Kguard MR-4020 User manual

MARS NVR Combo Kit
USER MANUAL
MR-4040 / MR-4020
Default user name: admin
Default password: 123456
NVR

ENGLISH
Preface
2
NVR User’s Manual
About this Manual
The material in this document is for informaon purpose and is subject to change without prior noce. We
made every eort to ensure that this user’s manual is accurate and complete. However, no liability is assumed
for any errors and omissions that may have occurred.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instrucons, may cause harmful interference
to radio communicaons. However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or television recepon, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the product and receiver.
• Connect the product into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Declaraon of Conformity
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operaon.
Copyright
Limitaon of Liability
• This publicaon is provided “AS IS” without warranty of any kind, either expressed or implied, including
but not limited to, the implied warranes of merchantability, tness for any parcular purpose, or non-
infringement of a third party’s rights.
• This publicaon may include technical inaccuracies or typographical errors. Changes may be made to the
informaon herein, at any me, for publicaon improvements and/or of the corresponding device(s).
Disclaimer of Warranty
In no event shall the supplier be liable to any party or any person, except for replacement or reasonable
maintenance of the product, for the cases, including but not limited to the following:
• Any damage or loss, including but without limitaon, direct or indirect, special, consequenal or exemplary,
arising out of or relang to the device;
• Personal injury or any damage caused by inapppropriate use or negligent operaon of the user;
• Unauthorized disassemble, repear or modicaon of the device by the user;
• Any problem, consequenal inconvenience, or loss or damage, arising out of combining the system with the
devices of a third party;
• Any claim or acon for damages, brought by any person or organizaon being a photogenic subject, due to
violaon of privacy with the result of pictures from a surveillance camera, including saved data, for some
reason, becomes public or is used for the purpose other than for surveillance.

ENGLISH
Preface
NVR User’s Manual
3
Safety Informaon
Warning
This is the symbol for indicang any potenal hazard,
risk or condion requiring special aenon.
The user needs to refer to the important operang
and maintenance or servicing instrucons.
Cauon
The lighng ash with an arrow head symbol, in an
equilateral triangle, is intended to alert the user.
There is dangerous “voltage” presence near by the
product’s enclosure which may be risk of person.
Safety Precauons
• Do not touch live electrical parts.
Electric shock can be avoided. Follow the
recommended pracces listed below. Faulty
installaon, improper grounding, and incorrect
operaon and maintenance of electrical equipment
are always sources of danger.
• Do not try to install equipment outdoor, during strong
wind and rain.
• Do not install or remove equipment outdoor, when
raining.
• Do not try to install or operate any equipment, during
a thunderstorm.
• Always ground all electrical equipment and the work
plaorm.
Prevent accidental electrical shocks. Connect power
source, control cabinets, and work plaorm to an
approved electrical ground.
• Always use the correct cable size.
Sustained overloading will cause cable failure and
result in possible electrical shock or re hazard. Work
cable should be the same rang as the factory.
• Always keep cables and connectors in good condion.
Improper or worn electrical connecons can cause
short circuits and can increase the chance of an
electrical shock. Do not use worn, damaged, or bare
cables.
• Always avoid open-circuit voltage.
The added voltages increase the severity of electric
shock hazard.
• Always wear insulated gloves while you adjust
equipment.
Electric power should be turned o and insulated
gloves should be worn when making any equipment
adjustment to assure shock protecon.
• Always wear protecve clothing such as long
sleeve shirts while you are installing or removing
equipment.
• Always wear high, snug ng shoes.
• Always wear clean clothes without grease or oil.
• Protect neighboring workers from exposure to arc
radiaon.
• Always wear long trousers or jeans while you are
installing or removing equipment.
• Always wear safety helmet or hard head and safety
shoes before work.
• Always keep the equipment in dry places.
• Always wear safety harnesses/belt while you work in
high places.
• Always wear dry clothing and avoid moisture and
water.
• Always wear Public Safety Vest, while you work at
night.
• Make sure all electrical connecons are ght, clean,
and dry.
• Make sure that you are well insulated to eliminate
electric stac charge.
• Always wear dry gloves, rubber-soled shoes, or stand
on a dry board or plaorm.
• Always follow recognized safety standards.
• Always wear correct eye, ear, and body protecon.
• Always have second person on-site, while you work in
dark, poor venlaon, or high places.
• Make sure that you are well protected against arc
ashes, mechanical injury, or other mishaps.
• Make sure that the polarity of wire is correct before
installing equipment.
• Always handle equipment with care.
• Do not block the venlaon of equipment.
• Do not put the magnec parts around the equipment.
• Do not put the objects on top of the equipment.

