHA to
CN104
IC304
AMP
MEMORY
IC302
SERIAL
X35-496 B/2
to CN302
to LCD PANEL
X35-496 A/2
to CN502
CN503
to TOUCH PANEL
CN501
V ILLUMI
FUNCTION
SCREEN
OPEN/CLOSE
IC1
INVERTER
SRC NAVI
KEY
(BACK LIGHT) to LCD
CN1
(SW5V)
P ON+5V SW+14V
TC3.3V MECHA3.3V
(SW3.3V)
T P+5V
DCDC
IC101
+12.5VD2.5V -12V
5V for IC1 D2.5V
-6V
IC357
DET
SLIDE
CHILT
CONTROL
DECODER
VIDEO
u-COM
USB5V
BU DET
ACC DET
REVERSE
PARKING
P CON
ANT CON
W REMO
ILLUMI
LINE MUTE
D3.3V
26
D+: USB3.3V
D-: USB1.8V
USB5V
BE A5V
V5V
AVSW SDA
AVSW SCL
AVSW PDN
u-COM
A5V V5V SW3.3V
BU14V
RST
SDATA
MREQ
JUDGE
SREQ
CLK
MDATA
u-COM
V5V
RX
TX u-COM
REMO
VIDEO DRIVERS
V5V
V5V
RGB SW1
TUNER
CD
MD
CDCH
AUX
MUXC VOL IN
MUXB AC IN 3
AC IN 1
AC IN 2
AC IN 0
PAOUT
LDOUT
AOUT MUTE
MUTEC
MUTE2
u-COM
EVOL SCL
MUTE0
MUTE1
EVOL SDA
DC DET
A8.35V
TUN IFC
AM+B
TUN SMET
TUN SDA
TUN SCL
R AFS H
R NOISE
u-COM
A8.35V SW5V
SW5V
u-COM
R CLK
R DATA
R QUAL
WININ u-COM
PW STBY
PW MUTE
BEEP
PRE FRRE
PRE
VOUT AV AV
AOUT
SW5V
3
21
NT PAL
COMPOSIT
SOG
NT PAL
VMUTE from u-COM
BE VMUTE from BE (MAGNUM)
MECHA7.5V
44
7RESET
LED R
EJECT
SW5V
SI
LED G
REMO
KEY2
GND
MAGNUM
SIGNAL
COMPOSIT
RGB
AUDIO
u-COMu-COM P ON SIR PON
u-COM
P ON
u-COM
P START
P GOOD
P PWM
MCNT
P ON
D5V
P5V
VOL-
AUTO
FM
REW
AM
VOL+
ATT
EJECT
RESET
FW
SW3.3V
SW3.3V
BU14V
10
TC WAIT
TC RST
TC SCL
TC SDA
NT PAL
SOG
COMPOSIT
VMUTE
HSY
VSY
TC3.3V
4
D2.5V
TC3.3V
P ON+5V
DEH
STHR
STHL
CKV
L/R
DEV
STVR
STVL
VCOM
CPH1
VCOMOUT
VCOMDC
-6V
TC3.3V
+18V
P ON+5V
YDATA
Y0
X0
X1
XDATA
T P+5V
LED G
LED B
LED R
KEY1
OPEN/CLOSE
INV PWM
INV SW
PWM
ENABLE
5V for IC1
SW14V
u-COM
DISC DET
D3.3VV3.3V D1.8V
TX
RX
CON
MAGNUM
RST
BU5V
BU3.3V
SW5V
MECHA3.3V
12
SIR SW14V
(X15-) (A/2)
(X35-) (B/2)
(X35-) (A/2)
(X15-) (B/2)

7
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
●VIDEO CONTROL UNIT (X15-110x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 3-terminal regulator 9V→5V regulator
IC2 3-terminal regulator For AUDIO8.5V
IC3 DC/DC converter IC MECHA7.5V/D5V control
IC4 DC/DC converter IC USB5V/D3.3V control
IC5 Motor driver Slide
IC6 Motor driver Tilt
IC7 3.3V regulator TC3.3V
IC8 Buffer for remote controller Remote controller signal waveform shaping
IC9 System μ-com IC System control
IC10 E2PROM For saving the settings
IC12 Voltage detector μ-com reset voltage (3.5V) monitoring
IC13 OR For VMUTE
IC351 POWER IC Power amplifier for speaker output
IC354 VIDEO ISO AMP IPod video signal
IC355 RDS decoder IC For RDS signal processing and demodulation
IC356 AND*4 KAB IF 3.3V→5V LEVEL SHIFT
IC357 Electronic volume IC AUDIO -VOL_CTL/SIG_SELECT
IC358 AV SWITCH 7-input/3-output AUDIO and 6-input/3-output VIDEO
IC361 VIDEO SELECTOR DVD_BE and NAVI_RGB SELECT
IC401,402 INVERTER TV_SDATA OUT BUFFER
