Product Introduction
The KDC180 Bluetooth barcode scanner is a 2D Imager Bluetooth Barcode Data Collector and it has several
variations: KDC180 with inductive charging, KDC180 with keypad, KDC180 with UHF RFID reader, and KDC180
with UHF RFID reader and no barcode scanner. They all support Bluetooth Low Energy (BLE) v5.0.
1.1 KDC180 Diagram

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p3
1.2 How to turn on and off
Refer to the figure in section 1.1 to locate the SCAN and DOWN buttons.
Note: The trigger on the Ring Scanner and Finger Trigger Glove work as SCAN buttons.
On the keypad variation, the DOWN button is in the lower area.
a) Press and hold the SCAN + DOWN buttons simultaneously for 3 seconds.
b) The KDC will beep when it is turned ON.
Pairing (Bluetooth or NFC)
Connecting your KDC using Bluetooth is made easy with the below pairing barcodes.
If using an Android device, pairing via NFC is even easier: just approaching the KDC to the back of the host
device’s NFC area is enough for pairing. For more details, see section 2.3
2.1 Bluetooth Profiles Explained
a. HID Profile: Allows one-way Bluetooth communication with an Android or iOS host
device. The KDC only transmits data to the host device.
b. SPP Profile: Allows two-way Bluetooth communication. The KDC transmits data to the
host device and the host device can transmit data back to the KDC.
c. HID Windows Profile: Allows one-way Bluetooth communication with a Windows PC. The
KDC only transmits data to the Windows PC.
Note:HID inputs data directly into an application. SPP requires the KOAMTAC KTSync®
app or integration of KOAMTAC SDK to input data into an application. To gain access to
the SDK, please complete the form here: https://www.koamtac.com/sdk/

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p4
2.2 Bluetooth Pairing a KDC180 to your smart device with special barcodes
Bluetooth Profile & Pairing
#1. HID-BLE & Pairing (Android, iOS, Mac)
#2. HID-Windows & Pairing (Windows)
#3. SPP-BLE & Pairing (Android, iOS, Mac, Windows)
a. Navigate to the Bluetooth setting on the host device and ensure that Bluetooth is both
enabled and searching for devices.
b. Using the KDC, scan the pairing barcode above that corresponds to your desired
Bluetooth profile. If you are unsure which Bluetooth profile is right for you, please refer
to Chapter section 2.1.
•If you use an Android, iOS, or Mac device and desire an HID connection, then scan
barcode #1 above.
•If you use a Windows device and desire an HID connection, then scan barcode #2
above.
•If you desire an SPP connection for any device, then scan barcode #3 above.
c. In HID or HID Windows Profile, check the list of available Bluetooth devices on your host
device. From the list, select the KDC180 listed by serial number in brackets that matches
the serial number found on the back side of the KDC180. KDC180 will beep upon
connection and display “BLE HID Connected” on its screen. Now it is ready to use.
d. In SPP Profile for non-iOS, check the list of available Bluetooth devices on your host
device. From the list, select the KDC180 listed by serial number in brackets that matches
the serial number found on the back side of the KDC180. KDC180 will beep upon
connection and display “BLE SPP Connected” on its screen, but you should launch
KTSync or your application and select KDC180 within the application to complete the
connection. Now it is ready to use.

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p5
e. In SPP Profile for iOS, the KDC is NOT listed on your host device, so you should launch
KTSync or your application and select the KDC180 listed by serial number in brackets that
matches the serial number found on the back side of the KDC180. KDC180 will beep upon
connection and display “BLE SPP Connected” on its screen. Now it is ready to use.
2.3 Bluetooth Pairing a KDC180 to your smart device with NFC (Android Only)
This feature applies only to Android. KDC may be paired in either HID or SPP only.
a. Navigate to the NFC setting on the host device and ensure that NFC is enabled.
b. On the KDC, make sure NFC pairing is enabled by navigating to KDC MENU →BLE
Config →NFC Pairing →Enabled →Save & Exit.
c. On the KDC, select the pairing profile by navigating to KDC MENU →BT Config →
Connect Device →Select HID or SPP →Save & Exit.
Or, select the profile using the special barcodes below:
d. Approach the NFC area on the back of the host device with the KDC to complete pairing.
Select Bluetooth Profile
#1. HID Profile (w/ NFC Enable)
#2. SPP Profile (w/ NFC Enable)

