Kohler Fluence K-702221-6L User manual

Features
•1/4" (6 mm) thick Crystal Clear tempered glass.
•Frameless design emphasizes glass and creates a sleek,
minimalist look.
•Smooth, quiet operation.
•Gently curved inside and outside towel bars complete the look
of this door.
•CleanCoat®nanotechnology provides a smooth, nonstick
surface to help prevent buildup of water stains, bacteria and
mildew on your glass, to make it easy to clean and keep it
looking like new.
Material
•Tempered glass ensures maximum safety and durability. Codes/Standards
•Anodized aluminum hardware prevents rusting or corrosion. ANSI Z97.1
Installation CPSC 16CFR 1201
•Fits opening widths 49" - 52" (1245 mm –1321 mm). KOHLER®One-Year Limited Warranty
•3/8" (10 mm) out-of-plumb adjustability per side allows for
simpler installation. See website for detailed warranty information.
•Door can be installed to open to the left or right to suit your
bathroom layout.
Available Colors/Finishes
•For residential use only.
Color tiles intended for reference only.
•Not for use in hospitality.
Recommended Products/Accessories
K-23723 Faucet cleaner
DescriptionCodeColor
Bright Polished SilverSHP
Included Components
Additional Components:
Hardware kit
Available Glass Options
DescriptionCode
Crystal ClearL
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-22-2020 11:57 - US/CA
Fluence®
Frameless shower door
K-702221-6L

1-1/2"
(38 mm)
3"
(76 mm)
3-1/8"
(79 mm)
1-5/8"
(41 mm)
1-15/16"
(49 mm)
7-1/4"
(184 mm)
49" (1245 mm) Min
52" (1321 mm) Max
*71-1/8"
(1807 mm)
*21-1/8" (537 mm) Min
*24-1/8" (613 mm) Max *Walk-through
75-11/16"
(1922 mm)
2-1/8"
(54 mm)
Notes
Technical Information Install this product according to the installation
instructions.
All product dimensions are nominal.
For shower base installationInstallation type: The vertical opening should be a minimum of
77-3/4" (1975 mm) to allow for installation
clearance.
49" (1245 mm)Opening Width - Min:
52" (1321 mm)Opening Width - Max:
21-1/8" (537 mm)Walk-through - Min:
24-1/8" (613 mm)Walk-through - Max:
1/4" (6 mm)Glass thickness:
CleanCoat®
Glass coating:
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-22-2020 11:57 - US/CA
Fluence®
Frameless shower door
K-702221-6L
