KISANKRAFT KK-18A2 User manual

KisanKraftTM
Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : inf[email protected] : +91.80. 22178200
Page 1 of 20
Product HTP Sprayers KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model
KK-18A2, KK-18A3, KK-22A3, KK-30A3, KK-45A3, KK-80A3,
KK-120A3 , KK-22B3, KK-30B3, KK-18CI3, KK-22CI3, KK-30CI3,
KK-33CI3, KK-53CI3, KK-45CI3, KK-80CI3, KK-120CI3
WARRANTY
PERIOD 6MONTHS
F
OR THE SPECIFIED PER
IOD FROM THE
DATE OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date Dealer’s
Invoice No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign Dealer’s Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers
warrant this product to be free from defects in material or workmanship. All parts
defective in material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as
appear to KisanKraft or its manufacturers, upon inspection, to be defective in material
and/or workmanship. KisanKraft or its manufacturers make no warranty with respect to
trade accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Machine Tools Private Limited nor any of its manufacturers, nor its authorized dealers
assumes any responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine
or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage,
(6) Repairs made by unauthorized parties and/or with unauthorized parts, (7) Improper
set up, adjustments, tampering or altered products

KisanKraftTM
Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : inf[email protected] : +91.80. 22178200
Page 2 of 20
Important: (1) Normal maintenance and adjustments to the product is the responsibility
of the customer. (2) Normal wear and tear is not covered under warranty (3)
Rubber/plastic parts and consumables such as blades, clutch and clutch-bell, spark-
plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss of
profits, loss of production, expense of substitute equipment or other commercial loss or
damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but
not limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranties hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Machine Tools Private Limited or any of its manufacturers has the authority
to increase or alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended to
the first end user (original purchaser), and no warranty is made, nor authorized to be
made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any
obligation under this warranty for failure during the applicable warranty period, deliver
the defective product, to the nearest Authorized Dealer. KisanKraft Machine Tools
Private Limited, its manufacturers and its dealers reserve the right to inspect the claimed
defective part(s) to determine if the malfunction is the result of a defect covered by this
warranty. Please note that the decision of KisanKraft Machine Tools Pvt Ltd with respect
to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines

KisanKraftTM
HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3-120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 3 of 20
Operation Manual
KisanKraft Machine Tools Pvt. Ltd.
Sri Huchhanna Tower, #4,1st Main,7-A Cross, Maruthi Layout, Dasarahalli,
HAF Post, Hebbal, Bangalore 560024,Karnataka,INDIA
♦Bangalore (HO) ♦ Ahmedabad ♦ Bhopal ♦ Bhubaneswar ♦ Coimbatore ♦
♦Ernakulam ♦ Guwahati ♦ Patna ♦ Hinudpur ♦ Hubli ♦ Hyderabad ♦
♦Jaipur ♦ Karnal ♦ Kolkata ♦ Lucknow ♦ Nagpur ♦ Pune ♦ Raipur ♦ Shimla ♦

KisanKraftTM
HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3-120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 4 of 20
CONTENTS
BEFORE GETTING STARTED ................................................................... 7
SAFETY INSTRUCTIONS ......................................................................... 7
PUMP DIAGRAMS ................................................................................. 8
OPERATING INSTRUCTIONS ................................................................ 10
PUMP LUBRICATION ........................................................................... 10
TROUBLE SHOOTING........................................................................... 11
MAINTENANCE AND STORAGE ........................................................... 11
TECHNICAL SPECIFICATIONS ............................................................... 12
DIAGRAM - POWER SPRAYER ............................................................. 14
POWER SPRAYER-PARTS LIST.............................................................. 15

