kincrome K12134 User manual

DUAL STAGE TRANSMISSION JACK
DUAL STAGE
TRANSMISSION
JACK
K12134
ED2/JULY 19 Caution: Do not allow persons to operate or assemble this jack until they have read this manual
and developed a thorough understanding on how the jack works
DUAL
STAGE
LIFT
INCLUDES
SAFETY
CHAINS WAY TILT
CRADLE
3
SWIVEL
CASTORS
4 HD

2
DUAL STAGE TRANSMISSION JACK
TABLE OF CONTENTS
Specifications.....................................................................................................................................2
Know Your Product............................................................................................................................2
Important Safety Instructions....................................................................................................... 3-4
Unpacking and Assembling..........................................................................................................4-5
Operation........................................................................................................................................ 5-6
Maintenance & Storage ....................................................................................................................7
Troubleshooting.................................................................................................................................7
Warranty.............................................................................................................................................8
KNOW YOUR PRODUCT
SPECIFICATIONS
1. Adjustable Saddle
2. Telescopic Tube (stage 2)
3. Telescopic Tube (stage 1)
4. Handle Assembly
5. Foot Pedal Assembly
6. Legs
7. Castors
8. Pump Assembly
9. Oil Filler Plug (not shown)
10. Safety Chains
11. Lowering Pedal
12. Stabiliser Arms
13. Stabiliser Mounting Bracket
14. Air Vent Screw
Model No:................................................................... K12134
Working Load Limit: ................................................ 1000kg
Minimum Height (w/saddle):..................................920mm
Maximum Height (w/saddle):...............................1905mm
Lift Height: ................................................................985mm
First Stage Ram Stroke: .......................................505mm
Second Stage Ram Stroke:...................................480mm
Saddle Dimension:................................ 280x280x165mm
Saddle Tilt-Forward: ............................................... 7-12º
Saddle Tilt-Backward:............................................. 7-12º
Base Dimension:........................................... 660x660mm
Gross Weight:............................................................ 83kg
Net Weight: ............................................................... 74kg
1
2
3
4
14
5
6
7
8
13
12 11
10

3
DUAL STAGE TRANSMISSION JACK
General Safety Warnings
Save all warnings and instructions for future reference.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
serious injury or death.
IMPORTANT SAFETY INSTRUCTIONS
The use of a vehicle jack has inherent dangers to avoid risk of personal injury or property damage make sure you are fully aware of
the operating instructions for this product, the recommendations in the vehicle owners manual for jacking of your vehicle prior to
lifting the transmission. Do not exceed maximum lifting capacity of this jack. This jack is intended for automotive use only. Be
aware that large or heavy transmissions may exceed jack’s stated capacity check vehicle owners manual or contact the vehicle
manufacturer. Do not use for any other purpose except the raising and lower of transmissions, Never use to raise any structure or
building, Do not lift any human load and never ride on jack.
Preparing Work Area
Before using jack to lift transmission, it is important to prepare work area properly. Follow this procedure each time the jack is
used to help prevent property damage and or serious injury.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood that common sense and caution are factors which cannot
be built into this product, but must be applied by the operator.
WARNING! Ensure all preliminary checks are carefully carried out before use of jack. Immediately repair or replace
damaged parts (use authorised service agent). Ensure use of genuine parts only.
Unauthorised parts may be dangerous and will invalidate the warranty.
WARNING! Use jack on level and solid ground, preferably concrete. Ensure the floor over which the jack will be
transported is swept clean.
DANGER! DO NOT use on tarmac, or any other soft surface as jack may sink or topple. Serious injury may result if ignored.
DANGER! If jack tips or leans Stop what your are doing. MOVE QUICKLY TO A SAFE DISTANCE. DO NOT TRY TO HOLD OR
STEADY JACK.
1. Use jack in a suitable work area. Keep the area clean and tidy and free from unrelated materials. Ensure there is adequate
lighting.
2. Before use ensure the gearbox weight and size does not exceed the capacity of the jack.
3. Ensure the vehicle is raised and stabilised at the correct height before attempting to move the jack
under the vehicle.
4. Ensure the jack saddle is fully lowered and is clean, dry, and oil free before attempting to transport the jack with or without
a load.
5. Keep all unauthorised persons away from the jack during lifting and lowering and when in transit.
6. Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
7. Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery, and contain/tie back long hair.
8. WARNING! Ensure that the load is placed level and centrally on the jack saddle and that it is fixed in place before attempting
to lift, lower or transport the load.
9. The lowering speed will vary according to the weight of the load and the release valve setting. Diligence is required in
ensuring that you continually monitor the operation until completed. Should the jack make any abnormal sounds during
use, STOP IMMEDIATELY and contact your local service agent.
10. DO NOT operate the jack if any parts are damaged or missing.
11. DO NOT exceed the rated capacity of the jack.
12. DO NOT raise/lower vehicle lifting platform whilst the transmission jack is being used.
13. DO NOT transport the jack with/without a load, with the saddle in the raised position.
14. DO NOT get the jack wet, or use it in damp or wet locations or areas where there is condensation.
15. DO NOT operate the jack when you are tired or under the influence of alcohol, drugs or intoxicating medication.