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p6
UHF Model: KDC180U or KDC180HU
3.1 Pairing (KDC180U: UHF Only. No Barcode Scanner)
The KDC180U is not equipped with for barcode scanning, so there are barcodes can no be used to change
settings. You must change settings through the menu.
➢Menu mode can be entered by pressing <UP> key and <DOWN> key at the same time.
➢For pairing, follow these steps:
1) Navigate to “BT Config” and select
2) Navigate to “ConnectDevice” and select
3) Navigate to the desired profile option and select
4) Navigate to “Save & Exit” and select
5) Navigate to “Top Menu” and select
6) Navigate to “Top Menu” and select
7) Navigate to “BT Service” and select
8) Navigate to “Pairing” and select
➢For NFC pairing, refer to chapter 2.3 above. To select a profile, follow these steps:
1) Navigate to “BT Config” and select
2) Navigate to “ConnectDevice” and select
3) Navigate to any profile option to be used and select
4) Navigate to “Save & Exit” and select
5) Navigate to “Top Menu” and select
3.2 Toggling the Read Mode: Barcode Mode vs. UHF Mode
The SCAN button or the trigger on the ring/glove can be used to read barcodes (Barcode mode) or UHF tags
(UHF mode) depending on the read mode and you can change the mode alternatively.
a) In “Barcode mode”, a barcode can be read by a SCAN button or trigger button.
b) In “UHF mode”, UHF tags can be read by a SCAN button or trigger button.
c) The KDC180U, by default, is set to “UHF mode.” After factory default, the device will still be in “UHF
mode.”
d) The KDC180HU, by default, is set to “Barcode mode.” After factory default, the device will be set to
“Barcode mode.”
e) There are two ways to change the read mode:
1) Press and hold the UP button for 3 seconds
2) Change from within the application using SDK
f) When the mode is changed, the KDC will give a series of beeps to confirm the mode change:
1. When you enter UHF Mode: 1 long and 2 short beeps
2. When you enter Barcode Mode: 1 long and 1 short beep

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p7
3.3 Changing the UHF Read Tag Modes: Single, Multiple, or Active
This mode only works when the device is in UHF Mode. Refer to 3.2 to see how to toggle read modes.
When in UHF Mode, you have the option of scanning in 3 different modes. The modes change in the following
order: Active (default) read -> Single read -> Multiple read. The mode can be changed by pressing the DOWN
button for 2 seconds.
•Single mode: Only one tag is read every time the scan button is pressed.
o1 short beep will occur when changing mode with Down key.
•Multiple mode: When the Scan button is pressed, reads multiple tags simultaneously for the set time
(default 10 seconds).
o2 short beeps will occur when changing mode with Down key.
oTime setting can be changed in Settings ->Reading Timeout.
•Active mode: Basic operation status. Simultaneous reading of multiple tags while pressing the scan
button (max. 10 minutes)
o3 short beeps will occur when changing mode with Down key.
Alternatively, you can scan the special barcodes to change the mode if KDC has a barcode scanner
(KDC180HU). To change from active mode to another mode, you should disable Active Mode first.
Active Mode (Enable)
Active Mode (Disable)
In Active Mode, if the SCAN button or Trigger button is pressed more than 10 minutes, the read mode
automatically changes from UHF Mode to Barcode Mode to save battery life in the case of the trigger being
stuck in the scan position. This option is enabled by default and may be disabled.
If you need to scan with the trigger depressed for more than 10 minutes, you need to disable the Active Read
10 Minute Timeout.
Single Mode
Multiple Mode