IC551 IR remote controller photoreceptor Remote controller signal detection
IC601 VIDEO AMP DVD_BE COMPOSITE SIG LPF/BUFFER
IC602 VIDEO AMP DVD_BE RGB SIG LPF/BUFFER
IC651 AUDIO DAC DVD_BE AUDIO D/A CONVERTER
IC652 OP-AMP*2 DVD_BE AUDIO LPF
IC691 INVERTER SPDIF OUT BUFFER
IC692 AND For DVD_BE IC RESET_SIG
IC701 MPEG DECODER DVD/USB MPEG DECODER
IC702 64M FLASH FLASH MEMORY (MP 4Z4) for MPEG DECODER
IC703,704 128M SDRAM SDRAM for MPEG DECODER
IC705 Regulator 3.3V→1.8V regulator for MPEG DECODER
IC801 USB HOST CONTROLLER 2PORT (External/GARMIN navigation) USB HOST CONTROLLER
IC804 Fixed Current Limit
Power Distribution Switch Large current distribution switch for USB
IC805 Regulator 5V→3.3V regulator for USB
IC806 Regulator SW3.3V→1.8V regulator for USB
IC807 D-TYPE LATCH X 8 Address latch for USB H/C
IC851 COPROCESSOR IPOD AUTHENTICATION
Q1 SW REVERSE detection
Q2 SW PARKING detection
COMPONENTS DESCRIPTION

8
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Ref. No. Application / Function Operation / Condition / Compatibility
Q3 SW ILLUMI detection
Q4-7 SW PCON output
Q8,9 SW ANT_CON output
Q11 SW ACC detection
Q12-20 SW Over voltage/Voltage reduction/BU_DET
Q21-25 SW BU5V circuit
Q26-28 SW BU3.3V circuit
Q29,30 SW T_P+5V circuit
Q35-37 SW P_ON SW+14V control
Q38 SW P_ON SW+14V ON/OFF
Q39 SW A8.5V circuit
Q40-42 SW A5V circuit
Q43,44 SW BE_A5V circuit
Q45 SW KAB SW+14V control
Q46 SW KAB SW+14V ON/OFF
Q51 SW DC/DC protection control
Q52 SW Z2-MECHA power supply voltage (7.5V/5V) switching
Q53 SW DC/DC protection control
Q54 SW DC/DC SW FET (MECHA7.5V)
Q55 SW DC/DC SW FET (D5V)
Q56,57 SW DC/DC protection control
Q58 SW DC/DC SW FET (USB5V)
Q59 SW DC/DC SW FET (D3.3V)
Q60,61 SW VILL_R power supply
Q62,63 SW VILL_G power supply
Q64,65 SW VILL_B power supply
Q66,67 SW LED_R power supply
Q68,69 SW LED_G power supply
Q71,72 SW A8.5V circuit
Q73 SW DETMUTE circuit (Trigger BU_DET), DETMUTE detection
Q74 SW DETMUTE circuit (Trigger RESET), DETMUTE detection
Q75 SW DETMUTE circuit (Trigger RESET), TV_RST detection
Q76 BUFFER HSY (3.3V→5V)
Q77 SW DC/DC PSTART
Q78 BUFFER AVSW_SDA (5V→3.3V)
Q79 BUFFER AVSW_SCL (5V→3.3V)
Q80 SW SI
Q82 SW KAB detection
Q350 SW KAB_RX error connection protection
Q351-353 SW Pre-Out_Mute circuit (FRONT)
Q354-356 SW Pre-Out_Mute circuit (REAR)
COMPONENTS DESCRIPTION

9
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Ref. No. Application / Function Operation / Condition / Compatibility
Q357-360 SW Pre-Out_Mute circuit (AVOUT)
Q361,362 SW ON when AM (TUNNER8.5V)
Q370 SW KAB_RX error connection protection
Q371-373 SW Tuner_Mute circuit (during ejection)
Q451 BUFFER HD
Q452 SW NT_PAL
Q453 BUFFER DVD_V
Q454,455 SW For KAB_TX control
Q651 SW DVD AUDIO MUTE LCH
Q652 SW DVD AUDIO MUTE RCH
