Introduction
The PAT-T series Communication Interface Manual explains the settings and commands for
remotely controlling the PAT-T series using the communication interface.
•RS232C interface
•GPIB interface (factory option)
•USB interface (factory option)
•LAN interface (factory option)
When the PAT-T is operating under remote control, the RMT LED on the display on the front
panel illuminates. To switch from the remote mode to the local mode (panel operation) from
the panel, press the LOCAL switch.
How to read this manual
This manual is in HTML format that can be viewed with a WWW (World Wide Web) browser.
The HTML manual can be viewed using the following browsers.
Operating environment: Windows 98 or later
Browser: Microsoft Internet Explorer 5.5 or later
Related manuals
For the safety precautions, installation, operation, and specifications of the PAT-T, read the
accompanying PAT-T User's Manual.
Intended readers
This manual is written for readers with sufficient basic knowledge of how to control
instruments using a personal computer.
Structure of the manual
This manual consists of the following sections.
•Overview
• Setup
• Overview of messages
•Command (list*1)
• Appendix
• Tutorial
*1. The list of command is provided in a PDF file. Adobe Reader 6.0 or later is required to
view the file.
Trademarks
Microsoft, Windows NT and Windows are registered trademarks of Microsoft Corporation in
the United States and/or other countries.
All other company names and product names used in this manual are trademarks or
registered trademarks of the respective company.
Firmware version of the product to which this manual
applies
This manual applies to 8 kW type products with firmware version 5.xx and 4 kW type
products with firmware version 4.xx.
