Beverage Center
LOCATION REQUIREMENTS
KBCS24
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice. Ref. 2300276B
3/18/10
PRODUCT MODEL NUMBER
Electrical: 115-Volt, 60-Hz, AC-only 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate circuit
serving only your beverage center be provided. Use an outlet that cannot
be turned off by a switch. Do not use an extension cord.
NOTE: Before performing any type of installation, cleaning or removing a
light bulb, unplug beverage center or disconnect power.
To ensure proper ventilation for your beverage center, allow for a
1⁄4" (6.35 mm) space on each side and at the top. When installing
your beverage center next to a fixed wall, leave 21⁄2" (6.35 cm)
minimum clearance on each side to allow for the door to swing
open.
NOTE: It is recommended that you do not install the beverage
center near an oven, radiator, or other heat source. Do not install
in a location where the temperature will fall below 55°F (13°C). for
best performance, do not install the beverage center behind a
cabinet door or block the base grille.
OVERALL DIMENSIONS
2¹⁄₂" (6.35 cm)
¹⁄₄" (6.35 mm)
Height to top of cabinet: 343⁄8" (87.31 cm)
Height to top of door hinge: 343⁄8" - 351⁄8"
(87.31 cm - 89.22 cm)
Width closed: 233⁄4" (60.33 cm)
Depth closed including handle: 263⁄8" (66.99 cm)
Depth closed excluding handle: 243⁄8" (61.91 cm)
Depth excluding doors: 22" (55.88 cm)
Depth with doors open 90˚: 47" (119.38 cm)
343⁄8"
(87.31 cm)
233⁄4"
(60.33 cm)
