KitchenAid KSMSIA User manual

KSMSIA
Shave Ice Attachment
W11499125A.indb 1W11499125A.indb 1 10/14/2021 12:55:08 PM10/14/2021 12:55:08 PM

2
PARTS AND FEATURES
1Detachable Ice Cup
2Ice Cup Pusher
3Main Upper Housing
4Convenient Storage Box
5Fine Shave Blade
6Coarse Shave Blade
7Ice Cup Sleeve
8Plastic Ice Mold w/Lid (x4)
3
2
1
7
5 6
8
4
W11499125A.indb 2W11499125A.indb 2 10/14/2021 12:55:08 PM10/14/2021 12:55:08 PM

ENGLISH
3
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience or
knowledge, unless they are closely supervised and instructed concerning use of
the appliance by a person responsible for their safety.
3. Close supervision is necessary when any appliance is used by or near children.
Children should be supervised to ensure that they do not play with the appliance.
4. Never leave the appliance unattended while it is in operation.
5. Avoid contacting moving parts. Keep ngers out of discharge opening.
6. The use of attachments not recommended or sold by KitchenAid may cause re,
electric shock, or injury.
7. Do not use the appliance outdoors.
8. Turn the appliance OFF/0, unplug from outlet and detach the attachment from
appliance before cleaning and when not in use. Turn the appliance OFF/0 and
make sure the motor stops completely before putting on or taking off parts.
9. Allow the appliance to cool completely before putting on or taking off parts, and
before cleaning the appliance.
10. Blades are sharp. Handle Carefully.
11. Also see the Important Safeguards section included in the Stand Mixer Use and
Care Guide.
SAVE THESE INSTRUCTIONS
This product is designed for household use only.
W11499125A.indb 3W11499125A.indb 3 10/14/2021 12:55:08 PM10/14/2021 12:55:08 PM

4
GETTING STARTED
The Shave Ice Attachment is compatible with all household KitchenAid Stand Mixers.
Set the Blades to Shave Ice as per requirement.
Name Icon Intended Use Speed
Coarse Shave
Blade
For coarser ice shaving /
ice chips. 10
Fine Shave
Blade
For a fine, fluffy, snow-
like ice shaving texture. 10
Tempering Ice means allowing the ice to adjust at room temperature until it
develops a glossy, wet look and is clear from all sides. Tempering is an
important step for producing the lightest and fluffiest shave ice. Many factors
determine the amount of time it takes to temper. In most cases, your ice puck
should be ready to use in 10 minutes or less.
The Ice Molds are used for best performance for both coarse and fine shaving. It's easy to
get shave ice from tempered ice out of the molds.
TIP: For the fluffiest shave ice, we recommend tempering the ice puck for 10 minutes,
and then using the Fine Shaving Blade.
TEMPERING THE ICE PUCKS
NOTE: For detailed instructions on swapping blades, please see “CHANGING THE
BLADE” section.
NOTE: Ice pucks made with plain water require tempering. For mixed base recipes, refer
to the recipe details for tempering instructions.
PRODUCT USAGE
ICE PUCK PREPARATION
Fill the ice mold with water or flavored ice
base mixture of your choice.
NOTE: To keep the mold from
overflowing while freezing, be sure not to
fill past the fill line visible just below the
rim of the mold.
1
Affix the lid to the top of the mold and
place it in the freezer for 12 to 24 hours.
NOTE: Freezing time may vary and will
depend both on the temperature of your
freezer as well as the sugar or alcohol
content of your mixture.
2
NOTE: See “Tips for Great Results” sections for more details on Ice Puck Preparation.
W11499125A.indb 4W11499125A.indb 4 10/14/2021 12:55:09 PM10/14/2021 12:55:09 PM

ENGLISH
5
PRODUCT USAGE
Turn the Stand Mixer OFF (0) and then
unplug.
3
For Stand Mixer with a hinged
attachment hub cover: Flip up to open.
For Stand Mixer with a removable
attachment hub cover: Turn the
attachment knob counterclockwise to
remove the attachment hub cover.
4
SET UP & ASSEMBLY - PREPARING TO MAKE SHAVE ICE
Before using your Shave Ice Attachment, clean it by following the detailed instructions in
“CARE & CLEANING” section.
After removing the ice molds from the
freezer, press firmly on the bottom and
sides to help release the puck from the
mold.
1
For Plain Ice recipes, allow ice to rest
for up to 10 minutes - this is called
“Tempering” and is recommended to
achieve ideal Shave Ice results.
2
W11499125A.indb 5W11499125A.indb 5 10/14/2021 12:55:09 PM10/14/2021 12:55:09 PM

