King Tony 9TY132 Series User manual

Enjoy your work
NO.9TY132
3
HYDRAULIC GARAGE JACK
OPERATION MANUAL

READ ALL INSTRUCTIONS BEFORE USE
• Study, understand, and follow all instructions before operating this device.
• Failure to heed these markings may result in serious personal injury and / or property damage.
• Prior to each use, visual inspection shall be made to the device by checking for abnormal conditions,
such as cracked welds, leaks, and damaged, loose, or missing parts.
• Do not exceed the rated capacity stated.
• Use only on hard level surfaces.
• This item is to be used as a lifting device only. Immediately support the vehicle with appropriate rated
jack stands after lifting.
• Do not move the vehicle while it is on the jack.
• Lift only on areas of the vehicle as specified by the vehicle manufacturer.
• No alterations shall be made to this product.
• Turn the handle/release valve clockwise to the closed position. Do not over tighten.
• Position the jack under the specified lift point.
• Begin lifting by pumping the handle up and down.
• Immediately support the vehicle with appropriately rated jack stands after lifting.
• Turn the handle/release valve slowly counterclockwise to lower the vehicle onto jack stands.
LIFTING
• Turn the handle/release valve clockwise to the closed position. Do not over tighten.
• Pump the handle up and down to lift vehicle off jack stands.
• Remove the jack stands. Do not get under or let anyone get under the vehicle while lowering.
• Turn the handle/release valve slowly counterclockwise to lower the vehicle onto the ground.
LOWERING
CHECK AND REFILL OIL :
• With the jack in the fully lowered level position, if unit cover is provided, remove unit cover, then
remove oil filler plug.
• Proper oil level should be just cover inner cylinder as seen from the oil filler plug hole.
• Do not overfill. Always fill with new, clean hydraulic jack oil as recommended above.
• Reinstall oil filler plug, then reinstall unit cover.
NOTICE : Use high grade hydraulic oil only. Never use brake fluid, motor oil, transmission fluid,turbine
oil or any other fluids.
MAINTENANCE
3 130 465
3 140 520
KT NO. Capacity (T) Min height (mm) Max height (mm)
9TY132-03A-B
9TY132B-03A-B

INSPECTION
• Visual inspection shall be made before each use of the device by checking for abnormal conditions,
such as cracked welds, leaks, and damaged, loose, or missing parts.
• This device shall be inspected immediately if the device is believed to have been subjected to an
abnormal load or shock.
• Periodically clean and lubricate all moving parts and pivot points.
• With the jack in the fully lowered position, unlock release valve, remove oil filler plug.
• Pump the handle rapidly several mins. Reinstall oil filler plug.
• Turn the handle/release valve clockwise to the closed position.
• Pump the handle until the arm reaches maximum height and continue to pump several mins. to remove
trapped air in the system.
• Turn the handle/release valve counterclockwise in one full turn and lower arm to the lowest position. Use
force on saddle if necessary.
• Carefully and slowly loosen oil filler plug to release pressurized air.
• Repeat above steps until trapped air is completely vented.
LUBRICATION AND CLEANING
AIR VENTING PROCEDURES
Problems Causes Solutions
Jack will not lift the load.
Jack will not hold the load.
Jack will not descend to
minimum height, or will
not remain in lowered
position.
Jack will not lift to max
height.
Jack will not function
properly after trying solution.
1. Release valve not tightly closed.
2. Low oil level.
3. Defective or worn internal parts.
4. Load exceeds maximum allowance.
1. Release valve not tightly closed.
2. Power unit malfunction.
1. Air trapped in system.
2. Reservoir oil overfilled.
1. Low oil level.
1. Internal malfunction or
structural damage.
1. Tighten release valve.
2. Check and add oil.
3. Discontinue use and contact a local
repair center.
4. Use a higher capacity jack.
1. Tighten release valve.
2. Discontinue use and contact a local repair
center.
1. Check and ensure proper oil level.
2. Vent air out of system. Follow “AIR
VENTING PROCEDURES” instructions.
1. Check and ensure proper oil level.
2. Follow “MAINTENANCE” instructions.
1. Discontinue use and contact a local repair
center.
TROUBLESHOOTING

899TY132-KT 297x210mm
www.kingtony.com
customer service e-mail : [email protected]
1 1
2 2
3 2
4 2
5 2
6 2
7 1
8 2
9 2
1
1
1
1
2
1
1
1
1
2
2
10
11
12
13
14
15
16
17
18
19
20
21 2
22 2
23 1
24 1
25 1
26 1
27 1
28 1
29 1
30 1
31 1
32 1
33 1
34 1
35 1
36 1
37 1
38 1
39 1
40 1
41 1
Description Qty
Part Description Qty Part
Side. plate weldment Lock washer
Bolt
Bolt
Torsion spring
Valve gear
Plunger pin
Gear shaft
Cotter pin
Washer
Gear Head screw
Lock washer
Hex nut
Handle bolt
Stud
Handle, lower
Handle, upper
Hex head screw
Handle socket
Lock washer
Lock washer
Caster assembly
Locknut
Wheel
Washer
Retaining ring
Power unit assembly
Socket head cpa screw
Split lock washer
Lift arm assembly
Shaft arm
Saddle
Grease fitting
Bolt
Retaining ring
Block link
Cotter
Return spring
Retaining ring
Lock washer
Nut
PARTS LIST