ENGLISH
Contents
4
NVR User’s Manual
Contents
About this Manual .................................................................................................................... 2
FCC Compliance Statement....................................................................................................... 2
Copyright .................................................................................................................................. 2
Safety Informaon .................................................................................................................... 3
Quick Setup Guide.............................................................................................. 6
Step 1: Unpack Your NVR .......................................................................................................... 6
Step 2: Install the Hard Disk Drive (HDD) .................................................................................. 7
Step 3: Make the Connecons .................................................................................................. 8
Front Panel ....................................................................................................................... 8
Rear Panel ........................................................................................................................ 8
Perform the connecons as shown on the diagrams. ............................................................ 10
Step 4: Switch ON the NVR ..................................................................................................... 11
Step 5: Go through the Items in Startup Wizard ..................................................................... 12
Step 6: Make Sure the Camera(s) are Funconing .................................................................. 16
Step 7: Mount the Camera(s).................................................................................................. 17
Understanding the Live Viewing Screen ............................................................ 18
Pop-Up Menu on Live Viewing Screen .................................................................................... 22
Basic NVR Operaon ........................................................................................ 24
Using the Supplied USB Mouse .............................................................................................. 24
Virtual Keyboard ............................................................................................................. 24
Locking the Screen ......................................................................................................... 24
Using the Supplied Remote Control ........................................................................................ 25
Reboong/Shung Down the NVR ........................................................................................ 26
Accessibility Features ....................................................................................... 27
Downloading New KView App ................................................................................................ 27
Using Cloud Storage ................................................................................................................ 29
How to Create a Dropbox Account ................................................................................. 29
How to Congure the Cloud Storage Sengs ................................................................ 30
Advanced E-mail Setup ................................................................................................... 31
Acvate Cloud ................................................................................................................ 32
Operang the NVR ........................................................................................... 35
Main Menu ............................................................................................................................. 35
Display: Camera ...................................................................................................................... 37
Display: Live ............................................................................................................................ 37
Display: Output ....................................................................................................................... 38
Display: Privacy Zone .............................................................................................................. 40
Record: REC Para ..................................................................................................................... 41
Record: Schedule .................................................................................................................... 42
Search: Record Search ............................................................................................................ 44
Playback Screen .............................................................................................................. 46
Trimming Videos ............................................................................................................. 47
Search: Event Search ............................................................................................................... 48
Search: Log .............................................................................................................................. 48

ENGLISH
Contents
NVR User’s Manual
5
Network: Network .................................................................................................................. 49
Network: Video Stream .......................................................................................................... 51
Network: Email ....................................................................................................................... 52
Network: DDNS ....................................................................................................................... 53
Alarm: Moon ........................................................................................................................ 56
About Moon Detecon ................................................................................................ 56
Set Moon Detecon Area ............................................................................................. 56
Alarm: Alarm ........................................................................................................................... 57
Device: HDD ............................................................................................................................ 58
Device: Cloud Storage ............................................................................................................. 59
System: General ...................................................................................................................... 61
System: Users .......................................................................................................................... 62
System: Info ............................................................................................................................ 63
Advanced: Maintain ................................................................................................................ 64
Advanced: Events .................................................................................................................... 67
Remote Access Via Web Client.......................................................................... 68
Logging In ............................................................................................................................... 68
Interface Overview ................................................................................................................. 69
Live Viewing ............................................................................................................................ 70
Switching Screen Modes ......................................................................................................... 71
Viewing and Recording ................................................................................................... 72
Viewing or Hiding Channels ............................................................................................ 72
Recording Channels Manually ............................................................................... 72
Taking Snapshots ............................................................................................................ 72
About the Main Menu ............................................................................................................ 73
Local Sengs .................................................................................................................. 74
Loggin O ....................................................................................................................... 74
Appendix.......................................................................................................... 75
Troubleshoong ...................................................................................................................... 75
Specicaons .......................................................................................................................... 76