Q653 SW DVD AUDIO MUTE control
Q654,655 SW DVD AUDIO neutral point circuit
Q681 BUFFER SPDIF OUT BUFFER
Q683 SW DVD AUDIO MUTE control
●VIDEO UNIT (X35-4960-10)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 Inverter IC Power supply for CCFL
IC101 Power supply IC for LCD Support 3 output (18V/12.5V/-12V)
IC102 Multi-vibrator IC For LCD power supply rising timing adjustment
IC103 Logic IC For LCD power supply rising timing adjustment
IC200 Op amp IC Buffer for VCOM signal
IC300 Power supply IC 2.5V output
IC302 Serial flush F/W storage for video decoder IC
IC304 Video decoder IC For decoding video signal
Q1 For switching Bright PWM signal SW
Q2,3 Dual FET For DC/AC conversion
Q4 Register integrated transistor External synchronization: 121kHz/Free run: 56kHz→ON (On when it is 56kHz)
Q5 Power supply transistor For inverter IC power supply (5V)
Q101,102 Power supply transistor For generating -6V from -12V (-12V→-6V)
Q200,202 Buffer transistor For VCOM signal level conversion
Q203 Integrated transistor For VCOM signal level conversion
Q501 Register integrated transistor For touch panel XY coordinate import switching
Q502,503 Integrated Register integrated transistor For touch panel signal
●DVD UNIT (X37-1100-03)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 RF signal processing IC RF signal processing
IC3 FLASH ROM Maintain F/W for optical DISC control IC
COMPONENTS DESCRIPTION

10
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Ref. No. Application / Function Operation / Condition / Compatibility
IC4 Optical disc control IC in μ-com Optical DISC general control / ATAPI interface
IC5 Voltage detection IC For system resetting of optical DISC control IC
IC7 3.3V power supply 5V→3.3V
IC8 Voltage detection IC For 1.5V power supply IC voltage monitor
IC9 1.5V power supply 5V→1.5V
IC10 Driver IC Focus coil, Tracking coil, Spindle motor, Sled motor and Lo/Ej motor drive
IC11 EEPROM Maintain data for optical DISC control IC
IC12 OP-AMP for Iop measurement For IOP measurement
Q1 Register integrated transistor SL. MUTE control
Q2 Register integrated transistor For FG signal
Q3 Register integrated transistor LO.MUTE control
Q4 Register integrated transistor DRMU control
Q5 MOS-FET Laser diode ON/OFF control for DVD
Q6 MOS-FET Laser diode ON/OFF control for CD
Q12 Transistor for APC Laser diode brightness control for CD
Q13 Transistor for APC Laser diode brightness control for DVD
Q14 MOS-FET For IOP measurement
Q15 Register integrated transistor HFM ON/OFF control
Q18,19 Register integrated transistor 3.3V power supply IC ON timing control
COMPONENTS DESCRIPTION

11
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
●SYSTEM MICROCOMPUTER: 30878MJBA22GP (X15-110: IC9)
