Kirisun PT8000 User manual

PT8000
INSTRUCTION MANUAL
FM MOBILE TRANSCEIVER

16
PT8000
INSTRUCTION MANUAL
VHF/UHF MOBILE RADIO
MANDATORY SAFETY INSTRUCTIONS TO INSTAL-
-LERS AND USERS
Use Only manufacturer or dealer supplied antennas.
Antenna minimum safe distance: 108 cm.
Antennas used for this transmitter must not exceed an
antenna gain of 3 dB.
The FCC (Federal Communications Commission) has
adopted a safety standard for human exposure to RF
energy which is below the OSHA (Occupational Safety
and Health Act) limits.
Antenna mounting: The antenna supplied by the manu-
-facturer or radio dealer must not be mounted at a location
such that during radio transmission, any person can come
NOTE

Closer than the above indicated minimum safe dista-
nce to the antenna (i.e. 108cm).
To comply with current FCC RF Exposure limitations,
the antenna must be installed at or exceeding the minim--
um safe distance indicated above, and in accordance with
the requirements to the antenna manufacturer or supplier.
Vehicle installation: The antenna can be mounted at
the center of a vehicle metal roof or trunk lid if the minim-
um safe distance is observed.
Antennasubstitution: Don't substitute any antennafor
the one supplied or recommended by the manufacturer
or radio dealer. You may be exposing person(s) toexcess--
ive radio frequency radiation. You may contact your radio
dealer or themanufacturer for furtherinstructions.
Maintain a separation distance from the antenna to
person(s) at least 108cm.
This transmitter is authorized to operate with a
maximum duty factor of 50%, in a typical push-to-talk
mode, for satisfying FCC RF exposure compliance
requirements.
Warning

Caution:
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
1. Package-opened Inspection and Installing......................................2
2. Radio Overview...............................................................................4
3. Basic Operation...............................................................................6
4. Programmable Button Function.......................................................7
5. Radio call........................................................................................8
6.Talk-around.....................................................................................9
7. Scan................................................................................................9
7.1 Start/End Scan Function...............................................................9
7.2 Nuisance Delete............................................................................9
8. Public Address..............................................................................10
9. Lone worker...................................................................................10
10. Emergency Alarm........................................................................10
11. Remote kill, stun, activate and revive.........................................11
12. Wired Clone Mode.......................................................................12
13. Trouble Shooting Guide...............................................................13
14. Major Specifications....................................................................13
CONTENTS
1

1.1 Supplied Accessories
1. Package-opened Inspection and Installing
Please check the host in the package and the supplied accessories in
the following table before using. Any articles are found lost or damaged,
please contact the distributor without delay.
M5*16 / M4*16
Self-tapping Screw
Power Cable
Microphone Hanger Fixed bracket
32
Hand Microphone
Accessories
Fixed bracket
Power Cable
Hand Microphone
Microphone Hanger
M4*10 Combination Screw
M4*16 Self-tapping Screw
M5*16 Self-tapping Screw
Instruction Manual
1
1
1
1
4
2
4
1
Quantity
1.2
1.2.1
1.2.2
Preparation
Connection of Power Cable
First of all, please check whether there is a hole for the power
cable on the insulating board. If no, please bore the board with
the suitable drill bit and fix a rubber grommet on it.
Afterwards,please have thecable pass throughthe insulating
board andlead from thecar into thecar engine. Connectthe red
conductor tothe positive terminalof the accumulatorand the
black conductorto the negativeterminal.
At last, ring the remained conductor and fix it.
Note: Please maintain the sufficient relaxation of the
power cable to make it convenient to dismantle the radio in
the state of power connection.
Radio Installing
Warning: For passengers' safety, please fix the radio firmly
on the fixed bracket so that the radio will not be loosened in
case of collision.
The fixed bracket is taken as an example. Draw the position
and drill a hole on the instrument panel first, and then install the
fixed bracket with 4 M5*16 self-tapping screws. (Note: please fix
the radio at the position convenient for operation and control,
and leave an enough space for fixation and connection of the
cable.)
Slide the radio into the fixed bracket and fix it with 4 M4*10
combination screws (plus plain washer and spring washer).
(Different combinations of fixing holes are selectable to adjust
the radio to the proper height and visual angle.)
M4*10 Combination Screw

4 5
P1 P2 P3
8
Note: When replacing the protective tube for the power cable,
please use the one of the same specification without fail. It is
not allowed to change it into the tube of higher capacity.
power button
Press this button for
a long time (more than
1.5 seconds) to switch
The radio on/off.
LED indicator
The red indicator will light while
transmitting; the green indicator
Will light when it receives the carrier.
/ button (programmable button)
Display screen
For details, see Display .
Volume Control knob
To be used to adjust volume.
Microphone/Programming Interface
2
2.1
Radio Overview
Description of
External View
8
8
2.2 DisplayScreen
Indicates the current channel in normal use,
ranging from 1~8.
Indicates the current squelch level when
squelch selection is enabled,ranging from
0.~9.
Displays "b " when Public Address is enabled.
Displays "-" when the radio has no channel.
Displays "u " when the radio is in the remote
stun status.
Displays "h " when the radio is in the remote
kill status.
SCAN indicator
LOW indicator
Scan indication: on when scan is enabled.
Power level indication: on when in low power.
Display Description
Connect the antenna and the power cable to the radio.
Install the microphone hanger at the position easy to use, with
2 M4*16 self-tapping screws. (The microphone and its cable should
be fixed at the position not affecting safe driving.)
Connect the microphone to the microphone jack on the front
panel of the radio and put it on the hanger.
P1button (programmable button)
P2 button (programmable button)
P3button (programmable button)
PTT button (on the hand microphone)
Press the PTT button first, and then speak to the microphone to transmit the
voice to the other. Loosen to receive.

