Kompernass KH123 User manual

KOMPERNASS GMBH · BURGSTRASSE 21
· D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH123-11/09-V3
ELECTRIC TOOTHBRUSH
KH123
6
ELECTRIC TOOTHBRUSH
Operating instructions
CV_KH123_45634_6_dentalux.indd 1-3CV_KH123_45634_6_dentalux.indd 1-3 12.01.2010 16:57:59 Uhr12.01.2010 16:57:59 Uhr

KH123
0
2
3
4
5
6
7
8
9
1
CV_KH123_45634_6_dentalux.indd 4-6CV_KH123_45634_6_dentalux.indd 4-6 12.01.2010 16:58:00 Uhr12.01.2010 16:58:00 Uhr

- 1 -
Index Page
Intended use 2
Safety Notices 2
Items supplied 3
Technical data 3
Appliance description 4
Set-up/Wall holder 4
First use 5
Fitting / removing brush heads 6
Operation 6
Brushing one’s teeth 6
Cleaning and care 9
Travelling case 9
Disposal 10
Warranty and Service 11
Importer 12
Read these operating instructions carefully before using the
appliance for the first time and preserve this booklet for later
reference. Pass this booklet on to whoever might acquire the
appliance at a future date.
IB_KH123_45634_LB6.indd Abs1:1IB_KH123_45634_LB6.indd Abs1:1 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 2 -
Intended use
This appliance is intended for personal dental care in domestic
situations. The appliance is not intended for use in commercial,
industrial or medical environments. It is not suitable for animal
care.
Safety Notices
To avoid damage, do not permit liquids of any kind to•
enter the appliance and do not submerse it in water.
Avoid also a possible penetration by foreign objects.•
In the event of malfunction or apparent damage, make•
contact with our Customer Services.
Ensure that the power cable never becomes wet or damp•
during operation. Place the power cable such that it cannot
become trapped or damaged in any way. Risk of electric
shock!
The power cable on this appliance cannot be replaced. In•
the event of it being damaged the whole appliance must
be disposed of.
NEVER touch the charging station if it has fallen into water.•
First of all remove the plug from the wall socket! Risk of
electric shock!
This appliance is not intended for use by individuals (in-•
cluding children) with restricted physical, physiological or
intellectual abilities or deficiences in experience and/or
knowledge unless they are supervised by a person respon-
sible for their safety or receive from this person instruction
in how the appliance is to be used.
Children should be supervised to ensure that they do not•
play with the appliance.
The electric toothbrush may only be recharged with the•
supplied charging station. Otherwise, the appliance could
be irreparably damaged.
Do not submerse the hand element or the charging station•
in water or other liquids. This would cause irreparable
damage to the appliance.
IB_KH123_45634_LB6.indd Abs1:2IB_KH123_45634_LB6.indd Abs1:2 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 3 -
Items supplied
Before using the appliance for the first time, check to ensure
that the following items are available and undamaged.
Hand element
8 Brush heads
Charging station
Travelling case
2 Screws
2 Plugs
Order card
Operating instructions
Remove all packaging materials and foils from the appliance.
Technical data
Power supply: 100 - 240 V ˜50 - 60 Hz
Power consumption : 2 W
Protection rating
(Charging station): IP X7
Protection class: II /
Charging time: approx. 14 - 16 hours
(first charging)
Protection type
(Hand element): IP X4
IB_KH123_45634_LB6.indd Abs1:3IB_KH123_45634_LB6.indd Abs1:3 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 4 -
Appliance description
1Brush head
2Brush holder
3Charging station
4Wall holder
5Charge indicator
6Pulse LED (yellow)
7Soft LED (green)
8“Clean” LED (orange)
9On/Off switch
0Travelling case
Set-up/Wall holder
The charging station 3may only be operated free-standing
in dry rooms.
In moist rooms, especially in the vicinity of water (bath), the
charging station 3must be firmly fixed to the wall, to protect
it from falling into water.
•Pull the wall holder 4downwards from underneath the
charging station 3.
•Using the screw openings of the wall holder 4, mark the
spacing for the boreholes on the wall. Check to ensure that
there is a mains power socket in close vicinity.
• Before boring the holes, check to ensure that there are no
electrical or water conduits behind the markings.
•Affix the wall holder 4using the plugs and screws.
• When you have attached the wall holder 4, guide the
power cable through the right or left recess in the wall
holder 4(see magnification on the fold-out side).
Using the guide rails, slide the charging station 3onto the
wall holder 4.
• Ensure that the power cable is not trapped and that it lies
properly in the recesses.
IB_KH123_45634_LB6.indd Abs1:4IB_KH123_45634_LB6.indd Abs1:4 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 5 -
First use
Before taking the appliance into use check to ensure that it is
in a fault-free condition. If it is not, it may not be used.
• Insert the power plug into a wall socket.
•Before the first use, clean the new brush heads 1with
clear water.
•Place a replacement brush head on the brush holder 2,
open the cover of the charging station 3and slide the
brush holder 2in.
•Place the hand element on the charging station 3so that
it slides onto the spike in the base.
•Allow the hand element to charge up for approx. 14 -
16 hours before using it for the first time. The charging
light 5on the front of the hand appliance glows red
during the charging process.
•Use the hand element repeatedly, and without charging
the battery, until the performance is noticeably weaker or
the toothbrush stops working and the charge indicator 5
blinks red. First then recharge the battery for 14 - 16 hours.
When the appliance is fully charged, the charge indicator 5
glows green.
• Charge and discharge the toothbrush completely 3 times.
The battery will have then reached its full capacity.
•You can now leave the hand element in the charging
