Konica Minolta Magicolor 5550 User manual

magicolor 5550/5570
User’s Guide
®
A011-9562-00A
1800825-001A

Trademarks
KONICA MINOLTA, the KONICA MINOLTA logo and PageScope are trademarks or registered
trademarks of KONICA MINOLTA HOLDINGS, INC.
magicolor is a trademark or registered trademark of KONICA MINOLTA PRINTING SOLU-
TIONS U.S.A., INC.
All other trademarks and registered trademarks are the property of their respective
owners.
Copyright Notice
Copyright © 2006 KONICA MINOLTA BUSINESS TECHNOLOGIES, INC., Marunouchi Center
Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005, Japan. All Rights Reserved. This
document may not be copied, in whole or part, nor transferred to any other media or language,
without written permission of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.
Notice
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make changes to
this guide and to the equipment described herein without notice. Considerable effort has been
made to ensure that this guide is free of inaccuracies and omissions. However, KONICA
MINOLTA BUSINESS TECHNOLOGIES, INC. makes no warranty of any kind including, but not
limited to, any implied warranties of merchantability and fitness for a particular purpose with
regard to this guide. KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no
responsibility for, or liability for, errors contained in this guide or for incidental, special, or conse-
quential damages arising out of the furnishing of this guide, or the use of this guide in operating
the equipment, or in connection with the performance of the equipment when so operated.

SOFTWARE LICENSE AGREEMENT
This package contains the following materials provided by Konica Minolta Business Technolo-
gies, Inc. (KMBT): software included as part of the printing system, the digitally-encoded
machine-readable outline data encoded in the special format and in the encrypted form (“Font
Programs”), other software which runs on a computer system for use in conjunction with the
Printing Software (“Host Software”), and related explanatory written materials (“Documenta-
tion”). The term “Software” shall be used to describe Printing Software, Font Programs and/or
Host Software and also include any upgrades, modified versions, additions, and copies of the
Software.
The Software is being licensed to you under the terms of this Agreement.
KMBT grants to you a non-exclusive sublicense to use the Software and Documentation, pro-
vided that you agree to the following:
1. You may use the Printing Software and accompanying Font Programs for imaging to the
licensed output device(s), solely for your own internal business purposes.
2. In addition to the license for Font Programs set forth in Section 1 (“Printing Software”)
above, you may use Roman Font Programs to reproduce weights, styles, and versions of
letters, numerals, characters and symbols (“Typefaces”) on the display or monitor for your
own internal business purposes.
3. You may make one backup copy of the Host Software, provided your backup copy is not
installed or used on any computer. Notwithstanding the above restrictions, you may install
the Host Software on any number of computers solely for use with one or more printing
systems running the Printing Software.
4. You may assign its rights under this Agreement to an assignee of all of Licensee’s right and
interest to such Software and Documentation (“Assignee”) provided you transfer to
Assignee all copies of such Software and Documentation Assignee agrees to be bound by
all of the terms and conditions of this Agreement.
5. You agree not to modify, adapt or translate the Software and Documentation.
6. You agree that you will not attempt to alter, disassemble, decrypt, reverse engineer or
decompile the Software.
7. Title to and ownership of the Software and Documentation and any reproductions thereof
shall remain with KMBT and its Licensor.
8. Trademarks shall be used in accordance with accepted trademark practice, including iden-
tification of the trademark owner’s name. Trademarks can only be used to identify printed
output produced by the Software. Such use of any trademark does not give you any rights
of ownership in that trademark.
9. You may not rent, lease, sublicense, lend or transfer versions or copies of the Software that
the Licensee does not use, or Software contained on any unused media, except as part of
the permanent transfer of all Software and Documentation as described above.
10. In no event will KMBT or its licensor be liable to you for any consequential, incidental INDI-
RECT, PUNITIVE or special damages, including any lost profits or lost saving, even if
KMBT has been advised of the possibility of such damages, or for any claim by any third
party. KMBT or its licensor disclaims all warranties with regard to the software, express or
implied, including, without limitation implied warranties of merchantability, fitness for a par-
ticular purpose, title and non-infringement of third party rights. Some states or jurisdictions
do not allow the exclusion or limitation of incidental, consequential or special damages, so
the above limitations may not apply to you.