Pin No. Pin Name I/O Application Processing Operation Description
1 EVOL_SDA I/O Communication data with E-VOL
1 EVOL_SDA/E2P_SDA O Communication data with E2P
2 X1 O Touch panel control
3 SIR_PON O SAT power supply ON/OFF H: ON, L: OFF
4 VSYNC_DET I Video external input detection Detects if there is VSYNC signal or not.
5 AVSW_SDA I/O Communication data with AV switch
6 AVSW_SCL O Communication clock with AV switch
7 HSY I HD input Counts HD.
8,9 NC O
10
TV_SC_REQ/TV_SC_REQ IRequest from TV μ-com
(For other destination than K and R)
10 TV_SC_REQ/NC O (K,R destination)
11
TV_MC_REQ/TV_MC_REQ ORequest to TV μ-com
(For other destination than K and R)
11 TV_MC_REQ/NC O (K,R destination)
12
TV_SC_CON/TV_SC_CON ORequest to start TV μ-com
(For other destination than K and R)
12 TV_SC_CON/NC O (K,R destination)
13 INV_PWM O Inverter frequency control
14 PWIC_MUTE O Power IC output mute control H: OFF, L: ON
15 BYTE
16 CNVSS
17 XCIN
18 XCOUT
19 RESET
20 XOUT
21 VSS
22 XIN
23 VCC1
24 NMI
25 ACC_DET I ACC detection H: ACC reduced power detection
26 BU_DET I Backup power supply detection H: Backup reduced power detection
27 R_CLK/R_CLK I Clock input from RDS decoder
(For other destination than X and (V))
27 R_CLK/NC O (X, (V) destination)
28 NC O
29 EJECT_MUTE O Mute control during loading/ejection
30 NC O
31 PWM O LCD brightness control PWM output synchronized with VSY
32 PRE_MUTEF O Pre-out mute (F/R) H: OFF, L: ON
33 BEEP O BEEP PWM output
MICROCOMPUTER’S TERMINAL DESCRIPTION

12
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Pin No. Pin Name I/O Application Processing Operation Description
34 PRE_MUTESW O Pre-out mute (SW) H: OFF, L: ON
35 POWER_PWM O Frequency control of DC-DC_IC
36 NAVI_RX I Communication with navigation system
37 NAVI_TX O Communication with navigation system
38
TV_MC_DATA/TV_MC_DATA OData output to TV μ-com
(For other destination than K and R)
38 TV_MC_DATA/NC O (K,R destination)
39 VCC1
40 TV_SC_DATA/TV_SC_DATA IData input from TV μ-com
(For other destination than K and R)
40 TV_SC_DATA/NC O (K,R destination)
41 VSS
42
TV_BP_CLK/TV_BP_CLK OCommunication clock with TV μ-com
(For other destination than K and R)
42 TV_BP_CLK/NC O (K,R destination)
43 NC O
44 TUN_SDA I/O Communication data with tuner
45 TUN_SCL O Communication clock with tuner
46 R_DATA/R_DATA I DATA input from RDS decoder
(For other destination than X and (V))
46 R_DATA/NC O (X, (V) destination)
47 R_QUAL/R_QUAL I QUAL input from RDS decoder
(For other destination than X and (V))
47 R_QUAL/NC O (X, (V) destination)
48 EVOL_MUTE0 O E-VOL front mute L: ON, H: OFF
49 EVOL_MUTE1 O E-VOL rear mute L: ON, H: OFF
50 EVOL_MUTE2 O E-VOL C·SW mute L: ON, H: OFF