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p8
Active Read 10 Minute Timeout
Enabled (Default)
Disabled
3.4 UHF Tag Counting (Beep Count)
By setting the Count attribute, you can get an estimate of how many tags are read per beep.
•Count = 0: The device only beeps once when you start reading
•Count = 5: Beeps once every 5 tags read. Example: 2 beeps means you read 10 to 14 tags.
•Count = 10: Beeps once every 10 tags read. Example: 2 beeps means you read 20 to 29 tags.
•Count = 20: Beeps once every 20 tags read. Example: 2 beeps means you read 40 to 59 tags.
•Count = 50: Beeps once every 50 tags read Example: 2 beeps means you read 100 to149 tags.
Scan the barcode on below that corresponds with your preference for Tag Counting.
Count = 0
Count = 50
Count = 5
Count = 10
Count = 20

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p9
Usage
4.1 Using Keyboard Wedge (HID Keyboard)
This option is only available using Bluetooth connection with HID profile.
Once the KDC is paired with the host, open any application with a text field and tap on the text field. Scan any
barcode and it will populate in the text field.
4.2 Using KTSync –Android/iOS
You can use KTSync to utilize your KDC alone or with a native application. This is only available using a
Bluetooth connection with SPP or MFi.
a) Download and install KTSync from the Google Play Store or the Apple App Store.
b) Open KTSync and tap on the “Connect” option on the bottom left to view a list of available devices.
(Fig. 1)
c) In case of Android, the pairing should be established from Settings of the phone and in case of iOS,
“START BLE SCANNING” menu should be run from “Connect” menu.
d) From the device list, select your KDC –ensuring that the serial number displayed in brackets matches
the serial number on the back of your KDC. (Fig. 2)
e) Upon successful connection, KTSync will display “Connected” next to the name of your KDC at the top
of the application. (Fig. 3)
f) To test your connection, scan any barcode. If the connection is successful, the barcode data will display
on the screen. (Fig. 3)
< Fig. 1 > < Fig. 2 > < Fig. 3 >

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p10
In Always-pairing mode, an application can connect to a KDC without reading a pairing barcode, so the
connection procedure is a little different.
a) In the KTSync app, tap the Connect icon at the bottom left of the app.
b) In KTSync, tap “START BLE SCANNING” in the top right.
c) In KTSync, check the list of found devices.
d) In KTSync, tap the KDC180 listed by serial number in brackets followed by [BLE] that matches the serial
number found on the back side of the KDC180. The format will look like this, KDC180[xxxxxx] [BLE],
where xxxxxx is the serial number.
e) The KDC180 will beep upon connection and display “BLE SPP Connected” on its screen. Now it is
ready to use.
< Fig. 4>

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p11
4.3 Using KTSync Keyboard –Android
Once your KDC is connected to KTSync, you can use your KDC as a keyboard.
a) While KTSync is running in the background, navigate to Settings > Language & Input > Virtual
Keyboard > Manage keyboards
b) Tap on “KTSync Keyboard” to enable it.
c) Change “KTSync Keyboard” to the default keyboard. (Fig. 5)
To switch back to the previous keyboard, simply change the default keyboard again. Or, when a text field is
selected swipe down from the top of the screen to bring up the notification panel. Select ‘choose input
method’ and you can select the default keyboard from here. (Fig. 6)
< Fig. 5 > < Fig. 6 >

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p12
4.4 Using KTSync Keyboard –iOS
Once your KDC is connected to KTSync, you can use your KDC as a keyboard.
a) Navigate to the iPhone/iPad/iPod Settings > General > Keyboard > Keyboards > Add New Keyboard...
> Select the KTSync keyboard to be added. (Fig. 7)
b) Select the KTSync Keyboard and toggle the switch to Allow Full Access. (Fig. 8)
< Fig. 7 > < Fig. 8 >
c) Open the application you want to scan into and tap on the screen, so the on-screen keyboard appears.
d) Press and hold the globe icon located to the left of the spacebar.
e) Select the KTSync Keyboard and begin scanning. (Fig. 9)
< Fig. 9 >
Note: The KDC must be connected to KTSync & the KTSync keyboard must be selected for this to work.

