Introduction
The magicolor®5440 DL is one fast color laser printer, whipping out
crisp, exciting prints at an amazing 27 ppm in both color and black &
white. This network-ready speed demon is so versatile that it can sup-
port almost any application for users throughout an entire office. And,
it features an optional camera-direct photo printing card, allowing the
customer to print pictures directly from any PictBridge-compliant digital
camera. The magicolor 5440 DL is a high-speed, whole-office solution
that will help the user’s performance soar to the extreme.
This Sales and Technical Guide is intended for use by KONICA
MINOLTA sales personnel and reseller partners. It includes complete
information about the magicolor 5440 DL and provides useful data that
can help sales personnel explain the features of the printer to cus-
tomers. For the most complete and up-to-date information on the
printer, be sure to check the password-protected partner web site at:
http://printer.konicaminolta.com/reseller

2
Specs at a Glance
An overview of the magicolor 5440 DL printer features.
Print Method Electrophotographic tandem color laser
Processor ARM9, 200 MHz
Print Speed Up to 27 ppm color (letter)
Up to 27 ppm b&w (letter)
Resolution 600 x 600 dpi, 1200 x 600 dpi (default),
2400 x 600 dpi
Duty Cycle Up to 60,000 prints/month maximum
Memory 64 MB on controller board
Standard Interfaces Ethernet®(10/100BaseTX), Hi-Speed USB
2.0; USB 1.1 Host Port (for Camera Direct
Photo Print Option)
Paper Sizes Up to 8.5" x 14"
Standard Paper Handling 500-sheet cassette, 100-sheet multipur-
pose tray, 250-sheet face-down output
tray, manual duplexing
Optional Paper Handling 500-sheet input feeder (add up to two),
Automatic duplexing
Print Media Types Plain paper, thick stock, glossy stock,
OHP transparencies, laser-quality labels,
envelopes
Software Utilities Printer drivers for Windows®Server 2003,
XP, 2000, NT4, Me, 98SE; Macintosh®OS X
(v10.2+); and Linux®Red Hat 8.0+, SuSE
8.1+; PageScope™ Web Connection; Status
Display (Windows only); compatible with
PageScope NetCare and HP Web
JetAdmin®; ICC device profiles
Color Control Enhanced Automatic Image Density
Control (eAIDC), Automatic ICC-based
color matching
Compatibility Microsoft®Windows Server 2003, XP,
2000, NT4, Me, 98SE; Macintosh OS X
(v10.2+); and Linux Red Hat 8.0+, SuSE
8.1+
Warranty One year exchange

3
Key Selling
Features
Affordability
Priced 27% less than other products in its class, the magicolor also
boasts a low overall cost per page in both color and black and white.
These affordability factors mean your customer can eliminate their
monochrome printers and let the magicolor 5440 DL be their office-wide
multi-tasking workhorse.
Productivity
The magicolor 5440 DL is designed for extreme productivity. It prints in
both color and black at 27 ppm—over 20% faster than other products in
its class. It features high-yield toner cartridges, a paper capacity of up to
1,600 pages, and a 60,000 print monthly duty cycle, allowing your cus-
tomer to easily print large volumes of material. And, an optional
automatic duplexer can be added for two-sided documents. With its
automatic media size detection, auto tray selection, automatic color cali-
bration and paper-jam recovery, the magicolor 5440 DL is practically
effortless to use and worry-free.
Versatility
Able to print on plain paper, labels, transparancies, glossy, and thick
paper, the magicolor 5440 DL is a true multi-media artist. It supports up
to 110 lb. index paper, in sizes from 3.6" x 5.8" to 8.5" x 14". And, its
camera-direct photo printing option allows customers to print directly
from their digital cameras.
The magicolor 5440DL’s cost per page is only 1.6¢ for
black & white, based on 5% coverage, and 9.3¢ for color,
based on 20% coverage.
1.6¢ 9.3¢
No
PC Required!

