Kleenmaid FEG 900 X User manual

DUAL FUEL COOKER
Instructions for Use
and Warranty Details
Model FEG 900 X
THE WORLD’S BEST

2
ongratulations on the purchase of your new Kleenmaid appliance. This
appliance has been designed and manufactured to give you years of
reliable performance. For best results, carefully read the instructions on
how to install your new appliance. Correct installation will avoid delays and
unnecessary service calls.
Once installation is complete, read this booklet and get to know the controls
and the features of your new appliance.
We reserve the right to alter the specifications with no influence on the operation of the
appliance. This instruction manual cannot be reason for a claim.
PRODUCT LABEL
This appliance is designed and manufactured solely for the cooking of domestic
(household) food and is not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used within a non domestic
environment i.e. a semi commercial, commercial or communal environment.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
After having unpacked the appliance, check to ensure that it is not damaged.
In case of doubt, do not use it and consult your supplier or a professionally qualified
technician.
Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not
be left around within easy reach of children, as these may cause serious injures.
[Do not attempt to modify the technical characteristics of the appliance as this may
become dangerous to use.
[Do not carry out cleaning or maintenance operations on the appliance without having
previously disconnected it from the electric power supply.
[After use, ensure that the knobs are in off position.
[Do not allow children or other incapable people to use the appliance without
supervision.
[During and after use of the cooker, certain parts will become very hot. Do not touch hot
parts.
[Keep children away from the cooker when it is in use.
[Some appliances are supplied with a protective film on steel and aluminium parts. This
film must be removed before using the appliance.
[Fire risk! Do not store flammable material in the oven, and in the dishwarmer
compartment.
[Make sure that electrical cables connecting other appliances in the proximity of the
cooker cannot come into contact with the hob or become entrapped in the oven door.
[Do not line the oven walls with aluminium foils. Do not pace baking trays or the drip tray
on the base of the oven chamber.
[The manufacturer declines all liability for injury to persons or damage to property
caused by incorrect or improper use of the appliance.
[If you should decide not to use this appliance any longer (or are replacing an older
model), before disposing of it, it is recommended that it be made inoperative in an
appropriate manner in accordance to health and environmental protection regulations,
ensuring in particular that all potentially hazardous parts be made harmless, especially
in relation to children who could play with unused appliances.
[This appliance shall not be used as a space heater, expecially if installed in
marine craft or caravans.
This appliance must be used only for the task it has explicitly been designed for, that
is for cooking foodstuffs. Any other form of usage is to be considered as
inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the event of damage caused by
improper, incorrect or illogical use of the appliance.
3

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR
USE OF ELECTRICAL APPLIANCES
Use of any electrical appliance implies the necessity to follow a series of fundamental rules.
In particular:
[Never touch the appliance with wet hands or feet.
[Do not operate the appliance barefooted.
[Do not allow children or other incapable people to use the appliance without your
supervision.
The manufacturer cannot be held responsible for any damages caused by improper,
incorrect or illogical use of the appliance.
FIRST TIME USE OF THE OVEN
It is advised to follow these instructions:
[Clean the interior of the oven with a cloth soaked in water and detergent (neutral) then
dry carefully.
[Fit the wire racks as described at chapter “Use and Care”.
[Insert shelves and tray.
[Switch on the empty oven to max to eliminate grease tracks from the heating elements.
4

GAS BURNERS
NaturalGas Propane
(Mj/hr) (Mj/hr)
1. Double-ring burner(DR).........................12,2 10,8
2. Semi-rapid burner(SR)............................6,1 5,6
3. Fish burner(FB).....................................10,1 11,0
4. Semi-rapid burner(SR)........................... 6,1 5,6
5. Auxiliary burner(A)..................................3,0 3,1
GAS HOB
5
Fig. 1
3
2
1
4
5

88-88
0 0
CONTROLS DESCRIPTION
1. Electronic clock/alarm
2. Multifunction oven switch knob
3. Multifunction oven thermostat knob
4. Front left burner control knob
5. Rear left burner control knob
6. Fish burner control knob
7. Rear right burner control knob
8. Front right burner control knob
9. Rotisserie control knob
10. Oven thermostat indicator light
Note: the electric ignition of the hob burners is incorporated in the knobs
6
CONTROL PANEL
Fig. 2
1 2 345 6 78 9
10

