Knightsbridge EMSWING Instruction Manual

54
INSTALLATION & MAINTENANCE MANUAL
EMSWING
IP
20
230V
50Hz
EMSWING INSTRUCTIONS WEB_.indd 1 20/03/2018 14:37

These instructions should be read carefully and retained after installation by the end user for future
reference and maintenance.
These instructions should be used to aid installation of the following product:
EMSWING
GENERAL INSTRUCTIONS:
SAFETY:
INSTALLATION:
• Installation of this luminaire should only be carried out by a qualifi ed electrician or competent
person to the latest Building and current IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit (including when this luminaire is fi tted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
• This product is Class 1
• This product is non-dimmable
• This product is IP20 rated
• Provide power to the required point of installation
• Remove the 2 screws at either end of the suspension housing and remove the back plate, see Fig 1
• Using the back plate as a template, mark the location for, and drill, 2 fi xing holes ensuring not to
infringe with any joists, gas or water pipes or electrical cables
• Feed the mains cable through the cable entry hole and secure the back plate to the surface
• Connect mains cable into the screw-fi t terminal block ensuring correct polarity is observed, see
Fig 2, Fig 3 and Fig 4 for un-switched maintained, un-switched non-maintained and switched
maintained wiring diagrams
Remove screws
Fig 1
EMSWING INSTRUCTIONS WEB_.indd 2 20/03/2018 14:37

This product must be disconnected from the circuit if subjected to any high voltage or insulation
resistance testing. Irreparable damage will occur if this instruction is not followed.
Recommended routine test procedure in accordance with BS5266.
Daily check – check that the status GREEN LED indicator is illuminated.
Monthly functional test – simulate a mains supply failure for approx. 30 secs by operation of key
switch or switching off a circuit breaker. Ensure normal supply is restored after test and the indicator
status LED is illuminated.
Twice yearly conduct a one hour duration test - simulate a mains supply failure for one hour
continuous test by operation of key switch or switching off circuit breaker. Ensure normal supply is
restored after test and the indicator status LED is illuminated.
Annual full three hour duration test - conduct a three hour continuous duration test. Simulate a
mains supply failure for three hour continuous test by operation of key switch or switching off circuit
breaker. Ensure normal supply is restored after test and the indicator status LED is illuminated.
If the luminaire fails any of the above tests, please contact a qualifi ed electrician. See overleaf for test
record sheet.
L Live Brown
N Neutral Blue
E Earth Yellow & green
LS Switched Live
Fig 3: Unswitched Maintained Fig 4: Switched Maintained operation
Fig 2: Non-Maintained operation
• Refi t the exit sign to the top cover ensuring all 4 lugs lock into place
• Switch on the power supply and check for correct operation
WARNING:
EMSWING INSTRUCTIONS WEB_.indd 3 20/03/2018 14:37

ML Accessories Limited
LU5 5TA
www.mlaccessories.co.uk AKMAR18_V2
GENERAL
WARRANTY
The LEDs fitted in this product are non-replaceable. The unit should be recycled in the correct
manner when it reaches the end of its life. Check local authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the fitting.
This product has a warranty of 3 years (excluding the battery) from date of purchase. Failure to
install this product in accordance with the current edition of the IEE Wiring Regulations, improper
use, or removal of the batch codes will invalidate the warranty. If this product should fail within its
warranty period it should be returned to the place of purchase for a free of charge replacement. ML
Accessories does not accept responsibility for any installation costs associated with the replacement
product. Your statutory rights are not affected. ML Accessories reserve the right to alter product
specification without prior notice.
TEST RECORD SHEET
FIRST YEAR SECOND YEAR THIRD YEAR FOURTH YEAR FIFTH YEAR
MONTH TEST
SIGNED DATE SIGNED DATE SIGNED DATE SIGNED DATE SIGNED DATE
1FUNCTIONAL
2FUNCTIONAL
3FUNCTIONAL
4FUNCTIONAL
5FUNCTIONAL
61 HOUR
7FUNCTIONAL
8FUNCTIONAL
9FUNCTIONAL
10 FUNCTIONAL
11 FUNCTIONAL
12 3 HOUR
Installed by: Installation date:
Contact number:
