bizhub PRO C65hc
Additional Information
This guide provides the information about corrections to be made in the three
user’s guides of bizhub PRO C65hc (Main Body and Security), as well as the
information about Stream Punch GP-501 option newly provided to the main
body.
Please refer to this guide for the operation and safety information, and keep
it inside the user’s guide of Main Body so that it is readily available for refer-
ence.

Contents
1 Errata for bizhub PRO C65hc User’s Guides
1.1 User’s Guide - Main Body: Auto Shut-Off ..........................................1
1.2 User’s Guide - Security: Version Number of the Image Control
Software ................................................................................................2
2 Stream Punch
2.1 Precautions for Installation and Use ..................................................3
2.1.1 Caution Notations and Labels ............................................................3
2.1.2 Space Requirements ..........................................................................5
2.2 Machine Configuration .........................................................................7
2.2.1 Standard/Optional Equipment ...........................................................7
2.2.2 Stream Punch GP-501 .......................................................................8
2.3 Using Stream Punch GP-501 .............................................................10
2.3.1 Exchanging the Die Set ....................................................................11
2.4 Maintenance & Troubleshooting .......................................................14
2.4.1 Emptying Waste Basket of Stream Punch GP-501 .........................14
2.4.2 If Burrs Remain in Punch Holes Using Stream Punch GP-501 ........16
2.5 Specifications .....................................................................................18
2.5.1 Stream Punch GP-501 (Die Set DS-501 to 506) ..............................18

Errata for bizhub PRO C65hc User’s Guides 1
bizhub PRO C65hc Additional Information 1
1 Errata for bizhub PRO C65hc User’s
Guides
1.1 User’s Guide - Main Body: Auto Shut-Off
“0 minute” is newly available as a setting option for Auto Shut-Off.
With “0 minute” specified, the Auto Shut-Off will function not after the ma-
chine is turned on and finishes warmup, but immediately after a printing op-
eration is completed.
According to this specification changes, description in the following pages
will be subject to the changes described above.
Machine Information & Printing Operation
POD Administrator’s Reference
Page Description to be corrected
p. 1-5 Automatic Shut-Off
p. 2-40 Automatically Conserving Energy (Auto Shut-Off)
Page Description to be corrected
p. 4-10 Setting items of 06 Power Save Setting
p. 4-12 Setting items of 01 Power Save Setting
p. 5-21 Description of 06 Power Save Setting
p. 6-6 Description of 01 Power Save Setting

1Errata for bizhub PRO C65hc User’s Guides
2 bizhub PRO C65hc Additional Information
1.2 User’s Guide - Security: Version Number of the Image
Control Software
The version number of the image control program (Image Control I1) de-
scribed in the title page will be modified as follows.
Page Former New
Title page Image control program (Image Con-
trol I1) version:
A03U0Y0-00I1-G00-50
Image control program (Image
Control I1) version:
A03U0Y0-00I1-G00-50
A03U0Y0-00I1-G00-60

Stream Punch 2
bizhub PRO C65hc Additional Information 3
2 Stream Punch
2.1 Precautions for Installation and Use
2.1.1 Caution Notations and Labels
Safety precaution notations and labels appear on this machine at the follow-
ing positions.
Be very careful that an accident does not occur when operations such as re-
moving mishandled paper are performed.

2Stream Punch
4 bizhub PRO C65hc Additional Information
2
Reminder
Do not remove caution labels. Should any caution label or caution indi-
cator be illegible due to soilage, clean the label. If any caution label is re-
moved or cleaning does not render the label legible, please contact your
service representative.
This safety message you could
get an electrical shock because
disconnecting power from this
section does not cut off power
from adjacent sections of the
machine.
WARNING
This safety message means
that you might get seriously
hurt or killed if you open the
product and expose yourself to
hazardous voltage. NEVER
remove the screwed on covers.
ALWAYS refer service
requirements to qualified
service personnel.
WARNING

Stream Punch 2
bizhub PRO C65hc Additional Information 5
2.1.2 Space Requirements
To ensure that machine operation, consumables replenishing, part replace-
ment, and regular maintenance can easily be performed, adhere to the rec-
ommended space requirements detailed below.
Be sure to choose a level and solid floor for the installation place.
64.1
37.329.912.013.8
3.9
6.9
3.9
40.2
15.8
8.1
21.410.0
143.7
4.6
FS-521 - RU-506 - GP-501 - RU-504 - Main body - PF-602
(Unit: inches)
64.1
48.5
37.329.912.013.815.7
3.9
6.9
3.9
40.2
15.8
8.1
21.410.0
159.4
4.6
FS-521 - FD-503 - RU-506 - GP-501 - RU-504 - Main body - PF-602
(Unit: inches)
64.1
37.329.912.013.8
3.9
6.9
3.9
40.2
15.8
8.1
30.921.410.0
174.6
4.6
FS-521 - LS-505 - RU-506 - GP-501 - RU-504 - Main body - PF-602
(Unit: inches)