ENGLISH
Mars Series: Quick Setup Guide
6
NVR User’s Manual
Quick Setup Guide
Thank you for purchasing the Mars Series Network Video Recorder (NVR). Your NVR allows you to use all the
advantages of the network video surveillance system, such as, superior image quality, remote accessibility and great
exibility.
The rst part of this User Manual provides you step-by-step instrucons on how to quickly set up and start using
your NVR with the precongured sengs. If you are interested in learning more about the funcons and accessibility
opons of your NVR then you can nd advanced conguraon in the laer part of the manual.
Step 1: Unpack Your NVR
Please take a moment to check if all the necessary items are included in the package. If anything is missing or
damaged, please contact your dealer immediately.
When you purchase the Mars Series NVR, the package should include the following items:
• NVR • IP security camera • Mouse • 19V/4A power adapter
4CH NETWORK VIDEO RECORDER
• 1.8M Ethernet cable • HDMI cable • PoE cable • Remote control
123 456 789
ALL
0
MENU
AUDIO/
SEARCH
MUTE
SEL
• Baery • 2.5”&3.5” HDD screws • Camera screw kit

ENGLISH
Mars Series: Quick Setup Guide
NVR User’s Manual
7
Step 2: Install the Hard Disk Drive (HDD)
The reason you need to install an HDD on the NVR is to be able to save video footages from the IP security camera(s).
This NVR supports one 3.5” and 2.5” SATA HDD.
CAUTION: DO NOT install or remove the hard disk drive while the device power is turned ON.
To install the HDD, follow the instrucons below.
1. Remove the cover
Loosen the screws as shown. Push back then li up the cover
to remove it.
2. Install and secure the HDD
Connect the data and power cables Align the HDD on the holes on the
to the HDD and place the HDD on NVR case and secure the HDD
the NVR case. using the four (4) supplied screws.
3. Replace the cover
Aach the cover and the screws
back in place.

ENGLISH
Mars Series: Quick Setup Guide
8
NVR User’s Manual
Step 3: Make the Connecons
In order to make the connecons, you need to know the connecon ports and the meaning of the control LEDs. Please
take a moment to review the front and rear panel.
Front Panel
4CH NETWORK VIDEO RECORDER
1 2
3
1) HDD Indicator:
• Solid ON: The HDD is installed.
• Blinking: The HDD is accessed.
2) Power Indicator: Lights green to indicate the power is turned on.
3) USB 2.0 port: Connect a USB compable device here. For example, an external USB storage device for backup or
rmware update, or USB mouse.
Rear Panel
VGA
ALARM
SENSOR
G1234
WAN
HDMIIR-EXT
AUDIO
OUTPUT LAN 4 LAN 2
LAN 3 LAN 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
19V
1 2 3 4 5 7 8 9 106
1) Infrared (IR) Extender Port: By default the NVR has a built-in IR receiver on front panel, allowing you to use the
remote control. However, if the distance between the remote control and the NVR is too large, you need to
install an IR extender into the IR extender port.
NOTE: The IR extender is not included.
2) HDMI Output: This is considered as the main output of the NVR. We recommend using this output for the best
available video output quality.
• For ulmate result, use a Full HD 1080p-capable monitor/TV.
NOTE: Please be noted that in many cases the TV which can display 1080p resoluon is not always a Full HD. In
reality they downscale a 1080p signal to the resoluon of the screen. For the best image quality, we recommend
to use a monitor/TV that can display a resoluon 1920 x 1080 or higher.
3) Audio Output: The supplied camera does not support audio recording. For normal operaon, the Audio Output
is not required.
4) VGA Output: If an HDMI monitor is not available, use this connecon to connect to a PC monitor using VGA
connecon.

ENGLISH
Mars Series: Quick Setup Guide
NVR User’s Manual
9
5) USB 2.0: Connect here an external HDD or a ash disk where you can backup footage.
NOTE: You can also congure the Cloud Storage for saving the snapshot on a me and moon interval to an o-
site cloud storage. See “Using Cloud Storage” on page 29.
6) Alarm and Sensor I/O Port: Here you can connect 4 external alarm sensors and an alarm output device, for
example a siren.
7) WAN Port: This port is for connecng the NVR to the network, usually directly into the network switch or router.
8) LAN 1 ~ LAN 4 Port: These ports are for the main video input from the IP cameras. When connecng the IP
camera(s) to these ports, make sure to use the supplied Ethernet (RJ45) cables. The channel labels of the ports
appear in the same order as they are shown on your NVR’s interface.
9) Power Input: Connect here the supplied power adapter cable.
10) Power Switch: Switch to turn ON/OFF the NVR.