KisanKraftTM
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 5 of 20
Product HTP Sprayers KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model
KK-18A2, KK-18A3, KK-22A3, KK-30A3, KK-45A3, KK-80A3,
KK-120A3, KK-22B3, KK-30B3, KK-18CI3, KK-22CI3, KK-30CI3,
KK-33CI3, KK-53CI3, KK-45CI3, KK-80CI3, KK-120CI3
WARRANTY
PERIOD 6MONTHS
FOR THE SPECIFIED PER
IOD FROM THE DATE
OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date Dealer’s
Invoice No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign Dealer’s Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers
warrant this product to be free from defects in material or workmanship. All parts
defective in material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as
appear to KisanKraft or its manufacturers, upon inspection, to be defective in material
and/or workmanship. KisanKraft or its manufacturers make no warranty with respect to
trade accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Machine Tools Private Limited nor any of its manufacturers, nor its authorized dealers
assumes any responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine
or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage,
(6) Repairs made by unauthorized parties and/or with unauthorized parts, (7) Improper
set up, adjustments, tampering or altered products

KisanKraftTM
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 6 of 20
Important: (1) Normal maintenance and adjustments to the product is the responsibility
of the customer. (2) Normal wear and tear is not covered under warranty.(3)
Rubber/plastic parts and consumables such as blades, clutch and clutch-bell, spark-
plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss of
profits, loss of production, expense of substitute equipment or other commercial loss or
damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but
not limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranties hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Machine Tools Private Limited or any of its manufacturers has the authority
to increase or alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended
to the first end user (original purchaser), and no warranty is made, nor authorized to be
made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any
obligation under this warranty for failure during the applicable warranty period, deliver
the defective product, to the nearest Authorized Dealer. KisanKraft Machine Tools
Private Limited, its manufacturers and its dealers reserve the right to inspect the
claimed defective part(s) to determine if the malfunction is the result of a defect covered
by this warranty. Please note that the decision of KisanKraft Machine Tools Pvt Ltd with
respect to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 7 of 20
BEFORE GETTING STARTED
Before using the machine for the first time be sure to read through this manual in order to
avoid wrong operation. Please preserve this manual properly so that it can provide you
with information whenever necessary.
SAFETY INSTRUCTIONS
1. Using this machine with extra high pressure is prohibited (≤35kgf/cm2);
2. The rotary parts should have safety protective device;
3. Protective Clothing:
Wear flange cap.
Wear dirt/fog-proof glasses.
Wear gauze mask.
Wear long gloves.
Wear coat guarding against
poisons.
Wear boots.
4. Spraying towards personnel and working at the downwind position are
prohibited;
5. Running the machine without water or lubricating oil is prohibited;
6. Using special working solutions as strong acid, strong alkali, etc. is prohibited
7. Following personnel should not use the machine:
Mentally challenged.
Drunk.
Under the age of 18 or older people.
Person with no knowledge of the machine.
Tired person or patient and others who cannot operate the machine
normally.
A person who has just exercised strenuously or has not slept enough.
Women feeding breast milk to the baby or is pregnant.
8. Spraying
It is fine to carry out an operation during cool weather with little wind.
For example, early in the mornings or in the late afternoons as this
can reduce the evaporation and drift of chemicals and improve the
protective effect.
The operator should move windward.
If your mouth or eyes are spattered with chemicals, wash them with
clean water and then visit a doctor.
If the operator has a headache or dizziness, should stop working at
once and consult a doctor immediately.

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 8 of 20
For the operator’s safety, misting/dusting must be carried out strictly
according to the instruction of the chemicals and agricultural
requirements.
Spray over, according to pesticide manual to clean out any residual
spray mixture in chemical tank.
After spraying always wash your hands and face thoroughly
PUMP DIAGRAMS