4
Simplicity
Like all KONICA MINOLTA printing products, the magicolor 5440 DL is
designed for ease of use. From set up to every day operation, this
printer’s equipped to keep it simple.
Pre-installed supplies: When the printer arrives, owners will find
the supplies have been pre-installed at the factory to save valu-
able time during set up.
Front-access to supplies: When supplies do run low, replace-
ment is easy. Toner cartridges are accessible from the front of the
printer, and the inside of the front panel features toner replace-
ment guidelines.
Auto-install software: The Software Utilities CD-ROM features
an auto-install interface that guides users, step-by-step, through
the installation of drivers and printer management utilities. It even
automatically detects the printer on the network.
Printer management with desktop convenience: Customers
doesn’t have to leave their desk to check the status of a print job
or to see if there’s enough supplies to handle a large print run.
The magicolor 5440 is equipped with PageScope Web
Connection to allow the user to view this information by
accessing the web browser and the printer’s IP address to
access real-time printer data.
Another desktop management tool included with the magicolor
5440 is the Status Monitor. It resides on your screen for easy
accessibility, and shows detailed information about the printer
including current status, current consumable levels, and explana-
tions of any errors that may have occurred. It provides this
information in a helpful, graphical format.
Front-access to supplies makes for easy replacement.
Auto-install software guides the user through set-up.
PageScope Web Connection and the Status Monitor provide
easy methods for checking print job and supply status.

5
Target Markets
The latest model in KONICA MINOLTA’s line of workgroup color laser
printers, the magicolor 5440 DL is made for small-to-medium sized
businesses that require high performance at an affordable price. It is a
perfect fit for:
Real estate offices
Accounting offices
Schools
Law offices
Doctors & hospitals
Development offices (non-profits)
Automotive dealerships
Convention centers
Hotels
Marketing communication departments
Sales departments
Human resources departments
Safety & training departments

Competitive
Overview
magicolor HP®4650n CLP Oki®7350n
5440 DL
Price* $1,299 $2,099 $1,984
Speed (color) 27 ppm 22 24
Speed (mono) 27 ppm 22 26
Resolution (dpi) 2400 x 600 600 x 600 1200 x 600
ImageRet 3600
Standard interfaces USB 2.0 USB 1.1 USB 2.0
10/100BaseTX Ethernet 10/100BaseTX Ethernet 10/100BaseTX Ethernet
Standard paper input 600 600 630
Maximum paper input 1,600 1,600 1,690
Standard paper output 250 250 Unknown
Standard paper size (max) 8.5" x 14" 8.5" x 14" 8.5" x 47.24"
Standard memory 64 MB 160 MB 192 MB
Camera direct photo print Yes (optional) No No
Consumables (# items) 6510
Consumables installed? Yes No No
Duty cycle (prints/month) 60,000 85,000 100,000
Footprint (sq. in.) 366.95 378 412.36
Weight (lbs.) 81.4 81 105
Automatic Duplex Optional Manual Only Optional
* mfgr. Web pricing as of 05/17/05
6

7
Competitive
Overview
magicolor Xerox®6250n Dell®5100cn
5440 DL
Price* $1,299 $2,099 $999
Speed (color) 27 ppm 26 25
Speed (mono) 27 ppm 26 35
Resolution (dpi) 2400 x 600 2400 2400 image quality
Standard interfaces USB 2.0 USB 2.0 USB 2.0
10/100BaseTX Ethernet 10/100BaseTX Ethernet 10/100BaseTX Ethernet
Standard paper input 600 600 650
Maximum paper input 1,600 2,100 2,150
Standard paper output 250 500 250
Standard paper size (max) 8.5" x 14" 8.5" x 35.45" 8.5" x 14"
Standard memory 64 MB 256 MB 128 MB
Camera direct photo print Yes No No
Consumables (# items) 676
Consumables installed? Yes (Optional) No No
Duty cycle (prints/month) 60,000 100,000 90,000
Footprint (sq. in.) 366.95 401.36 305.76
Weight (lbs.) 81.4 80 84
Automatic Duplex Optional Optional Standard
* mfgr. Web pricing as of 01/05/05