6
PRODUCT USAGE
Ensure that the upper lever of the
housing is rotated all the way to left. If
not, rotate it to the left until it clicks into
place. This will ready the attachment
for use and must be completed before
loading the Ice Puck into the Ice Cup and
attaching it to the housing.
7
Remove the Ice Cup from the housing
by rotating it to the right and pulling
downward. Take note of the small
indicator arrow which must line up with
the Lock and Unlock symbols on the
housing.
8
OPTIONAL : If you wish to change the
blade, grip the blade from the bottom
and rotate it to right to unlock and
remove.
Insert the Main Housing into the
attachment hub, make sure the power
shaft fits into the square hub socket. If
necessary, rotate the attachment back
and forth for proper fitment. The pin on
the attachment housing will fit into the
notch of the hub rim when in the proper
position.
5
Tighten the Stand Mixer attachment hub
knob clockwise until the attachment is
completely secured into the Stand Mixer.
6
W11499125A.indb 6W11499125A.indb 6 10/14/2021 12:55:10 PM10/14/2021 12:55:10 PM

ENGLISH
7
Grip the blade from the bottom and slowly
insert it into the bottom of the Ice Cup
by aligning the interlocking tabs. Once
inserted, rotate the blade to the left until
you hear a "Click", to properly lock the
blade in place.
NOTE: Each of the interlocking tabs is
unique size, ensuring the blade can only be
installed in the correct position.
1
PRODUCT USAGE
Insert the Ice Cup Sleeve into the
Detachable Ice Cup, then insert a
prepared Ice Puck. Be sure to insert the
ice puck with the cross hatches facing
upward.
2
Attach the Detachable Ice Cup to the
bottom side of the main housing, rotating
it to the left to lock it in place.
NOTE: The small indicator arrow on the
Detachable Ice Cup that should line up
with the Lock and Unlock symbols on the
main housing.
3
Release the top lever by gently rotating it
to the right. The spring will engage as the
Ice Pusher clamps down on the ice puck.
The Shave Ice Attachment is properly
loaded and ready to use.
4
ASSEMBLY
W11499125A.indb 7W11499125A.indb 7 10/14/2021 12:55:10 PM10/14/2021 12:55:10 PM

8
Once shaving is complete, turn off the
mixer and return the upper lever to the
leftmost locked position.
3
SHAVING ICE
Place a serving dish of your choice
beneath the Shave Ice Attachment. Do
this before starting the mixer.
1
Plug the Stand Mixer into a grounded
outlet Set the mixer to the highest speed
to begin shaving.
NOTE: For best results, consider rotating
the dish as the ice shaves to create a
more even, cone-shaped mound of ice.
2
PRODUCT USAGE
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong
outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions
can result in death, fire, or
electrical shock.
W11499125A.indb 8W11499125A.indb 8 10/14/2021 12:55:11 PM10/14/2021 12:55:11 PM

ENGLISH
9
Remove the Ice Cup from the housing
by rotating it to the right and pulling
downward. Discard any remaining ice.
4
Finish your Shave Ice dessert with a
variety of flavorings or toppings of your
choice.
5
See below for additional tips, tricks and
recipes to help make the most of your
Shave Ice experience.
For even more recipes and inspiration, visit
KitchenAid.com
PRODUCT USAGE
CHANGING THE BLADE
Grip the blade from the bottom and
rotate to the left to remove, or to the
right to install.
Once inserted, rotate the blade to the left
until you hear a "Click", to properly lock
the blade in place.
1
Each of the interlocking tabs is unique
size, ensuring the blade can only be
installed in the correct position.
2
W11499125A.indb 9W11499125A.indb 9 10/14/2021 12:55:11 PM10/14/2021 12:55:11 PM

10
CARE AND CLEANING
The following parts are dishwasher-
safe, top rack only: Detachable Ice Cup,
Fine and Coarse Blades, Plastic Ice Molds,
Ice Cup Pusher, Ice Cup Sleeve and Lids.
1
Do not immerse Housing in water or
other liquid. Wipe clean with a warm,
damp cloth, and dry thoroughly with a
soft cloth before re-use or storing.
2
NOTE: Disassemble the unit properly before cleaning. For instructions, refer to the
SET UP & ASSEMBLY section steps 7, 8, and optional.
IMPORTANT: Allow the appliance to cool completely before putting on or taking off
parts, and before cleaning the appliance.
TIPS FOR GREAT RESULTS
Setting Up Your Shave Ice Attachment
• It is recommended that you install
your Shave Ice Attachment on the Stand
Mixer first, before completing any other
set up step.
• To more easily install the clear plastic
Ice Cup into the Upper Housing, look
for the small black indicator arrow. This
arrow must line up with the Lock/Unlock
icons on the Upper Housing.
• When switching blades, please note
that the blades feature 3 uniquely
sized tabs that must line up with their
corresponding slots in the bottom of
the ice cup. If the tabs are lined up
incorrectly, the blade will not install.
Making Shave Ice
• Tempering is an important part of
making great Shave Ice since an ice puck
straight out of the freezer is actually
TOO COLD to shave. Tempering means
allowing your ice puck(s) to warm slightly
at room temperature, until the outside
of the puck has a nice glossy sheen to it.
This typically takes about 10 minutes.
NOTE: Ice pucks made with plain water
require tempering. For mixed base
recipes, refer to the recipe details for
tempering instructions.
• Some Shave Ice recipes, particularly
those with ingredients frozen into the ice
puck, may shave better with either the
Fine or Coarse blade. It is recommended
that you try out recipes with each blade
to see which produces your desired
result.