67
2.3 Rear Panel
AntennaInterface
Power Interface
External Speaker Interface
3. Basic Operation
1.Startup:
Press the red POWER button for a long time (at least 1.5 seconds)
to switch the radio on/off
2.Volume:
Press the MONITOR or Squelch Off button to listen to the
background noise first, and then adjust the volume by turning the
volume control knob.
3.Channel
The radio can provide 8 general channels. Press the CHANNEL
UP or CHANNEL DOWN button to select the channel.(Refre to P7
4 Programmable Button Function)
4.Transmission:
To send a call, press the PTTbutton and speak to the microphone
Display Description
Displays "P " when the radio enters the PC
Programming Mode.
Displays "t " when the radio enters the PC
Adjustment Mode.
Displays "C " when the radio enters the Wired
Clone Mode
in the normal voice. Please keep the microphone about 3 or 4 cm
far from your mouth. After speaking, please loosen the PTT button.
5. Receive:
The radio will return to the receiving state after you loosen the
PTT button. The distributor may have set the CTCSS/DCS
signaling in your radio. On the channels with CTCS S/DCS are
set,you canonly hear the call from other radio with the same
CTCSS/DCS.
4. Programmable Button Function
P1 P2 P3 / can be programmed as one of the following
functions.
0. None
1.Channel Up
2.Channel Down
3.Talk-around
4.Call Button1
5.Call Button2
6.Lone worker
7.Emergency
Alarm
8.Emergency
AlarmOff
9.Scan
10.Nuisance Delete
11.Hi-LowPower
Switch
No function
Select the next channel
Select the previous channel
Switch the radio mode between talk-around and repeater.
Sends the DTMF/2Tone code assigned to call 1 button.
Sends the DTMF/2Tone code assigned to call 2 button.
Enables Lone worker function
Press the button programmed as Emergency Alarm
to set alarm tone according to the programming software
or send your own ID or background voice to your partner
or the system.
Press this button to quit the Emergency Alarm mode.
Start/end the scanning function of system.
Press this button Nuisance Delete when the radio enables
the scan function and stays at the noise channel.
Pressto switch betweenhigh and lowpower of thesending
power of the radio, when the LOW is on the display,

89
12.Monitor
momentary
13.Monitor
14.Squelch off
momentary
15.Squelch off
16.Lone worker
reset
17
18.Squelch
Level
Selection
6. Talk-around
In thecommunication network, youcan expand communication
range through the repeater, but when the mobile radio is out of the
communication range,you can connectwith other radioin the
talk-around method.
Switch thetalk-around or repeatermode through "Talk-around"
button.
7. Scan
Theradio can beprogrammed to scanmultiple channels to
receive signals.
7.1 Start/End Scan Function
Press thebutton programmed for"Scan" to enablescanning.
When the scan function is enabled, the "SCAN" indicator is on
and thechannels being scannedare also displayed.Press the
"Scan" buttonagain to disablescanning and the"SCAN"
indicator willbe out.
Press this button to enter the Squelch Level Adjustment
Mode first, and then press the / button to adjust the level.
Press the PTT button to save the selected squelch level and
quit this mode. Press any other button to quit without saving.
Hold to disable CTCSS/DCS signaling according to the
setting to resume normal operation.
Press to disable CTCSS/DCS signaling to receive signals
that cannot be heart in normal operation, press again to
resume normal operation.
Hold to enable squelch and loosen to resume normal
operation.
Press this button to open the squelch. Press it again
to return to the normal operation.
Press this button in the selective call state to quit such a state.
After enabling the Lone worker, press this button to
reset the Lone worker timer and the timing resumes.
Start/end the public address function. Press this button and
the function will be activated. Press thePTTbutton and speak
to the micro-phone so that you can hear your voice through
the external speaker.Press this button once again and return
to the normal user mode.
.Public
Address
the current sending power is low.
5. Radio call
A.Press the button programmed as call Button 1 or call Button 2
to send the preset code .
B.Press PTT and talk with the microphone in the normal voice.
Please keep the microphone about 3-4cm away from your lips.
When finishtalking, release PTT .
""""
""
""
7.2 Nuisance Delete
If a channel continuously generates noise or interference, press
the button to remove this channel from the scan list temporarily.
Note: the priority channel can't be removed and the last one in the
scan list, either.Quit the Scan mode and enter it again, the deleted
channel will be added to the scan list again.