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 9 of 20

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 10 of 20
OPERATING INSTRUCTIONS
1. Check every fastener and make sure that the sprayer and the motor/engine are
installed firmly on the frame.
2. Set both the pulleys in a straight line and the belt in an appropriate tightness.
3. All joints of the hoses must be tightened to prevent any leakage.
4. Before starting the motor/engine shut-off the cock (valve) Loosen the pressure
adjusting screw and pull the pressure adjuster to the top.
5. Start the motor to power the sprayer. Keep a proper RPM. Press the pressure
adjuster to the bottom.
6. Keep the pressure around 20-35 Kgs by adjusting the Pressure adjusting screw.
7. Open the cock (valve) to start spraying.
8. After the spraying is over, pull the pressure adjuster to the top and operate the
sprayer with fresh water to clean out the remaining chemicals
PUMP LUBRICATION
1. Replace the lubricating oil, after the sprayer has been used for the first 10 hours.
Next oil change should be after 40 hours. Afterwards oil should be changed
every 70 hours.
2. Drain away the dirty oil by opening the drain plug.
3. After the drain plug is screwed back, remove the oil inlet cover and refill fresh
SAE 20W-40 engine oil.
4. Keep the oil level at 2/3rd of the oil gauge.
5. Always fill the grease cups with grease. Screw on the grease cups, 2-3 cycles
every 2 hours of spraying.

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 11 of 20
TROUBLE SHOOTING
Problem Probable cause Remedy
Feeding Failure &
Pressure Instability
The suction hose is leaking or is
blocked or struck
Clear the blockage and fix
the leakage
The valve assembly is damaged
or struck.
Remove the suction
chamber and the water
outlet chamber,
clean the
valve assembly.
Pressure
Insufficiency
Pressure screw is not adjusted
properly
Adjust the pressure screw
accordingly
Check if the belt is loose Tighten the belt
The
sprayer hose and the
couplings are broken or
damaged or loose
Repair or replace the
sprayer hose and the
coupling if necessary
Cylinder Leakage Problem with the adjusting rings
Remove the gland cover
and
wind up the adjusting
rings.
If the problem is not fixed
replace the v-packing in the
cylinder
MAINTENANCE AND STORAGE
1. Replace the oil after first 40 hours, and afterwards replace it once in every 70
hours.
2. Each and every time once the work is finished operate it with clean water for 2~
3 minutes to eliminate the residual chemical and keep all the parts clean.
3. For long term storage, clean and wipe the spraying machine dry and place it in
a cool and dry place

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 12 of 20
TECHNICAL SPECIFICATIONS
Model(Brass
Head)
KK-
18A2
KK-
18A3
KK-
22A3
KK-
30A3
KK-
45A3
KK-
80A3
KK-
120A3
Pump RPM 800 - 1200
Suction Vol.
(L/min)
5 –
10
10 –
18
13 –
22
30 –
40
30 –
45 65 - 80
100 -
120
Output Pressure
(Kg/cm2) 10 –50
Power (kW)
(engine required)
0.4 –
1.1 0.7-1.5 2.6-3.7 2.6-3.7 2.2-4.8 5.2-6.7 5.2-7.4
Pump Oil
(20W40 Grade)
in ml
250 450 700 900 1000 1500 2000
Consumption /
Output Capacity
(Pump Output) in
Litre/hour
420 -
900
540 -
1080
780 -
1320 1800 - 2400 3900 -
4800
600 -
7200
Weight of the
Machine (kg) 6.5 7 9 12 15 22 38
Note: The above sprayer models have the following:
1.
Brass head
5.
5m Suction hose
2.
SS Air Chamber
6.
5m Overflow hose
3.
Cast Aluminium Pulley
7.
Strainer kit
4.
Oil Pressure Gauge
8.
Tool-kit
Model
(Cast Iron)
KK-
18CI3
KK-
22CI3
KK-
30CI3
KK-
33CI3
KK-
53CI3
KK-
45CI3
KK-
80CI3
KK-
120CI3
Pump RPM 800 - 1200
Suction Vol.
(L/min)
10-
18
13 -
22
30 -
40
30 -
40
30 -
40
30 -
40
65 -
80
100 -
120
Output
Pressure
(Kg/cm
2
)
10 –50
Power (kW)
(engine
required)
1.5-2 2.2-
4.1
2.2-
4.8
2.2-
4.8
2.2-
4.8
2.2-
4.8
5.2-
6.7 5.2-7.4

