1 Overview
The Laser Imaging System is a continuous-tone laser imager with an internal
photothermographic film processor. Heat, rather than photo chemicals, is used to
develop the film. This easy-to-use and reliable imager provides high-quality prints. Use
the prints from this system for:
• Diagnostic purposes to determine patient treatments, including imaging for full field
digital mammography
• Referral, sharing, or educational purposes
The system receives and prints from qualified image sources such as medical electrical
equipment (modalities) and workstations over the network. You can send print jobs
simultaneously from multiple image sources. The open design lets you connect to
modalities of all types and vendors.
1Top cover. Covers the processor rollers. The top cover is interlocked.
2Display screen. Provides an interface to the imager, with status and error information.
3Right cover. Protects sensitive electronic equipment. The right cover is only accessed by
service personnel.
4Film supply door. Covers the upper and lower film supplies.
5Left cover. Covers the left side of the imager. You might remove the left cover to clear
an occasional film jam. The left cover is interlocked.

Overview
1–2 AD3435_en | 2017-11-17
Major Internal Assemblies
6Filter door. Covers the replaceable filter.
7Exit tray. Holds multiple sheets of processed film. Extend the exit tray to hold large film
(35 x 43 cm/14 x 17 in. and 35 x 35 cm/14 x 14 in.) as it finishes printing.
H241_0003DC
H241_0003DCA
1
2
3
4
5
6
7
8
9
10
11

Overview
AD3435_en | 2017-11-17 1–3
How the Imager Works
The imager receives, processes, manages, and prints the images on film. The imager has
limited storage to hold a small number of digital images. As images are received for
printing, they are stored in memory, placed in a sequential print queue, and printed in
order. The imager can continue to accept incoming print jobs even if temporarily unable
to print (if the film supply is empty, etc.).
During normal operation, the imager requires very little attention. It prints automatically
in response to print requests from the configured image sources. Information sent with
the images by the image source, such as film type and size and image quality settings, is
applied unless you set the imager to override information that comes from the image
source.
1Airflow manifold. Removes heat and processing odors from the processor assembly.
2Exit rollers. Move the film from the processor area to the exit tray.
3Optics module. Writes the image onto the film while the film is moved through the
exposure transport.
4Deodorant filter. Absorbs potential odors that may be caused by heat processing.
5Accumulator. Receives the film before it is imaged. The film is sent from the accumula-
tor up to the optics module, and then to the processor assembly where the heat is
applied to process the image.
6Rollback assemblies (upper and lower). Roll the film cartridge cover back so the
pickup assembly can lift the film. When the imager is not printing, the cover is closed
over the film cartridge to protect the film from light.
7Feed rollers. Move the film through the imager.
8Pickup assemblies (upper and lower). Lift a single sheet of film from the supply car-
tridge and feed it into the rollers.
9Transport guides. Orient the film while moving it (the film) from the supply to the
imaging portion of the imager.
10 Exposure transport. Moves the film past the scanning laser beam.
11 Processor drum. Provides the heat that processes the image on the film.

Overview
1–4 AD3435_en | 2017-11-17
Print Sequence
Each time the imager receives a print request, the following print sequence occurs. The
arrows show the film path.
1. Suction cups in the pickup area lift a single sheet of film out of one of the supply
cartridges and feed the film into the transport rollers.
2. The transport rollers move the film down to the accumulator area.
3. The film reverses direction and moves up during imaging (as the optics module writes
the image onto film). Then the film moves up to the processor.
4. As the film passes over the processor drum, the heat generated by the drum develops
the film.
5. The exit rollers move the developed film to the exit tray.

Overview
AD3435_en | 2017-11-17 1–5
Supported Film Sizes
The imager is available in different configurations; the following film sizes can be
supported:
• 35 x 43 cm (14 x 17 in.)
• 28 x 35 cm (11 x 14 in.)
• 25 x 30 cm (10 x 12 in.)
• 20 x 25 cm (8 x 10 in.)
Blue and mammography film types may be available.
Mammography Imaging
To manage and support mammography imaging, the imager provides these features.
• You can load mammography film in one or both film supplies.
• The imager can be configured to print mammography images exclusively on
mammography film. If a mammography image request is received, and:
– a cartridge with mammography film is not loaded,
and/or
– the requested mammography film size is not loaded,
then the imager will request the appropriate film size and type. You must load the
requested size and type to print the mammography job.
• Several mammography-specific test prints are provided, including a test print for the
routine calibration of mammography film (for example, a density wedge print). The
default mammography test print is configured during installation and can be
changed from the Web Portal.
Note
See the Mammography Quality Control Manual for more information. Requirements for
mammography quality control vary by region.
Automatic Image Quality and Processing
An internal densitometer enables the imager to automatically adjust image processing
parameters using Automatic Image Quality Control (AIQC) to produce an optimal image.
The imager adjusts these parameters each time it prints a calibration film.
A calibration film is printed when:
• A film cartridge is inserted in the imager with film of a new lot number.
• You request a calibration film at the display screen or the Web Portal.
• A film cartridge is inserted into the imager for which a current calibration is not
stored.