8
Engine
The magicolor 5440 DL features KONICA MINOLTA’s single-
pass imaging technology.
Type
The magicolor 5440 DL features KONICA MINOLTA’s single-pass
engine technology. The tandem design delivers fast, accurate and reli-
able color.
Speed
Page Size Color Monochrome
Simplex Duplex Simplex Duplex
Letter 27 ppm 15.5 ppm 27 ppm 15.5 ppm
Legal 22 ppm 11.3 ppm 22 ppm 11.3 ppm
A4 25.6 ppm 12.3 ppm 25.6 ppm 12.3 ppm
A5 27 ppm N/A 27 ppm N/A
B5 27 ppm 9 ppm 27 ppm 9 ppm
Transparency* 3 ppm N/A 9 ppm N/A
Thick Stock* 13.5 ppm N/A** 13.5 ppm N/A**
*Letter-size page
**Auto duplexing not available on thick stock. Use manual duplex to print on both sides of
thick stock.
First Page Out Time*
Simplex Color Monochrome
Letter 14.1 seconds 14.1 seconds
Legal 14.6 seconds 14.6 seconds
A4 14.2 seconds 14.2 seconds
Duplex Color Monochrome
Letter 22.3 seconds 22.3 seconds
Legal 23 seconds 23 seconds
A4 22.3 seconds 22.3 seconds
*From an idle, ready state.

9
Weights & Dimensions
Packaging
Width Depth Height
24.49" 21.42" 26.37"
622 mm 544 mm 670 mm
Printer
Width Depth Height
17.9" 20.5" 17.3"
455 mm 520 mm 440 mm
Weight
Shipping 94.6 lbs (43 kg)
Printer w/consumables 81.4 lbs (37 kg)
Printer w/o consumables 68.2 lbs (31 kg)
Duty Cycle
60,000 prints (letter size) per months maximum
Operating Environment Conditions
Power supply 120VAC ± 10%, 50/60 Hz ± 3%
Power consumption Maximum: 1250W maximum
Average: 800W
Standby: 170W
Energy Saver: 42.9W
Temperature Operating: 50° - 95° F (10° - 35° C)
Non-Operating: 32° - 95° F (0° - 35° C)
Humidity Operating: 15 – 85% RH
Non-Operating: 10 - 85% RH
Noise Operating: <54 dB(A)
Standby: <39 dB(A)
17.9"
17.3"
20.5"

10
Controller
The magicolor 5440 DL uses the power of the Windows, Mac, or
Linux operating system to deliver great performance for less cost.
Type
The magicolor 5440 DL uses an easy-to-access controller with 64 MB
SDRAM on board.
Processor
The magicolor 5440 DL supports the Graphical Display Interface (GDI)
for Windows, host-based PostScript®rasterizer for Macintosh, and
PageScope Raster Language for Linux. As such, the printer utilizes the
power of the host computer’s CPU for processing documents prior to
printing. The printer’s controller features an ARM9, 200 MHz processor
for imaging the document.
Memory
The magicolor 5440 DL includes 64 MB of RAM on the controller. This
memory is sufficient for printing all supported page sizes (simplex and
duplex) at all resolutions. The printer also has one available DIMM (Dual
In-Line Memory) socket for increasing system RAM.
Standard RAM: 64 MB on board
Maximum RAM: 576 MB
The magicolor 5440 DL has one open DIMM slot that accepts up to 512
MB RAM available exclusively from KONICA MINOLTA. Memory is
available in 128 MB, 256 MB, or 512 MB increments. This additional
memory can improve the printer’s performance, especially when used in
a network environment with the optional duplexer or camera-direct
photo printing feature installed.