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 13 of 20
Model
(Cast Iron)
KK-
18CI3
KK-
22CI3
KK-
30CI3
KK-
33CI3
KK-
53CI3
KK-
45CI3
KK-
80CI3
KK-
120CI3
Pump Oil
(20W40
Grade)
in ml
450 250 450 700 900 1000
Consumption
/
Output
Capacity
(Pump
Output) in
Litre/hour
420 -
900 540 - 1080 780 –1320 1800 -2400
Weight of the
Machine (kg) 6.5 7 9 12 15
Note: The above sprayer models have the following:
1.
Cast Iron head
5.
2.5m Suction hose
2.
SS Air Chamber
6.
2.5m Overflow hose
3.
Cast Aluminium Pulley
7.
Strainer kit
4.
Oil Pressure Gauge
8.
Tool-kit
Model (professional series) KK-22B3 KK-30B3
Pump RPM 800 - 1200
Suction Vol. (L/min) 10 –40
Output Pressure (Kg/cm2) 10 –50 bar
Power (hp) (engine required) 3 –3.5 3 –6.5
Pump Oil
(20W40 Grade) in ml 250 900
Consumption / Output Capacity
(Pump Output) in Liter/hour 780 - 1320 1800 - 2400
Note: The above sprayer models have the following:
1. Brass head 5. 5m Suction hose
2. SS Air Chamber 6. 5m Overflow hose
3. Cast Aluminium Pulley 7. Strainer kit
4.
Oil Pressure Gauge
8.
Tool-kit

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 14 of 20
DIAGRAM - POWER SPRAYER

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 15 of 20
POWER SPRAYER-PARTS LIST
Part No Part Name Part No Part Name
1.
Crank Case
54.
Hex Nut
2.
Oil Inlet Cover
55.
Air Chamber
3.
Name Plate
56.
Pressure Gauge
4.
Plunger
57.
Cock (valve)/Ball Cock
5.
Plunger Pin
58.
N/A
6.
Connecting Rod 59. Pressure Adjusting Screw
7.
Bolt Connecting Rod
60.
Fly Nut
8.
Spring Washer
61.
Spring Box
9.
Plain Washer
62.
Cross Screw
10.
Crank Case cover
63.
Plain Washer
11.
Packing Cover
64.
Spring Washer
12.
Screw Cover
65.
Level
13.
Oil Gauge
66.
Upper Metal
14.
Drain Plug
67.
Regulation Spring
15.
Packing Drain Plug
68.
Spring Seat
16.
Crank Shaft
69.
Pin-Spring Box
17.
Ball Bearing
70.
E-Ring
18.
Case Ball Bearing
71.
Plain Washer
19.
Oil Seal, Crank Shaft
72.
Pressure Adjuster
20.
Packing Bearing Case (Only
for 120A3) 73. Hex Bolt
21.
Hex Bolt (Only for 120A3) 74. Plain Washer
22.
Cover-Crank Shaft
75.
N/A
23.
Screw-Crank Cover
76.
N/A
24.
Plain Washer
77.
Box Oil Seal
25.
Gland Cover
78.
Spindle
26.
Plain Washer
79.
N/A
27.
Spring Washer
80.
Ball Valve / Steel Ball
28.
Stud Bolt
81.
Body Over Flow
29.
Plunger Oil Seal 82. Valve Seat/ Steel Ball Seat
30.
Check Ring
83.
Packing Valve Seat
31.
Adjusting Ring
84.
N/A