4
DUAL STAGE TRANSMISSION JACK
16. DO NOT lift or support vehicles with the jack and do not use the jack as a load sustaining device.
17. DO NOT use the jack for any purpose other than removal, transportation and the installation of transmissions.
18. DO NOT make any modifications to the jack.
19. DO NOT adjust, or tamper with, the safety valve.
20. DO NOT remove any labels from the jack.
21. DO NOT use brake fluid to top up the hydraulic unit.
22. Use Kincrome hydraulic oil only (K12400).
23. Use a qualified person to lubricate and maintain the jack.
24. Before storing the jack in a safe area, ensure that all parts are clean and free of grease and oil, especially the saddle.
Personal Safety
25. Stay alert. Watch what you are doing and use common sense when operating the tool. Do not use the tool while tired or
under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool increases the risk of
injury to persons.
26. Dress properly. Do not wear loose clothing or jewellery. Contain long hair. Keep hair, clothing, and gloves away from
moving parts. Loose clothes, jewellery, or long hair increases the risk of injury to persons as a result of being caught
in moving parts.
27. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the
tool in unexpected situations.
28. Use safety equipment. A dust mask, non-skid safety shoes and a hard hat must be used for the applicable conditions.
29. Always wear eye protection. Wear ANSI-approved safety goggles.
30. Keep Children away. Children must never be allowed in the work area. Do not let them handle tools, machines or extension
cords.
31. Use the right tool for the job. Do not attempt to force a small tool or attachment to do the work of a larger industrial tool, Do
not use a tool for a purpose it was not intended.
UNPACKING AND ASSEMBLING
Unpacking
Unpack all the components from the box.
When unpacking the transmission jack carefully inspect for any damage that may have occurred during transit.
Check for loose, missing or damaged parts.
1. Ensure all packaging materials are disposed of as per your local council guidelines.
Assembling
1. Place two leg assemblies (6) upside down, then bolt them together using the supplied bolts washers, lock washers and
nuts. Do not tighten fully.
2. Turn over the leg assembly to the normal upright position and fit the four castors (7) to the legs using the supplied washers,
lock washers and nuts. Do not tighten fully.
3. Place the base of the transmission jack main body pump assembly (8) into the centre of the legs and tighten using the
supplied washers, lock washers and bolts. Do not tighten fully.
4. Attach the stabiliser arm mounting bracket (13) to the jacks main body using the supplied bolts, washers, lock washers and
nuts. Do not tighten fully.
5. Attach the stabiliser arms (11) to the mounting bracket and leg assembly using the supplied bolts, washers and nuts.
Do not tighten fully.
6. Fasten the saddle (1) onto the top of the telescopic tube (2) using the supplied bolt, do not overtighten.
7. When completely level, go ahead and tighten all bolts, do not overtighten.

