INSTALLATION & MAINTENANCE MANUAL
EMXST
1
230V
50Hz
IP
20
ACCESSORIES LTD ACCESSORIES LTD
ACCESSORIES LTD
54

2
These instructions should be read carefully and retained after installation by the end
user for future reference and maintenance.
These instructions should be used to aid installation of the following product:
EMXST
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for
installation
• This product is Class II double insulated
• Provide power to the required point of installation
• Remove the top plate by inserting a screwdriver into the slots on the side (see Fig. 1)
INSTRUCTIONS EMXST
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following product:
EMXST
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
•This product is Class II double insulated
INSTALLATION
•Provide power to the required point of installation
•Remove the top plate by inserting a screwdriver into the slots on the side (see Fig. 1)
Fig. 1
•Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water pipes or
electrical cables
•Feed the mains cable through the cable entry hole on the top plate (see Fig. 2)
•Fix the luminaire to the surface using appropriate fixings
Fig. 2
•Connect the mains cable into the push-fit terminal block ensuring correct polarity is observed: Live
(brown), Neutral (blue)
Insert screwdriver to release top plate
Cable entry
Test button
LED indicator
Fig. 1

3
• Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water
pipes or electrical cables
• Feed the mains cable through the cable entry hole on the top plate (see Fig. 2)
• Fix the luminaire to the surface using appropriate fixings
INSTRUCTIONS EMXST
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following product:
EMXST
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
•This product is Class II double insulated
INSTALLATION
•Provide power to the required point of installation
•Remove the top plate by inserting a screwdriver into the slots on the side (see Fig. 1)
Fig. 1
•Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water pipes or
electrical cables
•Feed the mains cable through the cable entry hole on the top plate (see Fig. 2)
•Fix the luminaire to the surface using appropriate fixings
Fig. 2
•Connect the mains cable into the push-fit terminal block ensuring correct polarity is observed: Live
(brown), Neutral (blue)
Insert screwdriver to release top plate
Cable entry
Test button
LED indicator
Fig. 2
• Connect the mains cable into the push-fit terminal block ensuring correct polarity is observed: Live
(brown), Neutral (blue)
• For non-maintained operation, remove the 2-pin connector from the circuit board (see Fig. 3).
For maintained operation keep it in place. This fitting cannot be connected for switched-maintained
operation
•For non-maintained operation, remove the 2-pin connector from the circuit board (see Fig. 3). For
maintained operation keep it in place. This fitting cannot be connected for switched-maintained operation
Fig. 3
•Ensure the battery is connected via the plug and socket to the PCB
•Refit the luminaire to the top cover ensuring all 4 lugs lock into place
•Switch on and check for correct operation, ensuring the green indicator LED is illuminated
See below for operation of the self-test function
We recommend, on commissioning the installation, a minimum charge period of 24 hours before carrying out an
emergency duration test
If the batteries have been left in a discharged state for an extended period, we recommend that one or more
charge and discharge cycles are completed which should help to restore the battery capacity
SELF-TEST FUNCTION
This product is programmed to carry out its own self-test function according to the following programme:
1. 24 hours after first power-on
3 hour duration test
2. then every 28 days
3. 30 second monthly function test
4. and every 52 weeks
5. 3 hour duration test
Following self-tests, the unit will go back into charging mode, and any faults will be indicated by the bi-colour LED
indicator as follows:
LED indicator
Status
solid green
normal conditions / charging / test successful
1 red flash
battery fault
2 red flashes
lamp fault
3 red flashes
duration test failure
NB: power should be cut off and restored to the unit to clear a fault indication once the condition is rectified
Tests can also be initiated manually as follows:
Test button
green LED
Status
short press
off
emergency mode while test button held in
press for approx. 5 seconds
slow flash
emergency mode for 30 seconds (monthly function test)
press for approx. 7 seconds
fast flash
emergency mode for 3 hours (duration test)
press for approx. 10 seconds
end the duration test
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed
GENERAL
The LED lamps fitted in this product are non-replaceable. The unit should be recycled in the correct manner
when it reaches the end of its life. Check local authorities for where facilities exist
Fig. 3
• Ensure the battery is connected via the plug and socket to the PCB
• Refit the luminaire to the top cover ensuring all 4 lugs lock into place
• Switch on and check for correct operation, ensuring the green indicator LED is illuminated

4
See below for operation of the self-test function
We recommend, on commissioning the installation, a minimum charge period of 24 hours before
carrying out an emergency duration test
If the batteries have been left in a discharged state for an extended period, we recommend that one
or more charge and discharge cycles are completed which should help to restore the battery capacity
SELF-TEST FUNCTION
This product is programmed to carry out its own self-test function according to the following
programme:
Following self-tests, the unit will go back into charging mode, and any faults will be indicated by the
bi-colour LED indicator as follows:
LED INDICATOR STATUS
Solid green Normal conditions / charging / test successful
1 Red flash Battery fault
2 Red flashes Lamp fault
3 Red flashes Duration test failure
TEST BUTTON GREEN LED STATUS
Short press Off Emergency mode while test button held in
Press for approx.
5 seconds Slow flash Emergency mode for 30 seconds (monthly function test)
Press for approx.
7 seconds Fast flash Emergency mode for 3 hours (duration test)
Press for approx.
10 seconds
End the duration test
NB: power should be cut off and restored to the unit to clear a fault indication once the
condition is rectified
Tests can also be initiated manually as follows:
24 hours after first power-on 3 hour duration test
then every 28 days 30 second monthly function test
and every 52 weeks 3 hour duration test

5
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed
WARNING
GENERAL
WARRANTY
The LED lamps fitted in this product are non-replaceable. The unit should be recycled in the correct manner
when it reaches the end of its life. Check local authorities for where facilities exist
The batteries in this luminaire are Nickel Cadmium and must be disposed of correctly. Please contact the local
authorities for the disposal of this toxic waste.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product
This product is non-dimmable
This product has a warranty of 3 years (excluding battery) from date of purchase. Failure to install this product
in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of
the batch codes will invalidate the warranty. If this product should fail within its warranty period it should be
returned to the place of purchase for a free of charge replacement. ML Accessories does not accept responsibility
for any installation costs associated with the replacement product. Your statutory rights are not affected. ML
Accessories reserve the right to alter product specification without prior notice.

6
TEST RECORD SHEET
INITIAL COMMISSIONING
3 HOUR TEST
SIGNED DATE
MONTH TEST
FIRST YEAR SECOND YEAR THIRD YEAR FOURTH YEAR FIFTH YEAR
SIGNED DATE SIGNED DATE SIGNED DATE SIGNED DATE SIGNED DATE
1 FUNCTIONAL
2 FUNCTIONAL
3 FUNCTIONAL
4 FUNCTIONAL
5 FUNCTIONAL
6 FUNCTIONAL
7 FUNCTIONAL
8 FUNCTIONAL
9 FUNCTIONAL
10 FUNCTIONAL
11 FUNCTIONAL
12 3 HOUR
TEST RECORD
Recommended routine test procedure in accordance with BS5266:
• Daily check – check status of bi-colour LED indicator
• Monthly functional test - simulate a mains supply failure for approx. 30 seconds by operation of key switch,
switching off circuit breaker or using test button. Ensure normal supply is restored after test and check status
of bi-colour LED indicator
• Annual three hour duration test - simulate a mains supply failure for three hour continuous test by
operation of key switch, switching off circuit breaker or using test button. Ensure normal supply is restored
after test and check status of bi-colour LED indicator
If the luminaire fails any of the above tests, please contact a qualified electrician. See below for test record sheet