51 EVOL_MUTEB O E-VOL_B·AVOUT mute H: ON, L: OFF
52 EVOL_MUTEC O E-VOL_C mute L: ON, H: OFF
53 TV_JUDGE I Determination of TV_BOX if it is old or new H: Old, L: New
54 WRT_E2P I Used when writing into E2P L: Normal condition
H: When writing into E2P
55 AVSW_PDN O Communication clock with AV switch
56 VILL_R O Brightness control of “R” in variable illumination
57 VSS
58 VILL_G O Brightness control of “G” in variable illumination
59 VCC2
60 VILL_B O Brightness control of “B” in variable illumination
61 NT_PAL I NTSC/PAL determination signal input H: PAL, L: NTSC
62 VMUTE O LCD output mute control H: MUTE, L: Normal
63 X0 O Touch panel control
64 VILL_DET I Variable illumination identification terminal L: F3, H: F4
MICROCOMPUTER’S TERMINAL DESCRIPTION

13
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Pin No. Pin Name I/O Application Processing Operation Description
65 OPEN_CLOSE I Z-MECHA OPEN/CLOSE
66 Y0 O Touch panel control
67 INV_SW O Inverter free run frequency switching
68 BL_ENA O Back light ON/OFF control H: ON, L: OFF
69 NC I Reserve
70 Z_SWT I Detection of panel mechanism
71 SW_C I Detection of panel mechanism
72 SW_B I Detection of panel mechanism
73 SW_A I Detection of panel mechanism
74 VCC2
75 SMOTOR_M O Panel mechanism slide control
76 VSS
77 SMOTOR_P O Panel mechanism slide control
78 TMOTOR_M O Panel mechanism tilt control
79 TMOTOR_P O Panel mechanism tilt control
80 AM+B O Tuner AM power supply ON/OFF control H: ON, L: OFF
81 SI O SI control L: ON, H: OFF
82 EJECT I Disk ejection
83 BE_RESET O Reset request to back end L: Reset, H: Clear reset
84 BE_RESERVE2 I Operation identification terminal from back end H: Valid, L: Invalid
85 BE_STBY I Standby request from back end
86 BU_BUDET O
Notification of momentary power down detection to back end
87 BE_INI O Initial request to back end
88 BE_SDATA I Communication data from back end
89 BE_CLK I Communication clock with back end
90 BE_MDATA O Communication data to back end
91 VCC2
92 TYPE1 I Destination settings Refer to Destination settings
93 VSS
94 TYPE2 I Destination settings Refer to Destination settings
95 BE_CON O Control request to back end
96 BE_MREQ O Request to back end
97 DISC_DET I DVD mechanism function to detect if there is a disc or not. H: There is no disc, L: There is a disc
98 NC O
99 Z_CNT I Detection of panel mechanism
100 Z_SENS I Detection of panel mechanism
101 NC O
102 VSY I VD (VSYNC) input
103 BE_RESERVE1 CLK terminal for operation identification from back end CLK frequency: 1Hz
104 BE_SREQ I Request from back end
105 NC O
MICROCOMPUTER’S TERMINAL DESCRIPTION

14
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Pin No. Pin Name I/O Application Processing Operation Description