Overview
1–6 AD3435_en | 2017-11-17
Related topics:
Calibrate the Imager for the Loaded Film
Configure and Monitor the System (Using the Web
Portal)
The Web Portal is your interface to additional features. In addition to the installation and
setup of your system, you can view and manage the imager's connections over the
network, configure features, view error messages, and access general status information
at the Web Portal. You can also check film count, film size, and film type.
Related topics:
Access the Web Portal
Installation, Setup, and Safety
Installation and setup must be performed by a qualified service provider. Contact a
qualified service provider with any questions.
See the Safety Manual, available on the publications disc, for instructions to safely use
the imager and for agency compliance.

Overview
AD3435_en | 2017-11-17 1–7
User Manual Conventions
Note
Notes provide additional information, such as expanded explanations, hints, or reminders.
Important
Important notices highlight critical policy information that affects how you use this manual and
this product.
Caution
Cautions point out procedures that you must follow precisely to avoid injury to yourself or others,
damage to the system or any of its components, or loss of data or corruption of files in software
applications.
Laser Warning
Laser warnings warn personnel that access to laser radiation is possible and all personnel must
avoid direct exposure to the beam.

AD3435_en | 2017-11-17 2–1
2 Basic Operating Tasks
During normal operation, the imager receives and automatically prints images sent by
modalities over a network. Very little interaction is required. You can do the following:
• Turn the power on (|) and off (0).
• Load the film cartridges.
• Monitor the display screen for status and operating conditions.
Sometimes it will be necessary to perform preventive maintenance, filter replacement,
and other corrective actions such as a restart.
You also may access the Web Portal to perform additional configuration, optimize image
quality, or do troubleshooting tasks.
Related topics:
Maintenance and Troubleshooting
Access More Functionality with the Web Portal

Basic Operating Tasks
2–2 AD3435_en | 2017-11-17
The Display Screen
The display screen communicates the status of the imager.
Figure 1: Display screen: normal state, processing a print job from the upper supply. In this
example, there are 86 sheets of film in the upper cartridge and 113 sheets in the lower cartridge.
Symbol or code Description
Upper and lower
left side
Film counts. Displays the number of films that are remaining in the upper and
lower film cartridges.
If a blue number does not display while the imager is powered on, the associated
film cartridge is not inserted (or not fully inserted) into the imager.
Center right Error or status code. The 3-digit code displays when the error or status condition is
present. If the imager is on and a 3-digit code does not display, the imager is oper-
ating normally.
• If a print job requires a different film size and/or type from the loaded films, the
requested size and type displays along with the Film size symbol. For mammog-
raphy film, an Mdisplays in front of the film size, and Bindicates the blue base
film. Load the requested film size and type.
• When the imager is starting, a countdown displays the number of minutes until
the imager will be ready to print (for example, -4 means 4 minutes until the
imager will be ready to print).
Indicator light The light indicates the active cartridge. For example, when printing from the upper
supply, the indicator light appears next to the upper film count.
• When green, operation is normal.
• When amber, the light indicates that there is an issue with the film supply, such
as a jammed film.

Basic Operating Tasks
AD3435_en | 2017-11-17 2–3
Power When the symbol is green, the power is on and the imager is ready to print.
• The symbol flashes while the imager is processing, calibrating, or making a test
print.
•When the symbol is amber, the imager is not ready to print. Examples are when
the imager has just been started, when a film cartridge is empty or jammed, and
when a cover is removed.
Calibrate and Test
Print
Calibration might be needed if the symbol is on and code 624, 631, or 632
appears. Press the symbol to calibrate the upper or lower film cartridge.
• The symbol flashes while the calibration is in process, when making a test print
(upper or lower), and when you initiate a filter reset.
• When amber, there is an error such as a failed calibration. The indicator light
associates the error code to the film cartridge. Depending on the issue, you may
be able to keep printing (631 or 632 error), or it might be necessary to load a
different film cartridge (624 error).
To make a test print, press and hold the Calibrate symbol for three seconds until
the imager beeps twice. The test print varies depending on the type of film.
Pause
Important
To avoid exposing the film to light, do not open the film supply door until the Pause
symbol is off. Wait until the symbol is off to replace a cartridge.
• During most normal operation, including when the imager is idle, the symbol is
off.
•The symbol is on while the imager is processing images, test prints, and during
calibration.
•The symbol flashes when a film cartridge cover is in the process of being opened
(rolled back) or closed.
If the Pause symbol is on, you can press the symbol to temporarily pause printing.
Any jobs in progress finish printing, then the film cartridge cover closes. When the
Pause symbol turns off, you can open the film supply door.
Film Size When this symbol appears, the requested print job requires a different film size
and/or type. The required film size/type flashes in the location of the error or status
code.
You can also press this symbol for three seconds, until the imager beeps twice, to
cancel all pending print jobs that require an unavailable media size and/or type.
Restart Restart the imager. An error code also displays to indicate the reason for the
restart.
Symbol or code Description

