KinAn KM0104 User manual

4 Port KM Switch
(KM0104)
User Manual
www.kinankvm.com
@all right reserved Shenzhen Kinan Technology Co., Ltd.
Printing date：2021/09
Version：V2.1

4 Port User Manual
- 1 -
Overview
The 4 Port Keyboard-Mouse Switch enables users to manage and switch KM
(Keyboard and Mouse) functions of four connected computers, including
multi-head computers. It supports seamless Keyboard-Mouse Command on 4
computers from a single workstation. The KM0104 is completely driverless,
requiring no software. It is compatible with any PC and all major operating
systems without the need for software downloads.
Features
• Single USB keyboard and mouse control up to 4 computers
• Support stereo audio output
• Support USB2.0 HUB
• Port selection via front panel pushbuttons, keyboard hotkey and mouse
cursor
• No software required
• Support hot-plugging
• Support USB-C firmware upgrade
• Provide LED indicator to help you find your current mouse/keyboard
location (Optional)
• Management software is available providing customized switching
modes (Optional)
Structure and Size

4 Port User Manual
- 2 -
Installation
Before starting the installation, please confirm that all devices are powered
off.
1) Please connect USB keyboard and mouse to the USB port of the
KM0104(①)
2) Connect computers and KM switch with attached USB cables(②)
3) Plug in the power adapter(③)
4) Power on the computers, switch between computers easily trough push
buttons and keyboard hotkey
*The factory default setting is no hotkey. If you need hotkey
operation, press the two white [ ] + [ ] key. The hotkey will be
activated 2S after power on again.
5) If speaker is required, please plug in the audio port (④⑤)
6) If USB2.0 peripherals required, please connect peripherals to USB2.0
port(⑥)

4 Port User Manual
- 3 -
Components
No.
Button
Description
1
Switch Keyboard, Mouse and Audio to Previous
PC
STATTION (1-4): Switch to the previous PC, the
corresponding LED light is on
The flashing STAT1, STAT2 LED lights indicates
normal communication
2
Switch Keyboard, Mouse and Audio to Next PC
STATTION (1-4): Switch to the previous channel,
the corresponding LED light is on
The flashing STAT1, STAT2 LED lights indicates
normal communication
3
Press [ ]+ [ ] key for 2 seconds to disable
hotkey function.
To enable the hotkey function, Press[ ]+ [ ]
key for 2 seconds and restart the KM0104.

4 Port User Manual
- 4 -
Hotkeys
*The factory default setting is no hotkey. If you need hotkey operation,
press the two white [ ] + [ ] key for 2 seconds. The hotkey will be
enabled after restart the KM0104.
Commands
Hotkeys
Description
PC switching
L_Ctrl + L_Ctrl + port#
Switch Keyboard, Mouse, Audio and USB
from port 1 to port 4
Mode selection
L_Ctrl + L_Ctrl + M +0
All PC exit the Cross-display mode
L_Ctrl + L_Ctrl + M +
(1~3)
1：Horizontal Cross-display mode
2：Vertical Cross-display mode
3：Surround Cross-display mode
Cross-display
mode
L_Ctrl + L_Ctrl + E
The current PC exits the Cross-display
mode
L_Ctrl + L_Ctrl + S
Current PC (single-head display mode)
participates in the Cross-display mode
L_Ctrl + L_Ctrl + D +
(0~3)
The current PC (multi-head display
mode) participates in the Cross-display
mode, supporting up to 4 displays
Audio switching
L_Ctrl + L_Ctrl + A + 0
Audio unlock (Switch Audio, Keyboard,
Mouse and USB)
L_Ctrl + L_Ctrl + A +
port#
Switch Audio only (not Keyboard,
Mouse and USB)
HUB switching
L_Ctrl + L_Ctrl + U + 0
USB2.0 unlock (Switch USB2.0,
Keyboard, Mouse and Audio)
L_Ctrl + L_Ctrl + U
+port#
Switch USB2.0 only (not Keyboard,
Mouse and Audio)
Broadcast
L_Ctrl + L_Ctrl + B
Unlock and lock the broadcast mode,
concurrently control the keyboard and
mouse of the 4 connected computers
under the broadcast mode
Hotkey cycling
L_Ctrl + L_Ctrl + F
L_Ctrl -> L_Shift -> Scroll
Reset to factory
default
L_Ctrl + L_Ctrl + R
Restore factory setting

4 Port User Manual
- 5 -
Single-Head Mode KM Switching
Allows users to seamlessly switch between computers by moving the mouse
cursor from one display to another, making it easy and efficient for users to
switch between PCs.
Multi-Head Mode KM Switching
When using computers with multiple displays, simply press the scroll wheel
twice and then move the mouse in the direction of the channel you desire to
switch. This feature only works in Multi-Head display mode.
Note: Under the multi-head switching mode, the USB2.0 peripheral cannot
be switched.

4 Port User Manual
- 6 -
Specification
Model
KM0104
Computer Connections
4
Port selection
Pushbuttons, Hotkey, Mouse
cursor
Connectors
User
Console
Keyboard/Mouse
1 x double-layer USB type A
Speaker (out)
1 x Min Stereo Audio
PC ports
Keyboard/Mouse
4 x USB type B
Speaker (in)
4 x Min Stereo Audio
Power
1 x DC socket
USB2.0 Port
1 x double-layer USB type A
LED OUT
1 x DB9 (Female)
Upgrade Port
1 x USB-C
Button
Port selection
2 x buttons
Power
5V- 12V DC
Power Consumption
3W
Emulation
Keyboard/Mouse
USB
Environment
Operating Temperature
0-50℃
Storage Temperature
-20-60℃
Humidity
0-80%RH, Non-condensing
Other
Features
Material
Metal, Plastic
Weight
0.9kg
Dimension
263mm x 121 mm x 26.5mm