106 ILL_G O
ON/OFF of other GREEN illumination than variable illumination H: ON, L: OFF
107 ILL_R O
ON/OFF of other RED illumination than variable illumination H: ON, L: OFF
108 MCNT O
Switching of power supply voltage to the panel drive mechanism H: 7.5V, L: 5V
109 PGOOD I DC-DC power supply error detection H: Normal, L: Error
110 P_START O DC-DC power supply ON/OFF control
111 PON O SW power supply ON/OFF control
112 NC O
113 REVERSE I Reverse detection L: Detection, H: Normal
114 PARKING I Parking detection L: Detection, H: Running
115 SIR_DET I Sirius connection detection L: Detection, H: Not-connected
116 ANT_CON O Power antenna control H: UP, L: DOWN
117 P_CON O P-CON control L: STANDBY, POWER OFF, H: EXCEPT
118 ILLUMI I Illumination detection L: ON, H: OFF
119-121 NC O
122 TYPE0 I Destination settings Refer to Destination settings
123 KEY2 I Key 2 input Refer to KEY2
124 TUN_IFC I F/E IFC input H: Station found, L: Station not found
125 TUN_SMET I S meter input
126 R_NOISE I FM noise input
127 R_AFS_H I/O Time constant switching when F/E noise is detected.
128,129 NC O
130 VSS
131 NC O
132 VCC1
133 KEY1 I Key 1 input Refer to KEY1
134 NC O
135 PWIC_STBY O Power IC standby H: ON, L: OFF
136 VCOM I For VCOM level automatic adjustment
137 X_DATA I Touch data input
138 Y_DATA I Touch data input
139 LINE_MUTE I LINE-MUTE input detection Normal: 1.6V, TEL MUTE: 1V or less,
NAVI MUTE: 2.5V or higher
140 AVSS
141 PWIC_DC_DET I SP output DC offset detection L: When detected
142 VREF
143 AVCC
144 EVOL_SCL/EVOL_SCL O Communication clock with E-VOL
144 EVOL_SCL/E2P_SCL O Communication clock with E2P
MICROCOMPUTER’S TERMINAL DESCRIPTION

15
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Destination settings of KVT/DDX/DNX
MODEL Destination TYPE2 TYPE1 TYPE0
KVT
K00 *
E00 *
M0 0 *
V/X 0 0 *
R00 *
DDX
K01 *
E01 *
M0 1 *
V/X 0 1 *
R01 *
DNX
K11 *
E11 *
M1 1 *
V/X 1 1 *
R11 *
TYPE0 is AD input.
Refer to the next table (TYPE0 Setup Voltage) for the “*”.
• TYPE0 Setup Voltage
Power supply voltage Number of destinations Pull up resistor
3.3 5 10
Destination
μ-com setup value Pull down
resistor
Pull up
resistor
min max
K 0.00 0.41 10 None
E 0.42 1.23 3.3 10
M 1.24 2.06 10 10
V/X 2.07 2.88 30 10
R 2.89 3.30 None 10
KEY1 Settings
Power supply voltage Number of keys Pull up resistor
5412
Name of
key
μ-com setup value Resister
value
min max
KEY1 SCRN/ 0.00 0.69 0.2
KEY2 FNC/■0.70 1.92 3.9
KEY3 SRC/SRC 1.93 3.15 8.2
KEY4 NAV/- 3.16 4.38 24
NO KEY 4.39 5.00
When opened / When closed
When being pushed and held for a while
KEY2: TEL, KEY4: V.OFF (E), RCAM (K,R,M,X)
KEY2 Settings
Power supply voltage Number of keys Pull up resistor
5812
Name of
key
μ-com setup value Resister
value
min max
KEY1 VOL- 0.00 0.42 0.3
KEY2 ATT 0.43 1.03 1.8
KEY3 VOL+ 1.04 1.64 2.2
KEY4 AUTO 1.65 2.25 3.3
KEY5 AM 2.26 2.86 5.1
KEY6 FM 2.87 3.47 8.2
KEY7
SEEK DOWN 3.48 4.08 16
KEY8 SEEK UP 4.09 4.69 51
NO KEY 4.70 5.00
When being pushed and held for a while
KEY2: LOUD (K,R,X)
MICROCOMPUTER’S TERMINAL DESCRIPTION

16
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
1. Flicker adjustment
●Condition
Video source: VIDEO
Video: RAMP
BRIGHT: MAX
MODE: FULL
●Adjustment procedure
qDisplay RAMP.
wRotate VR200: X35-496 until the leading edge of black
area reaches far right of the screen. As shown in the
next picture, the edge is now located at about 1/5 of the
screen width from the left of the screen. (At the comple-
tion of this adjustment, most of the screen will be in
black.)
The position where the adjustment is best completed
can be shown darkest and clearest.
Adjust it by confirming this area
Example: Keep rotating the VR200 so that the black area
is gradually expanded (to the right), and if you rotate the
VR200 too much, the black area will start shrinking. So
when you see the black area starts shrinking, rotate the
VR200 backward a bit to make the adjustment relatively
stable.
2. VCOM Amplitude and AGC and WB
Automatic adjustments
●Adjustment Method
qInput 100% (white) in AV-IN.
wPress Auto Adjust on the Test Mode Main screen.
ePress Auto Adjust Start.
rAfter the automatic adjustment, “Auto Set OK” will be
shown to indicate the completion of the adjustment.