KisanKraftTM HTP SPRAYERS
KK-18A2-18A3-22A3-30A3-45A3-80A3
KK-120A3-22B3-30B3-18CI3-22CI3-30CI3
KK-33CI3-53CI3-45CI3-80CI3120CI3
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 16 of 20
Part No Part Name Part No Part Name
32.
Grease Seal
85.
N/A
33.
Grease Ring
86.
V-Pulley
34.
V-Packing
87.
Key-V-Pulley
35.
V-Packing Seat
88.
Plain Washer
36.
Grease Cup
89.
Spring Washer
37.
Cylinder
90.
Hex Bolt
38.
Set Clip For Adjusting
91.
Strainer Joint
39.
Valve Assembly
92.
Suction Hose
40.
N/A
93.
Wing Nut, Suction
41.
Valve Spring
94.
Male Joint
42.
N/A
95.
Suction Packing
43.
Valve Seat
96.
Strainer Suction Assy
44.
Valve Seal
97.
Overflow Hose
45.
Suction Chamber
98.
Wing Nut, Over Flow
46.
Stud Bolt-Suction Chamber 99. Male Joint
47.
Plain Washer
100.
Overflow Packing
48.
Spring Washer
101.
Bed, Crank Case
49.
Hex Nut
102.
Spring Washer
50.
Suction Cap
103.
Hex Bolt
51.
Water Outlet Chamber
104.
Adjusting Handle
52.
Stud Bolt-Outlet Chamber
105.
Partial Regulator
53.
Plain Washer

KisanKraft
TM
PRODUCT RANGE
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 17 of 20
KisanKraft has a large range of products to serve the farmers. A list of our products is
given below:
Brush Cutters and Accessories
Brush Cutter/Power Weeder
Backpack Brush Cutter
Tea Pruner
Pole pruner with Engine
Reaper Attachment
Blades-Circular
Blades (2 &3 points)
Baffle
Nylon Rope
Tap & Go
Chainsaws
Petrol Chainsaw
Electric Chainsaw
Chain Sharpening Machine
Engines and Water Pumps
Engine –Diesel-(Horizontal)
Engine –Diesel(Vertical)
Engine-Kerosene
Water
Pump
with Petrol Engine
Water Pump with Kerosene Engine
Water Pump with Diesel Engine
Hand Tools
Secateurs
Folding Saw
Garden Rake
Garden Shovel
Hedge Shear
Lopper
Telescopic Hedge Shear
Telescopic Lopping Shear
Tree Pruner
Telescopic Steel Pipe & Fruit Picker Bag
Sheep Shear
GardenTools
Electric Pressure Washer
Hedge Trimmer
Lawn Mower (Electric, Petrol & Manual)
Leaf Blower
Cultivators and Accessories
Petrol and Diesel
Sprayers and Accessories
BatterySprayer
Portable Power Sprayer
Trolley Sprayer
Manual Knapsack Sprayer
Manual Pressure Sprayer
Rose Cans
Hose Crimping Machine
HTP Sprayer
HTP Delivery Hose
HTP Hose Reel
HTP Stand
HTP Gun / Lance(Brass Rod
Knapsack Power Sprayer
Mister / Duster / GranuelSpreader
HTP Sprayer Set with Diesel Engine
HTP Sprayer Set with Kerosene Engine
Fogging Machine
Milking Machine
Wood Shredder
Fodder Ensiling Chaff Cutter
Fodder Grinder Chaff Cutter
Fodder Mini Chaff Cutter
Harvester
Maize Sheller
Maize Sheller + Dehusker
Maize Combine Harvester
Onion Digger Carlotti Italy
Tea Leaf Harvester
Sugarcane Combine Harvester
Sugarcane Leaf Stripper
Transplanter and Post Hole Digger
Paddy Transplanter (2 & 8 Rows)
Transplanter-Vegetable & Tobacco
Post Hole Digger(4” to 14”Augers)

KisanKraftTM
: www.kisankraft.com : [email protected] : +91.80. 22178200
Page 18 of 20
Wide Range of Products for Every Need
For more information give MISSED CALL: 07676065555
Many of our products have BIS: ISI certification.

