Kogan SuperScrub 360°
Model Number: KASUSCR360A
Quick Startup Guide
www.kogan.com 1 2
345

First of all, we sincerely thank you for purchasing our product, pls Read and follow all the instructions in
this “Use and Care” even if you feel you are familiar with the product, and find a place to keep it handy for
future reference.
For your convenience record the complete model number (located on the product identification plate) and
the date you received the product, together with your purchase receipt and attach to the warranty and
service information. Retain in the event that warranty service is required.
NOTE: The rating of this product (as marked on the product identification plate) is based on specific
loading tests. Normal use or the use of other recommended attachments may draw significantly less power.
IMPORTANT SAFEGUARDS
When using any electrically powered product, basic safety precautions should always be followed:
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE PRODUCT.
To reduce the risk of fire, electrical shock or injury to persons or property:
WARNING
Read all instructions before using this appliance and keep them for future reference.
1. Store out for reach of children, this product is not a toy. Close supervision is required when any appliance is
used by or near children.
2. To protect against the risk of electric shock, do not put the battery charger in water or other liquids, Do not charge
battery if it is wet or shows signs of corrosion.
3. Do not use an extension cord. Plug the charger directly into a Standard power outlet, please check the input data
from product Rating Label.
4. Do not attempt to use this charger with any other product.
5. Do not attempt to charge this product with any other charger.
6. If the charging cord is damaged, it must be replaced by the manufacturer or its service agent or similarly qualified
person in order to avoid hazard.
7. Do not use this charger in wet or damp conditions, it is intended for indoor use only.
8. Do not use charger near sinks or tubs, Do not immerse in water.
9. Do not abuse the cord. Do not carry away from heat and sharp edges.
10. Do not allow the cord to hang over the edge of a table or counter or touch hot surfaces. The charger should be placed
always from sinks and hot surfaces.
11. Unplug the charger when not in use and before cleaning
12. Do not operate adapter if it has received a sharp blow, been dropped or otherwise damaged in any other way.
Do not disassemble the adapter for any reason.
13. For best result do not charge a battery when it or the air temperature is below 40F(5°C) or above 105F(40°C).
14. Always store this unit indoors.
15. Do not operate in the presence of explosives and / or other flammable fumes or liquids.
16. Do not store or use this appliance close to high temperatures.
17. If abnormal noise, smell, smoke or any other failure or breakage if found during operation, turn o the switch and unplug it.
18. Only charge the unit when it is in the OFF position.
19. This appliance is only for household use, not for commercial or industrial use.
20. Always use proper eye protection when using this unit with irritating substance. Robber gloves are also recommended.
21. Only change the scrubber heads when the units are in the o position.
22. Keep hair, loose clothing and all parts o the body away from the moving parts of the unit.
23. Do not use this unit when the protective charging cover is not in place.
24. Do not submerge the handle in water or other liquids.
25. To avoid risk of suocation, keep all plastic bags away from children.
1 2
345

PRODUCT INORMATION
1. Main Handle
2. ON/OFF Switch
3. Charging Cover
4. Charging Port
5. Bottom Extension Release Button
6. Extension Handle
7. Top Extension Release Button.
8. Scrubber Head Assembly
9. Charging Adapter(Australia Type to be used)
10. Dome Brush Head
11. Flat Brush Head
12. Corner Brush
HANDLE ASSEMBLY
Before assembling any component of this product, make sure the unit is set to OFF position.
Assembly without Extension Handle.
- Connect the main handle to the Scrubber Head Assembley until you hear a “CLICK”
Assembly with Extension Handle.
- Connect the main handle to the Extension Handle until you hear a “CLICK”.
- Next, connect the Scrubber Head Assembly to the extension handle until you hear a “CLICK”.
1 2
345

BRUSH HEAD ASSEMBLY
Firmly hold the Scrubber Head Assembly with one hand and then press the selected scrubber head on until secured.
OPERATION
- Apply water and a cleaning agent to the surface needing cleaning and/or the head of the Kogan SuperScrub 360° Brush.
- To Start cleaning, turn the button to the ON position while the scrubber head is in contact with the desired
cleaning surface. Hold the unit by its handle and gently press the scrubbing head to the surface to be cleaned.
- Do not press too hard. The product has been specially designed to do all the work.
- Operate the Kogan SuperScrub 360° only when it is touching the area being cleaned in order to limit spraying of water.
- Cleaning chemicals should be used only in accordance with instructions of manufacturer of the surface being cleaned,
Abrasive cleaners should never be used.
- First try the brush on an inconspicuous surface.
CAUTION:
Before turning on the brush,
make sure to use proper eye wear
and glovoes to avoid eye and skin
contact from splatter.
1 2
3 4 5

MAIN UNIT CLEANING
- Clean all surfaces of the unit with a soft cloth
- Only use a mild detergent to clean the unit. Do not use alcohol-based or abrasive cleaners
- Aside from the unit’s brush head, do not submerge it, or shower it in water.
- Separate all sections of the unit and allow it to air dry.
CHARGING
- Charging requires that the ON/OFF button be set to OFF.
- Insert the Charging Adapter into the Charging Port located at the bottom of the unit.
- A RED indicator light means charging is occurring.
- Your first charge requires 20 hours, but later Charges take only 8 hours.
- If the unit does not charge, test the wall outlet that you are using with a known working device.
Also, if the wall outlet if connected to a wall switch, check and see that the switch is turned to
the ON position.
- If the unit’s handle feels warm during charging, do not worry this is completely normal.
- Close the Charging Cover once charging is complete.
- Keep the device OFF during the charging process.
- Do not separate the charging cover from the device.
- Do not worry, you cannot over-charge the battery by using the provided charging adapter.
1 2
34 5

- Using a Philips head screwdriver, remove the left and right side screws, as shown in Figure 1.
- Grasp the bottom of the handle and the top part of the unit and pull the battery assembly out,
as shown in Figure 2.
- Peel away the tape, unclip the red and black wires, and take out the battery, as shown in Figure 3
If you have further isues with Kogan SuperScrub 360° Brush or these suggested solutios do not help,
please contact the Kogan.com customer support team.
BATTERY REMOVAL
This product uses a Nickel-Cadmium(Ni-cad) rechargerable battery,
When the battery cannot be recharged anymore, it should be removed
from the unit and recycled properly, this battery cannot be incinerated
or composted