ADJUSTMENT

17
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
3. Adjustment of Horizontal display start
position and pixel
●Video displayed on Adjustment screen
GRAPHIC: Special screen used only for adjustment (See
below)
NAVI: Input KNA-DV3200 or KNA-G520
●Default Value
Pixel Adjustment key (DOT_PHASE): Adjustment of hori-
zontal display position of pixel (Default: 32)
Screen Position Adjustment key (HPOSI): Adjustment of
horizontal display starting position of the entire screen
(Default: 0)
Display Range Adjustment key (DOT_FREQ): Adjustment
of horizontal display range of the video (Default: 64)
●GRAPHIC Adjustment screen
Pixel Adjustment key
Proceed to the next
adjustment screen.
Horizontal
Screen Position
Adjustment OSD
Screen Position
Adjustment key
Display Range
Adjustment key
Return to the Menu
Horizontal
Screen Position
Adjustment OSD
●NAVI Adjustment screen
Adjustment screen changes depending on what type
(model) of NAVI is connected.
Screen Position
Adjustment key Proceed to the next
adjustment screen
●Adjustment Procedure
qPress HPOSI on the Test Mode Main screen.
w-1 Grafhic (DotPhase)
Then, adjust the Pixel Adjustment key so that the screen
becomes gray.
After the completion of the adjustment, press “NEXT”.
• Pixel Adjustment: GRAPHIC
OK
ADJUSTMENT

18
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
NG
Enlarge OK
Enlarge NG
w-2 Grafhic (HPOSI)
Adjust the Screen Adjustment key so that the screen be-
comes horizontally symmetrical.
• Screen Position Adjustment: GRAPHIC
w-3 Grafhic (DotFreq)
Then, adjust the Display Range Adjustment key so that
there is no vertical black stripes (blur) on the screen.
After the completion of the adjustment, press “NEXT”.
• Adjustment of display range: GRAPHIC
OK
NG
w-2-1 NAVI (In case of KNA-DV3200)
Adjust the Screen Adjustment key so that the NAVI
screen becomes horizontally symmetrical.
Adjust the screen such that KEY (gap) at the
right and left sides becomes symmetrical.
w-2-2 NAVI (In case of KNA-G520)
Adjust the Screen Adjustment key so that the NAVI
screen becomes horizontally symmetrical.
Adjust the space to become horizontal symmetry
ADJUSTMENT

19
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
Enlarge OK
Enlarge OK
●Confirmation after adjustment
After the adjustment, check that the screen is horizon-
tally symmetrical and that there is no blur on the screen.
The “HPOSI OK” will be shown to indicate the comple-
tion of the adjustment.
4. Touch panel adjustment
●Adjustment procedure
qPress the Touch Key on the Test Mode Menu screen to
enter the Touch panel adjustment screen.
wTouch the center of “+” mark below in the following or-
der.
Upper left
→Upper right →Lower left →Lower right
To touch, make sure to use the designated touch stick.
eAfter adjustment is completed for 4 areas, if “Write OK”
is displayed, the adjustment is completed.
Press Return to exit from the Touch screen.
Cancel Cancel
CancelCancel
∗If the center of “+” mark wasn’t pressed accurately, press
Cancel to start over the adjustment.
Note
The touch panel adjustment data is finalized when the
touch stick is released from the mark.
Therefore, the Knack for Adjustment is not to release the
touch stick from the mark right after touching the center
of the “+” mark, but to confirm that the stick is exactly
on the center of the “+” mark while keeping touching the
screen. (If the stick is not exactly on the center of the
mark, move the stick onto the center of the mark while
keeping touching the screen.)
Then, quickly and vertically release the stick from the
screen.
