Keybox KB 12 User manual

Secure Solutions For Protecting Your Keys
www.keyboxsystems.com
1
2
3
45
6
7
8
9
Smart-Box User
Guide

What’s Included With The Smart-Box KB 12
1 x KB 12 Smart-Box
Key Storage Unit
Or 1 x KB 12Plus Smart-Box
Key Storage Unit
with Shackle (Selectable
Purchased)
0
1
2
3
45
6
7
8
9
2 x Mounting Screws 2 x Screws Anchors 1 x Mounting Sticker
Samart-Box KB 12 User Guide
Front Inside Back
Specifications
Model: K12
Material: Body Zinc Alloy, SUS304 4
Battery: x AAA Alkaline Battery
Unlock Mechanism: Bluetooth, PIN Code, App
Jump Start: USB-C
m m (4 - 7 / 1 0 ’ ’ )
021
120mm ( 4- 7/10‘’ ）120mm ( 4- 7/10‘’ ）
22mm ( 4/5 ‘’ )
0
1
2
3
45
6
7
8
9
m m (4 - 7 / 1 0 ’ ’ )
021
Deepth
Page 2

Features
Lock & Unlock
.......
User Unlock
This Smart-Box allows to add
up to 100 user PIN codes for
your family, friends and
visitors.
Auto Locking
If there is no opening motions
in 10 seconds the box will be
automatically locked.
Dynamic Password Unlock
You could generate dynamic
PIN through mobile App, for
scheduled access, parcel
delivery, house keeping, etc.
Low Battery
When the battery runs out of
power, system will remind you
to replace the batteries.
System Lockdown
The lock will be lockdown for
5 minutes if continuously enter
wrong PINs for 5 times.
Emergency
Jump Start
hen the power is down and
use USB-C to jjump start
the lock and get it unlocked
A A A
A A A
A A A
A A A
Administrator Unlock
Set a Master Administrator PIN
for unlocking, settings,
operations etc. and only the
administrator could change the
administrator PIN code.
Anti-Peeping
Add up to 8 - 2 digits before
and after PI code to intensify
your PINs.
Mobile Control
Bluetooth one-touch unlock
With your Mobile you could
unlock the Smart-Box by
touching the Unlock key on the
App.
Mobile Administrator
Set Administrator PIN Codes
from your Mobile to unlock, add
users, delete users, etc.
Battery
Battery life
4 AAA batteries, the life cycle
will be more than 12 months, please
use high quality batteries.
Quick Mounting
Step 1>Install Battery
Please
remove the (4) screws on the battery
cover plate then put 4 AAA batteries
into the battery dock properly and put
the plate back with screws.
A A A
A A A
A A A
A A A
Page 3

Step 2>Wall Mounting
There are 2 screw holes on the
Smart-Box and use the screws and
the screw anchors in the package to
fix the Smart-Box
4XLFN6HWXS
Step 1!,QLWLDOL]HSmart-Box 
LIUHTXLUHG
>The Smart-Box was initialized from factory already, if need it to be initialized please
follow the steps below.
Press and hold the Reset Button for 5 beeps
Please remove the battery plate to Initialize the Smart-Box
and find the reset button hole on the battery dock.
Smart-Box will be initialized with a long beep right after
>1. Please scan QR Codes below and download the App, Scan any one you like.
>2. Run App from your Mobile phone, and make sure your Mobile Bluetooth is on.
Step 2>Mobile App Paring
Page 4

>3. Keep Mobile Bluetooth on and back to the Smart-Box then Press the “Reset ”
button one time only and Blue led light on(Enter Button) .
>4. Once you see the Blue LED on you need to Key in Administrator
password(123456) then press “Enter Button” and start paring(Picture Below)
>5. Right after you pressed the “Enter Button” Tap “Add device” on your App and
you will see the auto-detected smart Smart-Box, Please check the detail
operations below:
1
0
2
3
45
6
7
8
9
Press Reset button 1 time, blue light on
123456
Key in Admin Password and press Enter button
Blue LED on and start paring
Reset
Enter Button
Page 5

12
3
4
5
6
78
Page 6

Step 3>Add Administrator Password(Under Initialized Mode)
>1. Long press the Enter Button for 3 seconds.
>2. Key in new password(more than 4 digits).
>>>3.Press Enter Button in the middle to confirm the password.
>>>>4.Key in the new password again and press Enter Button to complete
1
0
2
3
45
6
7
8
9
Enter Button
Press the Enter Button for adding
and confirming password
Step 4>Add User Password
>1. Press the Enter Button for 3 seconds
>2. Key in Administrator password and press Enter to get Verified
>>>3. Then Key in new user password and press Enter Button
>>>>4. Key in the same user password again and press Enter Button to complete setting
1
0
2
3
45
6
7
8
9
Enter Button
Press the Enter Button for adding and confirming password
Page 7

Step 5>Testing
>1. Unlock the Smart-Box with Administrator Password.
>2. Unlock the Smart-Box with User Password.
>>>3. Lock the Smart-Box by closing back the front assembly, motor rolls up and
locked >>>>4. if everything worked well then move to Mobile control.
Trigger Latch
Motor pushs up the Lock Bolt
>1. Press 2 +Administrator Password+ + User Password to be deleted+
>1. Press +00000+ +Administrator Password+
>1.Press 1 + Administrator Password+ +Password to be Changed+ ,
>2.Enter New Password to be set + + New Password again + to finish the setting.
Manage Users
Change User Password
Delete User Password
Delete All Passwords
1
0
2
3
45
6
7
8
9
Enter Button
Press the Enter Button for adding and confirming password
Page 8

Tips
Sounds & Lights :
Anti-peeping:
Add digits before and after the password, make the password mixed up with
random digits to protect your password.
>1. Press any Button -------“Beep with green on the enter button” .
>2. Successfully added passwords and correct password ------Green flashes with sound “
>3. Improper operations and wrong passwords-------3 red flashes with sound“
>4. Sleep Mode------“Breathing blue light” on Enter button.
>5. Awaiting Operating Mode-----Bule light flashes.
>6. Operating Mode----------Bule light on.
>7. Battery Low------”Red flashes with sound when unlocked”.
>8. App Paring Mode------”Green light on 1 second with Beep Sound”
Distributed/Supported in North America by
Ti e Access Syste s Inc
Phone [phone] Toll Free 1-877-460-9602
www.keyboxsyste s.co
1
2
3
45
6
7
8
9Smart-Box Innovation
Key Storage Solutions
For Information Please Contact US
Page 9