11
Resolution
2400 x 600 dpi
1200 x 600 dpi (default)
600 x 600 dpi
As shipped, the magicolor 5440 DL’s print resolution is 1200 x 600 dpi.
This quality setting is perfect for printing general business documents
that include text and graphics. For printing document drafts and dispos-
able documentation, select the printer’s 600 x 600 dpi resolution.
For best print quality, choose the printer’s 2400 x 600 dpi resolution
through the printer driver. This resolution is perfect for printing every-
thing from photographs and clip art to text and graphics. It also provides
great detail and character in fine lines and halftones.
The magicolor 5440 DL’s print quality is further enhanced by the
printer’s unique polymer toner technology. See “Consumables and
Supplies” for more information.
With the 64 MB of RAM installed, the magicolor 5440 DL can print sim-
plex and duplex pages at all available resolutions.
Compatibility and System Requirements
Windows Server 2003/XP/2000/NT4/Me/98SE
Macintosh OS X (v10.2+)
Linux Red Hat 8.0+, SuSE 8.1+
The magicolor 5440 DL utilizes the processing capabilities contained in
the Windows, Mac OS X, and Linux operating systems to prepare docu-
ments for printing at the host computer. This method of document
production is efficient in that the data is prepared and transferred to the
printer in a compressed format. Leveraging the document printing capa-
bilities of the computer’s operating system also enables KONICA
MINOLTA to keep the cost of the 5440 DL very affordable.
Windows System Requirements
PC Hardware 400 MHz Pentium®II-class minimum;
500 MHz Pentium III-class recommended
Operating System Windows Server 2003
Windows XP
Windows 2000
Select the printer’s 2400 x 600 dpi setting for optimum
print quality.

12
Windows NT4
Windows Me
Windows 98 SE
PC Memory 128 MB
Hard Disk Space 256 MB or more
CD-ROM 1x or faster to install drivers & utilities
Macintosh System Requirements
Mac Hardware Power Mac®G3 minimum;
Power Mac G4 recommended
Operating System OS X (v10.2+)
Hard Disk Space 256 MB or more
CD-ROM 1x or faster to install drivers & utilities
Linux System Requirements
PC Hardware 400 MHz Pentium II-class minimum;
500 MHz Pentium III-class recommended
Operating System Red Hat 8.0+
SuSE 8.1+
Control Panel
To convey printer status and select configurations and options, the
magicolor 5440 DL has an easy-to-navigate control panel that features:
This multitasking keypad conveniently shows users
how much of each toner remains.
The keypad is also back lit for easy reading.

13
2 line, 16 character back-lit LCD
6 keys
2 LEDs
The LCD window serves three primary purposes. It displays a status
message indicating the current state of the printer or a printer idle
status; shows users their options when reviewing or altering settings
through the printer’s control panel menu; conveniently displays toner
supply levels.
LCD messages can be displayed in eight different languages—English,
French, German, Spanish, Italian, Czech, Japanese (Katakana), and
Brazilian Portuguese.
The six keys on the front panel enable users to review and change
printer settings.
Menu / Select: used to enter the menu system to view and
change specific menu options.
Up Arrow: used to scroll up through the entries in the menu
system and to scroll upward through available characters if in a
menu choice that is changeable character by character. Also used
to print a demo page. Simply press and hold for two seconds.
Down Arrow: used to scroll down through the entries in the
menu system. Also used to scroll downward through available
characters if in a menu choice that is changeable character by
character.
Left Arrow: scrolls left in the menu structure. Also moves left
through scrollable menu choice selections when selections are
whole words.
Right Arrow: scrolls right in the menu structure. Also moves right
through scrollable menu choice selections when selections are
whole words.
Cancel: cancels the current print job. Cancels the menu choice
or selection if in the menu system at the time.
The two LEDs provide visual indication of the following:
Error: lights amber to indicate the presence of an LCD message
generally referring to an offline condition such as paper empty,
toner empty, or paper jam.
Ready: lights green to indicate the printer is ready to accept and
process jobs. The LED will blink when the printer is receiving data.