11. Notice to Government End Users: The Software is a “commercial item,” as that term is
defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial
computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consis-
tent with 48 C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4, all U.S. Govern-
ment End Users acquire the Software with only those rights set forth herein.
12. You agree that you will not export the Software in any form in violation of any applicable
laws and regulations regarding export control of any countries.
About Adobe Color Profile
ADOBE SYSTEMS INCORPORATED
COLOR PROFILE LICENSE AGREEMENT
NOTICE TO USER: PLEASE READ THIS CONTRACT CAREFULLY. BY USING ALL OR ANY
PORTION OF THE SOFTWARE YOU ACCEPT ALL THE TERMS AND CONDITIONS OF
THIS SOFTWARE YOU ACCEPT ALL THE TERMS AND CONDITIONS OF THIS AGREE-
MENT. IF YOU DO NOT AGREE WITH THE TERMS OF THIS AGREEMENT, DO NOT USE
THE SOFTWARE.
1. DEFINITIONS In this Agreement, “Adobe” means Adobe Systems Incorporated, a Dela-
ware corporation, located at 345 Park Avenue, San Jose, California 95110. “Software”
means the software and related items with which this Agreement is provided.
2. LICENSE Subject to the terms of this Agreement, Adobe hereby grants you the worldwide,
non-exclusive, nontransferable, royalty-free license to use, reproduce and publicly display
the Software. Adobe also grants you the rights to distribute the Software only (a) as embed-
ded within digital image files and (b) on a standalone basis. No other distribution of the
Software is allowed; including, without limitation, distribution of the Software when incorpo-
rated into or bundled with any application software. All individual profiles must be refer-
enced by their ICC Profile description string. You may not modify the Software. Adobe is
under no obligation to provide any support under this Agreement, including upgrades or
future versions of the Software or other items. No title to the intellectual property in the Soft-
ware is transferred to you under the terms of this Agreement. You do not acquire any rights
to the Software except as expressly set forth in this Agreement.
3. DISTRIBUTION If you choose to distribute the Software, you do so with the understanding
that you agree to defend, indemnify and hold harmless Adobe against any losses, dam-
ages or costs arising from any claims, lawsuits or other legal actions arising out of such dis-
tribution, including without limitation, your failure to comply with this Section 3. If you
distribute the Software on a standalone basis, you will do so under the terms of this Agree-
ment or your own license agreement which (a) complies with the terms and conditions of
this Agreement; (b) effectively disclaims all warranties and conditions, express or implied,
on behalf of Adobe; (c) effectively excludes all liability for damages on behalf of Adobe; (d)
states that any provisions that differ from this Agreement are offered by you alone and not
Adobe and (e) states that the Software is available from you or Adobe and informs licens-
ees how to obtain it in a reasonable manner on or through a medium customarily used for
software exchange. Any distributed Software will include the Adobe copyright notices as
included in the Software provided to you by Adobe.

