Kogan KAMN32UCFLA User manual

32" UHD CURVED GAMING
MONITOR
USER GUIDE
3840x2160 60Hz
KAMN32UCFLA

1
SAFETY & WARNINGS
Read all instructions before using the appliance and retain for reference.
This monitor is designed with ventilation holes on the back of the casing. Do not cover or
block them.
Do not insert any object or spray any liquid into the vents.
Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat, as
well as in rooms lacking adequate ventilation.
Do not position the monitor in unsafe locations. If the monitor falls, it may be damaged
and may injure nearby people.
Unplug the monitor if it is not going to be used for an extended period.
Do not place heavy objects on the monitor, its power cord or any connected cable.
Do not open the back panel of the monitor, as it contains a high-voltage current even
when not plugged in.
There is a polarizer layer (not a protective film) on the surface of the screen. Do not peel it
o, or the product may be damaged and the warranty will be invalid.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the
United States and other countries.

2
COMPONENTS
Power cable User guideDP cableHeadphone stand
Monitor
BaseStand arm
32" UHD CURVED GAMING
MONITOR
USER GUIDE
3840x216060Hz
KAMN32UCFLA
Stand screws
(PM5*11 x4)
VESA screws
(M4*12 x4)

3
Solid Blue Power is on and the monitor operating normally.
Flashing Blue
Indicator Status
No video input signal or the monitor is in standby.
Ensure your computer is turned on and operates normally and check
that all video cables are fully plugged in and/or connected to the
monitor.
Indicator
OVERVIEW
M
E
Button Function
Menu button: Confirm/call up the main menu.
Down button: Move down in the menu/quickly enter the GamePlus.
Up button: Move up in the menu/quickly enter the ECO.
Exit button: Exit/return to the previous menu/quickly enter the RGB Range.
Power button: Turn on/o the monitor.
M E
Indicator

4
1. Open the carton, remove the stand arm, base and headphone stand. Leave the monitor
in foam.
Secure the stand arm to the base using one of the screws.
Attach the headphone stand to the stand arm.
2. Remove the bottom half of the protective foam from the monitor.
Press the quick release button and remove the stand plate then attach it to the stand
assembly using two screws.
ASSEMBLY
Headphone stand
Headphone
stand
Screw
Screws
Stand Plate
Stand arm Stand
arm
Stand
base
Stand
base
Note:
When handling the monitor, do not pinch the screen with your hand to avoid
damaging the display.

5
3. Attach the stand plate and stand assembly back onto the rear of the monitor.
Remove the remaining protective foam and stand the monitor upright.
Note: To remove the stand from the monitor, slide the quick-release button up and
pull the stand assembly outwards.
Quick-
release
button

6
VESA mounting pattern 75x 75mm, screw size M4.
Note: VESA mount or mounting accessories are not included.
1. Open the box, take out the monitor with protection foam attached and gently place it
on a desktop or table. Ensure all components are removed from the foam covering.
Press the quick release button to remove the stand plate.
If the monitor is already attached to the stand, remove the stand before proceeding
with VESA mount assembly.
2. Remove the four screws from the rear case. Do not remove the monitor from the foam at
this stage.
VESA MOUNT
Quick release
button
Protective foam
Screws

7
3. Remove the four VESA screws from the accessory bag and attach them to the rear
casing.
4. During hanging of the product, do not pinch the screen with your hand to avoid
damaging the screen.
Instructions for attaching to the specific wall mount will be included with the mount.
Notes: To prevent the monitor on the mount from failing, please install it firmly and protect it
fully. Do not place or hang any object on the mount. Ensure the height of the mount is less
than 2 meters.
VESA screws
Mount (not supplied)

8
Power Cable
Connect the included power cable to the monitor power port and then connect the other
end to a power outlet.
Audio Out
Connect an audio output device (speakers, headphone etc.) to the 3.5mm audio port on the
monitor.
Headphone/speakers
(not included)
Power cable
CONNECTIVITY

9
HDMI
Connect an HDMI cable from the computer's display output to the monitor's display input.
DisplayPort
Use the supplied DP cable to connect the computer's display output to the monitor's
display input.
HDMI cable
(not included)