GAS BURNERS
[Check that the electricity is switched on to allow spark ignition.
[Make sure that all controls are turned to zero.
[The gas flow to the burner is controlled by a tap with safety valve device. If the burner
flame should go out for some reason, the safety valve will automatically stop the gas
flow. The switch of the electric ignition is incorporated in the knobs.
[You control the flow by turning the knob indicator to line up with the following symbols:
BSymbol :tap closed(burner off)
BSymbol : High (maximum)
BSymbol : Low (minimum)
[To ignite automatically, simply push the required knob down and turn it to maximum,
keep the knob down until the burner lights. When the flame is lit, wait for about ten
seconds with the knob down (safety valve activation delay).
[You can control the temperature by turning the knob from “high” to “low”.
[To switch off, turn the knob clockwise until you hear the safety click.
[Note that, if you are using a burner at the minimum setting, you turn the knob clockwise
past the maximum setting before reaching the off position.
[If when lighting any of the burners an abnormal flame appears, switch that the burner off
and relight using the minimum setting.
[If the flame is still different from normal, turn the burner off and consult your Kleenmaid
service agent.
[In the case of an electric mains failure light the burner with a match or lighted taper.
USE OF COOKING HOB
7
Fig. 3

CHOICE OF THE BURNER
The burner must be chosen according to the diameter of the pans and energy required.
Saucepans with handles which are excessively heavy, in relationship to the weight of the
pan, are safer as they are less likely to tip.
Pans which are positioned centrally on burners are more stable than those which are offset.
It is far safer to position the pan handles in such a way that they cannot be accidentally
knocked.
When deep fat frying fill the pan only one third full of oil.
DO NOT cover the pan with a lid and DO NOT leave the pan unattended.
In the unfortunate event of a fire, leave the pan where it is and turn off all controls.
Place a damp cloth or correct fitting lid over the pan to smother the flames.
DO NOT use water on the fire.
Leave the pan to cool for at least 30 minutes.
GRATE FOR SMALL PANS
Supplied together with the appliance (see fig. 5).
This grate is to be placed on top of the (smaller) auxiliary
burner when using small diameter pans, in order to prevent
them from tipping over.
CORRECT USE OF DOUBLE-RING BURNER
[Flat-bottomed pans are to be placed directly onto the pan-support.(See fig.6a)
[To use the WOK you need to place the proper stand in order to avoid any faulty
operation of the wok burner.(See fig.6b)
8
WRONG CORRECT
Fig. 4
Fig. 6A Fig. 6B
Fig. 5
Burners Pot diameter
Auxiliary
Semi-rapid
Double-ring
Fish-burner
16 cm
16 to 22 cm
up to 30 cm
from 12x30 to 18x40 cm
Wok max 36 cm

GENERAL FEATURES
This is ovenfeatures 7 different programs to satisfy every cooking need. The 7 positions,
thermostatically controlled, are obtained by 4 heating elements.
OPERATING PRINCIPLES
Heating and cooking in the MULTI-FUNCTION oven are obtained in the following ways:
4by normal convection
The heat is produced by the upper and lower heating elements.
4by forced convection
The fan in the oven sucks the air from the oven housing at the rear of the oven and
forces it over the circular heating element. The hot air envelops the food in the oven
giving faster and more even cooking before it is sucked back into the housing to
repeat the cycle. It is possible to cook several dishes simultaneously due to the
even distribution of heat within the oven.
4by semi-forced convection
The heat produced by the top and bottom heating elements is distributed
throughout the oven by the fan.
4by radiant heat
The food is grilled by the infrared grill element.
4by radiant heat and ventilation
The food is grilled by the infrared grill element and the heat is distributed
throughout the oven by the fan.
4by ventilation
The food is defrosted by using the fan only function without heat.
MULTIFUNCTION OVEN
9

OVEN LIGHT
By setting the knob to this position, only the oven light comes on (15 W).
It remains on in all the cooking modes.
TRADITIONAL BAKE
The upper and lower heating elements come on. The heat being dispersed by natural
convection. The temperature range must be set between 50° and 225° C using the
thermostat.
The oven must be preheated before cooking.
Recommended for:
Food that requires the same degree of cooking both inside and out, for example roasts,
spare pork ribs, meringues etc.
10
Fig. 7
FUNCTION SELECTOR KNOB
Rotate the knob clockwise to set the oven
for one of the following functions.
THERMOSTAT KNOB
This only sets the cooking temperature and
does not switch the oven on.
Rotate clockwise until the required
temperature is reached (from 50 to 225°C).
0