4. DISCLAIMER OF WARRANTY Adobe licenses the Software to you on an “AS IS” basis.
Adobe makes no representation as to the adequacy of the Software for any particular pur-
pose or to produce any particular result. Adobe shall not be liable for loss or damage aris-
ing out of this Agreement or from the distribution or use of the Software or any other
materials. ADOBE AND ITS SUPPLIERS DO NOT AND CANNOT WARRANT THE PER-
FORMANCE OR RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE, EXCEPT
FOR ANY WARRANTY, CONDITION, REPRESENTATION OR TERM TO THE EXTENT
TO WHICH THE SAME CANNOT OR MAY NOT BE EXCLUDED OR LIMITED BY LAW
APPLICABLE TO YOU IN YOUR JURISDICTION, ADOBE AND ITS SUPPLIERS MAKE
NO WARRANTIES, CONDITIONS, REPRESENTATIONS OR TERMS, EXPRESS OR
IMPLIED, WHETHER BY STATUTE, COMMON LAW, CUSTOM, USAGE OR OTHER-
WISE AS TO ANY OTHER MATTERS, INCLUDING BUT NOT LIMITED TO NON-
INFRINGEMENT OF THIRD PARTY RIGHTS, INTEGRATION, SATISFACTORY QUALITY
OR FITNESS FOR ANY PARTICULAR PURPOSE. YOU MAY HAVE ADDITIONAL
RIGHTS WHICH VARY FROM JURISDICTION TO JURISDICTION. The provisions of Sec-
tions 4, 5 and 6 shall survive the termination of this Agreement, howsoever caused, but this
shall not imply or create any continued right to use the Software after termination of this
Agreement.
5. LIMITATION OF LIABILITY IN NO EVENT WILL ADOBE OR ITS SUPPLIERS BE LIABLE
TO YOU FOR ANY DAMAGES, CLAIMS OR COSTS WHATSOEVER OR ANY CONSE-
QUENTIAL, INDIRECT, INCIDENTAL DAMAGES, OR ANY LOST PROFITS OR LOST
SAVINGS, EVEN IF AN ADOBE REPRESENTATIVE HAS BEEN ADVISED OF THE POS-
SIBILITY OF SUCH LOSS, DAMAGES, CLAIMS OR COSTS OR FOR ANY CLAIM BY
ANY THIRD PARTY. THE FOREGOING LIMITATIONS AND EXCLUSIONS APPLY TO
THE EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION. ADOBE’S
AGGREGATE LIABILITY AND THAT OF ITS SUPPLIERS UNDER OR IN CONNECTION
WITH THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT PAID FOR THE SOFT-
WARE. Nothing contained in this Agreement limits Adobe’s liability to you in the event of
death or personal injury resulting from Adobe’s negligence or for the tort of deceit (fraud).
Adobe is acting on behalf of its suppliers for the purpose of disclaiming, excluding and/or
limiting obligations, warranties and liability as provided in this Agreement, but in no other
respects and for no other purpose.
6. TRADEMARKS Adobe and the Adobe logo are the registered trademarks or trademarks of
Adobe in the United States and other countries. With the exception of referential use, you
will not use such trademarks or any other Adobe trademark or logo without separate prior
written permission granted by Adobe.
7. TERM This Agreement is effective until terminated. Adobe has the right to terminate this
Agreement immediately if you fail to comply with any term hereof. Upon any such termina-
tion, you must return to Adobe all full and partial copies of the Software in your possession
or control.
8. GOVERNMENT REGULATIONS If any part of the Software is identified as an export con-
trolled item under the United States Export Administration Act or any other export law,
restriction or regulation (the “Export Laws”), you represent and warrant that you are not a
citizen, or otherwise located within, an embargoed nation (including without limitation Iran,
Iraq, Syria, Sudan, Libya, Cuba, North Korea, and Serbia) and that you are not otherwise
prohibited under the Export Laws from receiving the Software. All rights to use the Software
are granted on condition that such rights are forfeited if you fail to comply with the terms of
this Agreement.