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p13
4.5 Using other Developed Applications with SDK –Android/iOS
A Software Development Kit (SDK) for Android
and iOS is available to all KOAMTAC
customers to ensure smooth development of
applications that work seamlessly with a KDC
scanner. It’s easy to request the SDK from the
KOAMTAC website:
a) On any web browser, open
www.koamtac.com
b) Navigate to Support > Downloads > SDK
c) Complete the form and submit it.
After submission, a KOAMTAC representative
will reach out regarding next steps for
completing the SDK Agreement.
The SDK package will have libraries, documents,
a sample application and its source code.

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p14
Product Specifications
Physical
Design
Companion Bluetooth Barcode Scanner
Size
Wireless/Keypad: 1.57” x 2.72” x 0.8”
(40 mm x 69 mm x 20.3 mm)
UHF: 1.57” x 2.72” x 1.1”
(40 mm x 69 mm x 27.1 mm)
Weight
Scanner Only: 2.23 oz (63.2 g)
Wireless: 2.30 oz (65.3 g)
Keypad: 2.30 oz (65.3 g)
UHF: 2.87 oz (81.5 g)
UHF Only (Non-scanner): 2.66 oz (75.4 g)
Ring Trigger Only: 0.73 oz (20.6 g)
Glove Only: 1.76 oz (50 g)
Battery Only: 0.76 oz (21.5 g)
Functionality
Supporting OS
Android / iOS / Tizen / Windows / Mac OS X
Keys
Default: Scan Key, Up Key, Down Key
Keypad Module: Scan Key, Up Key, Down Key,
Numeric Keys (1, 2,3,4,5,6,7,.8,9,0)
Buzzer
Yes
LED Indicator
2 Tri-color Status LED’s and 5 Programmable LED’s
(Red / Amber / Green)
USB Port
1 Micro USB Port
Memory
RAM
SDRAM 64KB
ROM
Internal Flash ROM 512KB
(256KB for Program, 256KB for User Data)
Barcode Storage
10,000+ Barcodes (EAN-13)
Power
Battery (Standard)
1,010 mAh Lithium-ion
Charging Solution
USB Connector / Charging Cradle
Charging Time
4 Hours
Communication
Bluetooth
Bluetooth Low Energy V5.0, HID/SPP
Micro USB
USB HID
USB Serial (Android with OTG cable / Windows)
Barcode Reader
1D/2D Symbology
Yes
# of scans per charge
(1 sec interval)
25,000+ (10+ hours)
# of scans per charge
(10 sec interval)
20,000 (55+ hours)
Scan Range
(20mil Code39)
1.73 to 31.5 in (44 to 800 mm)

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p15
Screen Reading
Yes
Postal Codes / OCR
Passport
Yes / No
RFID Details
(Optional)
Supported Standards
IEPC Class1 Gen2, EPC Gen2 V2
Nominal Read Range
1.5’+ (0.5m+)
dependent on tag type and operating environment
Frequency
US, EU, JP, KR
Output Power Range
Up to +27dBm
Read Rate
100 tags per second
Tag Storage
> 21,000 RFID tags
(in case of 12 bytes of EPC Data)
Environment
Drop Spec
5 ft (1.5 m)
6 ft (1.8 m) with a protective boot
IP Rating
IP65
Operating Temp.
-44 ˚F to 122 ˚F (-20 ˚C to 50 ˚C)
Storage Temp.
-4 ˚F to 140 ˚F (-20 ˚C to 60 ˚C)
Humidity Spec
5% ~ 95% (non-condensing)
Regulatory
Conformance
Laser Safety
IEC60825-1 (Class II)
LED Safety
IEC62471:2006
Regulatory
RED, FCC, KC, TELEC, VCCI, SRRC, RoHS
Compliant
Accessories
2-Slot Charging Cradle
Yes
10-Slot Charging Cradle
Yes
Finger Trigger Glove
Yes
Ring Scanner
Yes
Protective Boot
Yes

