KinAn KM0104 User manual

4 Port Keyboard-Mouse Switch
KM0104
www.kinankvm.com
Version: V1.1

User Manual
- 1 -
Overview
The 4 Port Keyboard-Mouse Switch enables users to manage and switch KM
(Keyboard and Mouse) functions of four connected computers, including
multi-head computers. It supports seamless Keyboard-Mouse Command on 4
computers from a single workstation. The KM0104 is completely driverless,
requiring no software. It is compatible with any PC and all major operating
systems without the need for software downloads.
Product Features
Manage 4 connected computers
Dedicated simulation processor
Support keyboard and mouse emulation
Support multiple operating systems
Support front panel switching
Support stereo audio output
Applications
Government Operations
Defense Applications
Security Control Rooms
Corporate Communications
Server Operations
Medical Campuses
Airports
Structure

User Manual
- 2 -
Installation
Before starting the installation, please confirm that all devices are powered off.
1）Please plug USB keyboard and mouse in USB port(①)
2）Connect computers and KM switch with USB cable(②)
3）Plug in the power adapter(③)
4）Power on the computers, switch between computers easily trough push
button and hotkey
5）If speaker is required, please plug in the audio port (④⑤)
6）If USB2.0 peripherals required, please plug in USB2.0 port(⑥)
7) Connect the serial device to the RS232 interface (⑦)

User Manual
- 3 -
Pushbuttons
No.
Button
Description
1
Switch Keyboard, Mouse and Audio to Previous
Channel
STATTION (1-4): Switch to the previous channel, the
corresponding LED light is on
The flashing STAT1, STAT2 LED lights indicates
normal communication
2
Switch Keyboard, Mouse andAudio to Next Channel
STATTION (1-4): Switch to the previous channel, the
corresponding LED light is on
The flashing STAT1, STAT2 LED lights indicates
normal communication

User Manual
- 4 -
Hotkeys
Commands
Hotkeys
Description
PC switching
L_Ctrl + L_Ctrl + port#
Switch Keyboard, Mouse, Audio and
USB from port 1 to port 4
Mode selection
L_Ctrl + L_Ctrl + M +0
All PC exit the Cross-display mode
L_Ctrl + L_Ctrl + M +
(1~3)
1：Horizontal Cross-display mode
2：Vertical Cross-display mode
3：Surround Cross-display mode
Cross-display
mode
L_Ctrl + L_Ctrl + E
The current PC exits the
Cross-display mode
L_Ctrl + L_Ctrl + S
Current PC (single-head display
mode) participates in the
Cross-display mode
L_Ctrl + L_Ctrl + D +
(0~3)
The current PC ( multi-head display
mode) participates in the
Cross-display mode, supporting up to
4 displays
Audio switching
L_Ctrl + L_Ctrl + A + 0
Audio unlock (Switch Audio,
Keyboard, Mouse and USB)
L_Ctrl + L_Ctrl + A +
port#
Switch Audio only (not Keyboard,
Mouse and USB)
HUB switching
L_Ctrl + L_Ctrl + U +
0
USB2.0 unlock (Switch USB2.0,
Keyboard, Mouse and Audio)
L_Ctrl + L_Ctrl + U
+port#
Switch USB2.0 only (not Keyboard,
Mouse and Audio)
Broadcast
L_Ctrl + L_Ctrl + B
Unlock and lock the broadcast mode,
concurrently control the keyboard
and mouse of the 4 connected
computers under the broadcast mode
Hotkey cycling
L_Ctrl + L_Ctrl + F
L_Ctrl -> L_Shift -> Scroll
Reset to factory
default
L_Ctrl + L_Ctrl + R
Restore factory setting

User Manual
- 5 -
Single-Head Mode KM Switching:
Allows users to seamlessly switch between computers by moving the mouse
cursor from one display to another, making it easy and efficient for users to switch
between PCs.
Multi-Head Mode KM Switching:
When using computers with multiple displays, simply press the scroll wheel twice
and then move the mouse in the direction of the channel you desire to switch. This
feature only works in Multi-Head display mode.
Note: Under the multi-head switching mode, the USB2.0 peripheral cannot be
switched.

User Manual
- 6 -
Specification
Model
KM0104
Computer Connections
4
Port selection
Pushbuttons, Hotkey, Mouse
Connectors
User
Console
Keyboard/Mouse
1 x double-layer USB type A
Speaker (out)
1 x Min Stereo Audio
PC ports
Keyboard/Mouse
4 x USB type B
Speaker (in)
4 x Min Stereo Audio
Power
1 x DC socket
USB2.0 Port
1 x double-layer USB type A
RS232 Port
1 x DB9 (Female)
Button
Port selection
2* buttons
Power
DC 12V/ 2A
Power Consumption
10W
Emulation
Keyboard/Mouse
USB
Environment
Operating Temperature
0-40℃
Storage Temperature
-20-60℃
Humidity
0-80%RH,Non-condensing
Other
Features
Material
Metal, Plastic
Weight
0.5 kg
Dimension
228 x 121 x 26.5mm