9. GOVERNING LAW This Agreement will be governed by and construed in accordance with
the substantive laws in force in the State of California as such laws are applied to agree-
ments entered into and to be performed entirely within California between California resi-
dents. This Agreement will not be governed by the conflict of law rules of any jurisdiction or
the United Nations Convention on Contracts for the International Sale of Goods, the appli-
cation of which is expressly excluded. All disputes arising out of, under or related to this
Agreement will be brought exclusively in the state Santa Clara County, California, USA.
10. GENERAL You may not assign your rights or obligations granted under this Agreement
without the prior written consent of Adobe. None of the provisions of this Agreement shall
be deemed to have been waived by any act or acquiescence on the part of Adobe, its
agents, or employees, but only by an instrument in writing signed by an authorized signa-
tory of Adobe. When conflicting language exists between this Agreement and any other
agreement included in the Software, the terms of such included agreement shall apply. If
either you or Adobe employs attorneys to enforce any rights arising out of or relating to this
Agreement, the prevailing party shall be entitled to recover reasonable attorneys’ fees. You
acknowledge that you have read this Agreement, understand it, and that it is the complete
and exclusive statement of your agreement with Adobe which supersedes any prior agree-
ment, oral or written, between Adobe and you with respect to the licensing to you of the
Software. No variation of the terms of this Agreement will be enforceable against Adobe
unless Adobe gives its express consent, in writing, signed by an authorized signatory of
Adobe.
ICC Profile for TOYO INK Standard Color on Coated paper
(TOYO Offset Coated 2.1)
This ICC Profile (TOYO Offset Coated 2.1) characterizes Japanese offset press on Coated
paper and is fully compatible with ICC profile format.
About “TOYO INK Standard Color on Coated paper”
This is the standard for color reproduction of sheet-fed offset press on Coated paper made by
TOYO INK MFG.CO., LTD. (“TOYO INK”).
This standard is made from printing test with using TOYO INK’s sheet-fed offset printing inks
and TOYO INK’s own printing conditions.
“TOYO INK Standard Color on Coated paper” is compatible with “JAPAN COLOR”.
Agreement
1. The reproduction of images on a printer or a monitor using this ICC Profile do not com-
pletely match the TOYO INK Standard Color on Coated paper.
2. Any and all copyrights of this ICC Profile shall remain in TOYO INK; therefore you shall not
transfer, provide, rent, distribute, disclose, or grant any rights in this ICC Profile to any third
party without the prior written consent of TOYO INK.
3. In no event will TOYO INK its directors, officers, employees or agents be liable to you for
any consequential or incidential, either direct or indirect, damages(including damages for
loss of business profits, business interruption, loss of business information, and the
like)arising out of the use or inability to use this ICC Profile.
4. TOYO INK shall not be responsible for answering any question related to this ICC Profile.

5. All company names and product names used in this document is the trademarks or regis-
tered trademarks of their respective holder.
This ICC Profile made by GretagMacbeth ProfileMaker and granted TOYO INK certain license
to distribute by GretagMacbeth AG.
TOYO Offset Coated 2.1 © TOYO INK MFG. CO., LTD. 2004
For EU member states only
This symbol means: Do not dispose of this product
together with your household waste!
Please contact the Local Authority for appropriate dis-
posal instructions. In the case of a new device being
purchased, the used one can also be given to our dealer
for appropriate disposal. Recycling of this product will
help to conserve natural resources and prevent potential
negative consequences for the environment and human
health caused by inappropriate waste handling.
This product complies with RoHS (2002/95/EC) direc-
tive.

Contents
Contents i
1Introduction ....................................................................................................... 1
Getting Acquainted with Your Printer 2
Space Requirements 2
Printer Parts 4
Front View 4
Rear View 5
Front View with Options 5
2About the Software ........................................................................................... 7
Printer Driver CD-ROM 8
PostScript Drivers 8
PCL Drivers 8
PPD Files 9
Utilities and Documentation CD-ROM 9
Utilities 9
System Requirements 12
Selecting Driver Options/Defaults
(for Windows) 13
Windows XP/Server 2003/2000/NT 4.0 13
Windows Me/98SE (KONICA MINOLTA mc5570 PCL6) (KONICA MINOL-

