Keter MANOR 4x6S User manual

WWW.KETER.COM
ASSEMBLY INSTRUCTIONS | INSTRUCCIONES DE MONTAJE | MONTAGEANLEITUNG | CONSIGNES
DE MONTAGE | SAMLEVEJLEDNING | MONTAGE-VOORSCHRIFTEN | ISTRUZIONI D’ASSEMBLAGGIO
MANOR 4x6S
A-1265 553267
MANOR 4x6S
2 easy steps to use a QR-code:
1. Download a FREE QR-Code
reader from your smartphone
application site.
2. Scan the QR-Code.
SKU:
17197126 | 17194155
Thank you for your purchase of the Keter shed,
In order to activate your warranty, please enter
www.keter.com, under storage buildings
category and fill in the sheds warranty
activation form.
WARRANTY
ACTIVATION
WWW.KETER.COM
US: # 1-888-374-4262
Canada: # 1-800-661-6721
UK: # 0121-5060008
Other European Countries:
# 31-1612-28301
BRINGEN SIE IHR PRODUKT NICHT GLEICH ZUM LADEN ZURÜCK, FALLS TEILE FEHLEN ODER DEFEKT SIND.
VAN ONTBREKENDE OF GEBROKEN ONDERDELEN NIET HET PRODUCT NAAR DE WINKEL RETOURNEREN.
DI PARTI MANCANTI O DANNEGGIATE, EVITARE DI RESTITUIRE IL PRODOTTO AL NEGOZIO.
PEÇAS EM FALTA OU PARTIDAS, NÃO DEVOLVA O PRODUTO À LOJA.
IF THERE ARE MISSING OR BROKEN PARTS, PLEASE DO NOT RETURN THE PRODUCT TO THE STORE
Please log onto our website, or contact Customer Service at:
S’IL Y A DES PIÈCES MANQUANTES OU CASSÉES, NE RETOURNEZ PAS LE PRODUIT AU MAGASIN
Veuillez visiter notre site Internet, ou contacter notre Service Clientèle:
BITTE
Bitte loggen Sie in unsere Website ein oder wenden Sie sich an unseren Kundenservice:
SI HUBIERA ALGUNA PARTE FALTANTE O DAÑADA, NO DEVUELVA EL PRODUCTO A LA TIENDA
Inicie sesión en nuestro sitio en Internet o contáctese con nuestro servicio de atención al cliente:
IN GEVAL
Ga naar onze website of neem contact op met de Klantenservice:
IN CASO
Accedere al nostro sito o contattare il Servizio Clienti:
SE HOUVER
Entre na nossa página de Internet ou contacte o Serviço de Clientes:

2

3
Clear area of stones | Remove all plants, roots and other obstacles | Rake the ground | Make ground level using a long, flat object
(e.g. wood beam)
Retirez toutes les pierres | Arrachez toutes les plantes, racines et autres obstacles | Ratissez le sol | Aplanissez le sol à l'aide d'un
objet long et plat (une planche en bois par exemple)
Beseitigen Sie Steine | Entfernen Sie alle Pflanzen, Wurzeln und andere Hindernisse | Pflügen Sie den Boden durch | Ebenen Sie den
Boden mit Hilfe eines langen, flachen Objektes (wie z.B. eines Holzbalken) aus.
Saque las piedras del área | Retire todas las plantas, raíces y otros obstáculos | Rastrille la tierra | Nivele el suelo usando un objeto
largo y plano (por ejemplo, una viga de madera).
Verwijder stenen | Verwijder alle planten, wortels en andere obstakels | Hark de grond | Maak de grond met een lang, vlak onderw-
erp (bijv. een houten balk) waterpas
Eliminare le pietre | Rimuovere piante, radici e altri ostacoli | Livellare il terreno | Mettere a livello il terreno utilizzando un oggetto
lungo e piatto (ad es. un asse di legno)
Retire as pedras do local | Retire todas as plantas, raízes e outros obstáculos | Alise o local | Nivele o solo utilizando um objecto
comprido e plano (por exemplo, uma trave de madeira)
LEVEL THE GROUND | NIVELLEMENT DU SOL | NIVELE EL SUELO | SORGEN SIE FÜR EINE EBENE
GRUNDFLÄCHE MAAK DE GROND WATERPAS | METTERE IL TERRENO A LIVELLO | NIVELAR O SOLO
CAUTION | AVERTISSEMENT | WICHTIG | ADVERTENCIA | WAARSCHUWING | ATTENZIONE | ATENÇÃO

