Keysight Infiniium 9000 Series Instruction sheet

Keysight Infiniium
9000 Series Oscilloscopes
Evaluation Guide
The most recent PDF version of this guide will be placed on the
Keysight web site at:
http://literature.cdn.keysight.com/litweb/pdf/N2918-97003.pdf

Notices
© Keysight Technologies, Inc.
2009
No part of this manual may be
reproduced in any form or by any
means (including electronic stor-
age and retrieval or translation into
a foreign language) without prior
agreement and written consent
from Keysight Technologies, Inc. as
governed by United States and
international copyright laws.
Manual Part Number
N2918-97003
Edition
Third edition, August 2009
Printed in U.S.A.
Keysight Technologies, Inc.
1900 Garden of the Gods Rd.
Colorado Springs, CO 80907 USA
Warranty
The material contained in this doc-
ument is provided “as is,” and is
subject to being changed, without
notice, in future editions. Further,
to the maximum extent permitted
by applicable law, Keysight dis-
claims all warranties, either
express or implied, with regard to
this manual and any information
contained herein, including but
not limited to the implied warran-
ties of merchantability and fitness
for a particular purpose. Keysight
shall not be liable for errors or for
incidental or consequential dam-
ages in connection with the fur-
nishing, use, or performance of
this document or of any informa-
tion contained herein. Should Key-
sight and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the
separate agreement shall control.
Technology Licenses
The hardware and/or software
described in this document are fur-
nished under a license and may be
used or copied only in accordance
with the terms of such license.
Restricted Rights
Legend
If software is for use in the perfor-
mance of a U.S. Government prime
contract or subcontract, Software
is delivered and licensed as “Com-
mercial computer software” as
defined in DFAR 252.227-7014
(June 1995), or as a “commercial
item” as defined in FAR 2.101(a) or
as “Restricted computer software”
as defined in FAR 52.227-19 (June
1987) or any equivalent agency
regulation or contract clause. Use,
duplication or disclosure of Soft-
ware is subject to Keysight Tech-
nologies’ standard commercial
license terms, and non-DOD
Departments and Agencies of the
U.S. Government will receive no
greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2)
(June 1987). U.S. Government
users will receive no greater than
Limited Rights as defined in FAR
52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November
1995), as applicable in any techni-
cal data.
Safety Notices
CAUTION
CAUTION
A CAUTION notice denotes a
hazard. It calls attention to an
operating procedure, practice,
or the like that, if not correctly
performed or adhered to, could
result in damage to the prod-
uct or loss of important data.
Do not proceed beyond a CAU-
TION notice until the indicated
conditions are fully understood
and met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice,
or the like that, if not correctly
performed or adhered to,
could result in personal injury
or death. Do not proceed
beyond a WARNING notice
until the indicated conditions
are fully understood and met.
2

Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide 3
Keysight Infiniium 9000 Series Oscilloscope
Evaluation Guide
Does your job require an oscilloscope that can adapt to a wide variety of debug
and test challenges? Keysight engineers developed the Infiniium 9000 Series
oscilloscopes with the industry’s broadest measurement capability. What gives
the Infiniium 9000 Series the industry’s broadest measurement capability?
1. Best Fit for Workspace
Oscilloscopes are visual tools and large, high-resolution displays make the
product better. Largest in the industry, the 15” XGA screen makes it easier to
view analog, digital, or serial signals, especially when you need to view
multiple signals simultaneously.
Limited bench space? Not a problem. To achieve the thinnest depth, lightest
weight, and smallest footprint in its class, Keysight engineers developed a
single-acquisition board oscilloscope that extends up to 4 GHz bandwidth. A
precision-engineered dense 20-layer printed circuit board, 27 custom ASICs,
and multiple FPGAs, enables the instrument’s innovative form factor.
2. Three Instruments in One
With superior oscilloscope specifications and rich built-in analysis, the
Infiniium 9000 Series extends oscilloscope-centric testing with logic and
protocol analysis capabilities. Mixed-signal oscilloscope (MSO) models add
integrated 2 GSa/s digital channels. Infiniium 9000 Series oscilloscopes
incorporate hardware-based protocol triggering, protocol decode, and the
industry’s first oscilloscope-based protocol viewer that extends to PCI Express
and USB.
3. Widest Range of Debug and Compliance Application
Software
Expand your oscilloscope’s capabilities with our powerful lineup of
applications.
Keysight wants to help you get fast, accurate answers to your measurement
questions. That’s why the Infiniium 9000 Series oscilloscopes offer the largest
range of software applications engineered to quickly and easily provide
exceptional insight into technology-specific testing.

4 Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide
Required Equipment
• Keysight Infiniium 9000 Series oscilloscope.
• Two passive probes.
• Demo kit with demo board and USB cable.
Demo board connections:
Power is provided via
USB or MSO cable.
Oscilloscope Probe Connections
MODE Action
Select Knob
Power
or
MSO Cable
Connection
(Digital Inputs)
InfiniiMax
differential probe

Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide 5
In This Guide
If you are experiencing the Infiniium 9000 Series oscilloscope for the first time,
begin with Lab 1, the Getting Started Guide. If you have a basic knowledge of
the Infiniium 9000 Series oscilloscope’s front-panel controls, begin with Lab 2.
Topic Page
Time
Allowance
Lab 1:Getting Started 7 10 min.
Lab 2:Viewing Complex Signals 22 10 min.
Lab 3:Uncovering Signal Anomalies with
Responsive Deep Memory 26 10 min.
Lab 4:InfiniiScan Triggering 29 5 min.
Lab 5:Mixed-Signal Oscilloscope (MSO) 32 10 min.
Lab 6:USB 36 10 min.
Lab 7:I2C 45 10 min.
Lab 8:SPI 49 10 min.
Lab 9:CAN 55 10 min.
Lab 10:RS-232 57 10 min.
Lab 11:Segmented Memory 61 10 min.
Lab 12:Histograms 65 5 min.
Appendix A:Using Trigger Holdoff to Synchronize
Acquisition/Display on Complex Signals 67 10 min.

6 Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide

7
Keysight Infiniium 9000 Series Oscilloscopes
1 Getting Started
If you are not familiar with the Keysight Infiniium 9000 Series oscilloscopes,
please first look over the main sections of the front panel as illustrated and
then follow the exercises.

1Getting Started
8 Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide
Drag-and-drop
measurements
Status tab shows
current settings
Mixed-signal oscilloscope
(MSO) cable connection
15" XGA touch screen
display
AutoProbe interface

Getting Started 1
Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide 9
Run Control
Selection knob, immediate action keys, and special menus
Push the knob to toggle selection
Trigger level knob
and controls
Time/div and position
horizontal controls
Color-coded controls
for each oscilloscope
channel
Digital button for
mixed-signal
oscilloscope (MSO)
channels D0 – D15
Serial Decode button
for quick decode
access
USB ports

1Getting Started
10 Keysight Infiniium 9000 Series Oscilloscope Evaluation Guide
Capturing and Viewing a Simple Signal
1To power the demo board, connect a USB cable between it and the
Keysight Infiniium 9000 Series oscilloscope.
You can also apply power by connecting the oscilloscope’s MSO cable to
the demo board’s 40-pin connector.
2Connect the scope channel 1 probe to demo board CH1 and GND.
3Turn the SELECT switch to position 3 (Burst).
4Press the [Default Setup] key on the front panel.
The oscilloscope is now set in the default configuration. Because the
oscilloscope may have been used in a variety of applications by a variety of
people, it is a good measurement procedure to put the oscilloscope in a
known starting mode (Default Setup). This will make it easy to duplicate
measurements as no special conditions will be set.
Press