Contentsii
TA mc5550 PCL6) 14
Windows Me/98SE (KONICA MINOLTA mc5570 PPD) (KONICA MINOL-
TA mc5550 PPD) 15
Uninstalling the Printer Driver
(for Windows) 16
Windows XP/Server 2003/2000/NT 4.0/Me (PCL)/98SE (PCL) 16
Windows Me (PPD)/98SE (PPD) 16
Displaying Printer Driver Settings
(for Windows) 17
Windows XP/Server 2003 17
Windows 2000/Me/98SE/NT 4.0 17
Using the Postscript and PCL Printer Driver 18
Common Buttons 18
OK 18
Cancel 18
Apply 18
Help 18
Easy Set 18
Paper View 19
Printer View 19
Watermark View 19
Quality View 19
Default 19
Advanced Tab (PostScript Printer Driver Only) 19
Basic Tab 20
Layout Tab 20
Cover Page Tab 21
Overlay Tab 21
Watermark Tab 21
Quality Tab 22
Version Tab 22
Limitations on printer driver functions installed with Point and Print 22
Using the Windows Me/98SE PPD File 23
Common Buttons 23
OK 23
Cancel 23
Apply 23
Restore Defaults 23
Paper Tab 23
Graphics Tab 24
Font Tab 24
Device Options Tab 24
Postscript Tab 24
3Using the Status Monitor (Windows Only) ....................................................25
Working with the Status Monitor 26

Contents iii
Introduction 26
Operating Environment 26
Opening the Status Monitor 26
Using the Status Monitor 26
Recognizing Status Monitor Alerts 27
Recovering from a Status Monitor Alert 27
Closing the Status Monitor 27
4Printer Control Panel and Configuration Menu ............................................ 29
About the Control Panel 30
Control Panel Indicators and Keys 30
Message Window 32
Help Screens 33
Configuration Menu Overview 34
Main Menu 34
PROOF/PRINT MENU 36
Printing/Deleting a Stored Job 36
Entering the Password 38
PRINT MENU 39
PAPER MENU 41
QUALITY MENU 48
MEMORY DIRECT 67
CAMERA DIRECT 70
INTERFACE MENU 74
SYS DEFAULT MENU 77
MAINTENANCE MENU 88
SERVICE MENU 94
5Camera Direct .................................................................................................. 95
Camera Direct 96
Printing Directly from a Digital Camera 96
6Memory Direct ................................................................................................. 97
Memory Direct 98
Printing From a Connected USB Memory Device 98
7Using Media ..................................................................................................... 99
Media Specifications 100
Media Types 101
Plain Paper (Recycled Paper) 101
Thick Stock 103
Envelopes 103
Labels 104
Letterhead 105
Postcards 106
Transparencies 107

Contentsiv
Glossy Media 108
What Is the Guaranteed Imageable (Printable) Area? 109
Imageable Area—Envelopes 109
Page Margins 109
Loading Media 110
Tray 1 (Manual Feed Tray) 110
Loading Plain Paper 110
Other Media 112
Loading Envelopes 113
Loading Label Sheets/Postcards/Thick Stock/Glossy Media and Transpar-
encies 117
Loading Banner Paper 120
Tray 2 123
Loading Plain Paper 123
Tray 3/4 (Optional Lower Feeder Units) 125
Loading Plain Paper 125
Duplexing 128
Output Tray 129
Finishing 130
Job Separation Printing 130
Offset Printing 131
Staple printing 131
Media Storage 132
8Replacing Consumables ...............................................................................133
Replacing Consumables 134
About Toner Cartridges 134
Replacing a Toner Cartridge 137
Replacing a Print Unit 141
Replacing the Waste Toner Bottle 147
Replacing the Transfer Roller 150
Replacing the Transfer Roller 150
Replacing the Ozone Filter 153
Replacing the Transfer Belt Unit 154
Replacing the Backup Battery 160
Replacing the Staple 163
9Maintaining the Printer ..................................................................................167
Maintaining the Printer 168
Cleaning the Printer 170
Exterior 170
Media Rollers 171
Cleaning the Media Feed Rollers (Manual Feed Tray) 171
Cleaning the Media Feed Rollers (Tray 2/3/4) 173
Cleaning the Duplex Option Feed Rollers 174
Cleaning the Media Transfer Rollers for Tray 3 and 4 175