GRILLING
The infrared grill element at the top of the oven comes on. The heat is dispersed by
radiation.
Use with the function knob set to , the thermostat knob from 50 to 200°C and with the
oven door closed.
For cooking hints, see the chapter “USE OF THE GRILL”.
Recommended for:
Intense grilling, browining, cooking au gratin and toasting, etc.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Attention: The oven door becomes very hot during operation. Keep children away.
DEFROST
Only the oven fan comes on. Use with the thermostat knob set to “ ” - other positions
have no effect. The food is thawed by ventilation without heating.
Recommended for:
Quick thawing of frozen foods; one kg requires approximately 1 hour.
Thawing times vary according to the quantity and type of food to be thawed.
FAN FORCED
The circular element and fan come on. The heat is dispersed by forced convection and the
temperature can be varied to between 50° and 225°C via the thermostat knob. The oven
does not require preheating.
Recommended for:
Food which has to be well-cooked outside and soft or rosy inside, for example lasagne,
lamb, roast beef, whole fish etc.
FAN GRILL
Both the infrared grill and the fan come on. Most of the cooking is done by grilling and then
the hot air circulated around the oven.The oven door should be kept closed.
The temperature can be set between 50°C and 175° C maximum.
The oven should be preheated for approximately 5 minutes before cooking. For further
cooking hints see “GRILLING AND COOKING AU GRATIN”.
Recommended for:
Quick sealing in of food juices for example such as hamburger, chicken pieces, chops.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Attention: The oven door becomes very hot during operation. Keep children away.
11

MAINTAINING TEMPERATURE AFTER COOKING OR
SLOWLY HEATING FOODS
The upper element, the circular element and the fan come on.
The heat is circulated by forced convection with greater intensity in the upper part.
The temperature can be set to between 50° and 140°C via the thermostat knob.
Recommended for:
Keeping food warm after any type of cooking. Slow heating of cooked food.
MULTI-FUNCTION
The upper and lower heating elements and the fan come on - the heat from the element
being circulated by the fan.
The temperature range can be set to between 50° and 225° C using the thermostat.
Recommended for:
Large bulky quantities of food that require even cooking throughout for example large
roasts, turkey, roast turkey, cakes etc.
COOKING ADVICE
STERILIZATION
Sterilization of foods to be conserved, in full and hermetically sealed jars, is done in the
following way:
,Set the switch to position .
,Set the thermostat knob to 185° C and preheat the oven.
,Fill the dripping pan with hot water.
,Set the jars onto the dripping pan making sure they do not touch each other and the
door and set the thermostat knob to position 135° C.
When sterilization has begun, that is, when the contents of the jars start to bubble,turn off
the oven and let cool.
Check your recycle book for full instructions.
12

REGENERATION
Set the switch to position and the thermostat knob to position 150°C.
Bread becomes fragrant again if wet with a few drops of water and put into the oven for
about 10 minutes at the highest temperature.
SIMULTANEOUS COOKING OF DIFFERENT FOODS
The oven set on position can cook several different foods together. Foods as diverse
as fish and cakes can be cooked together without the cross transference of flavours. This
is because the fats and cooking smell that would normally be deposited on the different
foods are oxidised and are not absorbed by the foods.
The cooking temperature of the foods, however must be within 20°-25°C of each other.
The food with longest cooking time will be put into the oven first and the other foods are
added as necessary according to their cooking times.
GRILLING AND COOKING “AU GRATIN”
Grilling may be done without the roasting jack on position of the switch, because the
hot air completely envelops the food that is to be cooked.
Set the thermostat to position 175° C and after having preheated the oven, simply place
the food on the rack.
Close the door and let the oven operate on position 175° C, until grilling is done. Adding a
few dabs of butter before the end of the cooking time gives the golden “au gratin” effect.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Attention: The oven door becomes very hot during operation. Keep children away.
ROASTING
To obtain classical roasting, it is necessary to remember:
,that it is advisable to maintain a temperature between 180° and 200°C.
,that the cooking time depends on the quantity and the type of foods.
USE OF THE GRILL
Preheat the oven for about 5 minutes with the door closed.
Introduce the food to be cooked, positioning the rack as close to the grill as possible.
The dripping pan should be placed under the rack to catch the cooking juices and fats.
Grill with the oven door closed.
Do not grill for longer than 30 minutes at any one time.
Attention: The oven door becomes very hot during operation. Keep children away.
13