ENGLISH
Mars Series: Quick Setup Guide
10
NVR User’s Manual
Perform the connecons as shown on the diagrams.
1. Connect the monitor/TV to the NVR via HDMI (recommended) or VGA port.
VGA
ALARM
SENSOR
G1234
WAN
HDMIIR-EXT
AUDIO
OUTPUT LAN 4 LAN 2
LAN 3 LAN 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
19V
HDMI
VGA
If your monitor does not sup-
port HDMI then connect it to
the VGA Output on the NVR.
If your monitor/TV supports
HDMI, connect it to the HDMI
Output on the NVR.
2. Connect the IP cameras to the NVR and NVR to the network.
VGA
ALARM
SENSOR
G1234
WAN
HDMIIR-EXT
AUDIO
OUTPUT LAN 4 LAN 2
LAN 3 LAN 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
19V
WAN
LAN 4LAN 2
LAN 3LAN 1
WANLAN LAN LAN LAN
Internet
Use the supplied Ethernet cable
to connect the camera output to
the video input on the NVR.
NOTE: The power supply for the
camera is not required because
the NVR will provide the power
via Ethernet cable from its own
power supply.
Connect one end of the Ethernet
cable to the WAN Port on the
NVR and the other end to an
empty port on your router.

ENGLISH
Mars Series: Quick Setup Guide
NVR User’s Manual
11
3. Connect a USB mouse to the USB port on the NVR.
You need the USB mouse to go
through the inial setup menus once
the NVR is powered ON.
VGA
ALARM
SENSOR
G1234
WAN
HDMIIR-EXT
AUDIO
OUTPUT LAN 4 LAN 2
LAN 3 LAN 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
19V
Step 4: Switch ON the NVR
Follow the instrucons on the diagram, to switch ON the NVR.
VGA
ALARM
SENSOR
G1234
WAN
HDMIIR-EXT
AUDIO
OUTPUT LAN 4 LAN 2
LAN 3 LAN 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
19V
19V
19V
A) Connect the supplied
power cable to the
power adapter.
B) Plug in the power cable
to the power outlet.
C) Connect the
power adapter
(19V/4A only) to
the Power Input
on the NVR.
D) Press the Power
Switch to switch
ON the NVR.
Aer the NVR is switched ON, the Startup Wizard appears on your monitor/TV screen (please see the next step). If it
is the rst me you power ON the NVR, we recommend to go through the wizard and ll in the various setup opons
available.
NOTE: If you decide to skip the Startup Wizard, you can sll access all the setup opons later via the NVR’s interface.

ENGLISH
Mars Series: Quick Setup Guide
12
NVR User’s Manual
Step 5: Go through the Items in Startup Wizard
For going through the items on Startup Wizard, the most convenient way is to use the supplied USB mouse. See the
USB mouse operaons in “Using the Supplied USB Mouse” on page 24.
The wizard includes setup screens which allow you to choose how you want the NVR to operate. All items on the
wizard are also accessible via the NVR’s Main Menu (see “Main Menu” on page 35).
Startup Wizard
If you do not want to go through the Startup Wizard but access the Live Viewing screen immediately (step 6), you can
click Exit. A conrmaon message appears on the screen, click OK.
If you want to disable the Startup Wizard aer reboot, click Yes.
NOTE: All the items on Startup Wizard can be accessed also through the NVR’s Main Menu.
Click Next Step to move to the next screen.

ENGLISH
Mars Series: Quick Setup Guide
NVR User’s Manual
13
HDD Management
If you start up the NVR for the rst me, you need to format the HDD. To format the HDD, check the Select checkbox
and click Format HDD. A warning menu opens where you are asked to conrm your selecon. Click OK.
For the inial setup, keep the Overwrite opon Auto as by default. This is the me period when the old recordings are
overwrien. You can congure it later via NVR’s Main Menu.
NOTE: By default the NVR starts recording automacally aer the HDD is formaed and the connecon to the cameras
is established.
Click Next Step to move to the next window.