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p16
How to Use Tizen WebApp Demo Application (Only for KDC180/280)
KDC180 and KDC280 have BLE (Bluetooth® Low Energy) V5.0 and V4.1 each instead of Bluetooth V2.1 and
support the below two profiles:
➢SPP –It is a KOAMTAC-specific custom profile which provides bi-directional communication in the
paired mode.
➢HID –It is a Bluetooth Low Energy standard profile which supports Human Interface Device like a
keyboard or mouse. It is required to be paired first.
To connect with Gear S3 for the current demo application from KOAMTAC, you should use SPP profile
because Gear S3 does not support HID:
6.1 Connect the phone to Gear S3 and Install the demo application
➢Download Galaxy Wearable (Samsung Gear) application from Play Store. (Please make sure your
phone supports Galaxy Gear S3.)
➢Connect the Samsung Gear to your smartphone. (You can refer to the link to learn how to connect:
http://www.samsung.com/ca/support/skp/faq/1119975)
➢On the Gear press the home button and scroll to settings. Scroll down and select Connect to a New
Phone. On the phone, open the Samsung Gear application and search for nearby Gear devices.
Select your Gear from the list and confirm the passcode on both devices.
➢From Galaxy Store, search Koamtac apps, which is “Koamtac Simple Web Demo”App and install it
on Gear S3.

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p17
6.2 Pair/Connect KDC with Gear S3
➢Put KDC180/KDC280 into SPP mode and start pairing (you can also see Chapter 2 in this document)
Bluetooth Profile & Pairing
#3. SPP & Pairing
➢Run KTSimpleWebDemo on your Gear S3.
➢Tap “Connect” and the available devices will be listed on your Gear S3. Tap the KDC from the list of
available devices to connect. The number between the brackets refers to the serial number located
on the back of the KDC.

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p18
➢Now you can trigger the KDC scanner via the demo application or the KDC itself. Any scanned bar
code will be displayed on the Gear S3. There are also many commands that can be used to view or
set the configuration of the KDC.
➢If the KDC becomes disconnected or if you disconnect the current KDC, you can reconnect it later
by selecting Connect from the Gear S3.

KDC180 QG
Quick Guide
See Reference Manual for more detailed information
Visit store.koamtac.com to purchase additional products and accessories.
QG_KDC180_20220614 p19
Social Distancing Feature
The COVID-19 pandemic has added a new challenge to every workplace - warehouses,
manufacturing lines, and even retail store floors - the need to maintain distance between
people for their health and safety. Reopening your business is already an undertaking
but ensuring social distance among your workers is made easy with the KOAMTAC social
distancing feature.
Whether you’re a small or enterprise business, the KOAMTAC social distancing feature
works with the technology and systems you already have in place so you, and your
workers, can have peace-of-mind as you adjust to the new normal.
➢Supported on all Bluetooth Low Energy (BLE) 5.0 KDC devices.
➢For more on the social distancing feature, please watch: https://youtu.be/m4Manx9vK68
There are three ways to enable and control the settings for the social distancing feature:
1. Enable via the KDC menu
2. Scan the special Social Distance barcodes that correspond with the settings you wish to enable
3. Enable via the KTSync application
7.1 Social Distancing Feature Parameters
The following parameters can be changed:
➢Distance: Set the acceptable social distance range with values between 1 to 10 meters (Default:
Disabled).
➢Host Alert: This setting will forward distance alerts to the connected host device (Default: Disabled).
➢KDC Alert: This setting allows the user to enable/disable an audible beep sound (Default: Enabled),
vibration (Default: Disabled), and data storage (Default: Disabled) settings for distance violations on the
KDC.
➢Security Key: Choose keys between devices. Only KDC devices using the same key will be able to
detect and report the distance between devices. If the security key is “Disabled”, the KDC won’t use
any key. If “Fixed Key” is selected, the KDC will use a predefined key. If you prefer to set your own
custom key by selecting “Custom Key”, the custom key can only be set through KTSync (Default: Fixed
Key).