2Stream Punch
6 bizhub PRO C65hc Additional Information
2
Reminder
Be sure to allow a clearance of 200 mm (7-3/4 in.) or more at the back of
this machine for the ventilation duct.
64.1
37.329.912.013.8
3.9
6.9
3.9
40.2
15.8
8.1
46.121.410.0
189.8
4.6
FS-521 - SD-506 - RU-506 - GP-501 - RU-504 - Main body - PF-602
(Unit: inches)
64.1
37.329.912.013.8
3.9
6.9
7.9
48.1
40.2
15.8
8.1
30.929.122.2
193.9
PB-501/PB-502 - LS-505 - RU-506 - GP-501 - RU-504 - Main body - PF-602
(Unit: inches)

Stream Punch 2
bizhub PRO C65hc Additional Information 7
2.2 Machine Configuration
2.2.1 Standard/Optional Equipment
FS-521
FS-521 - FD-503
FS-521 - LS-505 RU-506 - GP-501 Main Body PF-602
HD-506
IC-305 IC-304
HT-504
RU-504
FS-521 - SD-506
PB-501/PB-502 - LS-505

2Stream Punch
8 bizhub PRO C65hc Additional Information
2.2.2 Stream Punch GP-501
1
2
3
4
5
6
7
8
9
10
11
12
13
14

Stream Punch 2
bizhub PRO C65hc Additional Information 9
No. Name Description
1 Stream punch front door Opens to allow replacement of die set or removal of
punch waste and mishandled paper.
2 Lever GP1 Opens downward for removal of mishandled paper.
3 Knob GP3 Turned for removal of mishandled paper.
4 Lever GP2 Opens to the upper-right for removal of mishandled pa-
per.
5 Knob GP4 Turned clockwise to move the punch blade for removal of
mishandled paper or replacement of die set.
6 Mounting of die set Mounts the die set.
7 Punch waste basket Withdrawn for removal of waste paper.
8 Power switch Turned on when using the stream punch.
9 Lever GP5 Opens downward for removal of mishandled paper.
10 Knob GP7 Turned for removal of mishandled paper.
11 Die set punch blade position
indicator
Used to check the position of die set punch blade when
clearing mishandled paper, replacing the die set, or turn-
ing the knob GP4.
12 Lever GP6 Opens to the upper-left for removal of mishandled paper.
13 Knob GP8 Turned for removal of mishandled paper.
14 Die set Punches various types of file holes.

2Stream Punch
10 bizhub PRO C65hc Additional Information
2.3 Using Stream Punch GP-501
Using Stream Punch GP-501, the following six types of punch holes can be
made in printed sheets.
Die set model Hole type
DS-501
DS-502
DS-503
DS-504
DS-505
DS-506

Stream Punch 2
bizhub PRO C65hc Additional Information 11
2.3.1 Exchanging the Die Set
Procedure
1Open the stream punch
front door.
2Turn the knob GP4 clock-
wise to set the die set
punch blade position indi-
cator to the horizontal posi-
tion as shown in the
illustration.
– Be sure to align the die
set punch blade posi-
tion indicator to the hor-
izontal line, otherwise
the die set cannot be
withdrawn.
3Slowly withdraw the die set.

2Stream Punch
12 bizhub PRO C65hc Additional Information
4Take out the desired die set from the rack to replace it with the one cur-
rently set.
– Securely set the die set in position.
5Put the replaced die set into
the rack.
– The replaced die set is
supposed to be stored
in the rack.

Stream Punch 2
bizhub PRO C65hc Additional Information 13
6Close the stream punch
front door.

2Stream Punch
14 bizhub PRO C65hc Additional Information
2.4 Maintenance & Troubleshooting
2.4.1 Emptying Waste Basket of Stream Punch GP-501
When the waste basket of the Stream Punch GP-501 becomes full, the
Punch Waste Basket indicator lights in red in the option status area of the
Machine Status Screen.
Follow the procedure below to empty the waste basket.
2
Reminder
Once withdrawing the waste basket, be sure to empty it even if a small
amount of punch scraps collects in the basket. Otherwise, punch scraps
may overflow due to the delay in indicating the emptying operation.
To empty the waste basket
1Open the stream punch
door.

Stream Punch 2
bizhub PRO C65hc Additional Information 15
2Withdraw the waste basket.
3Empty the waste basket.
4Return the waste basket to its original position, then close the stream
punch door securely.

2Stream Punch
16 bizhub PRO C65hc Additional Information
2.4.2 If Burrs Remain in Punch Holes Using Stream Punch GP-
501
If you find burrs remaining in punch holes when using the Stream Punch GP-
501, lubrication is required for the die set currently used.
Lubricate it at the position illustrated below.
2
Reminder
Never use the oil on the general market. For the oil to be used in this pro-
cedure, please contact your service representative.
If burrs still remain in punch holes after the lubrication, apply grease to the
positions illustrated below.