5
DUAL STAGE TRANSMISSION JACK
Purging
Prior to use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or
missing parts.
1. Following assembly and before first use leave the jack for one hour to allow the oil to settle before purging the system.
2. Loosen the air vent screw (14) no more than 2 full turns.
3. Purge the hydraulic system to eliminate any air in the system by depressing the foot operated release pedal (11) and
pumping the foot operated lift pedal (5) 15-20 times.
4. Test the jack without load by raising it to full height and then lowering the jack by depressing the release valve by pushing
the release foot pedal (11) down gently to control the rate of descent.
OPERATION
Inspection
1. Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and
damaged, loose, or missing parts.
2. The transmission Jack shall be maintained in accordance with the maintenance instructions. No alterations or
modifications should be made to this transmission jack or warranty void.
3. Inspections should be performed in accordance with this owner’s manual.
4. The transmission Jack must be inspected immediately if it is believed to have been subjected to abnormal load or shock.
Owners and /or operators should be aware that repair of this product may require specialised equipment and knowledge
(refer to maintenance section).
Operating Jack
1. Always loosen the air vent screw (14) before use.
2. Roll the transmission jack into position and pump the lift foot pedal (5) until the transmission adaptor reaches the desired
height.
NOTE: Follow the vehicle manufacturer’s recommended procedures for removing the load as outlined in the vehicle service
manual or repair guide.
3. Carefully centre the load on the saddle. Ensure the load’s centre of gravity is centred on the saddle and the transmission is
stable and secure. Use the chains to secure the load.
NOTE: Before lowering the load check to ensure all tools and personnel are clear and it is safe to lower the load.
4. SLOWLY and CAREFULLY push the release foot pedal (11) to lower the load to its lowest position.
NOTE: The speed of lowering is controlled by pressure on the release valve. The more the valve is opened the more rapidly the jack
descends. Ensure the decent is slow and controlled.
WARNING: Dangerous dynamic shock loads are created by quick opening and closing the release valve when the load is
being lowered. The resulting overload may cause hydraulic system failure which could cause property damage and/or
severe personal injury.
5. Once the load is lowered, CAREFULLY and SLOWLY move the transmission jack.
6. Transfer load immediately to appropriate support device for service or repair.
7. When work is complete, lower the saddle to its lowest position and tighten the air vent screw (14).
Removing the Gearbox
1. Removing Gearbox. Loosen all gearbox fixing bolts leaving them finger tight.
2. Raise the gearbox support close to the gearbox and adjust the angle of the support plate using the adjusting screws.
3. Position the sliding brackets and the chain mount brackets to best support and locate the transmission, ensuring that all nuts
and bolts are tightened.
4. Feed the safety chains (10) over the top of the gearbox and attach to the chain hooks leaving as little slack in the safety
5. chains (10) as possible. Fully tighten the safety chains (10) using the adjusters on the chain hooks.
6. Remove all gearbox fixings. Disconnect drive shaft. Ensure that the gearbox is stable on the support.