KisanKraftTM
Warranty Certificate
(KISANKRAFT COPY)
This warranty is null & void, if you fail to register the warranty with KisanKraft
by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80.22178200
Page 19 of 20
Product HTP Sprayers KisanKraftTM
Invoice Date
Brand KisanKraft KisanKraftTM
Invoice No.
Model
KK-18A2, KK-18A3, KK-22A3, KK-30A3, KK-45A3, KK-80A3,
KK-120A3 , KK-22B3, KK-30B3, KK-18CI3, KK-22CI3, KK-30CI3,
KK-33CI3, KK-53CI3, KK-45CI3, KK-80CI3, KK-120CI3
WARRANTY
PERIOD 6MONTHS
F
OR THE SPECIFIED PERIOD FROM THE
DATE OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date Dealer’s Invoice
No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign Dealer’s Sign
What is covered: KisanKraft Machine Tools Private Limited and its manufacturers warrant
this product to be free from defects in material or workmanship. All parts defective in
material and workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Machine Tools Private
Limited or its manufacturers at the premises of Authorized Dealers, of such parts as appear
to KisanKraft or its manufacturers, upon inspection, to be defective in material and/or
workmanship. KisanKraft or its manufacturers make no warranty with respect to trade
accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Machine Tools Private Limited nor any of its manufacturers, nor its authorized dealers
assumes any responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine or
misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage, (6)
Repairs made by unauthorized parties and/or with unauthorized parts, (7) Improper set up,
adjustments, tampering or altered products

KisanKraftTM
Warranty Certificate
(KISANKRAFT COPY)
This warranty is null & void, if you fail to register the warranty with KisanKraft
by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Machine Tools Private Limited
: www.kisankraft.com : [email protected] : +91.80.22178200
Page 20 of 20
Important: (1) Normal maintenance and adjustments to the product is the responsibility of
the customer. (2) Normal wear and tear is not covered under warranty
(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-bell, spark-
plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the warranty.
No Warranty On Electrical Motor / Electrical Parts Etc.
Incidental / Consequential Loss: KisanKraft Machine Tools Private Limited or its
manufacturers will not be liable for general damages, including bodily injuries, or for
incidental or consequential damages including, but not limited to, loss of use, loss of profits,
loss of production, expense of substitute equipment or other commercial loss or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but not
limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranties hereunder, including,
but not limited to, any implied warranty of merchantability must be brought within the
applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of KisanKraft
Machine Tools Private Limited or any of its manufacturers has the authority to increase or
alter the obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended to the
first end user (original purchaser), and no warranty is made, nor authorized to be made
assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any
obligation under this warranty for failure during the applicable warranty period, deliver the
defective product, to the nearest Authorized Dealer. KisanKraft Machine Tools Private
Limited, its manufacturers and its dealers reserve the right to inspect the claimed defective
part(s) to determine if the malfunction is the result of a defect covered by this warranty.
Please note that the decision of KisanKraft Machine Tools Pvt Ltd with respect to any
warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGarden Tools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines
This manual suits for next models
16
Table of contents
Other KISANKRAFT Paint Sprayer manuals

KISANKRAFT
KISANKRAFT KK-P767 User manual

KISANKRAFT
KISANKRAFT KK-BBS-212 User manual

KISANKRAFT
KISANKRAFT KK-KBS-165 User manual

KISANKRAFT
KISANKRAFT KK-1L User manual

KISANKRAFT
KISANKRAFT KK-PSK-18 User manual

KISANKRAFT
KISANKRAFT FarmBoy FB-KPS-204/804 User manual

KISANKRAFT
KISANKRAFT KK-BKS-16L User manual

KISANKRAFT
KISANKRAFT KK-P968 User manual

KISANKRAFT
KISANKRAFT KK-KPS-204 User manual