10
3.
4. Press (E) button to exit the menu screen.
Press up and down ( / ) buttons to browse the functions.
With the desired function highlighted, press (M) button to enter the sub-menu.
Press up and down ( / ) buttons to browse sub-menus, then press (M) button to
confirm the desired function.
Press up and down ( / ) buttons to highlight an option, then press (M) button to
confirm the settings and exit the current menu.
2. Press (M) to enter the OSD screen.
The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and
appears on the screen aer turning on the monitor and pressing the (M) button.
When using the monitor for the first time, it will configure optimal settings automatically.
1.
2.
3.
Connect the monitor to your input device via HDMI or DP.
Connect the power cable to your monitor and then connect the other end directly to
a power socket.
Use the power button to turn the monitor on.
1. Press one of the buttons ( , , , , ) to activate the browser screen.
On-Screen Display (OSD)
OPERATION
DP
Resolution：1920x1080@60Hz
I
B
C
P
D
A
M
O
O
DP
HDMI
HDMI
HDMI 3
Window2:
InputSource：
Resolution：
DP
Resolution: 3840x2160@60Hz
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
DP
HDMI1(2.0)
HDMI2(1.4)
HDMI3(1.4)
Window2:
InputSource:
Resolution:
Window1:
InputSource: DP
Resolution: 3840x2160@60Hz

11
Main Menu Sub Menu Option
List of Functions
Input Source
Brightness/
Contrast
Color Setting
Picture Quality
Setting
Display
Audio
Multi-Window
0-100
0-100
0-100
0-100
Auto Source/DP/HDMI1/HDMI2/HDMI3
O/PIP Mode/PBP 2Win
DP/HDMI1/HDMI2/HDMI3
Small/Medium/Large
TopRight/TopLe/BottomRight/BottomLe
O/High/Middle/Low
0-100
1.8/2.0/2.2/2.4/2.6
DP
HDMI1(2.0)
HDMI2(1.4)
HDMI3(1.4)
Blacklevel
Brightness
Contrast
DCR
Gamma
Picture Mode
Color Temperature
Standard/Photo/Movie/Game/FPS/RTS
Warm/Cool/USER
0-100
0-100
0-100
O/High/Middle/Low
On/O
On/O
On/O
Wide Screen/4:3/1:1/Auto
Normal/O/Flicker
Low Blue Light
Hue
Saturation
Sharpness
Response Time
Noise Resolution
Dynamic Luminous
Control
Aspect Ratio
LedMode
Mute
Volume
Audio Source
Multi-Window
Sub Win2 Input
PIP Size
PIP Position
Swap
O/High/Middle/LowSuper Resolution

12
Main Menu Sub Menu Option
OSD
Other
DP1.1/DP1.2
0-100
0-100
0-100
5-100
Normal/90/180/270
Language
OSD H-Position
OSD V-Position
OSD Transparency
OSD Time Out
OSD Rotation
DP Version
Reset
English/简体中文/한국어/РУССКИЙ/Español/
日本語/Français
None
On/OAdaptive-Sync
On/O/Auto DetectHDR

Press any of the buttons ( , , , , ) to activate the navigation window.
1.
2. Press button to switch GamePlus modes. According to the needs of your game,
choose the corresponding game icon. These game icons are primarily designed to
optimize your aim during shooting games, though they can be used for other
scenarios.
3. Press button to switch between multiple Picture modes, among which the
standard mode is suitable for most activities.
4.
Press Eto switch color gamut mode between “Limited” and “Full” when optimal
configuration is used.
13
GAMEPLUS & RGB RANGE

14
SPECIFICATIONS
Temperature: 0°C~ 40°C (32°F ~ 104°F)
Humidity: 10%~90% RH (non-condensing)
Temperature: -20°~ 60° (-4°F ~ 140°F)
Humidity: 5%~95% RH (non-condensing)
The standard voltage and power supply may vary with countries,
please refer to the label at the back of the product.
Product
Dimentions
Tilting Angle
Height Range
Rotation Angle
Vertical Angle
Environmental
Conditions
Action
Storage
32 inch
178°(H) / 178°(V)
0.18159(H) x 0.18159(V)
3000:1
16.7M
60Hz
16:9
3840×2160
Without base: 712.6 x 113.3 x 422.8mm / approx. 6.02kg
With base: 712.6 x 226.5 x505.6mm / approx. 7.07kg
N/A
Forward titling：5°±2°
Backward tilting：15°±2°
N/A
N/A
100-240V~ 50/60Hz 1.5A
Screen Size
Viewing Angle
Pixel Pitch
Contrast Ratio
Display Color
Refresh Rate
Aspect Ratio
Power Input
Resolution

15
NOTES

16

17

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
