KFI 101355 User manual

©2017 Copyright Kappers Fabricating, Inc. All rights reserved Page 1
CF-Moto CForce 400S
Winch Mount
Winch Mount PART # 101355
Hardware Kit: HK-326
Kit Components:
INSTALLATION INSTRUCTIONS:
Note: Make sure all of the hardware needed to complete this
mount are in the package. Depending on your winch you may
have extra hardware left over when finished installing. Read
through and understand the instructions before installing.
1. Removethe(4)boltsfromthefrontplasticfascia.
ShowninFigure2.
2. Setwinchmountplate(1)andwinch(A)upsidedown
intheopeningbehindthefrontframetubes.Shownin
Figure3.
3. Attachmountplate(1)looselytothebackofthe
frameusingthefourcarriagebolts(3)intothestock
holelocation.ShowninFigure4.
“Figure 1”
Item # Qty. Description
1 1 Winch Mount
2 1 Winch Fairlead Plate
3 4 3/8-16 X 1” Short Neck Carriage Bolt
4 4 3/8-16 Hex Flange Nylock Nut
5 2 5/16”-18 X 1-1/4” Hex Flange Bolt
6 2 5/16”-18 Hex Flange Nylock Nut
2
1
6
3
4
5
1
“Figure 4” Passenger Side.
“Figure 2”
“Figure 3” Front End
A
3
MotorSide
ClutchSide

©2017 Copyright Kappers Fabricating, Inc. All rights reserved Page 2
WIRING INFORMATION
1. The battery location is under the seat.
2. We recommend mounting the contactor next to the battery
under the seat.
3. Usethewiringdiagraminyourwinchmanualtoseehow
thewinchandcontrollersarewired.
4. Wire the red ignition wires from controllers to the red (+)
4. Attachtherearholesofthewinchtothewinch
mount(1)looselyusingthehardware(B)provided
withyourwinch.ShowninFigure5.
5. Setwinchfairleadplate(2)intotheintheopening
behindthefrontframetubesovertopofthewinch
mountplate.ShowninFigure6.
6. Attachthefrontholesofthewinchthroughthetwo
plateslooselyusingthehardwareprovidedwith
yourwinch.ShowninFigure7.
7. Bolttherollerfairleadtothefrontfactoryfairlead
locationontheframe.Byinsertingthesupplied
5/16bolts(5)throughthefairleadrollersintothe
threadedframeholesandoutthemountingholes.
Attachthe5/16angenut(6)totheboltsloosely.
ShowninFigures7&8.
8. Tightentherearframebolts(3)asshowningure
4,andfrontfairleadbolts(5)showningure7.
Nexttightenwinchboltsonthetopofthemount.
B
“Figure 5”
“Figure 6”
“Figure 7”
2
5
C
“Figure 8”
6