14
Connectivity
The magicolor 5440 DL is ready to serve one user or many
printer users.
Standard Interfaces
Ethernet (10/100BaseTX)
USB 2.0
USB 1.1
For workgroup printing, the magicolor 5440 DL has an auto-sensing,
resident Ethernet (10/100BaseTX) interface. This flexible interface oper-
ates in both the traditional 10 mbps LAN and Fast Ethernet (100 mbps)
networks, and supports TCP/IP, IPP, DHCP, BOOTP, HTTP, SNMP, SLP,
and LPR protocols.
A high-speed USB 2.0 interface is included with the magicolor 5440 DL.
It features a 4pin Series B connector and runs at 480 Mbps. This “Plug
and Play” interface supports Windows Server 2003, XP, 2000, NT4, Me,
and 98SE operating systems, as well as Linux and Macintosh OS X
systems.
The magicolor 5440 DL also features a USB 1.1 host port for optional
camera direct photo printing.
Hi-Speed USB Interface
10/100BaseTX Ethernet Interface
USB 1.1 Interface

15
Paper Handling
The magicolor 5440 DL supports a variety of paper sizes and
paper handling options to meet the needs of every office.
The standard cassette holds up to 500 sheets of paper
up to letter (8.5" x 11") size. It features a convenient
paper-level indicator.
Automatic Duplexer
Printer Cabinet
500-sheet Input Feeder
Multipurpose tray
500-sheet cassette
Standard Paper Handling
500-sheet cassette
100-sheet multipurpose tray
250-sheet face-down output tray
The magicolor 5440 DL includes a 500-sheet cassette for paper and
other print media. The cassette accommodates page sizes up to 8.5" x
11" and features a gauge that indicates the amount of paper inside.
The 100-sheet multipurpose tray accomodates up to legal size paper
(8.5" x 14").
Printed pages are delivered into the printer’s 250-sheet face-down
output tray.
Optional Paper Handling
500-sheet input feeder (up to 2)
Automatic duplexer
Printer cabinet
The magicolor 5440 DL has several paper handling options. Users can
increase paper input to 1,100 or 1,600 sheets by adding one or two
500-sheet input feeders. For two-sided printing, the magicolor 5440 DL
can be equipped with an automatic duplexer. And, the optional printer
cabinet provides convenient media storage, with a caster base to allow
the user to easily move the 5440 DL.

16
Print Media
The magicolor 5440 DL supports a range of print media to handle a
variety of applications. All media types are supported through the
printer’s standard input cassette and multipurpose tray.
Recommended Media
Several media types have been tested and approved for use with the
magicolor 5440 DL. The chart below indicates specific brands of media
recommended for printing with the magicolor 5440 DL.
Plain paper
Color Georgia-Pacific Microprint Laser 1000 - 24 lb. (90gsm)
Hammermill Laser Print Radiant White
Monochrome Xerox 4024P - 20 lb.
Recycled Georgia-Pacific Geo Cycle - (75 gsm)
Thick stock
Canon NS700 - (157 gsm)
Transparency
QMedia - 50-sheet letter - (P/N: 1710464-001)
QMedia - 5-sheet letter - (P/N: 1710464-002)
3M CG3700
Envelopes
Business envelopes 90008 - 24 lb.
Supported Media Specifications Driver Setting 500-Sheet Optional Optional
Std. Cassette/ Feeder Duplex
Multipurpose Tray
Plain paper 16–24 lb (60–90 gsm) Plain Paper Supported Supported Supported
Recycled paper 16–24 lb (60–90 gsm) Recycled Paper Supported Supported Supported
Letterhead 16–24 lb (60–90 gsm Letterhead Supported Supported Supported
Thick stock 1 24-50 lb (90–150 gsm) Thick Stock 1 Supported N/A N/A
Thick stock 2 50-110 lb Index (151–210 gsm) Thick Stock 2 Supported N/A N/A
Glossy Supported Glossy Supported N/A N/A
Transparency Supported Transparency Supported N/A N/A
Labels Supported Labels Supported N/A N/A
Envelopes Supported Envelope Supported N/A N/A