ENGLISH
Mars Series: Quick Setup Guide
14
NVR User’s Manual
System General Conguraon
It is very important that the me and date are set correctly. In case of a robbery, for example, the video footage can
be used as an evidence in the court, and if the date and me do not match, the footage is not regarded as a legimate
evidence.
Date and Time: The current date and me are displayed on the screen. To change the date and/or me, you need to
click on the corresponding eld and do the modicaons via the on-screen keyboard. Aer the changes are done, click
the Save buon.
Date Format: Choose how you would like the date to appear on the screen. We recommend to use the standard
formats in your locaon.
Time Format: Choose how you would like the me to appear on the screen. The available opons are 24-hour format
or 12-hour format.
DST: Congure the Daylight Saving Time if it is applicable in your region. By default the DST is set Disable.
NTP: Skip the NTP (Network Time Protocol) for the me being because it requires an acve Internet connecon. By
default, this item is enabled. It means that the me and date is updated automacally. However, we suggest to set the
date and me manually at this stage.
Language: Choose the preferred language you wish the menu items to appear on your NVR.
Click Next Step to move to the next screen.

ENGLISH
Mars Series: Quick Setup Guide
NVR User’s Manual
15
Network Conguraon
Network sengs should be congured if you want to connect to the NVR remotely for live viewing or for example,
if you want the NVR to synchronize the date and me automacally. For the inial setup of the NVR you can skip
conguring the network sengs and do it later via the Main Menu.
Type: Select the network type you are using. The most common types are DHCP or Stac. Most probably your network
type is DHCP, unless the network is manually addressed (usually called- Stac).
NOTE: If your network type is Stac, ask your ISP for assistance on determining the IP address, Subnet mask, Gateway,
and DNS 1/2 server. If your network type is DHCP, your NVR will optain the connecon parameters, like IP address,
Subnet Mask, Gateway and DNS 1/(2) automacally.
Client Port and HTTP Port: For me being, keep the default port values. These ports are important to congure if you
want to use UPnP feature or do Port Forwarding for allowing access to the NVR remotely from a PC via HTTP Interface.
For the rst me startup, you do not need to congure Email or DDNS.
Click Apply. A nocaon message appears on the screen, click OK.
Another nocaon messages appears on the screen, asking your conrmaon to disable Startup Wizard aer reboot.
Click Yes.
The NVR will reboot.

ENGLISH
Mars Series: Quick Setup Guide
16
NVR User’s Manual
Step 6: Make Sure the Camera(s) are Funconing
Aer you complete Step 5, you should be able to see the Live Viewing screen. You should see a live video from the
connected camera(s) in about 30 seconds.
NOTE: The example below is a live view from four cameras.
Please see “Understanding the Live Viewing Screen” on page 18, for more detail about the Live Viewing screen.

ENGLISH
Mars Series: Quick Setup Guide
NVR User’s Manual
17
Step 7: Mount the Camera(s)
If you are convinced that the camera(s) are funconing properly, it is me to mount the camera(s).
Position Gasket
2. Drill the holes and aach the camera.
Use a posion gasket to idenfy the correct posion of Insert the plasc washers into the holes. Then place
the screw holes. Then drill three (3) small holes on the the three (3) supplied screws into the three holes at
mounng locaon. the end of the camera Mount Bracket, and secure
them into the holes on the wall, using a screwdriver.
1. Locate your ideal camera posion on the selected surface, for example on the wall.
CAUTION: Please avoid installing the camera near the indoor lights, for example under uorescent light, and do NOT
point the camera to the light directly.
3. Adjust the camera.
Loosen the adjustment screw of the camera, using the When the adjustment is done and the best
star wrench. Adjust the camera posion to suit the posion is found, ghten the adjustment screw to
monitoring area. x the posion.
90°

ENGLISH
Mars Series: Understanding the Live Viewing Screen
18
NVR User’s Manual
Understanding the Live Viewing Screen
First sceen you see aer going through or skipping the Startup Wizard, is the Live Viewing screen. It is considered the
main screen. On this screen you see the live views from the connected cameras. Please be noted that the conneciton
to the cameras may take up to 30 seconds.
• 4 Split Screen (four cameras connected, default screen)
Live Viewing Screen (4 Cameras Connected)
Those channels that do not have any cameras connected, are in the status “Connecng”.

ENGLISH
Mars Series: Understanding the Live Viewing Screen
NVR User’s Manual
19
Live Viewing Screen (3 Cameras Connected, 1 Empty Channel)

ENGLISH
Mars Series: Understanding the Live Viewing Screen
20
NVR User’s Manual
• Full Screen Mode (one channel in full screen)
You need to double click on a channel live view, to see the channel in full screen. If you want to exit the full screen
mode, double-click, again.
Live Viewing Screen (Full Screen Mode)