Basic Operating Tasks
2–4 AD3435_en | 2017-11-17
Related topics:
Maintenance and Troubleshooting
Load a Different Film Size to Match a Print Request
Calibrate the Imager for the Loaded Film
Delete All Pending Jobs with Unavailable Media Size or Type
Test Prints
Restart the Imager
Preventive Maintenance
Film Jam Film is jammed from the upper or lower cartridge. The error code confirms the film
jam and gives direction on where to find the film inside the imager. The indicator
light associates the error code with the film cartridge.
Maintenance Preventive maintenance is required. An error code also displays to indicate the
action to take.
Symbol or code Description

Basic Operating Tasks
AD3435_en | 2017-11-17 2–5
Imager Power
Power Switch Location
The power switch (1) is on the lower portion of the imager’s back panel (2).
H241_0008GC
H241_0008GCA 1
2

Basic Operating Tasks
2–6 AD3435_en | 2017-11-17
Start the Imager
1. Press the power switch on the back of the imager on.
2. Wait as the imager warms up.
The warm-up period might last up to 30 minutes. The display screen shows the
progress as the imager becomes ready to print.
Figure 2: The imager counts up to zero (0) to indicate how soon the imager will be ready to
print. In this example, the imager will be ready to print in 7 minutes. The amber power symbol
also indicates that the imager is not ready to print.
The warm-up period varies depending on the amount of time the imager has been
off and the ambient temperature. During the warm-up period, the imager can
receive and store images but cannot print films.
When the imager reaches operating temperature, the display screen changes to show
that the system is ready to print, and the imager prints any images that were received
during the warm-up period.
Figure 3: The green power symbol indicates that the imager is ready to process job requests.

Basic Operating Tasks
AD3435_en | 2017-11-17 2–7
Emergency Shutdown or Power Loss
In the event of a power loss, or if an emergency requires an immediate shutdown of the
imager, films in process will not be completed. However, when power is restored, the
imager will restart. After warming up, the imager automatically reprints any films that
were in process when the power was interrupted.
Restart the Imager
If the imager encounters an error that is usually corrected with a restart, the display
screen shows the Restart symbol.
Figure 4: A restart is required, and the error code indicates the error condition.
Note
Check the Troubleshooting chapter or the Quick Reference Card to identify the error code.
1. Press the power switch on the back of the imager off.
2. Press the power switch on.
If the error does not clear after the restart, it might be necessary to contact a qualified
service provider.

Basic Operating Tasks
2–8 AD3435_en | 2017-11-17
About the Film Cartridges
Film Count
The upper and lower film counts appear on the display screen.
Figure 5: In this example, the upper cartridge has 86 sheets of film, and the lower has 113.
Size/Type of the Loaded Film
To check the size of the loaded film, open the film supply door and view the loaded
cartridges.
Note
Make sure the Pause symbol is off before you open the film supply door.
Film Count Flashes “0”
When either cartridge is empty, the film count flashes “0.” Replace the cartridge.
Figure 6: In this example, the upper film cartridge is empty. Replace the upper cartridge.

Basic Operating Tasks
AD3435_en | 2017-11-17 2–9
Film Size/Type Flashes
When a film size/type is requested that is not loaded, the Film Size symbol (1) appears,
and the requested film flashes (2). Change the loaded film to match the print request.
Figure 7: View and load the requested film size/type in the error code location (2). In this
example, “M” represents a request for mammography film.
Related topics:
Replace an Empty Film Cartridge
Load a Different Film Size to Match a Print Request
Replace an Empty Film Cartridge
When a film cartridge is empty, the film count appears as 0on the display screen.
Note
Before you load a new film cartridge, make sure that the Pause symbol is off. When the imager
is idle, the symbol is off. When the film cartridge cover is open, the symbol is on. To avoid
exposing the film to light, do not open the film supply door until the Pause symbol is off.
1. If the Pause symbol is on, press the symbol to close the film cartridge cover.
2. Open the film supply door (1).
3. Hold the edges of the film cartridge and lift the empty cartridge out of the film
supply.
4. Discard the empty cartridge.
5. Insert the new film cartridge. Align the cartridge (2) with the label facing up and the
perforations (3) leading into the imager. Set the leading edge (4) on the cartridge