station 3after every use, so as to always have full power
available.
For care of the batteries, we recommend the following:
When the hand element is fully charged, remove the plug
of the charging station 3from the mains power socket. First
reinsert the plug into the mains power socket and recharge
the hand element when the movement of the toothbrush is
noticeably weaker or the charge indicator 5blinks.
IB_KH123_45634_LB6.indd Abs1:5IB_KH123_45634_LB6.indd Abs1:5 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 6 -
Fitting / removing brush heads
To remove the brush head 1, turn it clockwise and then pull
it upwards.
To fit the brush head 1place it slightly offset on the hand
element and then turn it anti-clockwise.
The brush head 1must engage on being put back on. To
avoid damage to the appliance, use only original brush heads.
(For replacement brush heads, see the order card)
Operation
This toothbrush has 3 different performing levels:
- “Clean”: normal speed level, orange LED 8
For cleaning the teeth.
- “Soft”: slow speed level, green LED 7
For cleaning the teeth of people with sensitive gums.
- “Pulse”: variable speed levels, yellow LED 6
For massaging the gums.
•Press the on/off switch 9once to switch the level “Clean”
on. The “Clean” LED 8glows.
•Press once more to switch to the level “Soft”. The “Soft”
LED 7glows.
•Press it a third time to switch to the level “Pulse”.
The “Pulse” LED 6glows.
•To switch the toothbrush off, press once more on the on/
off switch 9.
Brushing one’s teeth
Warning
Due to the unaccustomed operation some gum bleeding may
initially occur, this is normal. Should this continue for more
than two weeks, consult your dentist.
IB_KH123_45634_LB6.indd Abs1:6IB_KH123_45634_LB6.indd Abs1:6 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 7 -
•Place the brush head 1on the hand element.
• Moisten the brush under flowing water.
• Apply some toothpaste to the moistened brush.
Notice
Wait until the appliance is in the mouth before switching it on,
to avoid spray.
•With the on/off switch 9select the desired operating
level.
Notice
This toothbrush has a 30 second interval timer, so that all four
jaw quandrants can be cleaned equally.
• Divide your jaw into four sections (quadrants): upper left,
upper right, lower left and lower right.
•Begin in one quadrant:
Place the brush head 1on your gums and move the brush
upwards/downwards from the gums to over the crown of
the tooth.
Proceed in this manner on both the inside and the outside
surfaces of the tooth. Start again from the gums for each
individual tooth.
IB_KH123_45634_LB6.indd Abs1:7IB_KH123_45634_LB6.indd Abs1:7 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 8 -
Do not forget the back surfaces of the rear molars.
To clean the chewing surfaces, direct the rotating brush
head with light pressure over the chewing surfaces.
• After 30 seconds the toothbrush interrupts its operation
briefly twice, to signalise to you that you should start to
clean the next quadrant. Clean all jaw quadrants with the
same technique.
• After two minutes the toothbrush stops its operation briefly
4 times. This informs you that you have complied with the
dental recommendation of two minutes cleaning.
•Press the on/off switch 9repeatedly until the toothbrush
stops.
• First take the toothbrush out of your mouth when it has
stopped.
• After use, clean the brush head thoroughly under running
water.
Notice
Regularly massage your gums. This promotes blood circulation
and thus the health preservation of the gums. Set the level at
“Pulse” and guide the moistened brush over your gums with a
light pressure.
IB_KH123_45634_LB6.indd Abs1:8IB_KH123_45634_LB6.indd Abs1:8 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 9 -
Cleaning and care
Warning:
First remove the plug from the mains power socket before
cleaning the charging station 3. There is a risk of receiving
an electric shock!
•NEVER open the housing of the charging station 3or the
toothbrush! They cannot be resealed in a water-tight manner.
•Clean the charging station 3only with a soft, lightly
moistened cloth. Do not use detergents or solvents. They
can damage the plastic surfaces.
•After use, clean the brush heads 1thoroughly under run-
ning water. We recommend cleaning the brush heads 1in
a standard commercial cleaning fluid for prosthetics every
2 - 4 weeks. After about 3 months, at the latest however
when the bristles bend outwards, you should fit a new
brush head 1.
•The brush holder 2can be cleaned without problem with
water and some liquid soap. For this, simply lift the brush
holder 2upwards.
Travelling case
Should you wish to take the toothbrush with you on a tour, you
can pack both the hand element and two brush heads in the
travelling case 0.
IB_KH123_45634_LB6.indd Abs1:9IB_KH123_45634_LB6.indd Abs1:9 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 10 -
Disposal
Do not dispose of the appliance in your normal
domestic waste. This product is subject to the
provisions of European Directive 2002/96/EC.
Dispose of the appliance through a registered specialist disposal
firm or through your community waste disposal department.
Observe the currently applicable regulations.
In case of doubt, contact your local waste disposal facility.
Disposal of batteries/accumulators
Used batteries/rechargeable batteries may not be disposed
of in household waste. Every consumer is statutorily obliged
to dispose of batteries at a collection site of his community/
city district or at a retail store.
The purpose of this obligation is to ensure that batteries are dis-
posed of in a non-polluting manner. Only dispose of batteries/
-cells when they are fully discharged.
Dispose of the packaging materials in an environ-
mentally responsible manner.
IB_KH123_45634_LB6.indd Abs1:10IB_KH123_45634_LB6.indd Abs1:10 14.01.2010 9:16:21 Uhr14.01.2010 9:16:21 Uhr