ADJUSTMENT

20
KVT-50DVDRY/512/522DVD
/522DVDY/532DVD/532DVDM
ABCDE
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDE VIEW)
E
B
EB
EB
EB
EB EB
EB
EB
EB
BE
BE
G
D
D
D
S
BE
GS
GS
BE
R674
C475
C476
C28
C456
C229
C673
L13
C19
L12
C459
L702
L851
R
1
R492
C761
C763
R123
R286
R
L731
L741
R840
R847
R833
R834
R835
R836
R841
R844
C762
C764
R157
R276
R288
C466
R769 R245
R246
R247
R248
R269
R270
R271
R770
C161
C162
C424
C390
C392
R412
C751
C464
R156
C672
C163
C164
R883
C460 C467
C468
L361
C851
C852
R662
R661
R845
R281
C704
C655
C657 L451
L703
C741
C742
C743
C744
C745
C746
C747
C748
C752
C753
C754
C755
C756
C757
C758
C18
F2
R46 R48
C89
C500
R266
L355
C397
R702
C663
C664
R677
R884
R885
L751
C352
R837
R543
C455
C479
C480
C481
C482
R760
R488
R495
R676
C656
C658
R673
R843
C26
R283
R284
R47
R
C173
C183
C184
C185
C186
C187
C188
C189 C190
C191 C192
C193
C194
C196
C406
C407
C702
R480
C731
C732
C853
C854
C855
CP751
CP752
R204
R205
R207
R208
R221
R222
R223
R250
R251
R252
R253
R272 R273
R274
R831 R832
R761
X2
R762
R544
R548
R385
R489
C150
C151
C152 C153
C154
C155
C156
C157
R402
R428
R511
R516
R517
C353
C356
C377
C379
C423
C425
C457
C462
C465
C469
C470
C471
C472
C473
C474
C477
C478
C494
C495
C496
C497
C498
C499
C661
C662
C665 C666
C667
C668
R49
R50
R73
R159 R160
R161
R162
R163
R164
R165 R166
R167
R168
R170
R171
R183
R184
R185
R186
R187
R188
R206
R210
R211
R212
R213
R214
R215
R217
R218 R219
R220
R225
R227
R228
R229
R230
R231
R232
R233
R234
R235
R236
R237
R238
R239
R240
R241
R242
R243
R244
R254
C463
R256
R258
R259
R260
R262
R263
R264
R265
R267
R268
R275
R386
C454
R390
L2
R394
R280
R400
R401
R403
R404
R405
R406
R411
R438
R439
R452
R453
R454
R501
R502
R503
R481 R482
R510
R512
R513
R515
R518
R519
R669
R670
C376
C385
C389
C378
R664
R846
R663
R654
R763 R764
L3
R652
R838
R653 R651
R667
R668
R666
R665
R255
R282
R216
R224
C703
R494
R493
X351
X851
R848
C380
C383
X1
CP753
C443
R249
C359
C735
R278
R279
C203
BE
BE
BE
BE
BE
BE
BE
15
202
191
202
191
21
B
E
C431 C384
R361 R354
R370 R364
168
1
64 49
16
48
33
17 32
36
37
1
72
144
109
10873
1
27
54
28
54
2827
1
24 1
4825
11
20
1
51
161
98
5
8
4
1
20
11
40
31
30 21
10
1
16
98
1
C11
1
1
18151
111
2
27
26
BE
19
2
20
D14
Q80
CN4
CN2
Q655
Q653
CN701
Q452
CN3
Q361
CN354
Q23
Q
Q654
Q651
Q652
D32
Q76
D19 D20
D21 D22
D23
D24
D25
D27
D28
D29
D30
D31
D34
D35
D36
D37
D41
P5
P2
Q362
D365
D366
D367
D369
D370
D371
D372
D373
D374
D375
D376
D384
CN355
Q78
Q79
D396
Q683
D401
CN352
D651
D701
D413
Q451
Q77
Q453
Q372
Q373
D368 Q371
CN351
CN357 CN356
W351
Q39
IC9
IC358
IC652
IC851
IC651
IC703
IC704
IC361
IC702
I
C
IC705
IC351
VIDEO CONTROL UNIT
X15-110x-xx A/2
(J76-0505-12)