ROTISSERIE
This is used for spit roasting under the grill and comprises:
[an electric motor fited to the rear of the oven;
[a stainless steel skewer provided with slide-out
heatless handgrip and two sets of adjustable forks;
[a skewer support to be fitted in the middle runner.
The rotisserie motor is operated by the knob illustrated in
fig. 8.
USE OF THE ROTISSERIE
[Insert the tray into the lowest rack holders of the oven and insert the rod support into
the intermediate rack holders.
[Put the meat to be cooked onto the rod, being careful to secure it in the center with
the special forks.
[Insert the rod into the side gear opening “P”.
[Remove the grip “H” by turning it to the left.
[Insert completely the rotisserie support; the shalf “S” must be inserted in the spit
motor collar “G”.
[
The rotation direction of the rotisserie can be either clockwise or counter-clockwise.
Select Fan Grill ( ) or Grill ( ) on function selector knob and set the oven thermo-
stat to a maximum of 175 degrees.
NOTE: The door and control panel may become very hot during operation. Keep
children away.
14
Fig. 8
0
Fig. 9

RECOMMENDED COOKING TEMPERATURES
15
Food
CAKES
Victoria sandwich
Small cakes/buns
Maidera cake
Fruit cake
Rich fruit cake
Scones
PASTRY
Puff
Short crust
Plate tarts
Quiches and flans
YEAST
Bread loaf
Bread rolls
Pizza dough
ROAST MEAT
Beef - Medium
Lamb
Pork
Veal
Chicken
Turkey up to 10lb
Stews/casseroles
°C
190
190
180
170
150
225
225
200
200-210
200-210
225
220
230
190
190
190-200
190
190
180
150-170
°F
375
375
350
325
300
425
425
400
400-410
400-410
425
425
450
375
375
375-400
375
375
350
300-325
Gas
Mark
5
5
4
3
2
8-9
8-9
6
6
6
7-8
7
8
5
5
5-7
5
5
4
2-3
Shelf
Position *
2 or 3
1 and 2
2 or 3
3
3 or 4
2
2
2
1 or 2
1 or 2
2
1 or 2
2
2 or 3
2 or 3
2 or 3
2 or 3
2 or 3
2 or 3
2 or 3
Cooking
Time (approx)
20-25 mins
15-20 mins
20 mins
1 ¾ hours
2 ½ hours
8-10 mins
10-20 mins
20-30 mins
30-35 mins
40-45 mins
35-55 mins
15-20 mins
20 mins
20 mins/lb + 20 mins
25-30 mins/b + 25 mins
30 mins/lb + 30 mins
30 mins/b + 30 mins
30 mins/b + 30 mins
18-20 mins/b + 20 mins
1 ½ 2 hours
N.B. For fan ovens reduce the temperature
by 10-20°C. For any dish taking one hour or
over to cook, reduce the cooking time by 10
minutes per hour.
*Shelf positions have been counted from
the top of the oven to the base.
A fan oven creates more even temperature
throughout, therefore the shelf positions are
not as critical.

The electronic clock / end cooking timer is a device with the following functions:
>24 hours clock with illuminated display;
>Timing of oven cooking with automatic switch-off (max. 99 minutes).
ELECTRONIC CLOCK
Upon immediate connection of the cooker or after a mains failure, three zeros will flash on
the programmer panel.
To set the clock it is necessary to push the button and then, within 7 seconds,
the or button until you have set the correct time.
The clock will show zero after a mains failure.
Attention: When the programmer display shows three flashing zeros the oven cannot be
switched on.
The oven can be switched on when the symbol is shown in the display.
COOKING WITH AUTOMATIC SWITCH-OFF
The aim of this function is to automatically stop the cooking after a pre programmed time, for
a maximum period of 99 minutes.
To set the cooking time, push the or button until you obtain the desired time in the
display. The symbolAUTO will be shown in the display. Then you adjust the oven thermostat
knob according to the required temperature. The oven will immediately start to operate and
will work for the pre programmed time. The display shows the count down. Clock time can be
displayed by pressing the button.
Once the time has elapsed, the oven will switch off automatically, the symbol AUTO will go
off and an intermittent buzzer, lasting 7 minutes, will start; this can be stopped by pressing
the button.
Important: Before the buzzer is stopped switch off the oven manually.
To cancel the cooking program at any time press the and buttons together and
release the button first.
SETTING THE FREQUENCY OF THE ALARM SOUND
The selection from 3 possibilities of sound can be made by pressing the button.
ELECTRONIC CLOCK/END COOKING TIMER
Fig.10
15-06
A
U
T
O
16

