Kohler ALEUTIAN K-24203T User manual

-1-
ALEUTIAN
INSTALLATION INSTRUCTIONS
BATHROOM CABINET
K-24203T
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Turn off the water supply.
The plumbing installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any
particular regulations and practices, specified by the local
water company or water undertakers. The installation
should be carried out by a plumber.
Before installation carefully inspect the new fixture for any
signs of damage.
This product complies with GB 24977-2010.
please leave instructions for the
consumer.
ALEUTIAN bathroom cabinet adopts E1 grade wood-
based panel of high quality, and with further processing,
its harmful emissions will be less than 1.5mg/L.
·
·
·
·
·
·
·
·
-
E1
1.5mg/L
GB 24977-2010
ORDERING INFORMATION
This installation covers the following products in the
ALEUTIAN range:
ALEUTIAN Bathroom Cabinet 1200mm.............K-24203T 1200mm .......................................K-24203T
SAFETY WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended
guidelines are given in the section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
MAINTENANCE
1.
2.
CHANGSHU KOHLER LTD., SOUTHEAST ECONOMIC DEVELOPMENT ZONE,
CHANGSHU, JIANGSU PROVINCE, CHINA POST CODE 215500
215500
©
©
Copyright Kohler China Investment Co., Ltd. 2018
2018
1374323-T01-A

ROUGHING-IN
-2-
UNIT : mm
Fig.2
2
INSTALLATION
A. Install Washbasin Cabinet
Install the services.
Hot (H) and Cold (C) inlets must be
connected to the correct inlet pipes.
Install the drain in accordance with the
manufacturer's instructions.
We suggest using P-trap drain. Connect P-
trap pipe with washbasin drain.
Make sure a watertight seal
exisits on all washbasin drain
connections.
Provide access to the
plumbing connections for future
plumbing maintenance.
The hot and cold water supplies must be
installed with isolating valves.
Caution!
Caution!
A.
(H) (C)
P
Fig.1
1
Kohler reserves the right to change marked dimensions without prior notice.
Reference Value
575
1176
505
1374323-T01-A

Fig.3
3
UNIT : mm
Wall Bracket
All installation dimensions are for reference only.
-3-
1. 3
1. Mark the position of hanged bracket according to
dimensions as illustrated, and loosen the suspension hook
of washbasin cabinet.
Avoid the cables and pipes inner set when
drilling in the wall.
Different types of bolts are required for different
decoration boards. Please apply suitable bolts and plugs.
Caution!
Note:
2.
3.
4. 4
2. Drill holes for fixing the bracket. Using a level, ensure that
the hanged bracket is level.
3. Use suitable plugs and bolts, and fix the hanged bracket on
the wall.
4. Hang the washbasin cabinet on the wall, and position the
suspension on the hanged bracket. See Fig.4.
Fig.4
4
2036041636020
538
175 1176
1374323-T01-A

-4-
11.
8
11. Apply a washer to the screw before tighten it. Make sure
the washbasin cabinet has been fixed firmly on the wall.
See Fig.8.
5.
5
5. Set the washbasin cabinet onto the wall bracket. Be sure
the cabinet adjusted level and the back board of cabinet
appressed to the wall by adjusting the screws of wall clips.
See Fig.5.
6. Mark the wall through two holes at the corresponding
positions as illustrated in Fig 6.
7. Dismount the washbasin cabinet and put aside. Drill holes
at the marked position.
8. Insert the plugs into the wall.
9. Take out the middle leg and screw from the hardware pack.
Align with the hole on the bottom board and fix the middle
leg, as shown in Fig.7.
Caution!
Note:
Avoid the cables and pipes inner set when
drilling in the wall.
Different types of bolts are required for different
decoration boards. Please apply suitable bolts and plugs.
6. 6
8.
9.
7
7.
Fig.5
5
Fig.6
6
MAX1
24
3
1
10.
5
10. Set the washbasin cabinet onto the brackets. Be sure the
cabinet adjusted level and the back board of cabinet
appressed to the wall by adjusting the screws of wall clips.
See Fig.5.
8
8
Fig.8
8
Fig.7
7
1374323-T01-A

-5-
Fig.9
9
Fig.10
10
12.
13. 9
12. Place the hinge cover and plastic cover.
13. Adjust the hinge of door in 3 direction to make sure the
door level.
C.
1. (P )
/U
C. Connect Drainage
1. Inwall drainage (P-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position
according to the suppliers instructions. You can put the
pipe into the U Notch.
B.
B. Install the Synthetic Top
Note: Please refer to the installation instructions of synthetic
top for its installation. To protect the cabinet from
dampness, please apply silicone sealant where the
synthetic top and the cabinet connect.
Faucet
Supply Lines
Shut-off Valve
Drain Assembly
1374323-T01-A

-6-
1.
2.
3.
4.
5.
6.
7.
USER MAINTENANCEUSER MAINTENANCE
WARNING! Risk of product damage.
1.
2.
3.
4.
5.
6. Please do not sit, lean or step on the basin cabinet.
7. If any fixtures caused by abnormal reasons, Kohler China
can supply paid replacement for service parts caused by
abnormal reasons as shown in the Service Parts Page in
the limited duration of warranty.
Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
Kohler bathroom cabinet are dealt with strict procedures
for damp-proof, whose good damp-proof function ensures
good performance even in bathroom of huge humidity. Yet
do not splash and pour water directly on the bathroom
cabinet. Make sure that the bathroom is not over damp
and wipe any splashes from surfaces immediately.
Maintenance of door board: Clean and wipe door board
regularly, and wipe the condensation vapor with dry and
soft cloth.
Ensure that electrical connections for appliances such as
head lamp is insulated wipe mirror surface with chamois
regularly to guarantee the persistent excellent performance.
2. S
2. Floor drainage (S-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position
according to the suppliers instructions.
Fig.11
11
Faucet
Supply Lines
Shut-off Valve
Drain Assembly
Ripple Pipe
1374323-T01-A
