Kicker KM67S User manual

KM COMPONENTS
KM67S | KMS67
Owner’s Manual | English
KM Components
2014 KMS Rev F.indd 12014 KMS Rev F.indd 1 4/4/2019 2:25:14 PM4/4/2019 2:25:14 PM

2
The Kicker KMS67 high-efficiency component system is specially designed for “Livin’ Loud” out in
the harsh marine environment, and is made using advanced materials and construction techniques,
maintaining optimal performance for years to come. The KMS67 features a pair of 6.75 inch mid-bass
woofers and 1.7 inch horn-loaded compression drivers. Combine the KMS67 and KM67S for a 6-driver
system.
SPECIFICATIONS
WIRING & INSTALLATION
Wire and install the KMS67 drivers and horns to your speaker
cans as per the manufacturer’s instructions. For optimal
performance, consider loosely filling 50%-100% of the can
with poly-fil.
Wire the cans in parallel as illustrated at the top of Page 3.
If you’ve added an additional mid to each channel with the
KM67S, please reference the diagram at the bottom of page
3.
To get the best performance with minimal distortion out of your
KM system, use a high-pass filter (or crossover); 80–100Hz is
a good starting point.
KMS Component System
Owner’s Manual
Authorized KICKER Dealer:
Purchase Date:
Speaker Serial Number:
KM67S | KMS67Models:
+
+
-
-
Model: KMS67 KM67S*
Woofer [in, mm] 6-3/4, 165 6-3/4, 165
Horn Loaded Compression Driver [in,mm] 1.7, 43 N/A
Dome Material Titanium N/A
Rated Impedance [Ω] 4 4
Peak Power Handling [ Watts] 400 200
Continuous Power Handling [Watts RMS] 200 100
Sensitivity [1W, 1m] 94.5dB 1 mid, 99.5dB 2 mids 90.5dB
Frequency Response [Hz] 50–22k 50-1700
Woofer Mounting Hole Diameter [in, mm] 5-11/16, 144 5-11/16, 144
Woofer Bottom Mount Depth [in, mm] 3-7/8, 99 3-7/8, 99
Horn Mounting Hole Diameter [in,mm] 5-11/16, 144 N/A
Horn Mounting Depth [in,mm] 7-3/16, 183 N/A
High Pass [dB], at Frequency [Hz] 18, 1700 N/A
Low Pass [dB], at Frequency [Hz] 12, 1700 12, 1700
High Frequency Output Attenuation [dB] 0, +6 N/A
*- Available through KICKER warranty
2014 KMS Rev F.indd 22014 KMS Rev F.indd 2 4/4/2019 2:25:18 PM4/4/2019 2:25:18 PM

3
CROSSOVER
The KMS67 uses a built-in crossover for both the mid and horn. To adjust the output level, use the jumper
on the back of the horn-loaded compression driver by pushing down on the terminal, inserting the wire
and then releasing the terminal to secure it. For example, when using the KMS67 with extra mids provided
in the KM67S, move the jumper wire to +6 dB.
Note: Kicker Marine speakers meet or exceed industry standards for environmental humidity and corrosion, and for
material degradation due to UV exposure.
From Amplifier
From Amplifier
0 dB gives a flat frequency
response and is the recommended
configuration for use with one mid.
+6 dB gives a flat frequency
response and is the recommended
configuration for use with two mids.
Jumper Wire
Horn Can Mid Can
Mid Can Horn Can Mid Can
Terminal Terminal
TerminalTerminalTerminal
+
+
-
-
Horn-loaded compression driver