CAUTION
[This appliance must be used only for task it has explicitly been designed for, that is for
cooking foodstuffs. Any other form of usage is to be considered as inappropriate and
therefore dangerous.
[Do NOT place combustible materials or products on this appliance at any time.
[Do NOT spray aerosols in the vicinity of this appliance while it is in use.
USING THE OVEN FOR THE FIRST TIME
[Clean the inside of the oven with a cloth soaked in water and neutral detergent and dry
thoroughly.
[Slide in the catalytic liners and wire racks on the oven wall as in fig. 11.
[Position the shelf and tray as per fig. 12.
[To eliminate traces of grease in manufacture it is necessary to pre-heat the oven at the
maximum temperature:
Bfor 60 minutes in the position, for 30 minutes in the position and for
another 15 minutes in the position.
USE AND CARE
17
Fig. 11 Fig. 12

GENERAL ADVICE
[Before you begin cleaning, you must ensure that the appliance is switched off.
[It is advisable to clean when the appliance is cold and especially when cleaning the
enamelled parts.
[Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the surfaces.
[Avoid using cleaning products with a chlorine or acidic base.
[Do not use a steam cleaner because the moisture can get into the appliance thus make
it unsafe.
ENAMELLED PART
All the enamelled parts must be washed only with a sponge and soapy water or with non-
abrasive products.
Dry, preferably, with chamois.
STAINLESS STEEL
The stainless steel parts should be rinsed with water and dried with a soft, clean cloth or
chamois. In case of difficult spots, use normal non abrasive detergents available on the
market or else a little warm vinegar.
CLEANING THE HOB
Spillage on the hob can usually be removed by a damp soapy cloth. More obstinate stains
can be removed by rubbing gently with a soapy scouring pad or mild household cleaner.
GAS TAPS
If a tap becomes stiff, do not force; contact your local Kleenmaid Service Agent.
OVEN
[The oven with smooth enamel (without catalytic panels) must be cleaned after every
use, using suitable products.
[Please note that after using the oven leaving it on for 30 minutes on the highest
temperature eliminates most grime reducing it to ashes.
[Do not use abrasive substances to clean the oven.
GRILL HEATING ELEMENT
[The heating element is self-cleaning and does not require maintenance.
CLEANING AND MAINTENANCE
18

BURNERS
These can be removed and washed only with soapy water.
Detergents can be used but they must not be abrasive or corrosive.
Do not use abrasive sponges or pads.
Do not put in dishwasher.
After each cleaning, make sure that the burner-caps, as well as the burners, have been well
wiped off and CORRECTLY POSITIONED.
It is essential to check the correct position of the burner-caps as the least displacement from
the housing may cause serious problems.
Special attention has to be paid in order not to exchange the housing of the two small
burners shown in fig. 13. The burner caps can instead be interchangeable. The inner
ring of Wok burner is partially drilled while the ring of Auxiliary burner is fully drilled.
Make sure that the probe of the safety valve, near to each burner, remains clean so that the
safety valves can work properly.
Check also that the electrodes for ignition are always clean in order to ensure a regular spark
shooting.
Advice for use and maintenance of catalytic panels.
The catalytic panels are covered with special microporous enamel which absorbs and does
away with oil and fat splashes during normal baking over 200°C.
If, after cooking very fatty foods, the panels remain dirty, operate the oven “idling” on max
temperature for about 30 minutes.
These panels do not need to be cleaned, however it is advised to periodically remove them
from the oven (at least the side panels) and to wash them with tepid soapy water and then
wipe off with a soft cloth.
Do not wash or clean with abrasive products or with products containing acids or
alkalis.
The side panels are reversible and when the catalytic microporous enamel degrades, they
can be turned to the other side.
19
Fig. 13
Burner-cap ring
partially drilled
Burner-cap ring
fully drilled

REMOVAL OF THE INNER GLASS DOOR PANEL
[The inner glass door panel can easily be removed for cleaning by unscrewing the four
screws (fig. 14).
[When re-assembling ensure that the inner glass is correctly positioned and do not over
tighten the screws.
STORAGE COMPARTMENT
The storage compartment is accessible through the pivoting panel (fig. 15).
Attention: Do not store flammable material in the oven or in the storage compartment.
REPLACING THE OVEN LIGHT
Before any maintenance is started involving electrical parts of the appliance, it must
be disconnected from the power supply.
The bulb must be a type resistant to high temperatures (300°C).
20
Fig. 14
Fig. 15