1110
8. Public Address
Press the button programmed for "Public Address", "b" will be
displayed.Press the PTT button, the voice from the MIC of the
radio willbe directly sentto the externalspeakers through the
interface onthe back.
Press the"Public Address"button again todisable the public
address function.
9. Lone worker
If Loneworker is setto be enabled,press the button"Lone
worker" to enable the Lone Worker Mode. Start the Lone worker
timer and when the preset Lone worker time is reached, the radio
will alarm,afterthe alarm time, the radio willenter the Emergency
AlarmMode.
In the Lone worker Mode, press the "Lone worker" button again
to quit the Lone worker mode.
In theLone worker Mode,press the buttonprogrammed for
"Lone workerreset" the specific buttonto select loneworker
reset mode or anybutton (any buttonto select loneworker
reset mode),the Lone workertimer will resetand start timing
again.
12. Wired Clone Mode
If thewired clone functionis enabled, theradio will notquit after
entering thewired clone mode.Toreturn to normaluser mode,
the user needs to restart the machine.
Theoperating steps goas follows:
1. Press [P1] buttonsfor power-on untilshow "C" andenter the
software or sendYour ownID orbackgroundvoice to yourpartner
or thesystem.
In theEmergency AlarmMode, press thebutton "Emergency
AlarmOff" toquit the EmergencyAlarm Mode anddisable the
alarm tone or stop sending it and resume normal operation.
11.Remote kill, stun, activate and revive
If the radioreceived DTMF codeprogrammed as remotestun,
the radiowill enterthe remotestun status,after replying
according to thesetting, "u" willbe displayed.The radio canonly
receive signalsand cannot sendsignals. If theradio received
DTMP code programmed as remote un-stun, the radio will quit
the remote stun status and enter normal operation.
If theradio received DTMFcode programmed asremote kill, the
radio willenter the remotekill status, afterreplying according to
the setting, "h" will be displayed. The radio cannot send or receive
signals. Ifthe radio receivedDTMP codeis programmed as
revive, theradio will quitthe remote killstatus and enternormal
operation.
10. Emergency Alarm
Press the button programmed for "Emergency Alarm" (the time of
pressing must be longer than the de-bounce time of the emergency
alarm switch) to enter the Emergency Alarm mode. "E" will be
displayed. You can set alarm tone according to the programming

12 13
2. Connect the slave radio with the wired clone cable first, and then
turn on.
3. Press button [P2] on the master radio for starting clone. During
transmitting the data, the master radio lightens red, and the slave
radio lightens green and indicates "P". After the slave radio recei-
-vingall the data, the red light on the masterradiois off, and the slave
radio restarts.
4. You can keep cloning according to step 3 above.
13. Trouble Shooting Guide
Problem
Power on
Failure
Phaselockloop
unlocked
(Beeping)
Notalkback
Noreceiving
signal
Solution
A.Thepowercableisnotconnectedwiththeaccumulatororthehost
reliably.Pleaseconnectthepowercablereliably.
B.Theprotectivetubeofpowercableisburntout.Pleasechangeit.
C.Thepowerbuttonisofpoorcontact.Pleasechange thesilica
gelbuttonorPCBbutton.
D.Therechargeablebatteryisoutofpower.Please rechargeor
change a new one.
E.CPUisbroken,PleasechangetheIC.
A.Channelfrequencybeyondtherange,resetchanneldata.
B.ThecrystalX1ofphaselockloopisbroken.Pleasechangeit.
C.Theoscillatortubeisbroken.Pleasechangeit.
D.TheIC3ofphaselockloopisbroken.PleasechangeIC.
A.Thefrequencyisnotright.Pleasereselectthechannel
of thesamefrequency.
B.TheCTCSS/DCScodeisnotthesame.Pleaseresetit.
C.Itisoutoftheeffectivecommunicationrange.
A.Theantennaisnotingoodcontact.Pleasefastentheantenna
head.
N Problem Solution
The red transmission
Indicator lights but no
sound is heard.
The green receiving
indicator lights but no
sound is heard.
10
B.Thehigh-frequencyamplifyingtubeQ18isbroken.
Pleasechange it.
C.ThesquelchlevelissettohighPleaseresetthe
squelchlevel.
D.ThemixedtubeQ19isbroken.Pleasechangeit.
E.TheFMIC6isbroken.PleasechangeIC.
A.PowermoduleIC1damaged,nopoweroutput,
pleasechange themodule.
B.MICdamaged,pleasechangeit.
A.Thespeakerisbroken.Pleasechangeit.
B.TheaudiopoweramplifierIC7isbroken.Please
changeIC.
14. Major Specifications
Frequency Range: 136MHz~174MHz 438MHz~490MHz
Channel Number: 8
Channel Spacing: 25kHz (wide band)/12.5kHz (narrow band)
Operating Voltage: 13.6V Dc 10%
OperatingTemperature:-25 -+55
External Dimension: machine only: 150mm*53mm*130mm;
plus fixedbracket: 165mm*62mm*130mm
Weight: machine only: 1030g;
Plus fixedbracket: 1310g
clone mode. If the function is disabled, it will enter the user mode.
N
5
6
1
2
3
4
O.
O.