6
DUAL STAGE TRANSMISSION JACK
Detach gearbox and lower away from underside of vehicle.
7. Refitting Gearbox. Secure the repaired/new gearbox to the support plate using the chains. Ensure that the sliding brackets
and the chain mount brackets are in a position to best support the transmission and all the nuts are fully tightened.
8. Raise the gearbox into the required position underneath the vehicle and make fine adjustments to the positioning using the
adjuster screws.
9. When the gearbox is in position and properly aligned with its fixing holes, insert all bolts finger tight before progressively
tightening them to the correct specified torque settings (See vehicle service manual).
10. Remove the safety chains (10) from gearbox and lower support away from underside of vehicle.
MAINTENANCE & STORAGE
Maintenance
Monthly maintenance is recommended. Lubrication is critical to transmission jacks as they support heavy loads. Any restriction due
to dirt, rust, etc, can cause either slow movement or cause extremely rapid jerks damaging the internal components. The following
steps are designed to keep the transmission lifter well maintained and operational.
Important: Dirt is the greatest single cause of failure in hydraulic units. Keep the transmission lifter clean and well lubricated to
prevent foreign matter from entering the system.
If the transmission lifter has been exposed to rain, snow, sand, or grit it must be cleaned before it is stored or used.
Important: Use only K12400 Kincrome hydraulic jack oil. Avoid mixing different types of fluid and NEVER use brake fluid, turbine
oil, transmission fluid, motor oil or glycerine.
Improper fluid can cause premature failure of the transmission lifter and the potential for sudden and immediate loss of load.
Periodically check the telescopic tubes for signs of rust or corrosion. Clean exposed areas with a clean oiled cloth.
WARNING: Never use sandpaper or abrasive material on these surfaces.
A coating of light lubricating oil to pivot points will help to prevent rust and ensure that castors, foot pedals and pump assemblies
move freely.
If efficiency drops, purge air from hydraulic system. Refer to the Purging section on pg. 5 for instructions.
With the transmission jack in the lowest position remove the air vent screw (14) to check the hydraulic oil level. If it is not adequate,
add Kincrome K12400 hydraulic jack oil as necessary.
Insert and tighten the air vent screw. Leave the transmission jack for one hour to allow the oil to settle before purging the system.
To ensure best performance and longer equipment life replace the complete hydraulic oil annually.
With the transmission jack in its lowest position remove the air vent screw (13), lay the transmission lifter on its side and drain the
oil into a suitable container.
Ensure that no dirt gets into the system.
Set the transmission lifter in its level upright position, fill with K12400 Kincrome hydraulic jack oil.
Replace the air vent screw and purge away air from hydraulic system as described in Purging section.
It is recommended that an annual inspection be conducted by a qualified technician.
Storage
This transmission jack should always be stored in a dry location on a level surface with the saddle fully lowered and the air vent
valve closed.
Service & Repair
Any jack found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by
an authorised service agent.
Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge.
Only authorised parts, labels, decals shall be used on this equipment.
Annual inspection of the jack is recommended and can be made by an authorised repair facility to ensure that your equipment is in
optimum condition and that the equipment has the correct decals and safety labels specified by the manufacturer.

7
DUAL STAGE TRANSMISSION JACK
Caring for the environment
When a tool is no longer usable it should not be disposed of with household waste, but in an environmentally friendly way.
Please recycle where facilities exist. Check with your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice.
TROUBLESHOOTING
Symptom Cause Remedy
Jack will not lift load. 1. Air in hydraulic system.
2. Oil level low.
1. Purge air from system.
2. Top-up to correct level.
Jack will not hold load. 1. Pedal (12) closed.
2. Overload condition
3. Hydraulic unit malfunction
1. Close release pedal (12) firmly.
2. Remedy overload condition
3. Contact Kincrome customer service.
Jack will not lift smoothly or to
full height.
1. Oil level low.
2. Air in hydraulic system.
1.Top-up to correct level.
2. Bleed system - Bleeding / Venting
Trapped Air on page 4.
Jack will not lower completely. 1. Pressure release pedal (12) not
sufficiently depressed.
2. Reservoir overfilled.
1. Slowly depress pedal (12) further.
2. Check oil level.
Office Contact Details:
Phone: [phone]
Fax: [phone]
Email: [email protected]om.au
Website: www.kincrome.com.au
YEAR
WARRANTY
2
Warranty given by Kincrome Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria (Tel [phone]). The applicable warranty period
(2 years) commences on the date that the product is purchased. If this product has materials or workmanship defects (other than defects caused by abnormal
or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for
repair or replacement. Your rights under this warranty are in addition to any other rights you have under the Australian Consumer Law or other applicable laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure. For further details please visit www.kincrome.com.au or call us. Due to minor changes in
design or manufacture, the product you purchase may sometimes differ from the one shown on the packaging.
Distributed by Kincrome Tools and Equipment www.kincrome.com.au 3 Lakeview Drive Scoresby Victoria Phone: [phone]
WARRANTY

DUAL STAGE TRANSMISSION JACK
www.kincrome.com.au