Contents v
Cleaning the Laser Lens 176
10 Troubleshooting ............................................................................................ 177
Introduction 178
Printing a Configuration Page 178
Preventing Media Misfeeds 179
Understanding the Media Path 180
Clearing Media Misfeeds 181
Media Misfeed Messages and Clearing Procedures 182
Clearing a Media Misfeed in Tray 2 183
Clearing a Media Misfeed in Tray 3/4 187
Clearing a Media Misfeed from the Duplex Option 189
Clearing a Media Misfeed from the Fuser Unit 190
Clearing a Media Misfeed from Tray 1 (Manual Feed Tray) and Transfer
Roller 193
Relay Unit 195
Staple Finisher (Case 1) 196
Staple Finisher (Case 2) 197
Staple Finisher (Case 3) 198
Clearing Jammed Staples 199
Solving Problems with Media Misfeeds 201
Solving Other Problems 204
Solving Problems with Printing Quality 210
Status, Error, and Service Messages 216
Standard Status Messages 216
Error Messages (Warning:) 217
Error Messages (Operator Call:) 221
Service Messages: 226
11 Installing Accessories .................................................................................. 227
Introduction 228
Antistatic Protection 228
Dual In-Line Memory Module (DIMM) 229
Installing a DIMM 229
Hard Disk Kit 232
Installing the Hard Disk drive 232
CompactFlash 235
Installing the CompactFlash card 235
Duplex Option 238
Installing the Duplex Option 238
Lower Feeder Unit 241
Kit Contents 241
Installing a Lower Feeder Unit 242
Staple Finisher 246
Accessories 246
Unpacking and installing the Staple Finisher 247

Contentsvi
AAppendix ........................................................................................................257
Safety Specifications 258
Technical Specifications 258
Printer 258
Consumable Life Expectancy Chart 263
Our Concern for Environmental Protection 265
What is an ENERGY STAR product? 265

Introduction

Getting Acquainted with Your Printer2
Getting Acquainted with Your Printer
Space Requirements
To ensure easy operation, consumable replacement and maintenance,
adhere to the recommended space requirements detailed below.
Front View with Options
Front View
704 mm (27.7")
100 mm
(3.9")
100 mm
(3.9")
420 mm (16.5")
284 mm
(11.2")
100 mm (3.9")
462 mm (18.2")
420 mm (16.5")
1175 mm (46.3")
480 mm (18.9")
420 mm (16.5")
100 mm
(3.9")
294 mm (11.6")
420 mm (16.5")
110 mm (4.3")
110 mm
(4.3")
934 mm (36.8")
100 mm
(3.9")
100 mm
(3.9")
60 mm
(2.4")
475 mm (18.7")

Getting Acquainted with Your Printer 3
" The options appear shaded in the above illustrations.
Side View with Options
846 mm (33.3")
100 mm
(3.9")
526 mm (20.7")

Getting Acquainted with Your Printer4
Printer Parts
The following drawings illustrate the parts of your printer referred to through-
out this guide, so please take some time to become familiar with them.
Front View
1—Control panel
2—Output tray
3—Fuser unit
4—Right side cover
5—Tray 1 (Manual feed tray)
6—Transfer roller
7—Transfer belt unit
8—Tray 2
9—Print unit
10—Grip
11—Laser lens cleaning tool
12—Front cover
13—Waste toner bottle
14—Toner cartridge
1
14
13
23
4
5
6
12
11
10 9 8 7
Y
Y
PUSH
14
13
6
7
9
11

Getting Acquainted with Your Printer 5
Rear View
1—KONICA MINOLTA Digital Cam-
era Direct Print Port
2—Power switch
3—Ozone filter
4—Power connection
5—Parallel port
6—10Base-T/100Base-TX/
1000Base-T Ethernet Interface
port
7—USB port
8—Ventilation grilles
Front View with Options
1—Duplex option
2—Lower feeder units (Tray 3 and
Tray 4)
3—Staple Finisher
1
2
3
45
6
7
8
3
1
2