- 11 -
Warranty and Service
The warranty for this appliance is for 3 years from the date
of purchase. The appliance has been manufactured with care
and meticulously examined before delivery. Please retain your
receipt as proof of purchase. In the event of a warranty claim,
please make contact by telephone with our Service Depart-
ment. Only in this way can a post-free despatch for your
goods be assured.
The warranty covers only claims for material and maufactur-
ing defects, but not for transport damage, for wearing parts or
for damage to fragile components, e.g. buttons or batteries.
This product is for private use only and is not intended for
commercial use. The warranty is void in the case of abusive
and improper handling, use of force and internal tampering
not carried out by our authorized service branch. Your statu-
tory rights are not restricted in any way by this warranty.
The warranty period will not be extended by repairs made
under warranty. This applies also to replaced and repaired
parts. Any damage and defects extant on purchase must be
reported immediately after unpacking the appliance, at the
latest, two days after the purchase date. Repairs made after
the expiration of the warranty period are subject to payment.
DES UK LTD
Tel.: [phone] (£ 0.10 / minute)
e-mail: [e-mail]
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: [e-mail]
IB_KH123_45634_LB6.indd Abs1:11IB_KH123_45634_LB6.indd Abs1:11 14.01.2010 9:16:22 Uhr14.01.2010 9:16:22 Uhr

- 12 -
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_KH123_45634_LB6.indd Abs1:12IB_KH123_45634_LB6.indd Abs1:12 14.01.2010 9:16:22 Uhr14.01.2010 9:16:22 Uhr