4
GENERAL PARTS LIST
Door Parts
Floor Parts
Roof Parts
Walls Parts
f1a
177x111 cm
fc1
fc1
t
t
t
t
c1z
c1z
FLOOR PARTS LIST (go to stage 1)
fc1(x2)
172 cm
c1z(x2)
106 cm s26b (x12)
26 mm
t (x4)
WINDOW PARTS LIST (stage 25)
f-out
(x1) f-in
(x1)
acw (x1)
pls (x1)
f - out (x1)
acw (x1)
sc15 (X7)
18mm
f-in (x1)
Window Parts

5
s13b (x21)
12mm dl (x1)
rc
rc
rc
rc
kc
kc
rc1
rc1
e1d
e1d
e1d
e1d
r1m
121 cm X195 cm
s1d
w1d
w1d
w1d
v
v
h1c
h1c
cc
cc
cc
cc
fu1b
bu1b
dh
dh
d
dl
WALL PARTS LIST (stage 6)
DOOR PARTS LIST (stage 22)
ROOF PARTS LIST (stage 15)
v (x2)
s1d (x1)
88x172 cm
w1d (x3)
88x172 cm
s26b (x60)
26 mm h1c (x2)
165 cm
cc (x4)
168 cm
fu1b (x1)
190x111 cm
bu1b (x1)
190x111 cm
rc(x4)
kc(x2)
s26b (x52)
26 mm
rc1 (x2)172cm
e1d (x4)56 cm
dh(x2) dl (x1)
s13b (x4)
12mm

6
FLOOR ASSEMBLY
t (x1)
f1a
177x111 cm
t
1
2
f1a
177x111 cm
t (x4)
fc1(x2)
172cm c1z(x2)
106cm
t
t
1
2
c1z
c1z
fc1
fc1
t
t

7
Flip the floor upsidedown
s26b(x12)
26mm
fully fit the panel
inside the porfile
10cm
10cm
s26b

8
WALL ASSEMBLY
Flip the floor upsidedown
Choose where do you wan to locate the window
IN OUT

9
cc1(x1)
168cm w1d(x1)
88cm x172cm
s26b(x8)
26mmbu1b(x1)
fully fit the panel
inside the porfile
s26b
cc
w1d
1
2

10
s26b(x8)
26mm
cc1(x1)
168cm w1d(x1)
88cm x172cm
fully fit the panel
inside the porfile
h1c h1c
12
This side up
fully fit the panel
inside the porfile
cc
This side up
w1d
s26b
h1c(x2)
165cm
this side
in

11
cc cc
fully fit the panel
inside the porfile
s13b (x4)
13mm
s1d(x1)
88cm x172 cm
w1d(x1)
88cm x172 cm
cc(x2)
168 cm s26b(x8)
26 mm
fully fit the panel
inside the porfile
inside view
s13b
s26b

12
s26b
s26b(x27)
26mm
fully fit the panel
inside the porfile
s26b
s26b
fu1b (x1)
190cm x 111cm s26b(x8)
26mm

13
ROOF ASSEMBLY
s26b(x8)
26mm
fully fit the panel
inside the porfile
s26b
r1m(x1)folded rc1(x2)172cm e1d(x4) 56cm rc(x4)
2
1
rc
rc
rc
rc
e1d
e1d
rc1
rc1
e1d
e1d
Note:
The roof folding line
and the ''this side down''
label, must be seen at this
stage.
r1m

14
s26b(x24)
26mm
s26b

15
12
12
s26b(x16)
26mm
screwe on the mark line
s26b

16
DOOR ASSEMBLY
d(x1) dl(x1) dh(x2) s13b(x11)
12mm
dl
Pre-drilled
holes
Pre-drilled
holes

17
dl (x1)
s13b (x10)
12mm
s13b
dl
s13b

18
ROOF CROWN ASSEMBLY
VENT ASSEMBLY
s26b(x4)
26mm kc(x2)
kc kc
s26b
v (x2)
v
v
Push vent into position. Your helper
holds the wall from the inside.

19
WINDOW ASSEMBLY
acw (x1)
acw
f-out
pls (x1)
f - out (x1)
4
inside view
3
21

20
f-in (x1)
f-in
sc15 (x7)
18mm
